Icom IC-F5060 SERIES Instruction Manual page 9

SCAN ADD/DEL (TAG) KEY
➥ Push to add the channel to, or delete it from, the current
scan group.
1. Push to display the scan group, then push [CH Up] or [CH Down]
to select the desired group.
2. Push to add or delete the channel to or from the selected scan
group.
3. Hold down for 1 second to exit the scan group selection mode.
➥ Push this key while the scan is paused (a signal is de-
tected) on a channel (except for priority channel,) and the
channel is cleared from the scan group.
Depending on the setting, the cleared channel is added
to the scan group again after the scan is cancelled.
PRIO A/B KEYS
➥ Push to select Priority A or Priority B channel.
➥ Hold down [Prio A (Rewrite)] or [Prio B (Rewrite)] for 1
second to rewrite the operating channel as the Priority A
or Priority B channel.
MR-CH 1/2/3/4 KEYS
Push to directly select the memory channel 1 to 4.
PANEL DESCRIPTION
MONI (AUDI) KEY
➥ Push to mute and release the CTCSS (DTCS) or 2-Tone
squelch mute. Open any squelch/deactivate any mute
while holding down this key. (Only in the LMR mode)
➥ Activates one of (or two of) the following functions on
each channel independently: (Only in the PMR mode)
• While holding down, audio is emitted ('Audible' mode).
• Push to mute the channel ('Inaudible' mode).
• Push to unmute the channel ('Audible' mode).
• After the communication is finished, push to send a 'reset code'.
(5-Tone/BIIS operation only)
NOTE: The 'Audible' (unmute) mode may automatically
return to the 'Inaudible' (mute) mode after a specified
period, depending on the presetting.
PUBLIC ADDRESS KEY
Push to activate the Public Address (PA) function for voice
amplification. When the PA function is activated, the audio
output can be separately controlled from the transceiver with
[CH Up]/[CH Down].
• This function is usable when an external unit, such as a audio
amplifier, speaker, and so on is additionally connected.
• Push this key, then speak into the microphone while holding down
[PTT].
