Operation/Reference Guide
AMX TDS
Television Distribution System
ClearQAM / ATSC (High Definition)
Terrestrial/Satellite (Standard Definition)
T e l e v i s i o n D i s t r i b u t i o n S y s t e m
L a s t R e v i s e d : 1 1 / 0 4 / 2 0 1 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TDS and is the answer not in the manual?

Questions and answers

Related Manuals for AMX TDS

Summary of Contents for AMX TDS

  • Page 1 Operation/Reference Guide AMX TDS Television Distribution System ClearQAM / ATSC (High Definition) Terrestrial/Satellite (Standard Definition) T e l e v i s i o n D i s t r i b u t i o n S y s t e m...
  • Page 2 AMX is not responsible for products returned without a valid RMA number. AMX is not liable for any damages caused by its products or for the failure of its products to perform. This includes any lost profits, lost savings, incidental damages, or consequential damages.

  • Page 3: Table Of Contents

    Table of Contents AMX Television Distribution System (TDS) ............1 Overview ........................1 Network Considerations....................1 System Diagram - TDS Distribution ................2 AMX TDS - ClearQAM/ATSC (High Definition) ...........3 Overview ........................3 System Components ....................3 DTV-TX03-US Transmitters ..................4 Product Specifications.....................
  • Page 4 Connecting DTV-RX02-HD Receivers to the Network ........... 18 Connecting an (Optional) Remote IR Receiver to DTV-RX02-HD Receivers....18 Configuring DTV-RX02-HD Receivers ................18 AMX TDS - Terrestrial/Satellite (Standard Definition) ........19 Overview ........................ 19 System Components ....................19 DTV-TX Transmitters....................20 DTV-TX01-DVB-T Transmitter .................
  • Page 5 Configuring DTV-TX-DVB Transmitters ................. 39 Installing DTV-RX01-SD Receivers ................40 Connecting DTV-RX01-SD Receivers to the Network............ 40 Configuring DTV-RX01-SD Receivers ................40 DTV-MA01 TDS Management Appliance ............41 Overview ........................ 41 Rear Panel Components..................42 12 VDC Power Connector ..................... 42 Video Output Connectors .....................
  • Page 6 2) Access the TDS Configuration Pages ..............48 3) Configure the NetLinx Master for AMX TDS ............48 Load the AMX TDS Module on the NetLinx Master ............49 Modify the Master’s Source Code ................. 49 4) Install System Hardware ..................49 5) Configure the Transmitter(s) ................
  • Page 7 FAQs........................87 Recommendations ....................88 Appendix B: Network Recommendations ............89 Products Applicability..................... 89 Introduction ......................89 Introduction to AMX Television Distribution System ..........89 Network Considerations ..................89 Network Switches ......................89 Channel/Transport Stream Bandwidth ................89 IGMP ..........................89 Power Over Ethernet ....................
  • Page 8 Table of Contents AMX TDS (Television Delivery System)

  • Page 9: Amx Television Distribution System (Tds)

    IT representative to determine the proper network configuration for the TDS system. The AMX TDS system transmits audio/video using IP multicast. In order for this to work satisfactorily, it is vital that the network switches are multicast-enabled in order to prevent unwanted flooding of traffic on the network.

  • Page 10: System Diagram - Tds Distribution

    AMX Television Distribution System (TDS) System Diagram - TDS Distribution NetLinx Central Controller DTV-MA01 Touch Panel Touch Panel DTV-RX01 DTV-RX02 DTV-TX03 DTV-TX01 DTV-TX02 FIG. 2 AMX TDS System Diagram AMX TDS (Television Delivery System)

  • Page 11: Amx Tds - Clearqam/Atsc (High Definition)

    AMX TDS - ClearQAM/ATSC (High Definition) Overview This section describes the QAM/ATSC (High Definition) version of the AMX TDS, intended primarily for use within the USA. The High Definition TDS utilizes DTV-TX03-US Digital TV Transmitters (FG1410-03) and DTV-RX02-HD High-Definition Receivers (FG1411-02).

  • Page 12: Dtv-Tx03-Us Transmitters

    AMX TDS - ClearQAM/ATSC (High Definition) DTV-TX03-US Transmitters The DTV-TX03-US Digital TV Transmitter (FG1410-03) receives the incoming ClearQAM or ATSC signal and sends the digital TV content to the DTV Receiver located at the display (FIG. 4). not used (front)

  • Page 13: Front Panel - Status Leds

    AMX TDS - ClearQAM/ATSC (High Definition) Front Panel - Status LEDs The two status LEDs are located on the front panel, directly beneath the AMX logo (FIG. 5): Communication Status LED (red) Power Status LED (green) FIG. 5 Status LEDs ...

