A. Rear wheel sensor system malfunction
Item/components and
probable cause
1 Connection of rear wheel
sensor (meter) coupler
Check the connection of the
coupler is secure.
Remove the coupler, and
check each pin (for bending,
wear, or locking).
2 Connection of wire harness
ECU coupler
Check the connection of the
coupler is secure.
Remove the coupler, and
check each pin (for bending,
wear, or locking).
3 Continuity of wire harness
4 Rear wheel sensor malfunc-
tion
FUEL INJECTION SYSTEM
Check or maintenance job
Poor connection → Connect it
securely, or repair/replace the
wire harness.
Poor connection → Connect it
securely, or repair/replace the
wire harness.
Open or short circuit →
Replace the wire harness.
White/red–White/red
White–White
Blue/white–Blue/white
White/yellow–White/yellow
Sensor inspection procedure
Refer to "MAINTENANCE OF
THE REAR WHEEL SEN-
SOR AND SENSOR ROTOR"
on page 4-25.
Replace if defective.
8-90
Sensor inspection proce-
dure
Check in the diagnostic code
(Code No. d07). With the rear
wheel rotated, check the
pulse input.
Then, check the fault code
indication.
No fault code indicated. →
Recovered.
Fault code indicated. →
Check the next step.
Check in the diagnostic code
(Code No. d07). With the rear
wheel rotated, check the
pulse input.
Then, check the fault code
indication.
No fault code indicated. →
Recovered.
Fault code indicated. →
Check the next step.
Check in the diagnostic code
(Code No. d07). With the rear
wheel rotated, check the
pulse input.
Then, check the fault code
indication.
No fault code indicated. →
Recovered.
Fault code indicated. →
Check the next step.
Check in the diagnostic code
(Code No. d07). With the rear
wheel rotated, check the
pulse input.
Then, check the fault code
indication.
No fault code indicated. →
Recovered.
Fault code indicated. →
Check the next step.
