This manual contains information about the AUTO
ACCESS SEAT. Refer to the "Owner's Manual" for other
information regarding your vehicle.
SIENNA AAS_OM45476U_(U)
Information regarding the AUTO ACCESS SEAT,
including usage procedure
Checking fuses and replacing the battery of the
wireless remote control
Points to check when you think a malfunction has
occurred
Alphabetical listing of information contained in this
manual
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Sienna 2013 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Toyota Sienna 2013

Summary of Contents for Toyota Sienna 2013

  • Page 1 TABLE OF CONTENTS AUTO Information regarding the AUTO ACCESS SEAT, ACCESS SEAT including usage procedure Checking fuses and replacing the battery of the Maintenance wireless remote control When trouble Points to check when you think a malfunction has arises occurred Alphabetical listing of information contained in this Index manual...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Index AUTO ACCESS SEAT When trouble arises 3-1. When you think  1-1. AUTO ACCESS SEAT a malfunction has occurred AUTO ACCESS SEAT ... 6 AUTO ACCESS SEAT ..44 Head restraint......9 If the AUTO ACCESS SEAT  Armrests .......
  • Page 3 Pictorial index AUTO ACCESS SEAT Seatback angle  Head restraint P. 9 adjustment switch P. 6 Armrests P. 11 Seat position  adjustment switch P. 6 Footrest P. 13 Seat position  Wireless remote control adjustment switch P. 6 P. 16 Seat raise/lower ...
  • Page 4 This is a warning against anything which may cause damage to the vehicle or its equipment if the warning is ignored. You are informed about what you must or must not do in order to avoid or reduce the risk of damage to your Toyota and its equipment.
  • Page 5 AUTO ACCESS SEAT 1-1. AUTO ACCESS SEAT AUTO ACCESS SEAT..6 Head restraint ...... 9 Armrests......11 Footrest......13 Correct riding posture ..14 Wireless remote control ..16 1-2. Operating  the AUTO ACCESS SEAT Before operating the AUTO  ACCESS SEAT....

  • Page 6: Auto Access Seat

    1-1. AUTO ACCESS SEAT AUTO ACCESS SEAT Seat position adjustment switch Seatback angle adjustment switch ■ Operating condition The seat position and seatback angle cannot be adjusted if the AUTO ACCESS SEAT is not stowed correctly inside the vehicle. ■ Seat movement amount The AUTO ACCESS SEAT can be moved 3.1 in.
  • Page 7 1-1. AUTO ACCESS SEAT ■ Disconnecting the battery Do not disconnect the battery while operating the AUTO ACCESS SEAT. The AUTO ACCESS SEAT will become inoperable. If the battery is disconnected during operation and the AUTO ACCESS SEAT becomes inoperable, reconnect the battery and refer to P. 47. CAUTION ■...
  • Page 8 1-1. AUTO ACCESS SEAT CAUTION ■ Seatback angle adjustment Do not recline the seat more than necessary when the vehicle is in motion to reduce the risk of sliding under the lap belt. If the seat is too reclined, the lap belt may slide past the hips and apply restraint forces directly to the abdomen or your neck may contact the shoul- der belt, increasing the risk of death or serious injury in the event of an acci- dent.

  • Page 9: Head Restraint

    1-1. AUTO ACCESS SEAT Head restraint Head restraint is provided for the AUTO ACCESS SEAT. Pull the head restraint up. Down Lock release Push the head restraint down button while pressing the lock release button. ■ Adjusting the height of the head restraint Make sure that the head restraint is adjusted so that the center of the head restraint is closest to the top of your ears.
  • Page 10 1-1. AUTO ACCESS SEAT ■ Installing the head restraint Align the head restraint with the installa- tion holes and push it down to the lock position. Press and hold the lock release button when lowering the head restraint. CAUTION ■ Head restraint precautions Observe the following precautions regarding the head restraint....