  • Page 14: Rear Panel - 10/100 Network Port

    For remote connectivity, the Firewall may have to be configured to open port 2008 for remote connectivity over UDP.  Ports 5000 and 5001 are required for the Transmitters as well as any ports used for the TDS Multicast stream. ...

  • Page 15: Ethernet Leds

    AMX TDS - ClearQAM/ATSC (High Definition) Ethernet LEDs L/A - Link/Activity LED SPD - Speed LED lights (green) when the lights (yellow) when the connection speed is 100 Mbps Ethernet cables are and turns Off when speed is connected and terminated 10 Mbps.

  • Page 16: Rear Panel - Power/12 Vdc Connector

    AMX TDS - ClearQAM/ATSC (High Definition) All DTV Transmitters and Receivers must have an assigned IP Address, Network Mask, and Gateway Address in order for the DTV system to work correctly. This applies to units that utilize DHCP and to units that have been assigned Static IP addresses.
  • Page 17 AMX TDS - ClearQAM/ATSC (High Definition) front Mounting Screw (x4) rear DTV-TX03-US Transmitter Mounting Hole (x4) Washer (x4) Mounting Post (x4) front Mounting Shelf rear FIG. 13 Placing the Transmitter on the mounting posts Insert a washer between each Mounting Post on the shelf and matching Mounting Hole on the Transmitter.

  • Page 18: Dtv-Rx02-Hd Receivers

    AMX TDS - ClearQAM/ATSC (High Definition) DTV-RX02-HD Receivers The DTV-RX02-HD High-Definition Receiver (FG1411-02) is located at the display and receives incoming transmitted digital TV signal (from a DTV Transmitter), and converts it to a compatible format for a target display in High Definition (FIG. 15).

  • Page 19: Feature Comparison - Hd Vs Sd Receivers

    AMX TDS - ClearQAM/ATSC (High Definition) Product Specifications - DTV-RX02-HD Receiver (Cont.) Rear Panel Connectors (Cont.) POWER: Barrel plug accepts 12VDC power from the included power supply. Note: This connector is intended to be used only with the provided power supply.

  • Page 20: Front Panel - External Ir Receiver Socket

    AMX TDS - ClearQAM/ATSC (High Definition) Front Panel - External IR Receiver Socket The IR Receiver socket on the front panel (FIG. 16) connects to the included External IR Receiver (60-1411-01). External IR Receiver FIG. 16 External IR Receiver Socket...

  • Page 21: Rear Panel - Video Output Connectors

    AMX TDS - ClearQAM/ATSC (High Definition) Rear Panel - Video Output Connectors The Video Output connectors contained within the AUDIO/VIDEO OUT group on the rear panel (FIG. 19): CVBS Composite Video cable Component Video cable HDMI Audio/Video cable FIG. 19 Video Output Connectors ...

  • Page 22: Setting The Receiver's Ip Address Via The Rs 232 Port

    AMX TDS - ClearQAM/ATSC (High Definition) Use hyper terminal with default serial settings to communicate with the DTV Transmitters: Default Serial Settings Baud Rate: 115200 Data Bits: Parity: None Stop Bits: Flow Control: None Setting the Receiver’s IP Address via the RS 232 Port In most cases, all setup and configuration for both Transmitters and Receivers is done via the Digital TV Configuration Manager (see the Digital TV Configuration Manager section on page 53 for information).

  • Page 23: Wiring And Connections

    AMX TDS - ClearQAM/ATSC (High Definition) Wiring and Connections FIG. 23 illustrates a common system installation of the AMX TDS ClearQAM/ATSC (High Definition) System: DTV-MA01 TDS Management Appliance Provides access to the TDS Configuration Manager Video Server providing multi-cast video stream...

  • Page 24: Installing Dtv-Tx03-Us Transmitters

    (rear) FIG. 26 Connecting a ATSC/AQM Digital TV signal to DTV-TX03-US Transmitters Recommended Signal Levels AMX DTV Transmitters require good quality input signals. The recommended signal levels are specified below. ATSC:  Signal level: > 45 dBµV and < 70 dBµV ...

