8
For your information
Main Owner's Manual
Please note that this manual applies to all models and all equipment, includ-
ing options. Therefore, you may find some explanations for equipment not
installed on your vehicle.
All specifications provided in this manual are current at the time of printing.
However, because of the Toyota policy of continual product improvement, we
reserve the right to make changes at any time without notice.
Depending on specifications, the vehicle shown in the illustrations may differ
from your vehicle in terms of equipment.
Noise from under vehicle after turning off the engine
Approximately five hours after the engine is turned off, you may hear sound
coming from under the vehicle for several minutes. This is the sound of a fuel
evaporation leakage check and, it does not indicate a malfunction.
Accessories, spare parts and modification of your Toyota
A wide variety of non-genuine spare parts and accessories for Toyota vehi-
cles are currently available on the market. You should know that Toyota does
not warrant these products and is not responsible for their performance,
repair, or replacement, or for any damage they may cause to, or adverse
effect they may have on, your Toyota vehicle.
This vehicle should not be modified with non-genuine Toyota products. Modi-
fication with non-genuine Toyota products could affect its performance, safety
or durability, and may even violate governmental regulations. In addition,
damage or performance problems resulting from the modification may not be
covered under warranty.
RAV4_OM_OM42809U_(U)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2013 Rav4 and is the answer not in the manual?

Questions and answers

Summary of Contents for Toyota 2013 Rav4

  • Page 1 Accessories, spare parts and modification of your Toyota A wide variety of non-genuine spare parts and accessories for Toyota vehi- cles are currently available on the market. You should know that Toyota does not warrant these products and is not responsible for their performance, repair, or replacement, or for any damage they may cause to, or adverse effect they may have on, your Toyota vehicle.
  • Page 2 Cruise control system ● Anti-lock brake system ● SRS airbag system ● Seat belt pretensioner system Be sure to check with your Toyota dealer for precautionary measures or spe- cial instructions regarding installation of a mobile two-way radio system. RAV4_OM_OM42809U_(U)
  • Page 3 ● Data usage Toyota may use the data recorded in these computers to diagnose malfunc- tions, conduct research and development, and improve quality. Toyota will not disclose the recorded data to a third party except: • With the consent of the vehicle owner or with the consent of the lessee if the vehicle is leased •...
  • Page 4 Event data recorder This vehicle is equipped with an event data recorder (EDR). The main pur- pose of an EDR is to record, in certain crash or near crash-like situations, such as an air bag deployment or hitting a road obstacle, data that will assist in understanding how a vehicle’s systems performed.
  • Page 5 ● Disclosure of the EDR data Toyota will not disclose the data recorded in an EDR to a third party except when: • An agreement from the vehicle’s owner (or the lessee for a leased vehi- cle) is obtained • In response to an official request by the police, a court of law or a govern- ment agency •...
  • Page 6 CAUTION ■ General precautions while driving Driving under the influence: Never drive your vehicle when under the influ- ence of alcohol or drugs that have impaired your ability to operate your vehi- cle. Alcohol and certain drugs delay reaction time, impair judgment and reduce coordination, which could lead to an accident that could result in death or serious injury.
  • Page 7: Before Driving

    1-1. For safe use Before driving Floor mat Use only floor mats designed specifically for vehicles of the same model and model year as your vehicle. Fix them securely in place onto the carpet. Insert the retaining hooks (clips) into the floor mat eyelets. Turn the upper knob of each retaining hook (clip) to secure the floor mats in place.
  • Page 8 When installing the driver’s floor mat ● Do not use floor mats designed for other models or different model year vehicles, even if they are Toyota Genuine floor mats. ● Only use floor mats designed for the driver’s seat. ●...
  • Page 9: For Safety Drive

    1-1. For safe use For safety drive For safe driving, adjust the seat and mirror to an appropriate position before driving. Correct driving posture Adjust the angle of the seat- back so that you are sitting straight up and so that you do not have to lean forward to steer.
  • Page 10 1-1. For safe use Adjusting the mirrors Make sure that you can see backward clearly by adjusting the inside and outside rear view mirrors properly. (→P. 151, 154) CAUTION Observe the following precautions. Failure to do so may result in death or serious injury. ●...
  • Page 11: Seat Belts

    1-1. For safe use Seat belts Make sure that all occupants are wearing their seat belts before driving the vehicle. Correct use of the seat belts ● Extend the shoulder belt so that it comes fully over the shoulder, but does not come into contact with the neck or slide off the shoulder.
  • Page 12 1-1. For safe use Fastening the seat belt (for the rear center seat) Press the plate to release, and then pull the seat belt. Push the plate into the buckle in Plate “B” Plate “A” the order of plate “A” and plate “B”...
  • Page 13 1-1. For safe use Releasing and stowing the seat belt (for the rear center seat) To release the hooked buckle “B”, push the buckle release button. Release button To release the hooked plate “A”, insert the mechanical key (→P. 96) or plate “B” or the wireless key into the hole on the buckle.
  • Page 14 1-1. For safe use Adjusting the seat belt shoulder anchor height (front seats) Push the seat belt shoulder anchor down while pressing the release button. Push the seat belt shoulder anchor up. Move the height adjuster up and down as needed until you hear a click.
  • Page 15 ■ Seat belt extender If your seat belts cannot be fastened securely because they are not long enough, a personalized seat belt extender is available from your Toyota dealer free of charge. RAV4_OM_OM42809U_(U)
  • Page 16 Each seat belt should be used by one person only. Do not use a seat belt for more than one person at once, including children. ● Toyota recommends that children be seated in the rear seat and always use a seat belt and/or an appropriate child restraint system. ●...
  • Page 17 ● Ensure that the belt and plate are locked and the belt is not twisted. If the seat belt does not function correctly, immediately contact your Toyota dealer. ● Replace the seat assembly, including the belts, if your vehicle has been involved in a serious accident, even if there is no obvious damage.
  • Page 18 1-1. For safe use CAUTION ■ Using a seat belt extender ● Do not wear the seat belt extender if you can fasten the seat belt without the extender. ● Do not use the seat belt extender when installing a child restraint system because the belt will not securely hold the child restraint system, increas- ing the risk of death or serious injury in the event of an accident.
  • Page 19: Srs Airbags

    1-1. For safe use SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury. RAV4_OM_OM42809U_(U)
  • Page 20 1-1. For safe use ◆ SRS front airbags SRS driver airbag/front passenger airbag Can help protect the head and chest of the driver and front pas- senger from impact with interior components SRS driver knee airbag Can help provide driver protection SRS seat cushion airbag Can help restrain the front passenger ◆...
  • Page 21 1-1. For safe use SRS airbag system components Side impact sensors (front Side impact sensors (rear) doors) Seat belt pretensioners and Front passenger airbag force limiters Curtain shield airbags Driver’s seat position sensor Front passenger’s seat cush- Driver’s seat belt buckle ion airbag switch...
  • Page 22 1-1. For safe use Your vehicle is equipped with ADVANCED AIRBAGS designed based on the US motor vehicle safety standards (FMVSS208). The airbag sensor assembly (ECU) controls airbag deployment based on infor- mation obtained from the sensors etc. shown in the system compo- nents diagram above.
  • Page 23 An infant or child who is too small to use a seat belt should be properly secured using a child restraint sys- tem. Toyota strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are safer for infants and children than the front passenger seat.
  • Page 24 1-1. For safe use CAUTION ■ SRS airbag precautions ● Do not allow a child to stand in front of the SRS front passenger airbag unit or sit on the knees of a front passenger. ● Do not allow the front seat occupants to hold items on their knees.
  • Page 25 Wash off any residue as soon as possible to prevent skin irritation. ● If the areas where the SRS airbags are stored, such as the steering wheel pad and front and rear pillar garnishes, are damaged or cracked, have them replaced by your Toyota dealer. RAV4_OM_OM42809U_(U)
  • Page 26 Modification and disposal of SRS airbag system components Do not dispose of your vehicle or perform any of the following modifications without consulting your Toyota dealer. The SRS airbags may malfunction or deploy (inflate) accidentally, causing death or serious injury.
  • Page 27 1-1. For safe use ■ SRS airbag deployment conditions (SRS front airbags) ● The SRS front airbags will deploy in the event of an impact that exceeds the set threshold level (the level of force corresponding to an approximately 12 - 18 mph [20 - 30 km/h] frontal collision with a fixed wall that does not move or deform).
  • Page 28 1-1. For safe use ■ Conditions under which the SRS airbags may deploy (inflate), other than a collision The SRS front airbags and SRS curtain shield airbags may also deploy if a serious impact occurs to the underside of your vehicle. Some examples are shown in the illustration.
  • Page 29 1-1. For safe use ■ Types of collisions that may not deploy the SRS airbags (SRS side and curtain shield airbags) The SRS side and curtain shield airbags may not activate if the vehicle is subjected to a collision from the side at certain angles, or a collision to the side of the vehicle body other than the passenger compartment.
  • Page 30 1-1. For safe use ■ When to contact your Toyota dealer In the following cases, the vehicle will require inspection and/or repair. Con- tact your Toyota dealer as soon as possible. ● Any of the SRS airbags have been inflated. ●...
  • Page 31 1-1. For safe use ● The portion of the front pillars, rear pil- lars or roof side rail garnishes (padding) containing the curtain shield airbags inside is scratched, cracked, or other- wise damaged. RAV4_OM_OM42809U_(U)
  • Page 32: Front Passenger Occupant Classification System

    1-1. For safe use Front passenger occupant classification system Your vehicle is equipped with a front passenger occupant classi- fication system. This system detects the conditions of the front passenger seat and activates or deactivates the devices for the front passenger. Seat belt reminder light SRS warning light “AIR BAG OFF”...
  • Page 33 1-1. For safe use Condition and operation in the front passenger occupant classi- fication system ■ Adult “AIR BAG ON” and “AIR BAG OFF” “AIR BAG ON” indicator lights Indicator/ SRS warning light warning light Seat belt reminder light flashing Front passenger airbag Side airbag Activated...
  • Page 34 1-1. For safe use ■ Child “AIR BAG OFF” “AIR BAG ON” and “AIR BAG OFF” indicator lights “AIR BAG ON” Indicator/ warning light SRS warning light Seat belt reminder light flashing Deactivated or Front passenger airbag activated Side airbag on the front passenger seat Activated Curtain shield airbag...
  • Page 35 1-1. For safe use ■ Unoccupied “AIR BAG ON” and “AIR BAG OFF” “AIR BAG OFF” indicator lights Indicator/ SRS warning light warning light Seat belt reminder light Front passenger airbag Deactivated Side airbag on the front passenger seat Activated Curtain shield airbag Devices in the front passenger side...
  • Page 36 1-1. For safe use ■ There is a malfunction in the system “AIR BAG ON” and “AIR BAG OFF” “AIR BAG OFF” indicator lights Indicator/ SRS warning light warning light Seat belt reminder light Front passenger airbag Deactivated Side airbag on the front passenger seat Activated Curtain shield airbag...
  • Page 37 1-1. For safe use CAUTION ■ Front passenger occupant classification system precautions Observe the following precautions regarding the front passenger occupant classification system. Failure to do so may cause death or serious injury. ● Wear the seat belt properly. ● Make sure the front passenger’s seat belt plate has not been left inserted into the buckle before someone sits in the front passenger seat.
  • Page 38 SRS warning light may come on to indicate a malfunction of the front passenger occupant classification system. In this case, contact your Toyota dealer immediately. ● Child restraint systems installed on the rear seat should not contact the front seatbacks.
  • Page 39: Safety Information For Children

    1-1. For safe use Safety information for children Observe the following precautions when children are in the vehi- cle. Use a child restraint system appropriate for the child, until the child becomes large enough to properly wear the vehicle’s seat belt.
  • Page 40: Child Restraint Systems

    1-1. For safe use Child restraint systems A child restraint system for a small child or baby must itself be properly restrained on the seat with the lap portion of the lap/ shoulder belt. The laws of all 50 states of the U.S.A. and Canada now require the use of child restraint systems.
  • Page 41 1-1. For safe use Types of child restraints Child restraint systems are classified into the following 3 types according to the age and size of the child: Rear facing ⎯ Infant seat/con- Forward facing ⎯ Convertible vertible seat seat Booster seat ■...
  • Page 42 ● Toyota strongly urges the use of a proper child restraint system that con- forms to the size of the child, installed on the rear seat. According to acci- dent statistics, the child is safer when properly restrained in the rear seat than in the front seat.
  • Page 43 1-1. For safe use CAUTION ■ Child restraint precautions ● Do not allow the child to lean his/her head or any part of his/her body against the door or the area of the seat, front and rear pillars or roof side rails from which the SRS side airbags or SRS curtain shield airbags deploy even if the child is seated in the child restraint system.
  • Page 44: Installing Child Restraints

    1-1. For safe use Installing child restraints Follow the child restraint system manufacturer’s instructions. Firmly secure child restraints to the seats using the LATCH anchors or a seat belt. Attach the top tether strap when installing a child restraint. The lap/shoulder belt can be used if your child restraint system is not compatible with the LATCH (Lower Anchors and Tethers for Children) system.
  • Page 45 1-1. For safe use Installation with LATCH system Adjust the seatback to the 8th lock position from the fully reclined position. (→P. 139) Fully reclined position 8th lock position If your child restraint system interferes with a head restraint and cannot be installed properly, install the child restraint system after removing the head restraint.
  • Page 46 1-1. For safe use Type B Latch the buckles onto the LATCH anchors. If the child restraint has a top tether strap, the top tether strap should be latched onto the top tether strap anchor. For owners in Canada: The symbol on a child restraint system indicates the presence of a lower connector system.
  • Page 47 1-1. For safe use Installing child restraints using a seat belt (child restraint lock function belt) Rear-facing ⎯ Infant seat/convertible seat ■ Adjust the seatback to the 8th lock position from the fully reclined position. (→P. 139) Fully reclined position 8th lock position If your child restraint system interferes with a head restraint and cannot be installed properly, install the child restraint system after...
  • Page 48 1-1. For safe use Fully extend the shoulder belt and allow it to retract to put it in lock mode. In lock mode, the belt cannot be extended. While pushing child restraint system down into the rear seat, allow the shoulder belt to retract until the child restraint system is securely in place.
  • Page 49 1-1. For safe use Forward-facing ⎯ Convertible seat ■ Adjust the seatback to the 8th lock position from the fully reclined position. (→P. 139) Fully reclined position 8th lock position If your child restraint system interferes with a head restraint and cannot be installed properly, install the child restraint system after removing the head restraint.
  • Page 50 1-1. For safe use Fully extend the shoulder belt and allow it to retract to put it in lock mode. In lock mode, the belt cannot be extended. While pushing child restraint system into the rear seat, allow the shoulder belt to retract until the child restraint system is securely in place.
  • Page 51 1-1. For safe use ■ Booster seat Adjust the seatback to the 8th lock position from the fully reclined position. (→P. 139) Fully reclined position 8th lock position If your child restraint system interferes with a head restraint and cannot be installed properly, install the child restraint system after removing the head restraint.
  • Page 52 1-1. For safe use Removing a child restraint installed with a seat belt Push the buckle release button and fully retract the seat belt. Child restraint systems with a top tether strap Remove the head restraint. Secure the child restraint sys- tem using the seat belt.
  • Page 53 1-1. For safe use Latch the hook onto the anchor bracket and tighten the top tether strap. Make sure the top tether strap is securely latched. ■ Laws and regulations pertaining to anchorages The LATCH system conforms to FMVSS225 or CMVSS210.2. Child restraint systems conforming to FMVSS213 or CMVSS213 specifica- tions can be used.
  • Page 54 1-1. For safe use CAUTION ■ When installing a booster seat To prevent the belt from going into ALR lock mode, do not fully extend the shoulder belt. ALR mode causes the belt to tighten only. This could cause injury or discomfort to the child. (→P. 34) ■...
  • Page 55 1-1. For safe use CAUTION ■ When installing a child restraint system ● When installing a child restraint system in the rear center seat, adjust both seatbacks at the same angle. Otherwise, the child restraint system cannot be securely restrained and this may cause death or serious injuries in the event of sudden braking, sudden swerving or an accident.
  • Page 56 1-1. For safe use CAUTION ■ Do not use a seat belt extender If a seat belt extender is used when installing a child restraint system, the seat belt will not securely hold the child restraint system, which could cause death or serious injury to the child or other passengers in the event of a sud- den braking, sudden swerving or an accident.
  • Page 57: Exhaust Gas Precautions

    Keep the back door closed. ● If you smell exhaust gases in the vehicle even when the back door is closed, open the windows and have the vehicle inspected at your Toyota dealer as soon as possible. ■ When parking ●...
  • Page 58: Engine Immobilizer System

    1-2. Theft deterrent system Engine immobilizer system The vehicle’s keys have built-in transponder chips that prevent the engine from starting if a key has not been previously regis- tered in the vehicle’s on-board computer. Never leave the keys inside the vehicle when you leave the vehi- cle.
  • Page 59 1-2. Theft deterrent system ■ Certifications for the engine immobilizer system (for vehicles sold in the U.S.A.) Vehicles without a smart key system FCC ID: MOZRI-42BTY FCC ID: WRKRI-44BTY Vehicles with a smart key system FCC ID: NI4TMIMB-3 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 60: Theft Prevention Labels (U.s.a.)

