Key to ICM Diagram

Pin Description
A1 Supply for indicator relays
A2 Left indicators output
A3 -
A4 -
A5 Fog switch input
A6 -
A7 -
A8 Headlamp powerwash output
A9 A.c. recirc. control output
A10 Supply for recirc. & powerwash control
A11 Horn output
A12 Supply for horn & foglamps
A13 Supply for indicator current sense
A14 Right indicators output
A15 Battery ground
A16 -
A17 -
A18 -
A19 LED lighting option input
A20 Left indicator switch input
A21 Right indicator switch input
A22 Intermittent variable input
A23 DRL option input
A24 Battery ground
A25 Fog lights output
A26 Indicators supply after current sensing
B1 Main beam flash input
B2 Recirc. switch input
B3 Hazard switch input
B4 Wiper int. input
B5 Washer monitor input
B6 HRW switch input
B7 A.c. request switch input
B8 Driver door switch input
B9 CDL switch illumination
B10 CDL switch monitor
B11 Lock status input
B12 Unlock status input
B13 -
B14 Passenger door switch input
B15 Headlamp switch input
B16 Sidelamps switch input
Pin Description
C1 Main beam flash power input
C2 Int. fan fast input
C3 Fog switch illum. input
C4 -
C5 Drive away locking output
C6 Sidelights switch illum. output
C7 HRS output
C8 Recirc. switch illum. output
C9 A.c. request output
C10 -
C11 -
C12 Diagnostic comms. KW2000
D1 ICM main supply & main lighting
D2 -
D3 HRS switch illumination
D4 Ignition switch input
D5 Headlamp relay output
D6 Hazard switch illumination
D7 Hazard active illumination
D8 A.c. switch illumination
D9 Headlamps switch illum. output
D10 -
D11 Door open output
D12 Sidelights output
D13 Main beam solenoid output
D14 Int. fan speed input
D15 Horn switch output
D16 -
D17 Eng. man. rpm input
D18 Wiper park input
D19 Wiper relay control output
D20 Auto demist input
D21 Indicators fault monitor input
D22 -
Section MR
Page 25
