Focal Point KENSINGTON REALITY Installation, Servecing And User Instructions

Coal effect
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
KENSINGTON
REALITY
Coal e e ffect
gas f f ires
INSTALLATION, S S ERVICING A A ND
USER I I NSTRUCTIONS
All i i nstructions m m ust b b e h h anded t t o t t he u u ser f f or s s afekeeping
Revision A 01/99
Country(s) of destination: GB, IE
Focal Point Fires plc, Avon Trading Park, Christchurch, Dorset BH23 2BT
: (01202) 499330
Fax: (01202) 499326
www.focalpointfires.co.uk
e-mail: sales@focalpointfires.co.uk

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KENSINGTON REALITY and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Focal Point KENSINGTON REALITY

Summary of Contents for Focal Point KENSINGTON REALITY

  • Page 1 All i i nstructions m m ust b b e h h anded t t o t t he u u ser f f or s s afekeeping Revision A 01/99 Country(s) of destination: GB, IE Focal Point Fires plc, Avon Trading Park, Christchurch, Dorset BH23 2BT : (01202) 499330 Fax: (01202) 499326 www.focalpointfires.co.uk...

  • Page 2: Table Of Contents

    Sec c tion Contents s Pag g e N N o. Sec c tion Contents s Pag g e N N o. Cable Fixing Important Notes Fitting the Burner Tray Appliance Data Fuel Bed Layout Installation Requirements 10.0 Fitting the Casing Site Requirements 11.0 Testing and Commissioning...

  • Page 3: Appliance D D Ata

    APPLIANCE D D ATA Gas Group G20 Natural Gas CAT I2H G31 Propane CAT I3P Inlet Pressure 20 mbar 37 mbar Max Energy Input (gross) 6.2 kW 6.2 kW Min Energy Input (gross) 3.5 kW 3.5 kW Pilot Energy Input (gross) 210 W 210 W Setting Pressure...

  • Page 4: Site Requirements

    SITE R R EQUIREMENTS The fireplace opening should be inspected and repairs made where necessary. Any chair brick or fireback may be left in place. The opening WIDTH and HEIGHT dimensions should be between 300mm and 440mm wide, and 505mm to 570mm high.

  • Page 5: Debris Collection Space

    SITE R R EQUIREMENTS ( ( continued) Any type of fire surround used with this appliance must be adequately sealed to the wall and floor. A combustible shelf may be fixed to the wall above the fire, providing that it complies with the dimensions given below.

  • Page 6: Unpacking The Appliance

    PREFABRICATED F F LUE B B OXES This appliance can be fitted into a number of proprietary flue boxes provided that the minimum dimensions given in the diagram below are complied with. Cons s truc c tional N N ote: The frame of the fire, any back panel or other infill panels, and the flue box must be sealed together so that there is no possibility of leakage between them.

  • Page 7: Component Checklist

    COMPONENT C C HECKLIST QUA A NTITY DESCRIPTION Firebox and burner tray assembly. Moulded ceramic fibre combustion matrix. Individual ceramic coals. Ceramic fibre side cheeks Ceramic brick panel. Cable fixing kit; 2 cables, 2 tensioners, 2 cable clamps, 4 fixing eyes, 4 rawlplugs Sealing grommet Lengths of adhesive sealing strip.

  • Page 8: Preparing The Opening

    PREPARING T T HE O O PENING Before installing the fire, check the flue for correct operation using a smoke pellet. All of the smoke should be drawn up the flue and exit correctly from the terminal. If problems are found DO NOT fit the fire until corrective action is completed.

  • Page 9: Cable Fixing

    CABLE FIXING Drill four holes as shown in the diagram and fit the fibre rawl plugs. If the fireplace does not allow for the exact layout shown, A. 250mm the eyebolts should be fixed to give a similar configuration as B.

  • Page 10: Fuel Bed Layout

    FUEL BED LAYOUT Place the brick panel against the rear of the firebox Place the ceramic combustion matrix onto the burner and the ceramic side cheeks onto the matrix. Place the front row of six coals on to the matrix, with the two coals second front each end turned on their sides.

  • Page 11: Fitting The Casing

    FUEL BED LAYOUT ( ( continued) Coals may be rotated slightly within their positions to give a good visual effect. The fire is designed to operate correctly with the coals supplied when assembled according to the instructions. Never add to the fifteen coals, or change them for a different type. Never throw rubbish or other matter onto the coal bed.

  • Page 12: Spark Failure

    11.1 OPERATING THE APPLIANCE ( ( continued) When the pilot lights after the spark, keep the knob depressed for approx- imately ten seconds. Now release the knob and the pilot should stay alight. If the pilot is extinguished during use, wait three minutes before repeating the ignition procedure.

  • Page 13: Testing For Spillage

    12.0 FLUE SPILLAGE MONITORING SYSTEM (continued) The aeration hole of the pilot must be carefully cleaned out on each annual service to ensure continued function of the ODS. The spillage monitoring system shall not be adjusted, modified, or put out of operation by the installer. Any spare parts fitted MUST be of a type supplied for the purpose by the appliance manufacturer.

  • Page 14: Servicing

    14.0 SERVICING Isolate the fire from the gas supply. Ensure that the fire is fully cold before attempting service. A suggested procedure for servicing is detailed below. 1. Lay out the dust sheet and tools. 2. Carefully remove the ceramic components. 3.

  • Page 15: Pilot Assembly

    14.3 REMOVING THE BURNER TRAY Remove the two screws retaining the decorative casing and lift away. Remove the ceramics and the data/control plate. Remove the two screws securing the tray legs to the firebox. Pull tray forward slightly and lift away. Refitting is the reverse of above, being sure to engage the tray location lugs on the shelf at the rear of the firebox.

  • Page 16: Troubleshooting Guide

    15.0 TROUBLESHOOTING G G UIDE Fire s s parks s b b ut p p ilot d d oes s n n ot l l ig g ht No gas to fire, check isolators are open. Pipework blockage, clean out. Air not fully purged, repurge supply or wait longer.
  • Page 17 USER INST T RUCT T IONS Sec c tion Contents s Pag g e N N o. Important Notes Firefront Clearances to Combustibles Ventilation Operating Instructions Flue Spillage Monitoring System Cleaning Coals and Ceramics Servicing IMPORTANT N N OTES The installation of this fire MUST only be carried out by a competent person (such as a CORGI registered fitter) in accordance with the Gas Safety (Installation and Use) Regulations 1998, the relevant British Standards, Codes of Practice, the Building Regulations and the manufacturers’...
  • Page 18 FIREFRONT This fire is supplied with a particular style of firefront. Use of the firefront will ensure an adequate airflow under the firebed for the correct functioning of this appliance. Compliance with safety standards cannot be guaranteed if another style of front is used. CLEARANCES T T O C C OMBUSTIBLES A combustible shelf may be fixed to the wall above the fire, providing that it complies with the dimensions given below.

  • Page 19: List Of Spares

    FLUE S S PILLAGE M M ONITORING S S YSTEM This fire is fitted with a flue spillage safety device (ODS). If the fire shuts down during use for no apparent reason then several reasons may be suspected. If a door or window has been opened creating a draught, then pilot disturbance could be the problem, and removal of the draught should resolve this.
