Fault Code 70 - Yamaha FZ8NA Service Manual

Fault code No.
Item
Fail-safe system
Diagnostic code No.
Meter display
Procedure
Item/components and
probable cause
Engine idling stop
Fault code No.
Item
Fail-safe system
Diagnostic code No.
Meter display
Procedure
Item/components and
probable cause
1 Connection of meter coupler
Check the connection of the
coupler is secure.
Remove the coupler, and
check each pin (for bending,
wear, or locking).
2 Connection of wire harness
ECU coupler
Check the connection of the
coupler is secure.
Remove the coupler, and
check each pin (for bending,
wear, or locking).
3 Continuity of wire harness
70
Engine idling stop: engine has been left idling. (The ECU automati-
cally stops the engine after 20 minutes if it is left idling.)
Able to start engine
Able to drive vehicle
—
—
—
Check or maintenance job
Er-1
ECU internal malfunction (output signal error): no signals are
received from the ECU.
Able to start engine (Unable if ECU Failure)
Able to drive vehicle (Unable if ECU Failure)
—
—
—
Check or maintenance job
Poor connection → Connect it
securely, or repair/replace the
wire harness.
Poor connection → Connect it
securely, or repair/replace the
wire harness.
Open or short circuit → Con-
nect it securely, or repair/
replace the wire harness.
Yellow/blue–Yellow/blue
FUEL INJECTION SYSTEM
8-102
Sensor inspection proce-
dure
Sensor inspection proce-
dure
Place the main switch to the
ON position, and check the
fault code indication.
No fault code indicated. →
Recovered.
Fault code indicated. →
Check the next step.
Place the main switch to the
ON position, and check the
fault code indication.
No fault code indicated. →
Recovered.
Fault code indicated. →
Check the next step.
Place the main switch to the
ON position, and check the
fault code indication.
No fault code indicated. →
Recovered.
Fault code indicated. →
Check the next step.