    1-2. Theft deterrent system Theft prevention labels (U.S.A.) These labels are attached to the vehicle to reduce vehicle theft by facilitating the tracing and recov- ery of parts from stolen vehicles. Do not remove under penalty of law. RAV4_OM_OM42809U_(U)
  • Page 61 1-2. Theft deterrent system RAV4_OM_OM42809U_(U)
  • Page 62 3-1. Key information Keys The keys The following keys are provided with the vehicle. Vehicles without a smart key system (type A) Master keys Operating the wireless remote con- trol function (→P. 113) Valet key Key number plate Vehicles without a smart key system (type B) Master keys Operating the wireless remote con- trol function (→P.
  • Page 63 ■ If you lose your keys New genuine keys can be made by your Toyota dealer using a master key (vehicles without a smart key system) or the other key (vehicles with a smart key system) and the key number stamped on your key number plate. Keep the plate in a safe place such as your wallet, not in the vehicle.
  • Page 64 When an electronic key is lost (vehicles with a smart key system) If the electronic key remains lost, the risk of vehicle theft increases signifi- cantly. Visit your Toyota dealer immediately with all remaining electronic keys that was provided with your vehicle.
  • Page 65: Smart Key System

    3-2. Opening, closing and locking the doors ∗ Smart key system Function summary The following operations can be performed simply by carrying the electronic key on your person, for example in your pocket. (The driver should always carry the electronic key.) Locks and unlocks the side doors (→P.
  • Page 66 3-2. Opening, closing and locking the doors Unlocking and locking the doors Front doors Grip the driver’s door handle to unlock the door. Grip the passen- ger’s door handle to unlock all the doors.* Make sure to touch the sensor on the back of the handle.
  • Page 67 3-2. Opening, closing and locking the doors Back door Press the unlock button to unlock all the doors. The doors cannot be unlocked for 3 seconds after the doors are locked. Press the lock button to lock all the doors. RAV4_OM_OM42809U_(U)
  • Page 68 3-2. Opening, closing and locking the doors Antenna location and effective range ■ Antenna location Antennas outside the cabin Antennas inside the cabin Antenna outside the luggage compartment RAV4_OM_OM42809U_(U)
  • Page 69 3-2. Opening, closing and locking the doors ■ Effective range (areas within which the electronic key is detected) When locking or unlocking the doors The system can be operated when the electronic key is within about 2.3 ft. (0.7 m) of either of the outside front door handles and back door opener switch.
  • Page 70 3-2. Opening, closing and locking the doors ■ Alarms and warning indicators A combination of exterior and interior alarms as well as warning lights are used to prevent theft of the vehicle and unforeseeable accidents resulting from erroneous operation. Take appropriate measures for the warning light that comes on.
  • Page 71 3-2. Opening, closing and locking the doors ■ Switching the door unlock function It is possible to set which doors the entry function unlocks using the wireless remote control. Turn the engine switch off. When the indicator light on the key surface is not on, press and hold for approximately 5 seconds while pressing and holding The setting changes each time an operation is performed, as shown below.
  • Page 72 3-2. Opening, closing and locking the doors ■ Battery-saving function The battery-saving function will be activated in order to prevent the electronic key battery and the vehicle battery from being discharged while the vehicle is not in operation for a long time. ●...
  • Page 73 3-2. Opening, closing and locking the doors ■ Conditions affecting operation The smart key system uses weak radio waves. In the following situations, the communication between the electronic key and the vehicle may be affected, preventing the smart key system, wireless remote control and engine immobi- lizer system from operating properly.
  • Page 74 3-2. Opening, closing and locking the doors ■ Note for the entry function ● Even when the electronic key is within the effective range (detection areas), the system may not operate properly in the following cases: • The electronic key is too close to the window or outside door handle, near the ground, or in a high place when the doors are locked or unlocked.
  • Page 75 3-2. Opening, closing and locking the doors ■ Note for locking the doors ● Touching the door lock sensor while wearing gloves may delay or prevent lock operation. Remove the gloves and touch the lock sensor again. ● When the lock operation is performed using the lock sensor, recognition sig- nals will be shown up to two consecutive times.
  • Page 76 To prevent theft of the vehicle, do not leave the electronic key within 6 ft. (2 m) of the vehicle. ● The smart key system can be deactivated in advance. Ask your Toyota dealer for details. ■ To operate the system properly Make sure to carry the electronic key when operating the system.
  • Page 77 3-2. Opening, closing and locking the doors ■ Electronic key battery depletion ● The standard battery life is 1 to 2 years. ● If the battery becomes low, an alarm will sound in the cabin when the engine stops. (→P. 513) ●...
  • Page 78 (→P. 102) The radio waves may affect the operation of such devices. If necessary, the entry function can be disabled. Ask your Toyota dealer for details, such as the frequency of radio waves and timing of emitting the radio waves.
  • Page 79: Wireless Remote Control

    3-2. Opening, closing and locking the doors Wireless remote control Function summary The wireless remote control can be used to lock and unlock the vehi- cle. It also opens and closes the back door. Vehicles without a smart key system Locks all the doors Unlocks all the doors Pressing the button unlocks the...
  • Page 80 3-2. Opening, closing and locking the doors ■ Operation signals Doors: A buzzer sounds and the emergency flashers flash to indicate that the doors have been locked/unlocked. (Locked: once; Unlocked: twice) Back door (if equipped): A buzzer sounds and the emergency flashers flash twice to indicate that the back door is opening/closing.
  • Page 81 →P. 462 ■ Confirmation of the registered key number The number of keys already registered to the vehicle can be confirmed. Ask your Toyota dealer for details. ■ Customization Settings (e.g. wireless remote control system) can be changed. (Customizable features: →P. 579)
  • Page 82 3-2. Opening, closing and locking the doors ■ Certification for wireless remote control (vehicles without a smart key system - type A) For vehicles sold in the U.S.A. FCC ID: HYQ23AAC FCC ID: HYQ12BDM NOTE: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 83 3-2. Opening, closing and locking the doors ■ Certification for wireless remote control (vehicles without a smart key system - type B) <RKE Transmitter> TRW Automotive Automobile Entry/Security Transmitter Model: 226624-101, 226624-102 FCC ID: GQ4-52T IC: 1470A-33T MADE IN U.S.A. This device complies with Part 15 of the FCC Rules and with Industry Canada license-exempt RSS standard(s).
  • Page 84 3-2. Opening, closing and locking the doors <TPM/RKE Integrated Receiver> TRW Automotive Auto Alarm/Security system Receiver Model: 230433 FCC ID: GQ4-45R MADE IN USA This device complies with Part 15 of the FCC Rules and with RSS-GEN of Industry Canada. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference...
  • Page 85 3-2. Opening, closing and locking the doors ■ Certification for wireless remote control (vehicles with a smart key sys- tem) For vehicles sold in the U.S.A. FCC ID: HYQ23AAB FCC ID: HYQ14FBA FCC ID: NI4TMLF10-13 NOTE: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 86: Side Doors

    3-2. Opening, closing and locking the doors Side doors Unlocking and locking the doors The vehicle can be locked and unlocked using the key, entry function, wireless remote control or door lock switch. ◆ Entry function (if equipped) →P. 99 ◆...
  • Page 87 3-2. Opening, closing and locking the doors ◆ Door lock switch Locks all the doors Unlocks all the doors ◆ Inside lock buttons Locks the door Unlocks the door The front doors can be opened by pulling the inside handle even if the lock buttons are in the lock position.
  • Page 88 3-2. Opening, closing and locking the doors Locking the front doors from the outside without a key Move the inside lock button to the lock position. Close the door. Vehicles without a smart key system The door cannot be locked if the key is in the engine switch. Vehicles with a smart key system The door cannot be locked if the engine switch is in ACCESSORY or IGNITION ON mode, or the electronic key is left inside the vehicle.
  • Page 89 3-2. Opening, closing and locking the doors Automatic door locking and unlocking systems The following functions can be set or canceled: For instructions on customizing, refer to P. 579. Function Operation All doors are automatically locked Speed linked door locking function when vehicle speed is approxi- (vehicles with a smart key system) mately 12 mph (20 km/h) or higher.
  • Page 90 3-2. Opening, closing and locking the doors CAUTION ■ To prevent an accident Observe the following precautions while driving the vehicle. Failure to do so may result in a door opening and an occupant throwing out of the vehicle, resulting in death or serious injury. ●...
  • Page 91 3-2. Opening, closing and locking the doors Back door The back door can be locked/unlocked and opened/closed by the following procedures. Locking and unlocking the back door ■ Door lock switch →P. 121 ■ Entry function (if equipped) →P. 101 ■...
  • Page 92 3-2. Opening, closing and locking the doors Opening the back door from outside the vehicle ■ Back door opener Vehicles without a power back door Raise the back door while pressing up the back door opener switch. Vehicles with a power back door When back...
  • Page 93 3-2. Opening, closing and locking the doors When closing the back door Lower the back door using the back door handle. Vehicles without a power back door Make sure to push the back door down from the outside to close it. Vehicles with a power back door The back door closing assist will...
  • Page 94 3-2. Opening, closing and locking the doors ■ The power back door can be operated when The power back door is unlocked. (Except for using the back door opener switch.) ■ Luggage compartment light The luggage compartment light turns on when the back door is opened with the luggage compartment light switch on.
  • Page 95 3-2. Opening, closing and locking the doors ■ Jam protection function (vehicles with a power back door) If anything obstructs the power back door while it is closing/opening, the back door will automatically operate in the opposite direction or stop. ■...
  • Page 96 3-2. Opening, closing and locking the doors CAUTION Observe the following precautions. Failure to do so may result in death or serious injury. ■ Before driving ● Make sure that the back door is fully closed. If the back door is not fully closed, it may open unexpectedly while driving and hit near-by objects or luggage in the luggage compartment may be thrown out, causing an acci- dent.
  • Page 97 3-2. Opening, closing and locking the doors CAUTION ■ Operating the back door Observe the following precautions. Failure to do so may cause parts of the body to be caught, resulting in death or serious injury. ● Remove any heavy loads, such as snow and ice, from the back door before opening it.
  • Page 98 ● Do not attach any accessories other than genuine Toyota parts to the back door. Such additional weight on the back door may cause the back door to suddenly shut again after it is opened.
  • Page 99 3-2. Opening, closing and locking the doors CAUTION ■ Power back door (if equipped) Observe the following precautions when operating the power back door. Failure to do so may cause death or serious injury. ● Check the safety of the surrounding area to make sure there are no obsta- cles or anything that could cause any of your belongings to get caught.
  • Page 100 3-2. Opening, closing and locking the doors CAUTION ■ Jam protection function (vehicles with a power back door) Observe the following precautions. Failure to do so may cause death or serious injury. ● Never use any part of your body to intentionally activate the jam protection function.
  • Page 101 Do not touch the damper stay rod with gloves or other fabric items. ● Do not attach any accessories other Damper stays than genuine Toyota parts to the back door. ● Do not place your hand on the damper stay or apply lateral forces to it. ■...
  • Page 102 3-2. Opening, closing and locking the doors NOTICE ■ To prevent back door closer malfunction (vehicles with a power back door) Do not apply excessive force to the back door while the back door closer is operating. ■ To prevent damage to the power back door (if equipped) ●...
  • Page 103: Front Seats

    3-3. Adjusting the seats Front seats Adjustment procedure Manual seat Seat position adjustment lever Vertical height adjustment lever (driver’s side only) Seatback angle adjustment lever Power seat (driver’s side only) Seat position adjustment switch Vertical height adjustment switch Seatback angle adjustment switch Lumbar support adjustment...
  • Page 104 3-3. Adjusting the seats CAUTION ■ When adjusting the seat position ● Take care when adjusting the seat position to ensure that other passen- gers are not injured by the moving seat. ● Do not put your hands under the seat or near the moving parts to avoid injury.
  • Page 105: Rear Seats

    3-3. Adjusting the seats Rear seats Adjustment procedure Pull up the lever. Then lean back to the desired angle and release the lever. When a person sits in the rear center position, align all seatbacks at the same angle. RAV4_OM_OM42809U_(U)
  • Page 106 3-3. Adjusting the seats Folding down the rear seatbacks ■ Before folding down the rear seatbacks Stow the rear center seat belt. (→P. 32) Stow the rear seat belt buck- les. Lower the head restraint to the lowest position. (→P. 147) ■...
  • Page 107 3-3. Adjusting the seats CAUTION ■ When folding the rear seatbacks down Observe the following precautions. Failure to do so may result in death or serious injury. ● Do not fold the seatbacks down while driving. ● Stop the vehicle on level ground, set the parking brake and shift the shift lever to P.
  • Page 108 3-3. Adjusting the seats CAUTION ■ After returning the rear seatback to the upright position Observe the following precautions. Failure to do so may result in death or serious injury. ● Make sure the seatback is securely locked by pushing it forward and rear- ward on the top.
  • Page 109: Driving Position Memory

    3-3. Adjusting the seats ∗ Driving position memory Your preferred driving position (the position of the driver’s seat) can be memorized and recalled by pressing a button. It is also possible to set this function to activate automatically when the doors are unlocked.
  • Page 110 3-3. Adjusting the seats Recalling the memorized position Check that the shift lever is in P. Turn the engine switch to the “ON” position (vehicles without a smart key system) or IGNITION ON mode (vehicles with a smart key system). Press button “1”...
  • Page 111 3-3. Adjusting the seats Linking driving position memory with door unlock operation (vehicles with a smart key system) A desired driving position can be recalled linked with the unlocking of the door. ■ Setting procedure Record your driving position to button “1” or “2” before performing the following: Carrying only the key to which you want to link the driving position, shift the shift lever to P and then close the driver’s door.
  • Page 112 3-3. Adjusting the seats ■ Cancelation procedure Carry only the key for which you want to cancel the linked door unlock operation. If 2 or more keys are in the vehicle, the driving position cannot be canceled properly. Turn the engine switch to IGNITION ON mode. While pressing the “SET”...
  • Page 113: Head Restraints

    3-3. Adjusting the seats Head restraints Head restraints are provided for all seats. Front seats Pull the head restraints up. Down Push the head restraint down while pressing the lock release button. Lock release button Rear seats Pull the head restraints up. Down Push the head restraint down while pressing the lock release button.
  • Page 114 3-3. Adjusting the seats ■ Removing the head restraints Front seats Pull the head restraint up while pressing the lock release button. Lock release button Rear seats Pull the head restraint up while pressing the lock release button. Lock release button ■...
  • Page 115 3-3. Adjusting the seats Rear seats Align the head restraint with the installa- tion holes and push it down while press- ing the lock release button. Lock release button ■ Adjusting the height of the head restraints Make sure that the head restraints are adjusted so that the center of the head restraint is closest to the top of your ears.
  • Page 116: Steering Wheel

    3-4. Adjusting the steering wheel and mirrors Steering wheel Adjustment procedure The steering wheel can be adjusted to a comfortable position. Hold the steering wheel and press the lever down. Adjust to the ideal position by moving the steering wheel hori- zontally and vertically.
  • Page 117: Inside Rear View Mirror

    3-4. Adjusting the steering wheel and mirrors Inside rear view mirror The rear view mirror’s position can be adjusted to enable suffi- cient confirmation of the rear view. Adjusting the height of rear view mirror The height of the rear view mirror can be adjusted to suit your driving posture.
  • Page 118 3-4. Adjusting the steering wheel and mirrors Auto anti-glare inside rear view mirror Responding to the level of brightness of the headlights of vehicles behind, the reflected light is automatically reduced. Changing automatic anti-glare function mode On/off When the automatic anti-glare function is in ON mode, the indica- tor illuminates.
  • Page 119 3-4. Adjusting the steering wheel and mirrors ■ To prevent sensor error (vehicles with an auto anti-glare inside rear view mirror) To ensure that the sensors operate prop- erly, do not touch or cover them. CAUTION Do not adjust the position of the mirror while driving. Doing so may lead to mishandling of the vehicle and cause an accident, resulting in death or serious injury.
  • Page 120: Outside Rear View Mirrors

    3-4. Adjusting the steering wheel and mirrors Outside rear view mirrors Adjustment procedure To select a mirror to adjust, press the switch. Left Right To adjust the mirror, press the switch. Right Down Left Folding the mirrors Push the mirror back in the direc- tion of the vehicle’s rear.
  • Page 121 3-4. Adjusting the steering wheel and mirrors ■ Mirror angle can be adjusted when Vehicles without a smart key system The engine switch is in the “ACC” or “ON” position. Vehicles with a smart key system The engine switch is in ACCESSORY or IGNITION ON mode. ■...
  • Page 122: Power Windows

    3-5. Opening, closing the windows and moon roof Power windows Opening and closing procedures The power windows can be opened and closed using the switches. Operating the switch moves the windows as follows: Closing One-touch closing (driver’s win- dow only) (if equipped) Opening One-touch opening...
  • Page 123 If you release the switch while the window is moving, start again from the beginning. If the window continues to close but then re-open slightly even after perform- ing the above procedure correctly, have the vehicle inspected by your Toyota dealer. RAV4_OM_OM42809U_(U)
  • Page 124 3-5. Opening, closing the windows and moon roof CAUTION Observe the following precautions. Failure to do so may result in death or serious injury. ■ Closing the windows ● Check to make sure that all passengers do not have any part of their body in a position where it could be caught when a window is being operated.
  • Page 125 3-5. Opening, closing the windows and moon roof ∗ Moon roof Use the overhead switches to open and close the moon roof and tilt it up and down. Opening and closing Opens the moon roof The moon roof stops slightly before the fully open position to reduce wind noise.
  • Page 126 3-5. Opening, closing the windows and moon roof ■ The moon roof can be operated when Vehicles without a smart key system The engine switch is in the “ON” position. Vehicles with a smart key system The engine switch is in IGNITION ON mode. ■...
  • Page 127 3-5. Opening, closing the windows and moon roof ■ Moon roof open reminder function Vehicles without a smart key system The buzzer sounds when the engine switch is turned to the “LOCK” position and the driver’s door is opened with the moon roof open. Vehicles with a smart key system The buzzer sounds when the engine switch is turned off and the driver’s door is opened with the moon roof open.
  • Page 128 3-5. Opening, closing the windows and moon roof CAUTION Observe the following precautions. Failure to do so may cause death or serious injury. ■ Opening the moon roof ● Do not allow any passengers to put their hands or heads outside the vehi- cle while it is moving.
  • Page 129: Driving The Vehicle

