Fault Code 15 - Yamaha FZ8NA Service Manual

Fault code No.
Item
Fail-safe system
Diagnostic code No.
Meter display
Procedure
Item/components and
probable cause
1 Connection of throttle posi-
tion sensor coupler
Check the connection of the
coupler is secure.
Remove the coupler, and
check each pin (for bending,
wear, or locking).
2 Connection of wire harness
ECU coupler
Check the connection of the
coupler is secure.
Remove the coupler, and
check each pin (for bending,
wear, or locking).
3 Connection of fuel injection
system sub-wire harness
coupler
Check the connection of the
coupler is secure.
Remove the coupler and
check each pin (for bending,
wear, or locking).
4 Continuity of wire harness
5 Sensor installation status
15
Throttle position sensor: open or short circuit detected. (no normal
signals are received from the throttle position sensor.)
Able to start engine
Able to drive vehicle
d:01
Throttle position sensor
• 14–20 (fully closed position)
• Check with throttle valves fully closed.
• Check with throttle valves fully open.
Check or maintenance job
Poor connection → Connect it
securely, or repair/replace the
wire harness.
Poor connection → Connect it
securely, or repair/replace the
wire harness.
Poor connection → Connect it
securely, or repair/replace the
wire harness.
Open or short circuit →
Replace the wire harness.
Black/blue–Black/blue
Yellow–Yellow
Blue–Blue
Check for loose mounting,
pinched mounting, or hard
mounting.
Make sure that the mounting
position is correct.
Refer to "ADJUSTING THE
THROTTLE POSITION SEN-
SOR" on page 7-11.
FUEL INJECTION SYSTEM
8-61
Sensor inspection proce-
dure
Place the main switch to the
ON position, and check the
fault code indication.
No fault code indicated. →
Recovered.
Fault code indicated. →
Check the next step.
Place the main switch to the
ON position, and check the
fault code indication.
No fault code indicated. →
Recovered.
Fault code indicated. →
Check the next step.
Place the main switch to the
ON position, and check the
fault code indication.
No fault code indicated. →
Recovered.
Fault code indicated. →
Check the next step.
Place the main switch to the
ON position, and check the
fault code indication.
No fault code indicated. →
Recovered.
Fault code indicated. →
Check the next step.
Place the main switch to the
ON position, and check the
fault code indication.
No fault code indicated. →
Recovered.
Fault code indicated. →
Check the next step.