  • Page 25: Connecting The Transmitters To The Network

    Pages section on page 54 for information. Installing DTV-RX02-HD Receivers DTV-RX02-HD Receivers receive TDS broadcasts from DTV-TX03-US Transmitters (via Ethernet), and pass the signal to the end display-device via standard A/V connectors. DTV-RX02-HD Receivers do not connect directly to the Transmitters. Rather, they connect to Transmitters indirectly via the LAN (using a network switch).

  • Page 26: Connecting Dtv-Rx02-Hd Receivers To The Network

    AMX TDS - ClearQAM/ATSC (High Definition) Connecting DTV-RX02-HD Receivers to the Network Use standard (Cat5/5e/6 UTP) network cable to connect the DTV-RX02-HD Receivers to a network switcher. DTV-RX02-HD Receivers feature standard A/V connectors to deliver the incoming TV signal to the display device (FIG.

  • Page 27: Amx Tds - Terrestrial/Satellite (Standard Definition)

     DTV-TX02-DVB-S - The DTV-TX02-DVB-S Transmitter supports DVB-S (satellite) signals. Note that both the High-Definition and Standard Definition versions of the AMX TDS utilize the DTV-MA01 TDS Management Appliance (FG1412-01) and (optionally) the DTV-RC01 Digital TV Remote Controller (FG1411-70).

  • Page 28: Dtv-Tx Transmitters

    AMX TDS - Terrestrial/Satellite (Standard Definition) AMX TDS - Terrestrial/Satellite (Standard Definition) - Component Devices Product Name Description DTV-TX01-DVB-T Digital TV Transmitter DVB-T FG1410-01 • For use with terrestrial digital TV broadcasts • Provides two transport streams DTV-TX02-DVB-S Digital TV Transmitter DVB-S FG1410-02 •...

  • Page 29: Product Specifications

    AMX TDS - Terrestrial/Satellite (Standard Definition) Product Specifications DTV-TX01-DVB-T Transmitter Dimensions (HWD): 2.18" x 5.41" x 7.60" (5.56cm x13.74cm x 19.30cm) Weight: 2.75 lbs (1.25 kg) Power Requirements: • Power Consumption: 6W • Voltage rating: nominal 12 to 13.5V DC •...

  • Page 30: Dtv-Tx02-Dvb-S Transmitter

    AMX TDS - Terrestrial/Satellite (Standard Definition) DTV-TX02-DVB-S Transmitter The DTV-TX02-DVB-S Transmitter (FG1410-02) supports DVB-S (satellite) signals (FIG. 32). Common Interface Slots 1 & 2 (front) NETWORK RJ45 connector (to network) Reset button Streaming status (green) Network Connectivity status (green) Power status (yellow)

  • Page 31: Dtv-Tx Transmitters - Front Panel Components

    AMX TDS - Terrestrial/Satellite (Standard Definition) DTV-TX02-DVB-S Transmitter (Cont.) • Common Interface Dual Common Interface Slots enable the Transmitter to select encrypted channels Slots 1 & 2: in cases where this is supported by the broadcaster. Note: Before de-scrambling content using the Common Interface Slots, ensure that you have the appropriate authority/rights to transmit the de-scrambled content on your network.

  • Page 32: Network Port Pinouts And Signals

    AMX TDS - Terrestrial/Satellite (Standard Definition) Network Port Pinouts and Signals The following table lists the pinouts, signals, and pairing for the NETWORK port. RJ45 Network Port Pinouts and Signals Signals Connections Pairing Color TX + 1 --------- 1 1 --------- 2...

  • Page 33: Front Panel - Status Leds

    AMX TDS - Terrestrial/Satellite (Standard Definition) Front Panel - Status LEDs There are three LEDs on the front panel to indicate various types of device status (FIG. 36): Streaming Status Power Status Network Connectivity FIG. 36 Status LEDs Status LEDs Streaming Status (green): Flashes if only one tuner is streaming.

  • Page 34: Front Panel - Reset Button

    AMX TDS - Terrestrial/Satellite (Standard Definition) Front Panel - Reset Button Press to reboot the Transmitter (FIG. 38). Reset Button FIG. 38 Reset Button DTV-TX Transmitters - Rear Panel Components The rear panel components and connectors for DTV-TX01-DVB-T and DTV-TX02-DVB-S Transmitters (FIG.