    4-1. Before driving Driving the vehicle The following procedures should be observed to ensure safe driving: Starting the engine →P. 197, 200 Driving With the brake pedal depressed, shift the shift lever to D. (→P. 207) Release the parking brake. (→P. 215) Gradually release the brake pedal and gently depress the accelera- tor pedal to accelerate the vehicle.
  • Page 130 4-1. Before driving Parking the vehicle With the shift lever in D, depress the brake pedal. Shift the shift lever to P. (→P. 207) Set the parking brake. (→P. 215) Vehicles without a smart key system: Turn the engine switch to the “LOCK” position to stop the engine. Vehicles with a smart key system: Press the engine switch to stop the engine.
  • Page 131 When the accelerator pedal is released ● When the brake pedal is depressed while sport mode is selected ■ Breaking in your new Toyota To extend the life of the vehicle, observing the following precautions is recom- mended: ● For the first 200 miles (300 km): Avoid sudden stops.
  • Page 132 Your vehicle has a drum-in-disc type parking brake system. This type of brake system needs bedding-down of the brake shoes periodically or whenever the parking brake shoes and/or drum are replaced. Have your Toyota dealer per- form the bedding down operation.
  • Page 133 4-1. Before driving CAUTION Observe the following precautions. Failure to do so may result in death or serious injury. ■ When starting the vehicle Always keep your foot on the brake pedal while stopped with the engine running. This prevents the vehicle from creeping. ■...
  • Page 134 4-1. Before driving CAUTION Observe the following precautions. Failure to do so may result in death or serious injury. ■ When driving the vehicle ● During normal driving, do not turn off the engine. Turning the engine off while driving will not cause loss of steering or braking control, but the power assist to these systems will be lost.
  • Page 135 4-1. Before driving CAUTION Observe the following precautions. Failure to do so may result in death or serious injury. ■ When driving on slippery road surfaces ● Sudden braking, acceleration and steering may cause tire slippage and reduce your ability to control the vehicle. ●...
  • Page 136 If you hear a squealing or scraping noise (brake pad wear limit indica- tors) Have the brake pads checked and replaced by your Toyota dealer as soon as possible. The rotor damage may result if the pads are not replaced when needed.
  • Page 137 4-1. Before driving CAUTION ■ When the vehicle is parked ● Do not leave glasses, cigarette lighters, spray cans, or soft drink cans in the vehicle when it is in the sun. Doing so may result in the following: • Gas may leak from a cigarette lighter or spray can, and may lead to a fire.
  • Page 138 4-1. Before driving CAUTION ■ When taking a nap in the vehicle Always turn the engine off. Otherwise, if you accidentally move the shift lever or depress the accelerator pedal, this could cause an accident or fire due to engine overheating. Additionally, if the vehicle is parked in a poorly ventilated area, exhaust gases may collect and enter the vehicle, leading to death or a serious health hazard.
  • Page 139 4-1. Before driving NOTICE ■ When driving the vehicle ● Do not depress the accelerator and brake pedals at the same time during driving, as this may restrain driving torque. ● Do not use the accelerator pedal or depress the accelerator and brake pedals at the same time to hold the vehicle on a hill.
  • Page 140 Short in electrical components ● Engine damage caused by water immersion In the event that you drive on a flooded road and the vehicle is flooded, be sure to have your Toyota dealer check the following: ● Brake function ●...
  • Page 141: Cargo And Luggage

    4-1. Before driving Cargo and luggage Take notice of the following information about storage precau- tions, cargo capacity and load: Capacity and distribution Cargo capacity depends on the total weight of the occupants. (Cargo capacity) = (Total load capacity) − (Total weight of occupants) Steps for Determining Correct Load Limit ⎯...
  • Page 142 4-1. Before driving Calculation formula for your vehicle Cargo capacity Total load capacity (vehicle capacity weight) (→P. 552) When 2 people with the combined weight of A lb. (kg) are riding in your vehicle, which has a total load capacity (vehicle capacity weight) of B lb.
  • Page 143 4-1. Before driving CAUTION ■ Things that must not be carried in the luggage compartment The following things may cause a fire if loaded in the luggage compartment: ● Receptacles containing gasoline ● Aerosol cans ■ Storage precautions Observe the following precautions. Failure to do so may prevent the pedals from being depressed properly, may block the driver’s vision, or may result in items hitting the driver or pas- sengers, possibly causing an accident.
  • Page 144 4-1. Before driving CAUTION ■ Capacity and distribution ● Do not exceed the maximum axle weight rating or the total vehicle weight rating. ● Even if the total load of occupant’s weight and the cargo load is less than the total load capacity, do not apply the load unevenly. Improper loading may cause deterioration of steering or braking control which may cause death or serious injury.
  • Page 145: Vehicle Load Limits

    4-1. Before driving Vehicle load limits Vehicle load limits include total load capacity, seating capacity, TWR (Trailer Weight Rating) and cargo capacity. ◆ Total load capacity (vehicle capacity weight): →P. 552 Total load capacity means the combined weight of occupants, cargo and luggage.
  • Page 146: Trailer Towing

    To tow a trailer safely, use extreme care and drive the vehicle in accordance with your trailer’s characteristics and operating conditions. Toyota warranties do not apply to damage or malfunction caused by towing a trailer for commercial purposes. Contact your Toyota dealer for further information about additional requirements such as a towing kit, etc.
  • Page 147 4-1. Before driving Towing related terms ■ GCWR (Gross Combination Weight Rating) The maximum allowable gross combination weight. The gross combination weight is the sum of the total vehicle weight (including the occupants, cargo and any optional equipment installed on the vehicle) and the weight of the trailer being towed (including the cargo in the trailer).
  • Page 148 4-1. Before driving ■ GAWR (Gross Axle Weight Rating) The maximum allowable gross Front GAWR axle weight. The gross axle weight is the load placed on each axle (front and rear). Rear GAWR ■ TWR (Trailer Weight Rating) The maximum allowable gross (With brakes) trailer weight.
  • Page 149 4-1. Before driving ■ Unbraked TWR (Unbraked Trailer Weight Rating) The trailer weight rating for tow- (Without brakes) ing a trailer without a trailer ser- vice brake system. ■ Tongue Weight The load placed on the trailer hitch ball. (→P. 186) RAV4_OM_OM42809U_(U)
  • Page 150 4-1. Before driving Weight limits ● The gross trailer weight must never exceed 1500 lb. (680 kg). ● The gross combination weight must never exceed the GCWR described below. 2WD models: 5985 lb. (2715 kg) AWD models: 6100 lb. (2765 kg) ●...
  • Page 151 4-1. Before driving Trailer Tongue Weight ● A recommended tongue weight varies in accordance with the types of trailers or towing as described below. ● To ensure the recommended values shown below, the trailer must be loaded by referring to the following instructions. •...
  • Page 152 Toyota hitch/bracket for your vehicle. For details, contact your Toyota dealer. ● If you wish to install a trailer hitch, contact your Toyota dealer. ● Use only a hitch that conforms to the gross trailer weight require- ment of your vehicle.
  • Page 153 ● Speed limits for towing a trailer vary by state or province. Do not exceed the posted towing speed limit. ● Toyota recommends that the vehicle-trailer speed limit is 65 mph (104 km/h) on a flat, straight, dry road. Do not exceed this limit, the posted towing speed limit or the speed limit for your trailer as set forth in your trailer owner’s manual, whichever is lowest.
  • Page 154 4-1. Before driving ● As stopping distance is increased when towing a trailer, vehicle-to vehicle distance should be increased. For each 10 mph (16 km/h) of speed, allow at least one vehicle and trailer length. ● Avoid sudden braking as you may skid, resulting in the trailer jack- knifing and a loss of vehicle control.
  • Page 155 4-1. Before driving ● Due to the added load of the trailer, your vehicle’s engine may over- heat on hot days (at temperatures over 85 °F [30 °C]) when driving up a long or steep grade. If the engine coolant temperature gauge indicates overheating, immediately turn off the air conditioning (if in use), pull your vehicle off the road and stop in a safe spot.
  • Page 156 4-1. Before driving ■ Matching trailer ball height to trailer coupler height No matter which class of tow hitch applies, for a more safe trailer hookup, the trailer ball setup must be the proper height for the coupler on the trailer. Coupler Trailer ball ■...
  • Page 157 Break-in schedule If your vehicle is new or equipped with any new power train components (such as an engine, transmission, differential or wheel bearing), Toyota rec- ommends that you do not tow a trailer until the vehicle has been driven for over 500 miles (800 km).
  • Page 158 4-1. Before driving ● After the trailer swaying has stopped: • Stop in a safe place. Get all occupants out of the vehicle. • Check the tires of the vehicle and the trailer. • Check the load in the trailer. Make sure the load has not shifted.
  • Page 159 4-1. Before driving CAUTION ● Do not apply the brakes suddenly as you may skid, resulting in jackknifing and loss of vehicle control. This is especially true on wet or slippery sur- faces. ● Do not exceed the trailer hitch assembly weight, gross vehicle weight, gross axle weight and trailer tongue weight capacities.
  • Page 160 NOTICE ■ When installing a trailer hitch Use only the position recommended by your Toyota dealer. Do not install the trailer hitch on the bumper; this may cause body damage. ■ Do not directly splice trailer lights Do not directly splice trailer lights.
  • Page 161: Dinghy Towing

    4-1. Before driving Dinghy towing Your vehicle is not designed to be dinghy towed (with 4 wheels on the ground) behind a motor home. NOTICE ■ To avoid serious damage to your vehicle Do not tow your vehicle with 4 wheels on the ground.
  • Page 162: Engine (Ignition) Switch (Vehicles Without A Smart Key System)

    4-2. Driving procedures Engine (ignition) switch (vehicles without a smart key system) Starting the engine Check that the parking brake is set. Check that the shift lever is set in P. Firmly depress the brake pedal. Turn the engine switch to the “START” position to start the engine. Changing the engine switch positions “LOCK”...
  • Page 163 “LOCK” position. ■ If the engine does not start The engine immobilizer system may not have been deactivated. (→P. 77) Contact your Toyota dealer. ■ When the steering lock cannot be released When starting the engine, the engine switch may seem stuck in the “LOCK”...
  • Page 164 Do not crank the engine for more than 30 seconds at a time. This may overheat the starter and wiring system. ● Do not race a cold engine. ● If the engine becomes difficult to start or stalls frequently, have your vehi- cle checked by your Toyota dealer immediately. RAV4_OM_OM42809U_(U)
  • Page 165: Engine (Ignition) Switch (Vehicles With A Smart Key System)

    4-2. Driving procedures Engine (ignition) switch (vehicles with a smart key system) Performing the following operations when carrying the elec- tronic key on your person starts the engine or changes engine switch modes. Starting the engine Check that the parking brake is set. Check that the shift lever is set in P.
  • Page 166 4-2. Driving procedures Stopping the engine Stop the vehicle. Shift the shift lever to P. Set the parking brake. (→P. 215) Press the engine switch. Release the brake pedal and check that the smart key system indi- cator light (green) is off. Changing engine switch modes Modes can be changed by pressing the engine switch with the brake pedal released.
  • Page 167 4-2. Driving procedures When stopping the engine with the shift lever in a position other than P If the engine is stopped with the shift lever in a position other than P, the engine switch will not be turned off but instead be turned to ACCESSORY mode.
  • Page 168 →P. 108 ■ If the engine does not start ● The engine immobilizer system may not have been deactivated. (→P. 77) Contact your Toyota dealer. ● The steering lock may not have been canceled. ■ Steering lock After turning the engine switch off and opening and closing the doors, the steering wheel will be locked due to the steering lock function.
  • Page 169 ■ When the smart key system indicator light flashes in yellow The system may be malfunctioning. Have the vehicle inspected by your Toyota dealer immediately. ■ If the electronic key battery is depleted →P. 462 ■...
  • Page 170 4-2. Driving procedures CAUTION ■ When starting the engine Always start the engine while sitting in the driver’s seat. Do not depress the accelerator pedal while starting the engine under any circumstances. Doing so may cause an accident resulting in death or serious injury. ■...
  • Page 171 Do not race a cold engine. ● If the engine becomes difficult to start or stalls frequently, have your vehi- cle checked by your Toyota dealer immediately. ■ Symptoms indicating a malfunction with the engine switch If the engine switch seems to be operating somewhat differently than usual, such as the switch sticking slightly, there may be a malfunction.
  • Page 172: Automatic Transmission

    4-2. Driving procedures Automatic transmission Shifting the shift lever Vehicles without a smart key system While the engine switch is in the “ON” position, move the shift lever with the brake pedal depressed. When shifting the shift lever between P and D, make sure that the vehicle is completely stopped.
  • Page 173 4-2. Driving procedures Shift position purpose Shift position Objective or function Parking the vehicle/starting the engine Reversing Neutral Normal driving S mode driving (→P. 210) : Shifting the shift lever to D allows the system to select a gear suitable for the driving conditions.
  • Page 174 4-2. Driving procedures Selecting the driving mode The following modes can be selected to suit driving conditions. ■ Eco drive mode Use Eco drive mode to help achieve low fuel consumption during trips that involve frequent accelerating. Press the “ECO MODE” button to select Eco drive mode.
  • Page 175 4-2. Driving procedures Selecting shift ranges in the S position To enter S mode, shift the shift lever to S. Shift ranges can be selected by operating the shift lever, allowing you to drive in the shift range of your choosing. The shift range can be selected by the shift lever. Upshifting Downshifting The selected shift range, from 1 to...
  • Page 176 4-2. Driving procedures ■ S mode ● When the shift range is 4 or lower, holding the shift lever toward “+” sets the shift range to 6. ● To prevent the engine from over-revving, upshifting may automatically occur. ● To protect the automatic transmission, a higher shift range may automati- cally selected when the fluid temperature is high.
  • Page 177 S This may indicate a malfunction in the automatic transmission system. Have the vehicle inspected by your Toyota dealer immediately. (In this situation, the transmission will operate in the same manner as when the shift lever is in D.)
  • Page 178 4-2. Driving procedures ■ AI-SHIFT The AI-SHIFT automatically selects the suitable gear according to driver per- formance and driving conditions. The AI-SHIFT automatically operates when the shift lever is in D. (Shifting the shift lever to S cancels the function.) CAUTION ■...
  • Page 179: Turn Signal Lever

    4-2. Driving procedures Turn signal lever Operating instructions Right turn Lane change to the right (move the lever partway and release The right hand signals will flash 3 times. Lane change to the left (move the lever partway and release The left hand signals will flash 3 times.
  • Page 180: Parking Brake

    4-2. Driving procedures Parking brake Sets the parking brake Fully set the parking brake while depressing the brake pedal. U.S.A. Canada Releases the parking brake Slightly raise the lever and lower it completely while pressing the but- ton. ■ Usage in winter time →P.
  • Page 181 4-2. Driving procedures Horn To sound the horn, press on or close to the mark. ■ After adjusting the steering wheel Make sure that the steering wheel is securely locked. The horn may not sound if the steering wheel is not securely locked. (→P.
  • Page 182: Headlight Switch

    4-3. Operating the lights and wipers Headlight switch The headlights can be operated manually or automatically. Operating instructions Turning the end of the lever turns on the lights as follows: Type A The side marker, parking, tail, license plate, daytime running lights and instru- ment panel lights turn on.
  • Page 183 4-3. Operating the lights and wipers Type B The side marker, parking, tail, license plate, daytime running lights and instru- ment panel lights turn on. The headlights and all lights listed above (except daytime running lights) turn on. The daytime running lights turn on.
  • Page 184 4-3. Operating the lights and wipers Turning on the high beam headlights With the headlights on, push the lever away from you to turn on the high beams. Pull the lever toward you to the center position to turn the high beams off.
  • Page 185 4-3. Operating the lights and wipers ■ Automatic light off system When the light switch is in AUTO: The lights turn off 30 seconds after the engine switch is turned to the “LOCK” position (vehicles without a smart key system) or off (vehicles with a smart key system) and a door is opened and all of the doors are closed.
  • Page 186: Automatic High Beam

    4-3. Operating the lights and wipers ∗ Automatic High Beam The Automatic High Beam uses an in-vehicle camera sensor to assess the brightness of streetlights, the lights of oncoming and preceding vehicles, etc., and automatically turns high beam on or off as necessary. Activating the Automatic High Beam system Push the lever away from you with the headlight switch in...
  • Page 187 4-3. Operating the lights and wipers High beam automatic turning on or off conditions When all of the following conditions are fulfilled, high beam will be automatically turned on: ● Vehicle speed is above approximately 21 mph (34 km/h). ● The area ahead of the vehicle is dark. ●...
  • Page 188 4-3. Operating the lights and wipers Turning the high beam on/off manually ■ Switching to low beam Pull the lever to original posi- tion. ■ Switching to high beam Turn the light switch to position. The Automatic High Beam indi- cator will turn off and the high beam indicator will turn on.
  • Page 189 4-3. Operating the lights and wipers ■ The Automatic High Beam can be operated when Vehicles without a smart key system The engine switch is in the “ON” position. Vehicles with a smart key system The engine switch is in IGNITION ON mode. ■...
  • Page 190 4-3. Operating the lights and wipers ● In the situations below, the system may not be able to correctly detect the surrounding brightness levels, and may flash or expose nearby pedestrians to the high beam. Therefore, you should consider turning the high beams on or off manually rather than relying on the Automatic High Beam system.
  • Page 191 Automatic High Beam (headlights) may turn on even the vehicle is stopped. ■ If the Automatic High Beam indicator turns to yellow... It may indicate a malfunction in the system. Contact your Toyota dealer. ■ Customization The Automatic High Beam can be turned off.
  • Page 192 Do not install a parking tag or any other accessories near or around the camera sensor. ● Do not overload the vehicle. ● Do not modify the vehicle. ● Do not replace windshield with non-genuine windshield. Contact your Toyota dealer. ● Do not replace headlights with non-genuine headlights. Contact your Toyota dealer. RAV4_OM_OM42809U_(U)
  • Page 193: Fog Light Switch