  • Page 11: Armrests

    1-1. AUTO ACCESS SEAT Armrests Lower the armrests as far as they will go when rotating or raising/ lowering the AUTO ACCESS SEAT. Raise Lower ■ Wearing the seat belt Wearing the seat belt is easier with the armrest raised. SIENNA AAS_OM45476U_(U)
  • Page 12 1-1. AUTO ACCESS SEAT CAUTION ■ When wearing the seat belt Wear the seat belt correctly, passing it underneath the armrest. If the seat belt is caught on the armrest, it may not be fully effective, which could cause death or serious injury in the event of a sudden braking, sudden swerving or an accident.

  • Page 13: Footrest

    1-1. AUTO ACCESS SEAT Footrest Lower the footrest as far as it will go when rotating or raising/lower- ing the AUTO ACCESS SEAT. Raise Lower CAUTION ■ When operating the footrest Operate the footrest by holding the front edge. You may be injured if your fingers get caught in the rotating parts. SIENNA AAS_OM45476U_(U)

  • Page 14: Correct Riding Posture

    1-1. AUTO ACCESS SEAT Correct riding posture Maintain the correct posture while sitting in the seat, as follows: while keeping both knees aligned and inside the AUTO ACCESS SEAT. Lower the armrests and keep both arms inside the armrests and inside the AUTO ACCESS SEAT.
  • Page 15 1-1. AUTO ACCESS SEAT CAUTION ■ When sitting in the seat ● When the seat is being used by a person who is unable to bend his/her knees or neck, or by a person that is unable to sit far back in the seat, be careful as their head, feet etc.

  • Page 16: Wireless Remote Control

    1-1. AUTO ACCESS SEAT Wireless remote control The wireless remote control can be used to rotate and raise or lower the AUTO ACCESS SEAT. Indicator light Seat raise switch Seat lower switch Effective range Approximately 3.3 ft. (1 m) from the AUTO ACCESS SEAT SIENNA AAS_OM45476U_(U)
  • Page 17 1-1. AUTO ACCESS SEAT ■ Operating conditions ● The effective range of the wireless remote control changes in accor- dance with surroundings. ● Interference from other radio waves may cause the AUTO ACCESS SEAT to stop moving temporarily even when pressing the wireless remote control switches.
  • Page 18 ■ When replacing either the transmitter or the receiver of the wireless remote control It is necessary to replace both the transmitter and the receiver. Contact your Toyota dealer. ■ Certification for the wireless remote control U.S.A. FCC ID: HYQ12BDF...

  • Page 19: Operating

    1-1. AUTO ACCESS SEAT CAUTION ■ Wireless remote control precautions Observe the following precautions to reduce the risk of injury. ● Operate the AUTO ACCESS SEAT from a position from which you can see the occupant of the seat. ● Make sure that the occupant’s head, arms and legs will not get caught between the seat and the body of the vehicle.

  • Page 20: The Auto Access Seat

    1-2. Operating the AUTO ACCESS SEAT Before operating the AUTO ACCESS SEAT The AUTO ACCESS SEAT (right-hand second seat) can be rotated, raised and lowered electrically to help the seat occupant easily enter and exit the vehicle. Have all operations carried out by an assistant. STEP Park the vehicle on a flat surface and leave the engine run- ning.
  • Page 21 1-2. Operating the AUTO ACCESS SEAT Fold the front passenger seat- STEP back while pulling the seat- back angle lever. STEP Unfasten the seat belt on the AUTO ACCESS SEAT. Adjust the armrest and foot STEP restraint AUTO ACCESS SEAT to the down- most position.
  • Page 22 1-2. Operating the AUTO ACCESS SEAT ■ Beep sounds The beep makes the following sounds in response to operating procedures and conditions. Beep Operation/Condition When the wireless remote control switches or the seat raise/lower switch is pressed and the AUTO ACCESS SEAT Once operates.
  • Page 23 1-2. Operating the AUTO ACCESS SEAT CAUTION ■ When operating the AUTO ACCESS SEAT ● Do not operate while parked on an incline or on uneven ground. The occu- pant may fall from the seat or from their wheelchair, or you may be hit by the wheelchair while putting it away, possi- bly causing an injury.
  • Page 24 1-2. Operating the AUTO ACCESS SEAT CAUTION ■ When operating the AUTO ACCESS SEAT ● Do not place luggage or hands and feet underneath around AUTO ACCESS SEAT. Hands and feet could get caught, possi- bly resulting in an injury. ●...
  • Page 25 1-2. Operating the AUTO ACCESS SEAT NOTICE ■ To prevent seat damage ● Before operating the AUTO ACCESS SEAT, make sure that there are no luggage items or other obstacles around the moving parts of the seat. The AUTO ACCESS SEAT may be damaged if it hits an obstacle. ●...