  • Page 35: Rear Panel - Rf In 1 & 2

    AMX TDS - Terrestrial/Satellite (Standard Definition) Rear Panel - RF IN 1 & 2 The RF IN 1 & 2 connectors accept incoming digital TV signals via a standard coaxial input. Incoming Digital TV Signal (up to 2 per DTV Transmitter)

  • Page 36: Rear Panel - Serial Port

    AMX TDS - Terrestrial/Satellite (Standard Definition) Rear Panel - SERIAL Port The SERIAL Port on the rear panel provides a RS232 serial interface for local device control, as well as diagnostic and troubleshooting purposes, via a standard DB9 connector. ...

  • Page 37: Dtv-Rx01-Sd Receivers

    DTV-RX01-SD Receivers The DTV-RX01-SD Receiver (FG1411-01) accepts the digital TV signals being output by the DTV Transmitters via TDS and decodes the signals, in order to provide standard A/V connections for target display devices (FIG. 43). (front)
  • Page 38 AMX TDS - Terrestrial/Satellite (Standard Definition) Product Specifications - DTV-RX01-SD (Cont.) Front Panel Components (Cont.) CONSOLE: RJ12 connector provides local command line interface (via RS232 only). The RS01 RS-232 Serial Transmit Cable (FG-RS01) is to be used on this port.

  • Page 39: Feature Comparison - Hd Vs Sd Receivers

    AMX TDS - Terrestrial/Satellite (Standard Definition) Feature Comparison - HD vs SD Receivers The following table provides a summarized feature comparison for the DTV-RX01-SD (Standard Definition) Receivers and DTV-RX02-HD (High-Definition) Receivers: Feature Comparison - HD vs SD Receivers Feature DTV-RX01-SD (FG1411-01)

  • Page 40: Rear Panel - Ir Rx Port

    AMX TDS - Terrestrial/Satellite (Standard Definition) Use the following command to configure the network settings: DHCPd,i.i.i.i,gw.gw.gw.gw, Sets IP details: nm.nm.nm.nm • ip = ip • gw = gateway • nm = network mask All DTV Transmitters and Receivers must have an assigned IP Address, Network Mask, and Gateway Address in order for the DTV system to work correctly.

  • Page 41: Connecting An Ir Emitter

    AMX TDS - Terrestrial/Satellite (Standard Definition) Connecting an IR Emitter Connect an IR01 IR Emitter cable (FG-IR01) to the IR Tx port on the DTV Receiver. Run the other end of the IRTX cable to the display device and locate the IR window.

  • Page 42: Rear Panel - Video Output Connectors

    AMX TDS - Terrestrial/Satellite (Standard Definition) Rear Panel - Video Output Connectors The Video Output connectors are grouped under "VIDEO" on the rear panel (FIG. 50): Component Video cable Composite Video cable FIG. 50 Video Output Connectors  Component: The green, red and blue COMPONENT RCA connectors provides Component (Y/Pb/Pr) video output.

  • Page 43: Performing A Full Factory Reset On The Dtv-Rx01-Sd Receiver

    AMX TDS - Terrestrial/Satellite (Standard Definition) Performing a Full Factory Reset on the DTV-RX01-SD Receiver The recessed Factory Reset button on the front panel, in conjunction with the Reset pushbutton on the rear panel (FIG. 52), allows you to perform a full factory reset of the DTV-RX01-SD Receiver. A full factory reset resets flash and reboots the unit in the factory default IP address mode (DHCP).

  • Page 44: Wiring And Connections

    AMX TDS - Terrestrial/Satellite (Standard Definition) Wiring and Connections FIG. 53 illustrates a common system installation of the AMX TDS Terrestrial/Satellite (Standard-Definition) Systems: DTV-MA01 TDS Management Appliance Provides access to the TDS Configuration Manager Video Server providing multi-cast video stream...

  • Page 45: Installing Dtv-Tx-Dvb Transmitters

    AMX TDS - Terrestrial/Satellite (Standard Definition) Installing DTV-TX-DVB Transmitters Applying Power to the Transmitters Each DTV-TX-DVB Transmitter receives 12 VDC power via the 2-pin captive-wire PWR connector on the rear panel (FIG. 54). Power Supply (rear) FIG. 54 Applying Power to the Transmitters Refer to the Rear Panel - 12VDC PWR Connector section on page 28 for details on the power connection.