    4-3. Operating the lights and wipers ∗ Fog light switch The fog lights secure excellent visibility in difficult driving con- ditions, such as in rain and fog. (U.S.A.) (Canada) Turns the fog lights off Turns the fog lights on ■ Fog lights can be used when The headlights are on in low beam.
  • Page 194: Windshield Wipers And Washer

    4-3. Operating the lights and wipers Windshield wipers and washer Operating the wiper lever The wiper operation is selected by moving the lever as follows. Intermittent windshield wipers (for the U.S.A.) If equipped, when intermittent windshield wiper operation is selected, wiper intervals can be also adjusted.
  • Page 195 4-3. Operating the lights and wipers Increases the intermittent wind- shield wiper frequency equipped) Decreases intermittent windshield wiper frequency (if equipped) Washer/wiper dual operation The wipers will automatically oper- ate a couple of times after the washer squirts. RAV4_OM_OM42809U_(U)
  • Page 196 4-3. Operating the lights and wipers Intermittent windshield wipers (for Canada) If equipped, when intermittent windshield wiper operation is selected, wiper intervals can be also adjusted. Intermittent wiper opera- tion Low speed wiper opera- tion High speed wiper opera- tion Temporary operation RAV4_OM_OM42809U_(U)
  • Page 197 4-3. Operating the lights and wipers Increases the intermittent wind- shield wiper frequency equipped) Decreases intermittent windshield wiper frequency (if equipped) Washer/wiper dual operation The wipers will automatically oper- ate a couple of times after the washer squirts. ■ The windshield wipers and washer can be operated when Vehicles without a smart key system The engine switch is in the “ON”...
  • Page 198 Do not operate the switch continually as the washer fluid pump may over- heat. ■ When a nozzle becomes blocked In this case, contact your Toyota dealer. Do not try to clear it with a pin or other object. The nozzle will be damaged. ■ To prevent battery discharge Do not leave the wipers on longer than necessary when the engine is off.
  • Page 199: Rear Window Wiper And Washer

    4-3. Operating the lights and wipers Rear window wiper and washer Turning the end of the lever turns on the rear window wiper and washer. For the U.S.A. Intermittent window wiper operation Normal window wiper operation Washer/wiper dual operation RAV4_OM_OM42809U_(U)
  • Page 200 4-3. Operating the lights and wipers For Canada Intermittent window wiper operation Normal window wiper operation Washer/wiper dual operation RAV4_OM_OM42809U_(U)
  • Page 201 4-3. Operating the lights and wipers ■ The rear window wiper and washer can be operated when Vehicles without a smart key system The engine switch is in the “ON” position. Vehicles with a smart key system The engine switch is in IGNITION ON mode. ■...
  • Page 202: Opening The Fuel Tank Cap

    4-4. Refueling Opening the fuel tank cap Perform the following steps to open the fuel tank cap: Before refueling the vehicle ● Close all the doors and windows, and turn the engine switch to the “LOCK” position (vehicles without a smart key system) or off (vehi- cles with a smart key system).
  • Page 203 4-4. Refueling CAUTION ■ When refueling the vehicle Observe the following precautions while refueling the vehicle. Failure to do so may result in death or serious injury. ● After exiting the vehicle and before opening the fuel door, touch an unpainted metal surface to discharge any static electricity.
  • Page 204 4-4. Refueling Opening the fuel tank cap Pull up the opener to open the fuel filler door. Turn the fuel tank cap slowly to open. Hang the fuel tank cap on the back of the fuel filler door. RAV4_OM_OM42809U_(U)
  • Page 205 CAUTION ■ When replacing the fuel tank cap Do not use anything but a genuine Toyota fuel tank cap designed for your vehicle. Doing so may cause a fire or other incident which may result in death or serious injury.
  • Page 206: Cruise Control

    4-5. Using the driving support systems Cruise control Summary of functions Use the cruise control to maintain a set speed without depressing the accelerator pedal. Indicators Cruise control switch Setting the vehicle speed Press the “ON-OFF” button to activate the cruise control. Cruise control indicator will come Press the button again to deacti- vate the cruise control.
  • Page 207 4-5. Using the driving support systems Adjusting the set speed To change the set speed, operate the lever until the desired set speed is obtained. Increases the speed Decreases the speed Fine adjustment: Momentarily move the lever in the desired direc- tion.
  • Page 208 If the cruise control speed cannot be set or if the cruise control cancels imme- diately after being activated, there may be a malfunction in the cruise control system. Have the vehicle inspected by your Toyota dealer. RAV4_OM_OM42809U_(U)
  • Page 209 4-5. Using the driving support systems CAUTION ■ To avoid operating the cruise control by mistake Switch the cruise control off using the “ON-OFF” button when not in use. ■ Situations unsuitable for cruise control Do not use cruise control in any of the following situations. Doing so may result in loss of control and could cause an accident resulting in death or serious injury.
  • Page 210 4-5. Using the driving support systems ∗ LDA (Lane Departure Alert) Summary of function While driving on a road that has lane markers, this system recognizes the lane markers using a camera as a sensor to alert the driver when the vehicle deviates from its lane.
  • Page 211 4-5. Using the driving support systems Turning the LDA system on Press the “LDA” switch to activate the system. LDA indicator will come on. Press the switch again to turn the LDA system off. The LDA system will remain on or off even if the engine switch is turned to the “ON”...
  • Page 212 4-5. Using the driving support systems Indication on the instrument cluster When the LDA system is on, the lane lines are shown. The indicators of the lane lines come on in green when the right and left lane markers are recognized.
  • Page 213 4-5. Using the driving support systems ■ Temporary cancelation of the LDA system If any of the following occurs, the LDA system will be temporarily canceled. The function will resume after the necessary operating conditions have returned. ● The vehicle speed deviates from the operating range of the LDA system. ●...
  • Page 214 4-5. Using the driving support systems ● When there are shadows on the road running parallel with lane markers, or if a shadow covers the lane markers ● When driving on a particularly bright road surface, such as concrete ● When driving on a road surface that is bright due to reflected light ●...
  • Page 215 4-5. Using the driving support systems CAUTION ■ Before using the LDA system Do not rely solely on the LDA system. The LDA system does not drive the vehicle automatically, nor does it reduce the amount of care you need to take.
  • Page 216 Do not install or place anything on the hood or the grille. Also, do not install a grille guard (bull bars, kangaroo bar etc.). ● If your windshield needs repairs, contact your Toyota dealer. ■ Camera sensor (→P. 245) Observe the following to ensure that the LDA system functions correctly.
  • Page 217 When cleaning the inside of the windshield, be careful not to get any glass cleaner etc. on the lens. Also, do not touch the lens. For lens repair, contact your Toyota dealer. ● Do not change the installation position or direction of the camera sensor or remove it.
  • Page 218: Intuitive Parking Assist

    4-5. Using the driving support systems ∗ Intuitive parking assist The distance from your vehicle to nearby obstacles when paral- lel parking or maneuvering into a garage is measured by the sensors and communicated via the indicator and a buzzer. Always check the surrounding area when using this system.
  • Page 219 4-5. Using the driving support systems The indicator and buzzer When a sensor detects an obstacle, the direction of and the approxi- mate distance to the obstacle are indicated and the buzzer sounds. ■ Intuitive parking assist indicator Vehicle indicator Rear corner indicators Rear center indicator ■...
  • Page 220 4-5. Using the driving support systems ■ Detection range of the sensors Approximately 4.9 ft. (150 cm) Approximately 1.6 ft. (50 cm) The diagram shows the detec- tion range of the sensors. Note that the sensors may not be able to detect obstacles that are extremely close to the vehicle.
  • Page 221 • The area directly under the bumpers is not detected. • If obstacles draw too close to the sensor. • A non-genuine Toyota suspension (lowered suspension etc.) is installed. • People may not be detected if they are wearing certain types of clothing.
  • Page 222 The indicator for the malfunctioning sensor flashes and the vehicle indicator turns off while the buzzer sounds for approximately 7 seconds. If the corner and center indicators flash after that, the sensor may be mal- functioning. Have the vehicle inspected by your Toyota dealer. ■ Certification (Canada only) This ISM device complies with Canadian ICES-001.
  • Page 223 When using intuitive parking assist In the following situations, the system may not function correctly due to a sensor malfunction etc. Have the vehicle checked by your Toyota dealer. ● A beep does not sound when you turn the main switch on.
  • Page 224: All-Wheel Drive Lock Switch (Awd Models)

    4-5. Using the driving support systems All-wheel drive lock switch (AWD models) All-wheel drive lock mode can be used when a large amount of drive power needs to be applied to all the wheels, such as when the vehicle gets stuck in mud and you need to free it. Press the switch.
  • Page 225: Driving Assist Systems

    4-5. Using the driving support systems Driving assist systems To help enhance driving safety and performance, the following systems operate automatically in response to various driving situations. Be aware, however, that these systems are supple- mentary and should not be relied upon too heavily when operat- ing the vehicle.
  • Page 226 4-5. Using the driving support systems ◆ AUTO LSD function (2WD models) The AUTO LSD function is activated when the system is in TRAC off mode. It operates when one of the drive wheels is spinning, such as when the wheel is spinning freely on ice or mud. The sys- tem applies the brakes to the spinning wheel and transfers some of the torque to the other wheel to secure drive power.
  • Page 227 4-5. Using the driving support systems When the TRAC/VSC systems are operating The slip indicator light will flash while the TRAC/VSC systems are operating. Disabling the TRAC system If the vehicle gets stuck in mud, dirt or snow, the TRAC system may reduce power from the engine to the wheels.
  • Page 228 When the “AUTO LSD” indicator light flashes even if the VSC OFF switch has not been pressed (2WD models) TRAC and AUTO LSD cannot be operated. Contact your Toyota dealer. ■ When the “TRAC OFF” indicator light comes on even if the VSC OFF switch has not been pressed (AWD models) TRAC cannot be operated.
  • Page 229 4-5. Using the driving support systems ■ Reduced effectiveness of the EPS system The effectiveness of the EPS system is reduced to prevent the system from overheating when there is frequent steering input over an extended period of time. The steering wheel may feel heavy as a result. Should this occur, refrain from excessive steering input or stop the vehicle and turn the engine off.
  • Page 230 The ABS, TRAC and VSC systems will not function correctly if different tires are installed on the vehicle. Contact your Toyota dealer for further information when replacing tires or wheels. ■ Handling of tires and the suspension Using tires with any kind of problem or modifying the suspension will affect the driving assist systems, and may cause a system to malfunction.
  • Page 231 4-5. Using the driving support systems ∗ BSM (Blind Spot Monitor) Summary of the Blind Spot Monitor The Blind Spot Monitor is a system that has 2 functions; ● The Blind Spot Monitor function Assists the driver in making the decision when changing lanes ●...
  • Page 232 4-5. Using the driving support systems Outside rear view mirror indicators Blind Spot Monitor function: When a vehicle is detected in the blind spot, the outside rear view mirror indicator comes on while the turn signal lever is not operated and the out- side rear view mirror indicator flashes while the turn signal lever is oper- ated.
  • Page 233 4-5. Using the driving support systems ■ Certification for the Blind Spot Monitor system For vehicles sold in the U.S.A. FCC ID: OAYSRR2A This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 234 If the sensor moves even slightly off position, the system may mal- function and vehicles that enter the detection area may not be detected. If the sensor or surrounding area is subject to a strong impact, always have the area inspected by your Toyota dealer. ● Do not disassemble the sensor.
  • Page 235 4-5. Using the driving support systems The Blind Spot Monitor function The Blind Spot Monitor function uses radar sensors to detect vehicles that are traveling in an adjacent lane in the area that is not reflected in the outside rear view mirror (the blind spot), and advises the driver of the vehicles existence via the outside rear view mirror indicator.
  • Page 236 4-5. Using the driving support systems ■ The Blind Spot Monitor function is operational when ● The BSM main switch is set to on ● Vehicle speed is greater than approximately 10 mph (16 km/h). ■ The Blind Spot Monitor function will detect a vehicle when ●...
  • Page 237 4-5. Using the driving support systems ■ Conditions under which the Blind Spot Monitor function may not func- tion correctly ● The Blind Spot Monitor function may not detect vehicles correctly in the fol- lowing conditions: • During bad weather such as heavy rain, fog, snow etc. •...
  • Page 238 4-5. Using the driving support systems The Rear Cross Traffic Alert function The Rear Cross Traffic Alert functions when your vehicle is in reverse. It can detect other vehicles approaching from the right or left rear of the vehicle. It uses radar sensors to alert the driver of the other vehi- cle’s existence through flashing the outside rear view mirror indicators and sounding a buzzer.
  • Page 239 4-5. Using the driving support systems The Rear Cross Traffic Alert function detection areas The areas that vehicles can be detected in are outlined below. To give the driver a more consistent time to react, the buzzer can alert for faster vehicles from farther away. Example: Approximate Approaching vehicle...
  • Page 240 4-5. Using the driving support systems ■ Conditions under which the Rear Cross Traffic Alert function will not detect a vehicle The Rear Cross Traffic Alert function is not designed to detect the following types of vehicles and/or objects. ● Small motorcycles, bicycles, pedestrians etc.
  • Page 241: Winter Driving Tips

    4-6. Driving tips Winter driving tips Carry out the necessary preparations and inspections before driving the vehicle in winter. Always drive the vehicle in a man- ner appropriate to the prevailing weather conditions. Preparation for winter ● Use fluids that are appropriate to the prevailing outside tempera- tures.
  • Page 242 4-6. Driving tips Before driving the vehicle Perform the following according to the driving conditions: ● Do not try to forcibly open a window or move a wiper that is frozen. Pour warm water over the frozen area to melt the ice. Wipe away the water immediately to prevent it from freezing.
  • Page 243 4-6. Driving tips Selecting tire chains Use the correct tire chain size when mounting the tire chains. Chain size is regulated for each tire size. Side chain: 0.12 in. (3 mm) in diameter 0.39 in. (10 mm) in width 1.18 in. (30 mm) in length Cross chain: 0.16 in.
  • Page 244 4-6. Driving tips ■ Tire chain installation Observe the following precautions when installing and removing chains: ● Install and remove tire chains in a safe location. ● Install tire chains on the front tires only. Do not install tire chains on the rear tires.
  • Page 245 NOTICE ■ Repairing or replacing snow tires Request repairs or replacement of snow tires from Toyota dealers or legiti- mate tire retailers. This is because the removal and attachment of snow tires affects the opera- tion of the tire pressure warning valves and transmitters.
  • Page 246: Utility Vehicle Precautions

    4-6. Driving tips Utility vehicle precautions This vehicle belongs to the utility vehicle class, which has higher ground clearance and narrower tread in relation to the height of its center of gravity to make it capable of performing in a wide variety of off-road applications. Utility vehicle feature ●...
  • Page 247 4-6. Driving tips CAUTION ■ Utility vehicle precautions Always observe the following precautions to minimize the risk of death, seri- ous injury or damage to your vehicle: ● In a rollover crash, an unbelted person is significantly more likely to die than a person wearing a seat belt.
  • Page 248 4-6. Driving tips Off-road driving When driving your vehicle off-road, please observe the following pre- cautions to ensure your driving enjoyment and to help prevent the clo- sure of areas to off-road vehicles. ● Drive your vehicle only in areas where off-road vehicles are permit- ted to travel.
  • Page 249 4-6. Driving tips CAUTION ■ Off-road driving precautions Always observe the following precautions to minimize the risk of death, seri- ous injury or damage to your vehicle: ● Drive carefully when off the road. Do not take unnecessary risks by driving in dangerous places.
  • Page 250 4-6. Driving tips NOTICE ■ To prevent the water damage Take all necessary safety measures to ensure that water damage to the engine or other components does not occur. ● Water entering the engine air intake will cause severe engine damage. ●...
  • Page 251: Manual Air Conditioning System

    5-1. Using the air conditioning system and defogger ∗ Manual air conditioning system Air outlet selector dial Cooling and dehumidification function on/off button Fan speed control dial Outside/recirculated air mode Temperature control dial button ∗ : If equipped RAV4_OM_OM42809U_(U)
  • Page 252 5-1. Using the air conditioning system and defogger Adjusting the settings To adjust the fan speed, turn the fan speed control dial clockwise (increase) or counterclockwise (decrease). Turning the dial to “0” turns off the fan. To adjust the temperature setting, turn the temperature control dial clockwise (warm) or counterclockwise (cool).
  • Page 253 5-1. Using the air conditioning system and defogger Defogging the windshield Set the air outlet selector dial to position. If the recirculated air mode is used, it will automatically switch to the outside air mode. Perform the following operations accordingly: ●...
  • Page 254 5-1. Using the air conditioning system and defogger Upper body and feet Feet Feet and windshield Switching between outside air and recirculated air modes Press The mode switches between outside air mode (indicator off) and recircu- lated air mode (indicator on) each time is pressed.
  • Page 255 5-1. Using the air conditioning system and defogger Adjusting the position of and opening and closing the air outlets ■ Front center outlets Direct air flow to the left or right, up or down. Turn the knob to open or close the vent for rear seat occupants.
  • Page 256 5-1. Using the air conditioning system and defogger ■ Operation of the air conditioning system in Eco drive mode In Eco drive mode, the air conditioning system is controlled to prioritize fuel efficiency by regulating the engine speed and compressor operation to restrict the heating/cooling capacity.
  • Page 257 5-1. Using the air conditioning system and defogger ■ Air conditioning odors ● During use, various odors from inside and outside the vehicle may enter into and accumulate in the air conditioning system. This may then cause odor to be emitted from the vents. ●...
  • Page 258: Automatic Air Conditioning System

