INST T ALLAT T ION I I NST T RUCT T IONS
P P relim m in n ary N N otes B B efore I I n n stallation n
This appliance is an Inset Live Fuel Effect appliance that provides radiant
warmth utilising the latest type burner technology.
The fire is designed to fit various types of fireplaces and natural draught flues as
listed in the Installation Requirements.
The appliance must be installed by a competent person in accordance with
Gas Safety (Installation and Use) Regulations 1998. It is strongly recommended
that a CORGI registered engineer be used for this purpose.
Read all these instructions before commencing installation.
This appliance must be installed in accordance with the rules in force and only
used in a sufficiently ventilated space.
The appliance is designed for installation on to a non-combustible hearth of at
least 300mm depth.
This appliance is factory set for operation on the gas type, and at the pressure
stated on the appliance data plate.
This appliance is available in either a manual (rotary) version, or a battery pow-
ered remote control version. These instructions cover both control options. See
the relevant section of these instructions for further details.