  • Page 46: Connecting A Satellite Source To Dtv-Tx02-Dvb-S Transmitters

    AMX TDS - Terrestrial/Satellite (Standard Definition) Connecting a Satellite Source to DTV-TX02-DVB-S Transmitters Each DTV-TX02 Transmitter has two tuners labelled RF1 and RF2 with standard coax inputs on the rear panel. To connect from the satellite dish to the DTV-TX02, use a co-axial cable with male F-type connector (FIG.

  • Page 47: Using Conditional Access Module (Cam) Modules

    AMX TDS - Terrestrial/Satellite (Standard Definition) Using Conditional Access Module (CAM) Modules Two Common Interface Slots on the front panel enable the Transmitter to select encrypted channels (in cases where this is supported by the broadcaster), via appropriate Conditional Access Module (CAM) modules (FIG.

  • Page 48: Installing Dtv-Rx01-Sd Receivers

    LAN, using a PoE-enabled network switch.  DTV-RX01-SD Receivers receive power via PoE, therefore it is required that a PoE network switcher (i.e. the NXA-ENET24PoE - FG2178-61 from AMX) is used to connect the Receivers to the network. ...

  • Page 49: Dtv-Ma01 Tds Management Appliance

    DTV-MA01 TDS Management Appliance DTV-MA01 TDS Management Appliance Overview The DTV-MA01 TDS Management Appliance (FG1412-01) manages television distribution in a TDS system (FIG. 60). USB Ports Power Switch (front) Status light (surrounds the Power Switch) Serial Port USB Ports Ethernet Port...

  • Page 50: Rear Panel Components

    DTV-MA01 TDS Management Appliance Product Specifications - DTV-MA01 TDS Management Appliance (Cont.) Rear Panel Components Power Connector: • 90W (20V,4.5A) AC Adapter • Input Voltage AC 100-240V Note: Isolate IT Power System Connection. USB Ports: 4 Type-B USB 2.0 Ports.

  • Page 51: Video Output Connectors

    10/100 Network Port The 10/100 (Ethernet RJ45) port on the front panel provides 10/100 BaseT network connectivity via Cat5/5e/6 network cable (FIG. 63). Refer to the AMX TDS Installation Overview section on page 47 for more information. 10/100 Network Port FIG. 63...

  • Page 52: Ethernet Leds

    For remote connectivity, the Firewall may have to be configured to open port 2008 for remote connectivity over UDP.  Ports 5000 and 5001 are required for the Transmitters as well as any ports used for the TDS Multicast stream. ...

  • Page 53: Dtv-Rc01 Digital Tv Remote Controller

    Press to access a sub-menu that allows access to the EPG (programming guide), Subtitles and Audio Language settings. These options allow the selection of the configured settings made in the TDS Configuration Menu, and apply only to the Receiver associated with the DTV-RC01.
  • Page 54 This button is user-programmable via NetLinx code. Refer to the Assigning a DTV-RC01 Remote Controller To a Specific Receiver section on page 51 for instructions on associating the DTV-RC01 to a specific Receiver in the system. AMX TDS (Television Delivery System)

  • Page 55: Amx Tds Installation Overview

    AMX TDS Installation Overview Overview This section gives a brief overview of the steps required to get the AMX TDS system up and running. All configuration is done via options in the Digital TV Configuration Manager web console. The DTV-MA01 requires Layer 3 switching. Therefore, a Layer 3 Network Switch (also referred to as a "Multilayer Switch") is required to operate properly.

  • Page 56: Access The Tds Configuration

    Serial) which can't be done through the web pages described in this document. In order to use a NetLinx Master with the TDS system, two steps must be taken to prepare the Master (both require the NetLinx Studio application): The AMX TDS Duet Module (.JAR file) must be loaded on the Master.

  • Page 57: Load The Amx Tds Module On The Netlinx Master

    Refer to the NetLinx Studio online help for instructions on transferring files to system devices. Modify the Master’s Source Code To run the AMX TDS Duet Module on the NetLinx Master, the following changes must be made to the Master’s Source Code file:...
  • Page 58 Channels found on the scanned frequency. Select the channels that you want to enable.  You can manually enable up to five channels from the same transport stream.  Select Full Stream to enable all channels from a transport stream. AMX TDS (Television Delivery System)

  • Page 59: Configure The Receiver(S)

    The default Remote Control Number for DTV-RC01 remote controllers is 6E. See the Receiver Setup - Output Settings (DTV-RX02-HD) section on page 69 for more information. Click Save to load the new remote control address into the Receiver. AMX TDS (Television Delivery System)
  • Page 60 Refer to the DTV-RC01 Digital TV Remote Controller section on page 45 for details on using the DTV-RC01. To return to the default remote control address (6E), press and hold the SEL and GUIDE buttons for 4 seconds. AMX TDS (Television Delivery System)

  • Page 61: Digital Tv Configuration Manager

    The DTV-MA01 TDS Management Appliance features a built-in web console called the Digital TV Configuration Manager. The Digital TV Configuration Manager allows you to configure the Receiver and all Transmitters in the TDS solution via a web browser on any PC that has access to the DTV-MA01 in the TDS system.

