3. PUTTING THE THERMOSTAT INTO OPERATION,
BASIC SETTINGS

3.1 Inserting batteries

The battery compartment is in the inner side of the front panel of the
housing. Insert 2 AA alkaline batteries (LR6 type) in accordance
with the diagram in the battery compartment. After the batteries
have been inserted, the display flashes the day, time and program
number as well as the adjusted and measured temperatures. (If this
information fails to appear on the display, press the "RESET" button
located on the main panel of the thermostat. After the batteries have
been inserted, snap the front panel of the device into the rear panel
and press the "SET" button. After the "SET" button is pressed, the
display stops flashing, the thermostat goes to the main screen and
the setting process can be started.
