Coal Effect Gas Fire
INSTALLATION, SERVICING
AND USER INSTRUCTIONS
All instructions must be handed to the user for safekeeping
Revision B 11/03
Country(s) of destination: GB, IE
Focal Point Fires plc, Avon Trading Park, Christchurch, Dorset BH23 2BT
: (01202) 499330
Fax: (01202) 499326
www.focalpointfires.co.uk
e-mail: sales@focalpointfires.co.uk
Advertisement
Table of Contents
Related Manuals for Focal Point JEMEZ
Summary of Contents for Focal Point JEMEZ
- Page 1 AND USER INSTRUCTIONS All instructions must be handed to the user for safekeeping Revision B 11/03 Country(s) of destination: GB, IE Focal Point Fires plc, Avon Trading Park, Christchurch, Dorset BH23 2BT : (01202) 499330 Fax: (01202) 499326 www.focalpointfires.co.uk e-mail: sales@focalpointfires.co.uk...
-
Page 2: Installation Instructions
INSTALLATION INSTRUCTIONS Preliminary Notes Before Installation This appliance is an Inset Live Fuel Effect appliance which provides radiant and convected warmth utilising the latest type burner technology. The fire is designed to fit various types of fireplaces and natural draught flues as listed in the Installation Requirements. -
Page 3: Table Of Contents
Section Contents Page No. Section Contents Page No. Cable Fixing Important Notes Fitting the Burner Tray Appliance Data Fuel Bed Layout Installation Requirements 10.0 Fitting the Fireframe/Hood Site Requirements 11.0 Testing and Commissioning Debris Collection Space 11.1 Operating the Appliance Ventilation 11.2 Spark Failure... -
Page 4: Appliance Data
APPLIANCE DATA Gas Group G20 Natural Gas CAT I2H G31 Propane CAT I3P Inlet Pressure 20 mbar 37 mbar Max Energy Input (gross) 6.2 kW 6.2 kW Min Energy Input (gross) 3.5 kW 3.5 kW Pilot Energy Input (gross) 210 W 210 W Setting Pressure 17.5 mbar... -
Page 5: Site Requirements
SITE REQUIREMENTS The fireplace opening should be inspected and repairs made where necessary. Any chair brick or fireback may be left in situ, providing that the dimensional requirements for debris collection space and spigot clearances are met. See diagram below.. The opening WIDTH and HEIGHT dimensions should be between 380mm and 440mm wide, and 540mm to 575mm high. -
Page 6: Debris Collection Space
SITE REQUIREMENTS (continued) Any type of fire surround used with this appliance must be adequately sealed to the wall and floor. A combustible shelf may be fixed to the wall above the fire, providing that it complies with the dimensions given below. -
Page 7: Unpacking The Appliance
PREFABRICATED FLUE BOXES This appliance can be fitted into a number of proprietary flue boxes provided that the minimum dimensions given in the diagram below are complied with. Constructional Note: The frame of the fire, any back panel or other infill panels, and the flue box must be sealed together so that there is no possibility of leakage between them. -
Page 8: Component Checklist
COMPONENT CHECKLIST QUANTITY DESCRIPTION Firebox and burner tray assembly. Decorative frame Decorative hood Cast front fret with seperate ashpan door. Moulded ceramic fibre combustion matrix. Individual ceramic coals. Ceramic brick panel. Cable fixing kit; 2 cables, 2 tensioners, 2 cable clamps, 4 fixing eyes, 4 rawlplugs Sealing grommet Lengths of adhesive sealing strip. -
Page 9: Preparing The Opening
PREPARING THE OPENING Before installing the fire, check the flue for correct operation using a smoke pellet. All of the smoke should be drawn up the flue and exit correctly from the terminal. If problems are found DO NOT fit the fire until corrective action is completed. -
Page 10: Cable Fixing
CABLE FIXING Drill four holes as shown in the diagram and fit the fibre rawl plugs. If the fireplace does not allow for the exact layout shown, A. 250mm the eyebolts should be fixed to give a similar configuration as B. -
Page 11: Fuel Bed Layout
FUEL BED LAYOUT This fire is supplied with 11 ceramic coals. The coals may vary slightly in size, shape, in order to allow a realistic layout. Firstly, remove the ceramic compnents from their protective packaging, and place the brick panel against the rear of the firebox Place the ceramic combustion matrix onto the burner. -
Page 12: Fitting The Fireframe/Hood
10.0 FITTING THE DECORATIVE FRAME AND HOOD The appliance is supplied with a decorative frame and hood. The frame attaches to the firebox using either four magnetic pieces, or as a three piece clip-on assembly. The side pieces of the clip on assembly should be pushed into position first, followed by the top bar, which should overlap the sides. -
Page 13: Spark Failure
11.2 SPARK FAILURE The gap between the spark electrode and the pilot should be 3.5 - 4.5mm to produce a good spark. There should be no need to adjust this. If under any circumstances the electric spark fails, the pilot may be lit manually by proceeding with the ignition sequence as previously described, and after turning the control knob through the spark position, the knob should be held in and the pilot lit with a taper. -
Page 14: Testing For Spillage
12.1 TESTING FOR SPILLAGE Close all doors and windows to the room containing the appliance. Let the fire run on HIGH for five minutes. Take a smoke match, light it, and using a smoke match tube, hold it at the top edge of the fire opening, 25mm down and 25mm in. -
Page 15: Servicing
14.0 SERVICING Isolate the fire from the gas supply. Ensure that the fire is fully cold before attempting service. A suggested procedure for servicing is detailed below. 1. Lay out the dust sheet and tools. 2. Carefully remove the ceramic components. 3. -
Page 16: Pilot Assembly
14.3 REMOVING THE CONVECTOR BOX Remove the burner tray as described previously. Protect the hearth from potential damage. Unroll the coiled tensioner cables from the rear of the firebox. Remove the securing nipples and tensioner adjusters. The firebox is now released from the opening and can be slid outward onto the hearth. Inspect the fireplace opening for debris and if excessive rectify the flue before proceeding further. -
Page 17: Troubleshooting Guide
15.0 TROUBLESHOOTING GUIDE Fire sparks but pilot does not light No gas to fire, check isolators are open. Pipework blockage, clean out. Air not fully purged, repurge supply or wait longer. Spark earthing to metal work, reset gap correctly. Blocked pilot, clean out internally. Pilot lights but then goes out Severe restriction in gas supply, clear obstruction. -
Page 18: User Instructions
USER INSTRUCTIONS Section Contents Page No. Important Notes Firefront Clearances to Combustibles Ventilation Operating Instructions Flue Spillage Monitoring System Cleaning Coals and Ceramics Servicing IMPORTANT NOTES The installation of this fire MUST only be carried out by a competent person (such as a CORGI registered fitter) in accordance with the Gas Safety (Installation and Use) Regulations 1998, the relevant British Standards, Codes of Practice, the Building Regulations and the manufacturers’... -
Page 19: Clearances To Combustibles
FIREFRONT This fire is supplied with a particular style of firefront. Use of the firefront will ensure an adequate airflow under the firebed for the correct functioning of this appliance. Compliance with safety standards cannot be guaranteed if another style of front is used. CLEARANCES TO COMBUSTIBLES A combustible shelf may be fixed to the wall above the fire, providing that it complies with the dimensions given below. -
Page 20: List Of Spares
FLUE SPILLAGE MONITORING SYSTEM This fire is fitted with a flue spillage safety device (ODS). If the fire shuts down during use for no apparent reason then several reasons may be suspected. If a door or window has been opened creating a draught, then pilot disturbance could be the problem, and removal of the draught should resolve this.