  • Page 26: Moving The Auto Access Seat Outside The Vehicle

    1-2. Operating the AUTO ACCESS SEAT Moving the AUTO ACCESS SEAT outside the vehicle STEP Park the vehicle on a flat surface and leave the engine run- ning. STEP Shift the shift lever to P and set the parking brake. STEP Confirm the following: •...
  • Page 27 1-2. Operating the AUTO ACCESS SEAT The beep will sound once, and the AUTO ACCESS SEAT will begin to move automatically. The indicator light on the wire- less remote control will flash. The AUTO ACCESS SEAT will rotate while the seat- back reclines and while moving towards the front of the vehicle.
  • Page 28 1-2. Operating the AUTO ACCESS SEAT ■ Operating conditions Under the following conditions, the seat will not rotate or lower even if the seat lower switch is pressed. ● The right-hand sliding door is not opened completely. ● The seat belt is caught up in the AUTO ACCESS SEAT. ●...
  • Page 29 1-2. Operating the AUTO ACCESS SEAT CAUTION ■ Before moving the AUTO ACCESS SEAT outside the vehicle ● Check that the right-hand third seat occupant is safe. ● Do not try to close the right-hand sliding door while operating AUTO ACCESS SEAT.

  • Page 30: Returning The Auto Access Seat To The Vehicle

    1-2. Operating the AUTO ACCESS SEAT Returning the AUTO ACCESS SEAT to the vehicle STEP Park the vehicle on a flat surface and leave the engine run- ning. STEP Shift the shift lever to P and set the parking brake. STEP Confirm the following: •...
  • Page 31 1-2. Operating the AUTO ACCESS SEAT The beep will sound once, and the AUTO ACCESS SEAT will begin to move automatically while seatback reclines. The indicator light on the wire- less remote control will flash. The AUTO ACCESS SEAT will rotate while the seat- back raises and while mov- ing towards the rear of the vehicle.
  • Page 32 1-2. Operating the AUTO ACCESS SEAT ■ Jam protection function If the operation of the AUTO ACCESS SEAT is interrupted by collision with an obstacle etc., the beep will sound twice and the seat will retreat slightly and then stop. If this happens, make sure that the hands, feet etc. of the occupant will not hit the body of the vehicle, and operate the seat once again after removing the obstacle.
  • Page 33 1-2. Operating the AUTO ACCESS SEAT CAUTION ■ When the AUTO ACCESS SEAT has been returned to the vehicle ● Shake the AUTO ACCESS SEAT gen- tly to check that the seat is stowed properly. If not stowed properly, the seat may move unexpectedly, and could cause injuries.
  • Page 34 1-2. Operating the AUTO ACCESS SEAT NOTICE ■ To prevent AUTO ACCESS SEAT damage ● Press and hold the wireless remote control switches, instead of pressing them repeatedly. ● Wait for approximately 1 second before changing to another switch. ● Open the right-hand sliding door fully before returning the AUTO ACCESS SEAT inside the vehicle.