    5-1. Using the air conditioning system and defogger ∗ Automatic air conditioning system Air outlets and fan speed are automatically adjusted according to the temperature setting. Driver’s side temperature con- Simultaneous mode button trol dial Passenger’s side temperature control dial Automatic mode button Micro dust and pollen filter Cooling and dehumidification...
  • Page 259 5-1. Using the air conditioning system and defogger Using the automatic air conditioning system Press The dehumidification function begins to operate. Air outlets and fan speed are automatically adjusted according to the temperature setting and humidity. Turn clockwise to increases the temperature and turn counterclockwise to decreases the temperature.
  • Page 260 5-1. Using the air conditioning system and defogger Adjusting the settings manually To adjust the fan speed, press “∧” on to increase the fan speed and “∨” to decrease the fan speed. Press to turn the fan off. To adjust the temperature setting, turn clockwise to increases the temperature and turn counterclockwise to...
  • Page 261 5-1. Using the air conditioning system and defogger Defogging the windshield Press dehumidification function operates and fan speed increases. Set the outside/recirculated air mode button to outside air mode if the recirculated air mode is used. (It may switch automatically.) To defog the windshield and the side windows early, turn the air flow and temperature up.
  • Page 262 5-1. Using the air conditioning system and defogger Upper body and feet Feet Feet and windshield If the recirculated air mode is used, it will automatically switch to the outside air mode. RAV4_OM_OM42809U_(U)
  • Page 263 5-1. Using the air conditioning system and defogger Switching between outside air and recirculated air modes Press The mode switches between outside air mode (the indicator is off) and recirculated air mode (the indicator is on) each time is pressed. Micro dust and pollen filter mode button Operates micro dust and pollen fil- ter mode on/off.
  • Page 264 5-1. Using the air conditioning system and defogger Adjusting the position of and opening and closing the air outlets ■ Front center outlets Direct air flow to the left or right, up or down. Turn the knobs to open or close the vents.
  • Page 265 5-1. Using the air conditioning system and defogger ■ Operation of the air conditioning system in Eco drive mode In Eco drive mode, the air conditioning system is controlled as follows to pri- oritize fuel efficiency: ● Engine speed and compressor operation controlled to restrict heating/cool- ing capacity ●...
  • Page 266 5-1. Using the air conditioning system and defogger ■ When the outside temperature exceeds 75°F (24°C) and the air condition- ing system is on ● In order to reduce the air conditioning power consumption, the air condition- ing system may switch to recirculated air mode automatically. This may also reduce fuel consumption.
  • Page 267 5-1. Using the air conditioning system and defogger ■ Air conditioning odors ● During use, various odors from inside and outside the vehicle may enter into and accumulate in the air conditioning system. This may then cause odor to be emitted from the vents. ●...
  • Page 268: Rear Window And Outside Rear View Mirror Defoggers

    5-1. Using the air conditioning system and defogger Rear window and outside rear view mirror defoggers These features are used to defog the rear window, and to remove raindrops, dew and frost from the outside rear view mir- rors (if equipped). Vehicles with a manual air conditioning system On/off The defoggers will automatically...
  • Page 269 5-1. Using the air conditioning system and defogger ■ Operating conditions Vehicles without a smart key system The engine switch is in the “ON” position. Vehicles with a smart key system The engine switch is in IGNITION ON mode. ■ The outside rear view mirror defoggers (vehicles with outside rear view mirror defoggers) Turning the rear window defogger on will turn the outside rear view mirror...
  • Page 270: Windshield Wiper De-Icer

    5-1. Using the air conditioning system and defogger ∗ Windshield wiper de-icer This feature is used to prevent ice from building up on the wind- shield and wiper blades. On/off The windshield wiper de-icer will automatically turn off after approxi- mately 15 minutes.
  • Page 271: Audio System Types

    5-2. Using the audio system Audio system types Vehicles with a Display Audio system Refer to the “Display Audio System Owner’s Manual”. Display Audio system Premium Display Audio system RAV4_OM_OM42809U_(U)
  • Page 272 5-2. Using the audio system Vehicles without a Display Audio system CD player with AM/FM radio Title Page Using the radio P. 312 Using the CD player P. 315 Playing back MP3 and WMA discs P. 320 Operating an iPod P.
  • Page 273 5-2. Using the audio system ■ Using cellular phones Interference may be heard through the audio system’s speakers if a cellular phone is being used inside or close to the vehicle while the audio system is operating. CAUTION ■ Certification for the disc player ●...
  • Page 274 5-2. Using the audio system CAUTION FCC WARNING Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Radio Frequency Radiation Exposure: This equipment complies with FCC radiation exposure limits set forth for uncontrolled equipment and meets the FCC radio frequency (RF) Exposure Guidelines in Supplement C to OET65.
  • Page 275: Using The Radio

    5-2. Using the audio system ∗ Using the radio Power AM/FM mode button Volume Station selectors Adjusting the frequency Seeking the frequency Scanning for receivable sta- Displaying text message tions Setting station presets Search for the desired stations by turning the “TUNE•SCROLL” knob or pressing “∧”...
  • Page 276 5-2. Using the audio system Scanning radio stations ■ Scanning the preset radio stations Press and hold the “SCAN” button until you hear a beep. Preset stations will be played for 5 seconds each. To cancel, press the button again. When the desired station is reached, press the button again.
  • Page 277 5-2. Using the audio system ■ When the battery is disconnected Stations presets are erased. ■ Reception sensitivity ● Maintaining perfect radio reception at all times is difficult due to the continu- ally changing position of the antenna, differences in signal strength and sur- rounding objects, such as trains, transmitters, etc.
  • Page 278: Using The Cd Player

    5-2. Using the audio system ∗ Using the CD player Power Repeat play Volume Fast forwarding or rewinding CD eject Changing the audio source/ playback Selecting a track or displaying track list Playback/pause Searching playback Selecting a track Random play or back button Displaying text message Loading CDs Insert a CD.
  • Page 279 5-2. Using the audio system Selecting a track from a track list Press the “TUNE•SCROLL” knob. The track list will be displayed. Turn and press the knob to select a track. To return to the previous display, press (BACK). Scanning tracks Press the “SCAN”...
  • Page 280 “WAIT”: Operation has stopped due to a high temperature inside the player. Wait for a while and then press the “MEDIA” button. If the CD still cannot be played back, contact your Toyota dealer. ■ Discs that can be used Discs with the marks shown below can be used.
  • Page 281 5-2. Using the audio system NOTICE ■ CDs and adapters that cannot be used Do not use the following types of CDs or 3 in. (8 cm) CD adapters or Dual Disc. Doing so may damage the player and/or the CD insert/eject function. ●...
  • Page 282 5-2. Using the audio system NOTICE ● CDs with a transparent or translucent recording area ● CDs that have tape, stickers or CD-R labels attached to them, or that have had the label peeled off ■ CD Player precautions Failure to follow the precautions below may result in serious damage to the CDs or the player itself.
  • Page 283: Playing Back Mp3 And Wma Discs

    5-2. Using the audio system ∗ Playing back MP3 and WMA discs Power Repeat play Volume Fast forwarding, rewinding or selecting a folder CD eject Changing the audio source/ Selecting a file or displaying playback folder list Playback/pause Searching playback Previous commands Next commands, random play or back button...
  • Page 284 5-2. Using the audio system Selecting a folder ■ Selecting folders one at a time Press (<FOLDER) or (FOLDER>) to select the desired folder. Press (MORE>) to display the commands. ■ Selecting a folder and file from folder list Press the “TUNE•SCROLL” knob. The folder list will be displayed.
  • Page 285 5-2. Using the audio system Fast forwarding and rewinding files Press ) or Press (<BACK) to display the commands. Random play Pressing (RDM) changes modes in the following order: Folder random→Disc random→Off Press (MORE>) to display the command. Repeat play Pressing (RPT) changes modes in the following order: →Off...
  • Page 286 5-2. Using the audio system ■ Display →P. 317 ■ Error messages “ERROR”: This indicates a trouble either in the CD or inside the player. “CD CHECK”: The CD may be dirty, damaged or inserted up-side down. “NO SUPPORT”: This indicates that the MP3/WMA file is not included in the CD. ■...
  • Page 287 5-2. Using the audio system ■ MP3 and WMA files MP3 (MPEG Audio LAYER3) is a standard audio compression format. Files can be compressed to approximately 1/10 of their original size by using MP3 compression. WMA (Windows Media Audio) is a Microsoft audio compression format. This format compresses audio data to a size smaller than that of the MP3 for- mat.
  • Page 288 5-2. Using the audio system ● Compatible media Media that can be used for MP3 and WMA playback are CD-Rs and CD- RWs. Playback in some instances may not be possible, depending on the status of the CD-R or CD-RW. Playback may not be possible or the audio may jump if the disc is scratched or marked with fingerprints.
  • Page 289 5-2. Using the audio system ● MP3 and WMA playback When a disc containing MP3 or WMA files is inserted, all files on the disc are first checked. Once the file check is finished, the first MP3 or WMA file is played.
  • Page 290: Operating An Ipod

    5-2. Using the audio system ∗ Operating an iPod Connecting an iPod enables you to enjoy music from the vehicle speakers. ■ Connecting an iPod Open the cover and connect an iPod using an iPod cable. Turn on the power of the iPod if it is not turned on.
  • Page 291 5-2. Using the audio system ■ Control panel Power Fast-forwarding or rewinding Volume Changing the audio source/ playback Selecting an iPod menu/song or displaying song list Playback/pause Random play or back button iPod menu mode, playback Repeat play Selecting a song Displaying text message Selecting a play mode Press...
  • Page 292 5-2. Using the audio system ■ Play mode list First Second Third Fourth Play mode selection selection selection selection Playlists “Playlists” Songs select select Albums “Artists” Artists select Songs select select Albums “Albums” Songs select select “Songs” Songs select Podcasts Episodes “Podcasts”...
  • Page 293 5-2. Using the audio system Selecting songs ∧ Turn the “TUNE•SCROLL” knob or “ ” or “∨” on the “SEEK/TRACK” button to select the desired song. Selecting a song from the song list Press the “TUNE•SCROLL” knob. The song list will be displayed. Turn the knob to select a song.
  • Page 294 5-2. Using the audio system Playing and pausing tracks Press Switching the display Press the “TEXT” button to display or hide the album title. If there are following texts, is displayed. Press and hold the button to display the remaining texts. ■...
  • Page 295 5-2. Using the audio system ■ iPod functions ● When an iPod is connected and the audio source is changed to iPod mode, the iPod will resume play from the same point in which it was last used. ● Depending on the iPod that is connected to the system, certain functions may not be available.
  • Page 296 5-2. Using the audio system ■ Compatible models ® ® ® ® ® The following iPod , iPod nano , iPod classic , iPod touch and iPhone devices can be used with this system. ● Made for • iPod touch (4th generation) •...
  • Page 297 5-2. Using the audio system CAUTION ■ While driving Do not connect iPod or operate the controls. Doing so may cause an acci- dent, resulting in death or serious injury. NOTICE ■ To prevent damage to iPod ● Do not leave iPod in the vehicle. The temperature inside the vehicle may become high, resulting in damage to the iPod.
  • Page 298: Operating A Usb Memory

    5-2. Using the audio system ∗ Operating a USB memory Connecting a USB memory enables you to enjoy music from the vehicle speakers. ■ Connecting a USB memory Open the cover and connect a USB memory. Turn on the power of the USB memory if it is not turned on.
  • Page 299 5-2. Using the audio system ■ Control panel Power Fast forwarding, rewinding or selecting a folder Volume Changing the audio source/ Selecting a file or displaying playback folder list Playback/pause Searching playback Previous commands Next commands, random play or back button Selecting a file Repeat play Displaying text message...
  • Page 300 5-2. Using the audio system Selecting a folder ■ Selecting folders one at a time Press (<FOLDER) or (FOLDER>) to select the desired folder. Press (MORE>) to display the commands. ■ Selecting a folder and file from folder list Press the “TUNE•SCROLL” knob. The folder list will be displayed.
  • Page 301 5-2. Using the audio system Random play Pressing (RDM) changes modes in the following order: Folder random→All folder random→Off Press (MORE>) to display the command. Repeat play Pressing (RPT) changes modes in the following order: →Off File repeat→Folder repeat : Available except when RDM (random play) is selected Press (MORE>) to display the command.
  • Page 302 5-2. Using the audio system ■ USB memory functions ● Depending on the USB memory that is connected to the system, the device itself may not be operable and certain functions may not be available. If the device is inoperable or a function is unavailable due to a malfunction (as opposed to a system specification), disconnecting the device and recon- necting it once again may resolve the problem.
  • Page 303 5-2. Using the audio system ● MP3 and WMA files MP3 (MPEG Audio LAYER3) is a standard audio compression format. Files can be compressed to approximately 1/10 of their original size by using MP3 compression. WMA (Windows Media Audio) is a Microsoft audio compression format. This format compresses audio data to a size smaller than that of the MP3 format.
  • Page 304 5-2. Using the audio system ● File names The only files that can be recognized as MP3/WMA and played are those with the extension .mp3 or .wma. ● ID3 and WMA tags ID3 tags can be added to MP3 files, making it possible to record the track title, artist name, etc.
  • Page 305 5-2. Using the audio system ● Playback • To play MP3 files with steady sound quality, we recommend a fixed bit rate of at least 128 kbps and a sampling frequency of 44.1 kHz. • There is a wide variety of freeware and other encoding software for MP3 and WMA files on the market, and depending on the status of the encod- ing and the file format, poor sound quality or noise at the start of playback may result.
  • Page 306: Optimal Use Of The Audio System

    5-2. Using the audio system ∗ Optimal use of the audio system Displays the current mode Changes the following settings • Sound quality and volume balance →P. 344 The sound quality and balance setting can be changed to pro- duce the best sound. •...
  • Page 307 5-2. Using the audio system Using the audio control function ■ Changing sound quality modes Press the “SETUP” button. Turn the “TUNE•SCROLL” knob to select “Sound Setting”. Press the knob. Turn the knob as corresponds to the desired mode. “BASS”, “TREBLE”, “FADER”, “BALANCE”, or “ASL” can be selected. Press the knob.
  • Page 308: Using The Aux Port

    5-2. Using the audio system ∗ Using the AUX port This port can be used to connect a portable audio device and lis- ten to it using the vehicle’s speakers. Open the cover and connect the portable audio device. Press the “MEDIA” button repeatedly until “AUX” is displayed. Silencing a sound Press (MUTE).
  • Page 309: Using The Steering Wheel Audio Switches

    5-2. Using the audio system ∗ Using the steering wheel audio switches Some audio features can be controlled using the switches on the steering wheel. Operation may differ depending on the type of audio system or navigation system. For details, refer to the manual provided with the audio system or navigation system.
  • Page 310 5-2. Using the audio system Turning on the power Press the “MODE” switch when the audio system is turned off. Changing the audio source Press the “MODE” switch when the audio system is turned on. The audio source changes as follows each time the button is pressed. If a mode cannot be used, it will be skipped.
  • Page 311 5-2. Using the audio system Selecting a track/file or song ® Press the “MODE” switch to select the CD, Bluetooth audio, iPod or USB memory mode. Press the “∧” or “∨” switch to select the desired track/file or song. Selecting an album ®...
  • Page 312: Bluetooth ® Audio/Phone

    5-2. Using the audio system ∗ ® Bluetooth audio/phone ® ■ Bluetooth audio ® The Bluetooth audio system enables you to enjoy music played on a portable digital audio player (portable player) from the vehicle speakers via wireless communication. ® This audio system supports Bluetooth , a wireless data system capable of playing portable audio music without cables.
  • Page 313 5-2. Using the audio system ■ When transferring ownership of the vehicle Be sure to initialize the system to prevent personal data from being improp- erly accessed. (→P. 371) ■ ® About Bluetooth Bluetooth is a registered trademark of Bluetooth SIG, Inc. ■...
  • Page 314 5-2. Using the audio system ■ Certification FCC ID: BABFT0023A IC: 2024B-FT0023A For vehicles sold in the U.S.A. and Puerto Rico This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 315 5-2. Using the audio system CAUTION ■ FCC WARNING Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Radio Frequency Radiation Exposure: This equipment complies with FCC radiation exposure limits set forth for uncontrolled equipment and meets the FCC radio frequency (RF) Exposure Guidelines in Supplement C to OET65.
  • Page 316 5-2. Using the audio system CAUTION ■ While driving ® Do not use the portable audio player or connect the Bluetooth system. ■ Caution regarding interference with electronic devices ® ● Your audio unit is fitted with Bluetooth antennas. People with implanted pacemakers or cardiac defibrillators should maintain a reasonable dis- ®...
  • Page 317: Using The Bluetooth ® Audio/Phone

