TECHNICAL DATA

— switchable voltage:
— switchable current:
— temperature measurement range:
— adjustable temperature range:
— temperature measurement accuracy:
— temperature calibration range:
— selectable switching sensitivity:
— storage temperature:
— battery voltage:
— power consumption:
— battery lifetime:
— dimensions:
— weight:
— temperature sensor type:
24V AC/DC to 250V AC, 50Hz
8A (2A inductive load)
5 to 35°C (in 0. 1 °C increments)
5 to 35°C (in 0.5°C increments)
±0.5°C
±3°C (in 0. 1 °C increments)
±0. 1 °C; ±0.2°C; ±0.3°C
-10°C to +40°C
2 x 1.5V ALKALINE batteries
(LR6 type; AA size)
1.3mW
approx. 1 year
130 x 80 x 22mm
120g
NTC 10kΩ ±1% at 25°C
45