  • Page 62: Transmitter Setup Pages

    Transmitter Setup - Network Settings Manage Unit • Device List: The Manage Unit window displays a list of all DTV Transmitters connected to the Master. • Refresh List: Click to refresh the Transmitters list (in the Manage Unit window).: AMX TDS (Television Delivery System)
  • Page 63 Click to send a poll to the selected Transmitter to see if it is online. • Refresh: Click to refresh the unit status. Reset to Default • Reset unit to factory default: Click to reset the Network Settings for selected Transmitter to DHCP. AMX TDS (Television Delivery System)

  • Page 64: Transmitter Setup - Tuner Setup (Dtv-Tx03-Us)

    • Scan: Click to initiate a scan for transponders, based on the parameters entered. Note: This scan may take several minutes to complete, depending on the number of frequencies, and the number of channels present AMX TDS (Television Delivery System)
  • Page 65 Disable all Channels: Click to disable (and de-select) all channels from all streams. Note: If the tuner unit is currently streaming, the unit may reboot depending on the stream type. AMX TDS (Television Delivery System)

  • Page 66: Transmitter Setup - Tuner Setup (Dtv-Tx01-Dvb-T)

    Select Tuner B Setup in the Manage Transmitters page to access Tuner B Setup options. The configuration options are identical for both Tuners. The only difference is that the changes made are applied to Tuner B. AMX TDS (Television Delivery System)
  • Page 67 "Full Stream" is a technology that uses a hardware accelerated filtering method to improve the performance and visual quality of streaming video playback. Note: If streaming has been changed between Full Stream and individual channel selection the unit will automatically reboot. AMX TDS (Television Delivery System)
  • Page 68 Disable all Channels: Click to disable (and de-select) all channels from all streams. Note: If the tuner unit is currently streaming, the unit may reboot depending on the stream type. AMX TDS (Television Delivery System)

  • Page 69: Transmitter Setup - Tuner Setup (Dtv-Tx02-Dvb-S)

    Tuner A can handle a single (frequency) stream, with a maximum total of five channels per stream, unless Full Stream is selected.  Tuner B can output up to five channels, but does not support Full Stream. AMX TDS (Television Delivery System)
  • Page 70 The "Full Stream" option is available only for Tuner A: • Tuner A can perform a full stream or output up to 5 channels. • Tuner B can output up to 5 channels, but does not support Full Stream. AMX TDS (Television Delivery System)

  • Page 71: Transmitter Setup - Firmware Upgrade

    Transmitter Setup - Firmware Upgrade Select Firmware Upgrade in the Manage Transmitters page to access the options shown in : FIG. 79 Transmitter Setup - Firmware Update The options on the Transmitter Setup - Firmware Update page include: AMX TDS (Television Delivery System)
  • Page 72 Master, and then loaded to the units. At the point that the file is loaded to the units, a 0 - 100% indicator is presented on the Firmware Update page.  Do not interrupt the upload operation during an upgrade.  See the Firmware Upgrades section on page 83 for details. AMX TDS (Television Delivery System)

  • Page 73: Transmitter Setup - Diagnostic Logs

    Click to send the Setup Log (or configuration) of the specified Transmitter to port 23. Note: The data is in XML format. • All Tx Units: Check this option to send the Setup Log of all Transmitters to port 23. AMX TDS (Television Delivery System)

  • Page 74: Receiver Setup Pages

    Receiver Setup - Network Settings Manage Unit • Device List: The Manage Unit window displays a list of all Receivers connected to the Master. • Refresh List: Click to refresh the Receivers list (in the Manage Unit window).: AMX TDS (Television Delivery System)
  • Page 75 Note: It can take up to 5 seconds before the poll will state the unit is offline. • Refresh: Click to refresh the unit status. Reset to Default • Reset to default: Click to reset the Network Settings for selected Receiver to DHCP. AMX TDS (Television Delivery System)