    5-2. Using the audio system ® ∗ Using the Bluetooth audio/phone ■ Audio unit ® Bluetooth connection condi- tion If “BT” is not displayed, the ® Bluetooth audio/phone cannot be used. Displays set up menu Selects items such as menu and number Turn: Selects an item Press: Inputs the selected item...
  • Page 318 5-2. Using the audio system ® ■ Steering wheel switches (Bluetooth audio) →P. 346 ® ■ Steering wheel switches (Bluetooth phone) Volume The voice guidance volume cannot be adjusted using this button. Off-hook switch Turns the hands-free system on/start a call On-hook switch Turns the hands-free system off/ends a call/refuse a call...
  • Page 319 5-2. Using the audio system ® Using the Bluetooth audio/phone for the first time ® Before using the Bluetooth audio/phone, it is necessary to register a ® Bluetooth device in the system. Follow the procedure below to regis- ter (pair) a device: Press the “SETUP”...
  • Page 320 5-2. Using the audio system ® Menu list of the Bluetooth audio/phone First menu Second menu Third menu Operation details Registering “BT pairing” ® Bluetooth device Listing the registered “List phone” cellular phones Listing the registered “List audio” portable players Changing the pass- “Passkey”...
  • Page 321 5-2. Using the audio system First menu Second menu Third menu Operation details Adding a new num- “Add contacts” Registering a speed “Add SD” dial Deleting a number “Delete call stored in the call his- “Phonebook” history” tory Deleting a number “Delete contacts”...
  • Page 322 5-2. Using the audio system ® Operating a Bluetooth enabled portable ∗ player Power Changing the audio source/ playback Volume Playback/pause Search playback Previous commands Next commands, random play or back button Selecting a track Repeat play Displaying text message Fast forwarding, rewinding or selecting an album ∗...
  • Page 323 5-2. Using the audio system Selecting an album Press (<FOLDER) or (FOLDER>) to select desired album. Press (MORE>) to display the commands. Scanning an album Press and hold the “SCAN” button until you hear a beep. The first 10 seconds of the first track in each album will be played. To cancel, press the button again.
  • Page 324 5-2. Using the audio system Playing and pausing tracks Press Press (<BACK) to display the command. Switching the display Press the “TEXT” button to display or hide the album title. If there are following texts, is displayed. Press and hold the button to display the remaining texts. ■...
  • Page 325: Making A Phone Call

    5-2. Using the audio system ∗ Making a phone call To enter the “PHONE” mode, press the off-hook switch. ■ Making a phone call ● Dialing by inputting a name ● Speed dialing ● Dialing by entering the number ● Dialing from call histories ■...
  • Page 326 5-2. Using the audio system Dialing by selecting a name Select “Phonebook” using the “TUNE•SCROLL” knob. Select the desired name using the knob and press the off-hook switch. By pressing (Add S. Dial) and one of the speed dial buttons (from [1] to [5]) while the desired name is selected, it can be regis- tered as a speed dial.
  • Page 327 5-2. Using the audio system Dialing by entering the number Select “Dial by number” using the “TUNE•SCROLL” knob. Enter the phone number and press the off-hook switch. Dialing from call histories Select “All calls”, “Missed calls”, “Incoming calls” or “Outgoing calls” using the “TUNE•SCROLL”...
  • Page 328 5-2. Using the audio system When receiving a phone call ■ Answering the phone Press the off-hook switch. ■ Refusing the call Press the on-hook switch. ■ Receiving a call when on another call Press the off-hook switch. Pressing the off-hook switch again returns you to the previous call. Operations during a call ●...
  • Page 329 5-2. Using the audio system Adjusting the ring tone volume when receiving a call To decrease the volume: Turn the “PWR•VOL” knob counterclock- wise. To increase the volume: Turn the “PWR•VOL” knob clockwise. ■ When talking on the phone ● Do not talk simultaneously with the other party.
  • Page 330: Using The "Setup" Menu ("Bluetooth*" Menu)

    5-2. Using the audio system Using the “SETUP” menu (“Bluetooth*” ∗ menu) ® Registering a Bluetooth device in the system allows the system to function. The following functions can be used for registered devices: ■ Functions and operation procedures Press the “SETUP” button and select “Bluetooth ”...
  • Page 331 5-2. Using the audio system ® Registering a Bluetooth device Select “BT pairing” using the “TUNE•SCROLL” knob and press (Add New). ® ● If a Bluetooth device is not connected currently ® Perform the procedure for registering a Bluetooth device from step .
  • Page 332 5-2. Using the audio system Listing the registered portable players Select “List audio” using the “TUNE•SCROLL” knob. The list of regis- tered portable players will be displayed. ● Connecting the registered portable player to the audio system Select the name of the portable player to be connected using the “TUNE•SCROLL”...
  • Page 333 5-2. Using the audio system Changing the passkey Select “Passkey” using the “TUNE•SCROLL” knob. Select a 4 to 8-digit passkey using the knob. Input the number 1 digit at a time. When the entire number to be registered as a passkey has been input, press (ENTER).
  • Page 334 5-2. Using the audio system Setting the automatic connection confirmation display to on or If the “Display setting” is set to on, the portable player connection sta- tus will be displayed when the engine switch is turned to the “ACC” or “ON”...
  • Page 335 5-2. Using the audio system ∗ Using the “SETUP” menu (“PHONE” menu) ■ Functions and operation procedures To enter the menu for each function, press the “SETUP” button and follow the steps below using the “TUNE•SCROLL” knob: ● Adding a new phone number 1.
  • Page 336 5-2. Using the audio system Adding a new phone number Select “Add contacts” using the “TUNE•SCROLL” knob. ● Transferring all contacts from the cellular phone Select “Overwrite all” using the “TUNE•SCROLL” knob and press (YES). ● Transferring one contact from the cellular phone Select “Add one contact”...
  • Page 337 5-2. Using the audio system Deleting call histories Select “Delete call history” using the “TUNE•SCROLL” knob. ● Deleting outgoing call history Select “Outgoing calls” using the “TUNE•SCROLL” knob. Select the desired phone number using the knob and press (YES). To delete all outgoing call history data, press (ALL) and then press (YES).
  • Page 338 5-2. Using the audio system Deleting a registered phone number Select “Delete contacts” using the “TUNE•SCROLL” knob. Select the desired phone number using the knob and press (YES). To delete all the registered phone numbers, press (ALL) and then press (YES).
  • Page 339 5-2. Using the audio system Setting ring tone Select “Ringtone” using the “TUNE•SCROLL” knob. Using the knob, select a ring tone (1 - 3). To set the selected ring tone, press (SAVE). Transferring call histories Select “Transfer histories” using the “TUNE•SCROLL” knob and press (YES).
  • Page 340: Interior Lights List

    5-3. Using the interior lights Interior lights list Interior lights (→P. 378) Engine switch light equipped) Interior/personal lights (→P. 378) Cup holder light (if equipped) RAV4_OM_OM42809U_(U)
  • Page 341 5-3. Using the interior lights Interior lights ■ Front Door position The personal lights and interior light come on when a door is opened. They go off when the doors are closed. ■ Rear Door position The interior lights come on when a door is opened.
  • Page 342 5-3. Using the interior lights ■ Illuminated entry system Vehicles without a smart key system The lights automatically turn on/off according to the engine switch position, whether the doors are locked/unlocked, and whether the doors are open/ closed. Vehicles with a smart key system The lights automatically turn on/off according to engine switch mode, the presence of the electronic key, whether the doors are locked/unlocked, and whether the doors are opened/closed.
  • Page 343: List Of Storage Features

    5-4. Using the storage features List of storage features Glove box (→P. 381) Console box (→P. 382) Bottle holders (→P. 384) Cup holders (→P. 383) Storage boxes (→P. 386) RAV4_OM_OM42809U_(U)
  • Page 344 5-4. Using the storage features CAUTION ■ Items that should not be left in the storage spaces Do not leave glasses, lighters or spray cans in the storage spaces, as this may cause the following when cabin temperature becomes high: ●...
  • Page 345 5-4. Using the storage features Console box Lift the lid while pulling up the lever to release the lock. ■ When using the console box lid as an armrest (vehicles with slide func- tion) Slide the console box lid forward as needed.
  • Page 346 5-4. Using the storage features Cup holders ■ Front ■ Rear Pull the armrest down. ■ Adjusting the size of the cup holder (front passenger’s side) The adjuster can be removed. CAUTION ■ Items unsuitable for the cup holders Do not place anything other than cups or aluminum cans in the cup holders. Other items may be thrown out of the holders in the event of an accident or sudden braking, causing injury.
  • Page 347 5-4. Using the storage features Bottle holders ■ Front ■ Rear CAUTION ■ Items unsuitable for the bottle holder Do not place anything other than a bottle in the bottle holders. Other items may be thrown out of the holders in the event of an accident or sudden braking and cause injury.
  • Page 348: Luggage Compartment Features

    5-4. Using the storage features Luggage compartment features Cargo hooks Raise the hooks to use. The cargo hooks are provided for securing loose items. CAUTION ■ When the cargo hooks are not in use To avoid injury, always return the cargo hooks to their stowed positions. Grocery bag hooks NOTICE ■...
  • Page 349 5-4. Using the storage features Storage boxes ■ Front Open the deck board by pulling up the strap. ■ Rear Type A Open the deck board by pull- ing up the strap. Fold up the deck board. The lid can be removed. RAV4_OM_OM42809U_(U)
  • Page 350 5-4. Using the storage features Type B Open the deck board by pulling up the strap. CAUTION ■ Caution while driving Do not drive with any of the deck boards opened. Items may fall out and cause injury. RAV4_OM_OM42809U_(U)
  • Page 351 5-4. Using the storage features Luggage cover (if equipped) ■ Installing the luggage cover With the “TOP” marks up, insert the right end of the lug- gage cover into the recess, then compress the left of the luggage cover and insert it into the recess.
  • Page 352 5-4. Using the storage features ■ Stowing the luggage cover Open the rear deck board and remove the deck side covers. Insert the right end of the lug- gage cover into the recess, then compress the left end of the luggage cover and insert it into the recess.
  • Page 353 5-4. Using the storage features CAUTION ■ When installing/stowing the luggage cover Make sure that the luggage cover is securely installed/stowed. Failure to do so may result in serious injury in the event of sudden braking or a collision. ■ Caution for the luggage cover ●...
  • Page 354 5-4. Using the storage features Rear cargo net (if equipped) Position of the rear cargo net can be changed. Position A (except for full-size spare tire) Insert the right end of the rear cargo net into the recess, then compress the left end of the rear cargo net and insert it into the recess.
  • Page 355 5-4. Using the storage features Position B Insert the right end of the rear cargo net into the recess, then compress the left end of the rear cargo net and insert it into the recess. RAV4_OM_OM42809U_(U)
  • Page 356 5-4. Using the storage features ■ Stowing the rear cargo net (vehicles with the rear cargo net holders) Open the rear deck board and remove the deck side covers. Insert the right end of the rear cargo into recess, then compress the left end of the rear cargo net and insert it into the recess.
  • Page 357 5-4. Using the storage features CAUTION ■ When installing/stowing the rear cargo net Make sure that the rear cargo net is securely installed/stowed. Failure to do so may result in serious injury in the event of sudden braking or a collision. ■...
  • Page 358: Sun Visors And Vanity Mirrors

    5-5. Other interior features Sun visors and vanity mirrors Sun visors Forward position: Flip down. Side position: Flip down, unhook, and swing to the side. Side extender (if equipped): Place in side position then slide backwards. Vanity mirrors Slide the cover to open. The light turns on when the cover is opened.
  • Page 359 5-5. Other interior features Clock The clock can be adjusted by pressing the buttons. Adjusts the hours. Adjusts the minutes. ■ The clock is displayed when Vehicles without a smart key system The engine switch is in the “ACC” or “ON” position. Vehicles with a smart key system The engine switch is in ACCESSORY or IGNITION ON mode.
  • Page 360: Power Outlets

    5-5. Other interior features Power outlets The power outlet can be used for 12 V accessories that run on less than 10 A. Open the lid. ■ The power outlets can be used when Vehicles without a smart key system The engine switch is in the “ACC”...
  • Page 361: Seat Heaters

    5-5. Other interior features ∗ Seat heaters Turns on the front left seat heater (high) Turns on the front left seat heater (low) Turns on the front right seat heater (high) Turns on the front right seat heater (low) The indicator light comes on. ■...
  • Page 362 5-5. Other interior features CAUTION ■ Burns ● Use caution when seating the following persons in a seat with the seat heater on to avoid the possibility of burns: • Babies, small children, the elderly, the sick and the physically chal- lenged •...
  • Page 363 5-5. Other interior features Armrest ■ Front (vehicles with slide function) Slide the console box lid for- ward or backward as needed. Pull the lid forward by holding the front of the lid. ■ Rear Fold down the armrest for use. NOTICE ■...
  • Page 364: Coat Hooks

    5-5. Other interior features Coat hooks The coat hooks are provided with the rear assist grips. CAUTION ■ Items that cannot be hung on the coat hook Do not hang coat hangers or other hard or sharp objects on the hook. If the SRS curtain shield airbags deploy, these items may become projectiles, causing death or serious injury.
  • Page 365: Assist Grips

    5-5. Other interior features Assist grips An assist grip installed on the ceil- ing can be used to support your body while sitting on the seat. CAUTION ■ Assist grip Do not use the assist grip when getting in or out of the vehicle or rising from your seat.
  • Page 366: Cleaning And Protecting The Vehicle Exterior

    6-1. Maintenance and care Cleaning and protecting the vehicle exte- rior Perform the following to protect the vehicle and maintain it in prime condition: ● Working from top to bottom, liberally apply water to the vehicle body, wheel wells and underside of the vehicle to remove any dirt and dust.
  • Page 367 6-1. Maintenance and care ■ Automatic car washes ● Before washing the vehicle: • Fold the mirrors • Remove the antenna • Turn off the power back door (if equipped) Start washing from the front of the vehicle. Make sure to re-install the antenna and extend the mirrors before driving.
  • Page 368 ■ Precautions regarding the Blind Spot Monitor (if equipped) If the paint of the rear bumper is chipped or scratched, the system may mal- function. If this occurs, consult your Toyota dealer. RAV4_OM_OM42809U_(U)
  • Page 369 6-1. Maintenance and care NOTICE ■ To prevent paint deterioration and corrosion on the body and compo- nents (aluminum wheels etc.) ● Wash the vehicle immediately in the following cases: • After driving near the sea coast • After driving on salted roads •...
  • Page 370: Cleaning And Protecting The Vehicle Interior

    6-1. Maintenance and care Cleaning and protecting the vehicle interior The following procedures will help protect your vehicle’s interior and keep it in top condition: Protecting the vehicle interior Remove dirt and dust using a vacuum cleaner. Wipe dirty surfaces with a cloth dampened with lukewarm water.
  • Page 371 6-1. Maintenance and care ■ Caring for leather areas Toyota recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle’s interior. ■ Shampooing the carpets There are several commercial foaming-type cleaners available. Use a sponge or brush to apply the foam.
  • Page 372 6-1. Maintenance and care NOTICE ■ Cleaning detergents ● Do not use the following types of detergent, as they may discolor the vehi- cle interior or cause streaks or damage to painted surfaces: • Non-seat portions: Organic substances such as benzene or gasoline, alkaline or acidic solutions, dye, and bleach •...
  • Page 373 6-1. Maintenance and care NOTICE ■ When cleaning the inside of the windshield (vehicles with LDA [Lane Departure Alert] and Automatic High Beam) Be careful not to touch the camera sensor (→P. 227, 245). If the camera is accidentally scratched or hit, LDA and Automatic High Beam may not operate properly or may cause a malfunction.
  • Page 374: Maintenance Requirements

    Toyota recommends performing the fol- lowing maintenance: General maintenance General maintenance should be performed on a daily basis. This can be done by yourself or by a Toyota dealer. Scheduled maintenance Scheduled maintenance should be performed at specified intervals according to the maintenance schedule.
  • Page 375 ■ Repair and replacement It is recommended that genuine Toyota parts be used for repairs to ensure performance of each system. If non-Toyota parts are used in replacement or if a repair shop other than a Toyota dealer performs repairs, confirm the war- ranty coverage.
  • Page 376 6-2. Maintenance CAUTION ■ If your vehicle is not properly maintained Improper maintenance could result in serious damage to the vehicle and possible death or serious injury. ■ Handling of the battery ● Engine exhaust, some of its constituents, and a wide variety of automobile components contain or emit chemicals known to the State of California to cause cancer and birth defects and other reproductive harm.
  • Page 377: General Maintenance

    “Owner’s Warranty Information Booklet” or “Owner’s Manual Supplement/Sched- uled Maintenance Guide”. It is recommended that any problem you notice should be brought to the attention of your Toyota dealer or qualified service shop for advice. Engine compartment...
  • Page 378 6-2. Maintenance Vehicle interior Items Check points • The accelerator pedal should Accelerator pedal move smoothly (without uneven pedal effort or catching). • When parked on a slope and the Automatic transmission “Park” shift lever is in P, is the vehicle mechanism securely stopped? •...
  • Page 379 6-2. Maintenance Items Check points • Do the head restraints move Head restraints smoothly and lock securely? • Do the indicators and buzzers Indicators/buzzers function properly? Lights • Do all the lights come on? • Does the parking brake lever move smoothly? Parking brake •...
  • Page 380 6-2. Maintenance Vehicle exterior Items Check points Doors • Do the doors operate smoothly? • Does the engine hood lock system Engine hood work properly? • There should not be any signs of Fluid leaks fluid leakage after the vehicle has been parked.
  • Page 381: Emission Inspection And Maintenance (I/M) Programs

    The OBD system determines that a problem exists somewhere in the emission control system. Your vehicle may not pass the I/M test and may need to be repaired. Contact your Toyota dealer to service the vehicle. Your vehicle may not pass the I/M test in the following situations: ●...
  • Page 382: Do-It-Yourself Service Precautions