  • Page 35: Operating With The Seat Raise/Lower Switch

    1-2. Operating the AUTO ACCESS SEAT Operating with the seat raise/lower switch If the battery of the wireless remote control has discharged or another malfunction has occurred, the seat raise/lower switch can be used to operate the AUTO ACCESS SEAT. (The AUTO ACCESS SEAT will operate in the same way as when operated using the wire- less remote control).
  • Page 36 1-2. Operating the AUTO ACCESS SEAT STEP When the AUTO ACCESS SEAT stops automatically, release the switch. When returning the AUTO ACCESS SEAT to the vehicle, release the switch after the seat has stopped automatically and the beep has sounded once. ■...

  • Page 37: Maintenance

    Maintenance 2-1. Maintenance Checking and replacing  fuses ........ 38 Wireless remote control  battery ......40 SIENNA AAS_OM45476U_(U)

  • Page 38: Maintenance Checking And Replacing  Fuses

    2-1. Maintenance Checking and replacing fuses If the AUTO ACCESS SEAT does not operate when the switches are pressed, a fuse may have blown. If this happens, check and replace the fuses as necessary. Fuse layout and amperage rating ■ AUTO ACCESS SEAT Ampere Circuit...
  • Page 39 2-1. Maintenance ■ After a fuse is replaced Have the vehicle inspected by your Toyota dealer in the following situations. ● If the replaced fuse blows again. ● If the AUTO ACCESS SEAT does not operate. CAUTION ■ To prevent system breakdowns and vehicle fire Observe the following precautions....

  • Page 40: Wireless Remote Control Battery

    2-1. Maintenance Wireless remote control battery Replace the battery with a new one if it is discharged. ■ You will need the following items: ● Flathead screwdriver ● Lithium battery CR2032 ■ Replacing the battery Remove the cover using a STEP coin protected with tape etc.
  • Page 41 The wireless remote control will not function properly. ■ Use a CR2032 lithium battery ● Batteries can be purchased at your Toyota dealer, local electrical appli- ance shops or camera stores. ● Replace only with the same or equivalent type recommended by the Toyota dealer.
  • Page 42 2-1. Maintenance NOTICE ■ For normal operation after replacing the battery Observe the following precautions to prevent accidents. ● Always work with dry hands. Moisture may cause the battery to rust. ● Do not touch or move any other components inside the wireless remote control.

  • Page 43: When Trouble Arises

    When trouble arises 3-1. When you think  a malfunction has occurred AUTO ACCESS SEAT..44 If the AUTO ACCESS SEAT  does not move while outside  the vehicle......47 Wireless remote control ..59 SIENNA AAS_OM45476U_(U)

  • Page 44: When You Think A Malfunction Has Occurred Auto Access Seat

    If the seat still does not operate even after trying the procedures, it is likely that the seat is malfunctioning. Do not use the AUTO ACCESS SEAT, and have the seat inspected by your Toyota dealer immedi- ately. ■...
  • Page 45 3-1. When you think a malfunction has occurred Reason Correction procedure Start the engine. If the AUTO ACCESS SEAT is operated The engine is not running. while the engine is stopped and the vehicle battery is low, the AUTO ACCESS SEAT may stop during operation.
  • Page 46 3-1. When you think a malfunction has occurred If the AUTO ACCESS SEAT retreats a little and then stops Reason Correction procedure The AUTO ACCESS SEAT has hit an obstacle, or opera- Remove the obstacle and try operating the tion has been otherwise AUTO ACCESS SEAT again.