  • Page 76: Receiver Setup - Channel Setup

    Click to de-select all channels. • Enable All Channels: Click to enable all channels in the list. • All Units: Select this option to save the channel settings on this Receiver to all Receivers in the system. AMX TDS (Television Delivery System)

  • Page 77: Receiver Setup - Output Settings (Dtv-Rx02-Hd)

    See the DTV-RX02-HD Receivers - Supported Output Resolutions section on page 11 for details. • All Units: Select this option to set the selected Video Output Resolution setting to all Receivers. • Save: Click to save the current Video Output Resolution setting. AMX TDS (Television Delivery System)

  • Page 78: Receiver Setup - Output Settings (Dtv-Rx01-Sd)

    Click the down arrow to select the aspect ratio setting for the selected Receiver. • All Units: Select this option to set the selected Picture Aspect setting to all Receivers. • Save: Click to save the current Picture Aspect setting. AMX TDS (Television Delivery System)
  • Page 79 • Upload New IR • Browse - Click to browse and select a new IR library file to upload to the selected File: Receiver. • Submit - Click to upload the selected IR file to the selected Receiver. AMX TDS (Television Delivery System)

  • Page 80: Receiver Setup - Firmware Upgrade

    Firmware updates typically take about 10 minutes to complete. The firmware file is initially loaded onto the Master, and then loaded to the units. At the point that the file is loaded to the units, a 0 - 100% indicator is presented on the Firmware Update page. AMX TDS (Television Delivery System)

  • Page 81: Receiver Setup - Diagnostic Logs

    Note: The data is in XML format. Remote Communication • Send Command: This text field allows you to send a UDP command to the selected Receiver: Enter the command string in the text field, and click Send to send the string. AMX TDS (Television Delivery System)

  • Page 82: External Av Setup Page

    External AV command button FIG. 89 External AV Setup Page The options on this page allow you to add and configure externally sourced TDS streams (such as from a MAX-CSE): External AV Setup Page Options Add New External AV Source •...

  • Page 83: System Setup Page

    Click the System Setup command button (FIG. 90) to access the System Setup page described below (FIG. 91). FIG. 90 System Setup command button FIG. 91 System Setup The options on this page allow you to configure system-level options for the TDS system: AMX TDS (Television Delivery System)
  • Page 84 Time Zone Modify Time: Click to open the Modify Time drop-down menu to set the time zone for the TDS system, relative to GMT in 1-hour increments (+/- 12 hours). Update: Click to update the Time Zone settings. Extended Log Information Enable extended data log: Click to enable extended data log information.
  • Page 85 Click to disable the current System Maintenance Control settings immediately. Management Software This read-only field indicates the version of Duet Module currently loaded on Version: the DTV-MA01. Note: The Duet Module is the source for these Digital TV Configuration Manager pages. AMX TDS (Television Delivery System)
  • Page 86 Digital TV Configuration Manager AMX TDS (Television Delivery System)

  • Page 87: Serial Commands

    Gateway Address in order for the DTV system to work correctly. This applies to units that uti- lize DHCP and to units that have been assigned Static IP addresses. If you are using DHCP, verify that these address assignments are provided by the DHCP Server. AMX TDS (Television Delivery System)

  • Page 88: Terrestrial/Satellite (Standard Definition) Serial Commands

    • G = Frontend - Type of Tx it is (DVB-T, S or cable) • H = whether the signal is encrypted • I = whether the CAM is being used • J = The number of PIDs being used AMX TDS (Television Delivery System)

  • Page 89: Status

    • F = What the audio type is set to (0 for analogue and spdif) • G = Whether OSD is on or off (0 off, 2 on) • H = Whether the signal is being decrypted AMX TDS (Television Delivery System)
  • Page 90 Serial Commands AMX TDS (Television Delivery System)

  • Page 91: Firmware Upgrades

    Press the Power Switch on the front panel to power the unit on (FIG. 93). Power Switch FIG. 93 DTV-MA01 (front panel) When the unit is fully booted up, click on the Knopflerfish desktop UI and select the AMX-TDS bundle (FIG. 94). AMX TDS (Television Delivery System)
  • Page 92 C:\Program Files\AMX\TDS Management\ In the Knophlerfish desktop UI: Select the AMX-TDS bundle. Select Bundles > Update Selected Bundles. Click the Start toolbar button, or select Start on the Bundle menu, to restart the AMX-TDS bundle. AMX TDS (Television Delivery System)

  • Page 93: Upgrading Firmware On Dtv Transmitters And Receivers

    Before attempting to upgrade the firmware, you must have the appropriate *.DST file for your DTV Transmitter and/or Receiver.  Check www.amx.com for the latest device firmware files. Upgrading Firmware on DTV Transmitters Access the Digital TV Configuration Manager (see the Digital TV Configuration Manager section on page 53).