    6-3. Do-it-yourself maintenance Do-it-yourself service precautions If you perform maintenance by yourself, be sure to follow the correct procedure as given in these sections. Items Parts and tools • Warm water • Baking soda Battery condition (→P. 438) • Grease •...
  • Page 383 6-3. Do-it-yourself maintenance Items Parts and tools • “Toyota Super Long Life Coolant” or a similar high quality ethylene glycol-based non-silicate, non- amine, non-nitrite and non-borate coolant with long-life hybrid organic acid technology For the U.S.A.: “Toyota Super Long Life Coolant”...
  • Page 384 6-3. Do-it-yourself maintenance Items Parts and tools • Fuse with same amperage rating Fuses (→P. 465) as original • Bulb with same number and watt- age rating as original Light bulbs (→P. 476) • Phillips-head screwdriver • Flathead screwdriver • Wrench ⎯...
  • Page 385 6-3. Do-it-yourself maintenance CAUTION The engine compartment contains many mechanisms and fluids that may move suddenly, become hot, or become electrically energized. To avoid death or serious injury, observe the following precautions. ■ When working on the engine compartment ● Keep hands, clothing and tools away from the moving fan and engine drive belt.
  • Page 386 6-3. Do-it-yourself maintenance CAUTION ■ When working near the electric cooling fans or radiator grille Vehicles without a smart key system Be sure the engine switch is off. With the engine switch in the “ON” position, the electric cooling fans may automatically start to run if the air conditioning is on and/or the coolant temperature is high.
  • Page 387 6-3. Do-it-yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Pull the hood lock release lever. The hood will pop up slightly. Push the auxiliary catch lever to the left and lift the hood. Hold the hood open by inserting the supporting rod into the slot.
  • Page 388 6-3. Do-it-yourself maintenance CAUTION ■ Pre-driving check Check that the hood is fully closed and locked. If the hood is not locked properly, it may open while the vehicle is in motion and cause an accident, which may result in death or serious injury. ■...
  • Page 389: Positioning A Floor Jack

    6-3. Do-it-yourself maintenance Positioning a floor jack When raising your vehicle with a floor jack, position the jack cor- rectly. Improper placement may damage your vehicle or cause injury. ◆ Front ◆ Rear RAV4_OM_OM42809U_(U)
  • Page 390 6-3. Do-it-yourself maintenance CAUTION ■ When raising your vehicle Make sure to observe the following precautions to reduce the possibility of death or serious injury: ● Lift up the vehicle using a floor jack such as the one shown in the illustra- tion.
  • Page 391: Engine Compartment

    6-3. Do-it-yourself maintenance Engine compartment Engine coolant reservoir Radiator (→P. 436) (→P. 434) Condenser (→P. 436) Engine oil filler cap (→P. 432) Electric cooling fans Battery (→P. 438) Engine oil level dipstick Brake fluid reservoir (→P. 430) (→P. 436) Washer fluid tank (→P. 442) Fuse box (→P.
  • Page 392 6-3. Do-it-yourself maintenance Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick. ■ Checking the engine oil Park the vehicle on level ground. After warming up the engine and turning it off, wait more than 5 minutes for the oil to drain back into the bottom of the engine.
  • Page 393 6-3. Do-it-yourself maintenance Holding a rag under the end, pull the dipstick out and check the oil level. Normal Excessive Flat dipstick Non-flat dipstick The shape of the dipstick may differ depending on the type of vehicle or engine. Wipe the dipstick and reinsert it fully. RAV4_OM_OM42809U_(U)
  • Page 394 6-3. Do-it-yourself maintenance ■ Adding engine oil If the oil level is below or near the low level mark, add engine oil of the same type as that already in the engine. Make sure to check the oil type and prepare the items needed before adding oil.
  • Page 395 Dispose of used oil and filters only in a safe and acceptable manner. Do not dispose of used oil and filters in household trash, in sewers or onto the ground. Call your Toyota dealer, service station or auto parts store for information concerning recycling or disposal. ●...
  • Page 396 If the coolant level drops within a short time of replenishing Visually check the radiator, hoses, engine coolant reservoir cap, drain cock and water pump. If you cannot find a leak, have your Toyota dealer test the cap and check for leaks in the cooling system. RAV4_OM_OM42809U_(U)
  • Page 397 6-3. Do-it-yourself maintenance CAUTION ■ When the engine is hot Do not remove the engine coolant reservoir cap. The cooling system may be under pressure and may spray hot coolant if the cap is removed, causing serious injuries, such as burns. NOTICE ■...
  • Page 398 Radiator and condenser Check the radiator and condenser and clear away any foreign objects. If either of the above parts is extremely dirty or you are not sure of their condition, have your vehicle inspected by your Toyota dealer. CAUTION ■...
  • Page 399 6-3. Do-it-yourself maintenance ■ Brake fluid can absorb moisture from the air Excess moisture in the brake fluid can cause a dangerous loss of braking effi- ciency. Use only newly opened brake fluid. CAUTION ■ When filling the reservoir Take care as brake fluid can harm your hands and eyes and damage painted surfaces.
  • Page 400 6-3. Do-it-yourself maintenance Battery Check the battery as follows: ■ Battery exterior Make sure that the battery terminals are not corroded and that there are no loose connections, cracks, or loose clamps. Terminals Hold-down clamp ■ Before recharging When recharging, the battery produces hydrogen gas which is flammable and explosive.
  • Page 401 Make sure to turn off the engine before disconnect the battery. Take extra care when connecting the battery if the engine switch mode prior to discharge is unknown. If the engine will not start even after multiple attempts, contact your Toyota dealer. RAV4_OM_OM42809U_(U)
  • Page 402 6-3. Do-it-yourself maintenance CAUTION ■ Chemicals in the battery A battery contains poisonous and corrosive sulfuric acid and may produce hydrogen gas which is flammable and explosive. To reduce the risk of death or serious injury, take the following precautions while working on or near the battery: ●...
  • Page 403 6-3. Do-it-yourself maintenance CAUTION ■ Emergency measures regarding electrolyte ● If electrolyte gets in your eyes Flush your eyes with clean water for at least 15 minutes and get immedi- ate medical attention. If possible, continue to apply water with a sponge or cloth while traveling to the nearest medical facility.
  • Page 404 6-3. Do-it-yourself maintenance Washer fluid If any washer does not work or the low washer fluid warning light comes on, the washer tank may be empty. Add washer fluid. CAUTION ■ When adding washer fluid Do not add washer fluid when the engine is hot or running as washer fluid contains alcohol and may catch fire if spilled on the engine etc.
  • Page 405 6-3. Do-it-yourself maintenance Tires Replace or rotate tires in accordance with maintenance sched- ules and treadwear. Checking tires New tread Treadwear indicator Worn tread The location of treadwear indica- tors is shown by the “TWI” or “∆” marks, etc., molded on the sidewall of each tire.
  • Page 406 Front Front Do not fail to initialize the tire pressure warning system after tire rotation. To equalize tire wear and extend tire life, Toyota recommends that tire rota- tion is carried out at the same interval as tire inspection. RAV4_OM_OM42809U_(U)
  • Page 407 ID codes must be registered in the tire pressure warning computer and the tire pressure warning system must be initialized. Have tire pressure warning valve and transmitter ID codes registered by your Toyota dealer. (→P. 447) ◆ Initializing the tire pressure warning system ■...
  • Page 408 6-3. Do-it-yourself maintenance ■ How to initialize the tire pressure warning system Park the vehicle in a safe place and turn the engine switch to the “LOCK” position (vehicles without a smart key system) or off (vehicles with a smart key system). Initialization cannot be performed while the vehicle is moving.
  • Page 409 A tire goes flat repeatedly or cannot be properly repaired due to the size or location of a cut or other damage If you are not sure, consult with your Toyota dealer. ■ Replacing tires and wheels (vehicles with the tire pressure warning sys-...
  • Page 410 6-3. Do-it-yourself maintenance ■ Maximum load of tire Check that the number given by dividing the maximum load by 1.10 of the replacement tire is greater than 1/2 of the Gross Axle Weight Ratings (GAWR) of either the front axle or the rear axle, whichever is greater. For the GAWR, see the Certification Label.
  • Page 411 ● In the following cases, the tire pressure warning system may not operate properly. • If non-genuine Toyota wheels are used. • A tire has been replaced with a tire that is not an OE (Original Equipment) tire. • A tire has been replaced with a tire that is not of the specified size.
  • Page 412 If repeated attempts to record tire inflation pressure settings are unsuccessful, have the vehicle inspected by your Toyota dealer. ● When operating the tire pressure warning reset switch, the tire pressure warning light does not blink 3 times.
  • Page 413 6-3. Do-it-yourself maintenance ■ Tire pressure warning system certification TRW Automotive Tire Pressure Monitoring Sensor FCC ID: GQ4-51T NOTE: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
  • Page 414 Do not mix tires of different makes, models or tread patterns. Also, do not mix tires of remarkably different treadwear. ● Do not use tire sizes other than those recommended by Toyota. ● Do not mix differently constructed tires (radial, bias-belted or bias-ply tires).
  • Page 415 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact your Toyota dealer or other qualified service shop as soon as possible. Make sure to replace the tire pressure warning valve and transmitter when replacing the tire.
  • Page 416: Tire Inflation Pressure

    6-3. Do-it-yourself maintenance Tire inflation pressure Tire inflation pressure The recommended cold tire infla- tion pressure and tire size are dis- played on the tire and loading information label. (→P. 561) RAV4_OM_OM42809U_(U)
  • Page 417 Driving with incorrect tire inflation pressure may result in the following: ● Reduced fuel efficiency ● Reduced driving comfort and tire life ● Reduced safety ● Damage to the drive train If a tire needs frequent inflating, have it checked by your Toyota dealer. RAV4_OM_OM42809U_(U)
  • Page 418 6-3. Do-it-yourself maintenance ■ Instructions for checking tire inflation pressure When checking tire inflation pressure, observe the following: ● Check only when the tires are cold. If your vehicle has been parked for at least 3 hours or has not been driven for more than 1 mile or 1.5 km, you will get an accurate cold tire inflation pressure reading.
  • Page 419 ● Used wheels ● Bent wheels that have been straightened Aluminum wheel precautions ● Use only Toyota wheel nuts and wrenches designed for use with your aluminum wheels. ● When rotating, repairing or changing your tires, check that the wheel nuts are still tight after driving 1000 miles (1600 km).
  • Page 420 6-3. Do-it-yourself maintenance ■ When replacing wheels (vehicles with the tire pressure warning sys- tem) The wheels of your vehicle are equipped with tire pressure warning valves and transmitters that allow the tire pressure warning system to provide advance warning in the event of a loss in tire inflation pressure. Whenever wheels are replaced, tire pressure warning valves and trans- mitters must be installed.
  • Page 421 Because tire repair or replacement may affect the tire pressure warn- ing valves and transmitters, make sure to have tires serviced by your Toyota dealer or other qualified service shop. In addition, make sure to purchase your tire pressure warning valves and transmitters at your Toyota dealer.
  • Page 422: Air Conditioning Filter

    6-3. Do-it-yourself maintenance Air conditioning filter The air conditioning filter must be changed regularly to maintain air conditioning efficiency. Removal method Vehicles without a smart key system: Turn the engine switch to the “LOCK” position. Vehicles with a smart key system: Turn the engine switch off. Open the glove box.
  • Page 423 6-3. Do-it-yourself maintenance Remove the air conditioning fil- ter and replace it with a new one. The “↑UP” marks shown on the fil- ter should be pointing up. ■ Checking interval Inspect and replace the air conditioning filter according to the maintenance schedule.
  • Page 424: Wireless Remote Control/Electronic Key Battery

    6-3. Do-it-yourself maintenance Wireless remote control/electronic key battery Replace the battery with a new one if it is depleted. You will need the following items: ● Flathead screwdriver ● Small flathead screwdriver ● Lithium battery CR2016 (vehicles without a smart key system), or CR2032 (vehicles with a smart key system) Replacing the battery Vehicles without a smart key system...
  • Page 425 6-3. Do-it-yourself maintenance Open the case cover using a coin protected with tape etc. and remove the depleted bat- tery. Insert a new battery with the “+” terminal facing up. Vehicles with a smart key system Take out the mechanical key. Remove the cover.
  • Page 426 Use a CR2016 (vehicles without a smart key system), or CR2032 (vehi- cles with a smart key system) lithium battery ● Batteries can be purchased at your Toyota dealer, local electrical appliance shops or camera stores. ● Replace only with the same or equivalent type recommended by the manu- facturer.
  • Page 427: Checking And Replacing Fuses

    6-3. Do-it-yourself maintenance Checking and replacing fuses If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as nec- essary. Vehicles without a smart key system: Turn the engine switch to the “LOCK” position. Vehicles with a smart key system: Turn the engine switch off.
  • Page 428 6-3. Do-it-yourself maintenance Behind the instrument panel Remove the instrument panel. Remove the fuse with the pull- out tool. Only type A fuse can be removed using the pullout tool. RAV4_OM_OM42809U_(U)
  • Page 429 Type A and B: Replace the blown fuse with a new fuse of an appropriate amperage rat- ing. The amperage rating can be found on the fuse box lid. Type C and D: Contact your Toyota dealer. Type A Type B Type C...
  • Page 430 6-3. Do-it-yourself maintenance Fuse layout and amperage ratings ■ Engine compartment Fuse Ampere Circuit RADIO Audio system Wireless remote control, steering sensor, main body ECU, clock, power back door ECU-B NO.1 ECU, tire pressure warning system, driv- ing position memory ECU Engine switch light, interior lights, vanity DOME lights, luggage compartment light, per-...
  • Page 431 6-3. Do-it-yourself maintenance Fuse Ampere Circuit 11 RDI FAN Electric cooling fans 12 ABS NO.1 Vehicle stability control 13 HTR Air conditioning system H-LP RH-LO, H-LP LH-LO, H-LP RH-HI, 14 H-LP-MAIN H-LP LH-HI, daytime running lights 15 AMP Audio system 16 ST Starting system Multiport fuel injection system/sequential...
  • Page 432 6-3. Do-it-yourself maintenance Fuse Ampere Circuit Windshield wiper switch, electric current 31 WIPER-S sensor 32 H-LP LH-LO Left-hand headlight (low beam) 33 H-LP RH-LO Right-hand headlight (low beam) Air flow meter, purge control VSV, ACIS 34 EFI NO.1 Multiport fuel injection system/sequential 35 EFI NO.2 multiport fuel injection system, key off pump module...
  • Page 433 6-3. Do-it-yourself maintenance ■ Under the instrument panel Fuse Ampere Circuit STOP Stop lights S/ROOF Moon roof IG1 NO.1, IG1 NO.2, IG1 NO.3, ACC On-board diagnosis system Power door lock system (side doors), D/L NO.2 main body ECU FOG RR No circuit D/L BACK Power door lock system (back door)
  • Page 434 6-3. Do-it-yourself maintenance Fuse Ampere Circuit Power outlets, audio system, outside rear 18 ACC view mirrors, main body ECU, clock, electric current sensor VSC OFF switch, instrument cluster (indi- cators and warning lights), BSM main switch, all-wheel drive lock switch, wind- shield wiper de-icer switch, multiport fuel injection system/sequential multiport fuel injection system, intuitive parking assist...
  • Page 435 6-3. Do-it-yourself maintenance Fuse Ampere Circuit SRS airbag system ECU, front passen- 28 A/B ger occupant classification system ECU 29 METER Gauges and meters Alternator, anti-lock brake system/vehicle stability control ECU, stop lights, FAN 30 ECU-IG NO.3 NO.1, FAN NO.2, FAN NO.3, HTR, PTC, DEF, DEICER, windshield wiper de-icer switch RAV4_OM_OM42809U_(U)
  • Page 436 6-3. Do-it-yourself maintenance ■ Behind the instrument panel Fuse Ampere Circuit P/SEAT F/L Left-hand power seat P/SEAT F/R No circuit Power back door Front power windows, power window P/W MAIN main switch RAV4_OM_OM42809U_(U)
  • Page 437 If the lights do not turn on even after the fuse has been replaced, a bulb may need replacement. (→P. 476) ● If the replaced fuse blows again, have the vehicle inspected by your Toyota dealer. ■ If there is an overload in a circuit The fuses are designed to blow, protecting the wiring harness from damage.
  • Page 438: Light Bulbs