  • Page 47: If The Auto Access Seat Does Not Move While Outside The Vehicle

    If the AUTO ACCESS SEAT still does not move even after the fuses have been checked and replaced, have the seat inspected by your Toyota dealer. If the AUTO ACCESS SEAT stops moving while raising, lowering or rotating, or while it is outside the vehicle, you will not be able to close the right-hand sliding door.
  • Page 48 3-1. When you think a malfunction has occurred Press and hold the seat position STEP adjustment switch on the right- hand side of the seat in either the front or back direction and, at the same time as press and hold the seat raise/lower switch in either the raise or lower direction for approximately 10 seconds,...
  • Page 49 3-1. When you think a malfunction has occurred If the AUTO ACCESS SEAT moves when a switch is pressed ● Initialize the seat position information before conducting the opera- tions listed here. ● The movements of the seat while conducting these operations will be different from normal.
  • Page 50 3-1. When you think a malfunction has occurred Press the rear side of the seat STEP position adjustment switch on the right-hand side of the seat, and slide the AUTO ACCESS SEAT toward the rear of the vehicle by 2 in. (5 cm). If the rear side of the seat position adjustment switch is pressed and held while the lower side of the...
  • Page 51 3-1. When you think a malfunction has occurred Press the rear side of the seat STEP position adjustment switch on the right-hand side of the seat, and slide the AUTO ACCESS SEAT toward the rear of the vehicle until the beep sounds. If the rear side of the seat position adjustment switch is pressed and held while the lower side of the...
  • Page 52 3-1. When you think a malfunction has occurred Press and hold the front side of STEP the seatback angle adjustment switch on the right-hand side of the seat until a long beep sounds. SIENNA AAS_OM45476U_(U)
  • Page 53 3-1. When you think a malfunction has occurred If the AUTO ACCESS SEAT does not move even when a switch is pressed Before conducting this procedure, conduct the procedures explained in the “Initializing the seat position information” and “If the AUTO ACCESS SEAT moves when a switch is pressed”...
  • Page 54 3-1. When you think a malfunction has occurred Take combination STEP wrench. Removal Replacement Combination wrench Remove the connector. STEP Turn the bolt with yellow marking STEP using the combination wrench, and move the AUTO ACCESS SEAT until the marks are aligned as shown in the illustration.
  • Page 55 3-1. When you think a malfunction has occurred Use the combination wrench to STEP remove the 2 bolts on the under- side of the AUTO ACCESS SEAT. Slide the AUTO ACCESS SEAT STEP into the vehicle. Turn the bolt with yellow marking STEP using the combination wrench, and move the AUTO ACCESS...
  • Page 56 3-1. When you think a malfunction has occurred Turn the bolt with yellow marking STEP clockwise using the combination wrench, and slide the seat until the marks are aligned as shown in the illustration. If you are unable to slide the seat until marks aligned...
  • Page 57 Turn the power sliding door main switch off and close the right-hand sliding door manually. Have the seat inspected by your Toyota dealer immediately. The power sliding door will not operate if the AUTO ACCESS SEAT has been stowed inside the vehicle manually.
  • Page 58 3-1. When you think a malfunction has occurred CAUTION ■ When stowing the AUTO ACCESS SEAT manually Do not put your feet or hands into the AUTO ACCESS SEAT stowage space. Your feet or hands may be caught in the movable parts of the AUTO ACCESS SEAT, which could cause injuries.

  • Page 59: Wireless Remote Control

    Use the seat raise/lower switch to operate the AUTO ACCESS SEAT (P. 35), and have the wireless remote control inspected by your Toyota dealer immediately. If the AUTO ACCESS SEAT does not move...
  • Page 60 Replace the battery. (P. 40) control is discharged. If the indicator light is illuminated or flashing even though the wireless remote control switches are not being pressed Reason Correction procedure The wireless remote control may be Contact your Toyota dealer. malfunctioning. SIENNA AAS_OM45476U_(U)

  • Page 61: Index

    Index Alphabetical index ... 62 SIENNA AAS_OM45476U_(U)

  • Page 62: Alphabetical Index Alphabetical Index

    Alphabetical index Alphabetical index Operating with the seat  Armrests ........11 AUTO ACCESS SEAT ....6 raise/lower switch ....35 Battery Replacing the fuses....38 Returning the seat to  Disconnecting......7 Beep sounds ......22 the vehicle........ 30 Before operating the seat..20 Seat position adjustment ...