  • Page 94: Upgrading Firmware On Dtv Receivers

    Select the desired firmware file and click Upload. Alternatively, click Upload To All to upgrade all Receivers to the new firmware. The file is initiated and loaded onto the NetLinx Master before it is uploaded into the unit. This process can take over 10 minutes and should not be interrupted. AMX TDS (Television Delivery System)

  • Page 95: Appendix A: Faqs And Recommendations

    FAQs The System is locking up, or generally is having issues streaming.  Reboot the DTV-MA01 or stop and re-start the AMX TDS bundle, in the Knopflerfish desktop UI (see FIG. 94 on page 84).  Select System Factory Reset in the System Setup page to initiate a full factory reset on the DTV-MA01 (see the System Setup Page section on page 75).

  • Page 96: Recommendations

    Log out of Windows. The DTV-MA01 will automatically log back in and restart the Knopflerfish desktop UI and the AMX-TDS bundle.  Select the AMX-TDS bundle in the Knopflerfish desktop UI, select Stop on the toolbar, then select Start on the toolbar (see FIG. 94 on page 84). Unable to scan DVB-S channels Verify that the LNB and 22kHx tone have been set correctly.

  • Page 97: Appendix B: Network Recommendations

    DTV Management Software is required for managing all TDS devices on the network. The AMX NetLinx controller transmits a multicast beacon to discover TDS devices on the system and later sends UDP packages to control and communicate with each device.

  • Page 98: Power Over Ethernet

    All network connections should be 100m or less. DHCP Server TDS devices are delivered with DHCP set as default, this can be changed to static if required, but otherwise a DHCP server is required for managing and assigning IP’s to each unit.

  • Page 99: Appendix C: Lnb Recommendations For Dtv-Tx02-Dvb-S Installations

    Introduction This tech note briefly describes Satellite Low Noise Block down-converters (LNBs) and recommended methods for interfacing AMX DTV-TX02-DVB-S units. Introduction To Satellite LNBs An LNB is used to down convert high satellite frequencies down to an appropriate Intermediate Frequency (IF) for distributing over cable and being received by a suitable receiver.

  • Page 100: Recommendations For Installing Dtv-Tx02-Dvb-S - Large System With Quattro Lnb

    LNB and not re-tuned regularly. FIG. 97 shows a typical recommended installation for the AMX DVB-S receiver. Various options are available, including alternative manufacturers for the satellite amplifier, and the active splitters shown could be replaced by passive alternatives if the number of receivers is small and the associated signal lose is acceptable.

  • Page 101: Recommendations For Installing Dtv-Tx02-Dvb-S - Small System With Quad Lnb Or Multiswitcher

    An alternative to using a Quad Compatible Multiswitch for generating the DC Voltage and tone, is the ETL Model 2772-xx-E range that provides switchable LNB power and tone injection. This 19in rack system provides a more flexible system enabling the user to switch receivers between LNBs without changing the installation. AMX TDS (Television Delivery System)
  • Page 102 Injecting DC Voltage or Tone onto Individual Line If ‘high’ band frequencies are not required, the 22khz tone inserter can be removed, however a 13V or 18V DC voltage are always required to switch the multiswitch outputs. AMX TDS (Television Delivery System)

  • Page 103: Notes And Examples

    The FEC should be entered as 7 (the default setting). If the frequency to be entered into the web pages is greater than 2150MHz, the Local Oscillator frequency would need to be changed from 9750MHz to 10600MHz, by injecting 22kHz tone. AMX TDS (Television Delivery System)
  • Page 104 Appendix C: LNB Recommendations for DTV-TX02-DVB-S Installations AMX TDS (Television Delivery System)
  • Page 105 FAQs and Recommendations AMX TDS (Television Delivery System)
  • Page 106 - Schedules and registration for any AMX University course - Travel and hotel information - Your individual certification requirements and progress 3000 RESEARCH DRIVE, RICHARDSON, TX 75082 USA • 800.222.0193 • 469.624.8000 • 469-624-7153 fax • 800.932.6993 technical support • www.amx.com...

Table of Contents