    Toyota dealer. For more information about replacing other light bulbs, contact your Toyota dealer. Preparing for light bulb replacement Check the wattage of the light bulb to be replaced. (→P. 562) Bulb locations ■...
  • Page 439 6-3. Do-it-yourself maintenance ■ Rear Tail light Stop/tail light and rear side marker light Back-up light License plate lights Rear turn signal light RAV4_OM_OM42809U_(U)
  • Page 440 6-3. Do-it-yourself maintenance Replacing light bulbs ■ Headlight low beams For the right side only: Remove the securing clip. Then move the washer tank inlet. Disconnect connector and turn the cover counter- clockwise. RAV4_OM_OM42809U_(U)
  • Page 441 6-3. Do-it-yourself maintenance Unplug the connector while pulling the lock release. Turn the bulb base counter- clockwise. Set the new light bulb. Align the 3 tabs on the light bulb with the mounting, and insert. Turn it clockwise to set. RAV4_OM_OM42809U_(U)
  • Page 442 6-3. Do-it-yourself maintenance Set the connector. After installing the connector, shake the bulb base gently to check that it is not loose. Set the connector and install the cover. Before installing the cover, turn the headlight low beams on once and visually confirm that no light is leaking through the mounting.
  • Page 443 6-3. Do-it-yourself maintenance Replace the light bulb, and install the bulb base. Align the 3 tabs on the light bulb with the mounting, and insert. Turn and secure the bulb base. Shake the bulb base gently to check that it is not loose, turn the headlights on once and visu- ally confirm that no light is leak- ing through the mounting.
  • Page 444 6-3. Do-it-yourself maintenance ■ Front turn signal lights/parking lights Turn the bulb base counter- clockwise. Remove the light bulb. When installing, reverse the steps listed. RAV4_OM_OM42809U_(U)
  • Page 445 6-3. Do-it-yourself maintenance ■ Front side maker lights Turn the bulb base counter- clockwise. Remove the light bulb. When installing, reverse the steps listed. RAV4_OM_OM42809U_(U)
  • Page 446 6-3. Do-it-yourself maintenance ■ Fog lights (if equipped) To allow enough working space, turn steering wheel to the opposite side of the bulb to be replaced. Turn the steering wheel to the left when replacing the right side light bulb, and turn the steering wheel to the right when replac- ing the left side light bulb.
  • Page 447 6-3. Do-it-yourself maintenance Set the new light bulb. Align the 3 tabs on the light bulb with the mounting, and insert. Turn it clockwise to set. Set the connector. After installing the connector, shake the bulb base gently to check that it is not loose, turn the fog lights on once and visu- ally confirm that no light is leak- ing through the mounting.
  • Page 448 6-3. Do-it-yourself maintenance ■ Stop/tail lights and rear side marker lights, and rear turn signal lights Open the back door and remove bolts, remove the lamp assembly by pulling it directly backward from the rear of the vehicle. Turn the bulb base counterclockwise. Stop/tail lights and rear side Rear turn signal lights marker lights...
  • Page 449 6-3. Do-it-yourself maintenance ■ Tail lights and back-up lights Open the back door and remove the cover. To prevent damage, cover the tip of the screwdriver with rag. Turn the bulb base counterclockwise. Tail lights Back-up lights Remove the light bulb. Tail lights Back-up lights When installing, reverse the steps listed.
  • Page 450 6-3. Do-it-yourself maintenance ■ License plate lights Open the back door and remove the cover. To prevent damage, cover the tip of the screwdriver with rag. Turn the bulb base counterclockwise. Left side Right side Remove the light bulb. When installing, reverse the steps listed. RAV4_OM_OM42809U_(U)
  • Page 451 ■ Condensation build-up on the inside of the lens Contact your Toyota dealer for more information in the following situations. Temporary condensation build-up on the inside of the headlight lens does not indicate a malfunction.
  • Page 452 6-3. Do-it-yourself maintenance CAUTION ■ Replacing light bulbs ● Turn off the lights. Do not attempt to replace the bulb immediately after turning off the lights. The bulbs become very hot and may cause burns. ● Do not touch the glass portion of the light bulb with bare hands. Hold the bulb by the plastic or metal portion.
  • Page 453: Reporting Safety Defects For U.s. Owners

    If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Toyota Motor Sales, U.S.A., Inc. (Toll-free: 1-800-331-4331). If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
  • Page 454: Seat Belt Instructions For Canadian Owners (In French)

    Seat belt instructions for Canadian owners (in French) The following is a French explanation of seat belt instructions extracted from the seat belt section in this manual. See the seat belt section for more detailed seat belt instructions in English. Utilisation correcte des ceintures de sécurité...
  • Page 455 Guide confort de ceinture de sécurité (sièges arrière latéraux) Si la sangle diagonale est proche du cou d’une personne, utilisez le guide confort de la ceinture de sécurité. Sortez le guide confort de la ÉTAPE pochette. Glissez la ceinture dans la fente ÉTAPE du guide.
  • Page 456 ■ Ceinture de sécurité latérale arrière Si la ceinture de sécurité est sortie de son guide, repassez-la dedans avant de l'utiliser. Entretien et soin ■ Ceintures de sécurité Nettoyez avec un chiffon ou une éponge humectée d'eau savonneuse tiède. Vérifiez régulièrement que les ceintures ne sont pas effilochées, entaillées ou exagérément usées.
  • Page 457: Srs Airbag Instructions For Canadian Owners (In French)

    SRS airbag instructions for Canadian owners (in French) The following is a French explanation of SRS airbag instructions extracted from the SRS airbag section in this manual. See the SRS airbag section for more detailed SRS airbag instructions in English. Airbags frontaux Airbag conducteur et passager avant Participent à...
  • Page 458 Composition du système d’airbags Capteurs d’airbag avant Témoin d'alerte SRS Système de classification Contacteur de boucle de l'occupant siège ceinture sécurité passager avant (ECU et passager avant capteurs) Boîtier électronique Capteurs de porte d’airbags Airbag passager avant Capteurs airbags rideau Airbags latéraux Airbag conducteur Prétensionneurs...
  • Page 459 Votre véhicule est équipé de ADVANCED AIRBAGS conçus selon les normes de sécurité américaines applicables aux véhicules à moteur (FMVSS208). Le boîtier électronique (ECU) des sacs de sécurité gonflables régule le déploiement de ces derniers sur la base des informations qu'il reçoit des capteurs, etc. indiqués ci-dessus dans le schéma illustrant les composants du système.
  • Page 460 ATTENTION ■ Précautions avec les airbags SRS Respectez les précautions suivantes concernant les airbags. Autrement, des blessures graves, voire mortelles, pourraient s'ensuivre. ● Le conducteur et tous les passagers à bord du véhicule doivent porter leur ceinture de sécurité correctement. Les airbags SRS sont des dispositifs de protection complémentaires aux ceintures de sécurité.
  • Page 461 ATTENTION ■ Précautions avec les airbags SRS ● Si vous attachez une rallonge de ceinture de sécurité aux boucles de ceinture de sécurité avant, mais pas au pêne de la ceinture de sécurité, les airbags SRS frontaux détectent que le conducteur et le passager avant ont attaché...
  • Page 462 être grièvement blessés ou tués par le déploiement d'un airbag. Installez dans un siège de sécurité enfant les enfants trop jeunes pour pouvoir utiliser la ceinture de sécurité. Toyota recommande vivement que les nourrissons et les jeunes enfants soient installés sur le siège arrière du véhicule et convenablement attachés.
  • Page 463 ATTENTION ■ Précautions avec les airbags SRS ● Ne laissez pas un enfant rester debout devant l’airbag SRS passager avant ou bien s'asseoir sur les genoux du passager avant. ● Ne conduisez pas le véhicule lorsque le conducteur ou le passager avant a quelque chose de posé...
  • Page 464 ATTENTION ■ Précautions avec les airbags SRS ●Ne rien fixer aux portes, à la vitre du pare-brise, aux vitres latérales, aux montants avant et arrière, au rail latéral de toit et à la poignée de maintien. ●Ne suspendez crochets à vêtements aucun cintre nu ni aucun objet dur.
  • Page 465 Toyota. ■ Modification et mise au rebut des éléments du système d’airbags SRS Consultez impérativement votre concessionnaire Toyota si vous avez besoin d'intervenir sur votre véhicule ou de procéder à l'une des modifications suivantes.
  • Page 466: Maintenance Data (Fuel, Oil Level, Etc.)

    8-1. Specifications Maintenance data (fuel, oil level, etc.) Dimensions and weights Overall length 179.9 in. (4570 mm) Overall width 72.6 in. (1845 mm) Without the roof 65.4 in. (1660 mm) luggage carrier Overall height With the roof lug- 67.1 in. (1705 mm) gage carrier Wheelbase 104.7 in.
  • Page 467 The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Toyota. It is used in registering the ownership of your vehicle. This number is stamped on the top left of the instrument panel.
  • Page 468 8-1. Specifications ■ Engine number The engine number is stamped on the engine block as shown. Engine Model 2.5 L 4-cylinder (2AR-FE) Type 4-cylinder in line, 4-cycle, gasoline 3.54 × 3.86 in. (90.0 × 98.0 mm) Bore and stroke Displacement 152.2 cu.in.
  • Page 469 ■ Engine oil selection “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy the following grade and viscosity. Oil grade: ILSAC GF-5 multigrade engine oil...
  • Page 470 8-1. Specifications Recommended viscosity: SAE 0W-20 SAE 0W-20 is the best choice for good fuel economy and good starting in cold weather. If SAE 0W-20 is not available, SAE 5W-20 oil may be used. However, it must be replaced with SAE 0W-20 at the next oil Outside temperature change.
  • Page 471 8-1. Specifications Cooling system Capacity 7.2 qt. (6.8 L, 6.0 Imp. qt.) Use either of the following: • “Toyota Super Long Life Coolant” • Similar high-quality ethylene glycol-based Coolant type non-silicate, non-amine, non-nitrite, and non-borate coolant with long-life hybrid organic acid technology Do not use plain water alone.
  • Page 472 Toyota Genuine Differential gear oil LT Oil type and viscosity 75W-85 GL-5 or equivalent Your Toyota vehicle is filled with “Toyota Genuine Differential Gear Oil” at the factory. Use Toyota approved “Toyota Genuine Differential Gear Oil” or an equivalent of matching quality to satisfy the above specification. Please contact your Toyota dealer for further details.
  • Page 473 Toyota Genuine Differential gear oil LT Oil type and viscosity 75W-85 GL-5 or equivalent Your Toyota vehicle is filled with “Toyota Genuine Differential Gear Oil” at the factory. Use Toyota approved “Toyota Genuine Differential Gear Oil” or an equivalent of matching quality to satisfy the above specification. Please contact your Toyota dealer for further details.
  • Page 474 8-1. Specifications Brakes 15-inch front brake models 3.74 in. (95 mm) Min. Pedal clearance 16-inch front brake models 4.02 in. (102 mm) Min. 0.04 ⎯ 0.24 in. (1 ⎯ 6 mm) Pedal free play Brake pad wear limit 0.04 in. (1.0 mm) 6 ⎯...
  • Page 475 8-1. Specifications Tires and wheels 17-inch tires Tire size 225/65R17 102H Tire inflation pressure Front: 33 psi (230 kPa, 2.3 kgf/cm or bar) (Recommended cold Rear: 33 psi (230 kPa, 2.3 kgf/cm or bar) tire inflation pressure) 17 × 6 1/2J (steel wheel), Wheel size 17 ×...
  • Page 476 8-1. Specifications Light bulbs Light bulbs Bulb No. Type Headlights High beam 9005 Low beam 9005 ⎯ Fog lights Front turn signal lights/ 7444 28/8 parking lights ⎯ Front side marker lights Exterior Stop/tail lights and rear side 7443 21/5 marker lights Tail lights Rear turn signal lights...
  • Page 477: Fuel Information

    In very few cases, driveability problems may be caused by the brand of gaso- line you are using. If driveability problems persist, try changing the brand of gasoline. If this does not correct the problem, consult your Toyota dealer. ■...
  • Page 478 ■ Recommendation of the use of gasoline containing detergent additives ● Toyota recommends the use of gasoline that contains detergent additives to avoid the build-up of engine deposits. ● All gasoline sold in the U.S.A. contains minimum detergent additives to clean and/or keep clean intake systems, per EPA’s lowest additives concen-...
  • Page 479 Non-recommendation of the use of gasoline containing MMT Some gasoline contains an octane enhancing additive called MMT (Methylcy- clopentadienyl Manganese Tricarbonyl). Toyota does not recommend the use of gasoline that contains MMT. If fuel containing MMT is used, your emission control system may be adversely affected.
  • Page 480: Tire Information

    8-1. Specifications Tire information Typical tire symbols Full-size tire Compact spare tire RAV4_OM_OM42809U_(U)
  • Page 481 8-1. Specifications Tire size (→P. 569) DOT and Tire Identification Number (TIN) (→P. 568) Location of treadwear indicators (→P. 443) Tire ply composition and materials Plies are layers of rubber-coated parallel cords. Cords are the strands which form the plies in a tire. Radial tires or bias-ply tires A radial tire has “RADIAL”...
  • Page 482 8-1. Specifications Typical DOT and Tire Identification Number (TIN) DOT symbol Tire Identification Number (TIN) Tire manufacturer’s identifica- tion mark Tire size code Manufacturer’s optional tire type code (3 or 4 letters) Manufacturing week Manufacturing year : The DOT symbol certifies that the tire conforms to applicable Federal Motor Vehicle Safety Standards.
  • Page 483 8-1. Specifications Tire size ■ Typical tire size information The illustration indicates typical tire size. Tire use (P = Passenger car, T = Temporary use) Section width (millimeters) Aspect ratio (tire height to section width) Tire construction code (R = Radial, D = Diagonal) Wheel diameter (inches) Load index (2 digits or 3 digits)
  • Page 484 8-1. Specifications Tire section names Bead Sidewall Shoulder Tread Belt Inner liner Reinforcing rubber Carcass Rim lines Bead wires Chafer RAV4_OM_OM42809U_(U)
  • Page 485 U.S. Department of Transportation. It provides the purchasers and/or prospective purchasers of Toyota vehicles with information on uniform tire quality grading. Your Toyota dealer will help answer any questions you may have as you read this information. ■ DOT quality grades All passenger vehicle tires must conform to Federal Safety Require- ments in addition to these grades.
  • Page 486 8-1. Specifications ■ Temperature A, B, C The temperature grades are A (the highest), B, and C, representing the tire’s resistance to the generation of heat and its ability to dissi- pate heat when tested under controlled conditions on a specified indoor laboratory test wheel.
  • Page 487 8-1. Specifications Glossary of tire terminology Tire related term Meaning Tire pressure when the vehicle has been Cold tire inflation pres- parked for three hours or more, or has not sure been driven more than 1 mile or 1.5 km under that condition The maximum cold inflated pressure to which Maximum...
  • Page 488 8-1. Specifications Tire related term Meaning The combined weight of installed regular pro- duction options weighing over 5 lb. (2.3 kg) in excess of the standard items which they Production options replace, not previously considered in curb weight weight or accessory weight, including heavy duty brakes, ride levelers, roof rack, heavy duty battery, and special trim A metal support for a tire or a tire and tube...
  • Page 489 8-1. Specifications Tire related term Meaning A pneumatic tire in which the ply cords that extend to the beads are laid at alternate Bias ply tire angles substantially less than 90 degrees to the centerline of the tread The tire structure, except tread and sidewall Carcass rubber which, when inflated, bears the load The breaking away of pieces of the tread or...
  • Page 490 8-1. Specifications Tire related term Meaning A tire designated by its manufacturer as pri- Light truck (LT) tire marily intended for use on lightweight trucks or multipurpose passenger vehicles The maximum load that a tire is rated to carry Load rating for a given inflation pressure The load rating for a tire at the maximum per- Maximum load rating...
  • Page 491 8-1. Specifications Tire related term Meaning The linear distance between the exteriors of the sidewalls of an inflated tire, excluding ele- Section width vations due to labeling, decoration, or protec- tive bands That portion of a tire between the tread and Sidewall bead The parting of the rubber compound from the...
  • Page 492 8-1. Specifications Designated seating Occupant distribution Vehicle normal load, capacity, Number of in a normally loaded Number of occupants occupants vehicle 2 through 4 2 in front 2 in front, 1 in second 5 through 10 seat 2 in front, 1 in second 11 through 15 seat, 1 in third seat, 1 in fourth seat...
  • Page 493: Customizable Features

    Customizable features Some function settings are changed simultaneously with other func- tions being customized. Contact your Toyota dealer for further details. Vehicles with a Display Audio system: Settings that can be changed using the Display Audio system (For further information on custom- izing settings using the Display Audio system, refer to the “Display...
  • Page 494 8-2. Customization Definition of symbols: O = Available, — = Not available Default Custom- Item Function setting ized setting Driver’s door unlocked in All doors Unlocking using a key one step, unlocked in — O all doors one step unlocked in two steps Speed-detecting auto-...
  • Page 495 8-2. Customization Default Custom- Item Function setting ized setting Operation signal Level 7 — O (Buzzers) Level 1 to 6 Operation signal — O (Emergency flashers) Time elapsed before the automatic door lock func- Smart key tion is activated if a door is seconds —...
  • Page 496 8-2. Customization Default Custom- Item Function setting ized setting Smart key system — O Smart key Driver’s All the Select doors to unlock — O system door doors (→P. 99) Number consecutive As many 2 times — O door lock operations as desired Driving Selecting the door linking...
  • Page 497 8-2. Customization Default Custom- Item Function setting ized setting Light sensor sensitivity Level 3 Level 1 to 5 O O Automatic Time elapsed before the light control headlights automatically seconds system turn off after the doors are seconds (→P. 217) closed seconds Automatic High Beam...
  • Page 498 8-2. Customization Default Custom- Item Function setting ized setting Interior lights illumination — O control seconds Time elapsed before the — O interior lights turn off seconds seconds Operation after the engine switch is turned to the “LOCK” position (vehicles without a smart key sys- —...
  • Page 499 8-2. Customization Default Custom- Item Function setting ized setting Seat belt Vehicle speed linked seat reminder — O belt reminder buzzer (→P. 510) : If equipped : For vehicles with the power back door and/or driving position memory sys- tem, the default setting is “5”. : Settings that can be changed by electronic key (→P.
  • Page 500 8-2. Customization CAUTION ■ During customization As the engine needs to be running during customization, ensure that the vehicle is parked in a place with adequate ventilation. In a closed area such as a garage, exhaust gases including harmful carbon monoxide (CO) may collect and enter the vehicle.
  • Page 501: Items To Initialize

    8-3. Items to initialize Items to initialize The following items must be initialized for normal system opera- tion after such cases as the battery being reconnected, or main- tenance being performed on the vehicle: Item When to initialize Reference • After reconnecting or chang- Power back door ing the battery P.
  • Page 502 8-3. Items to initialize RAV4_OM_OM42809U_(U)
