Publication Part No. C132T0324
© Lotus Cars Ltd 2011
&
OWNER'S HANDBOOK
USA
*Vehicles from VIN BH_11178 equipped with Lotus Dynamic Program Management
Lotus Cars USA Inc.
2236 Northmont Parkway, Duluth, Georgia 30096.
Tel: 770 476 6540 Fax: 770 476 6541
www.LotusCars.com
oh_evoraS_a_USA.indd 1
28/04/2011 11:52:58

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Evora 2011 and is the answer not in the manual?

Questions and answers

Related Manuals for Lotus Evora 2011

Summary of Contents for Lotus Evora 2011

  • Page 1 Publication Part No. C132T0324 © Lotus Cars Ltd 2011 & OWNER’S HANDBOOK *Vehicles from VIN BH_11178 equipped with Lotus Dynamic Program Management Lotus Cars USA Inc. 2236 Northmont Parkway, Duluth, Georgia 30096. Tel: 770 476 6540 Fax: 770 476 6541 www.LotusCars.com...
  • Page 2 & oh_evoraS_a_USA.indd 2 28/04/2011 11:52:59...

  • Page 3: Table Of Contents

    CONTENTS 1. FASCIA OVERVIEW ........... 10 2. INTRODUCTION .............. 11 3. IMPORTANT SAFETY INFORMATION ........ 13 Care of the Environment ............18 Reporting Safety Defects ............19 4. VEHICLE IDENTIFICATION ........... 20 5. KEYS & SECURITY ALARM Transmitter Keys ............... 22 Vehicle Security Alarm ............23 Disarming the Alarm/Unlocking ........
  • Page 4 Seat Belt Precautions ............37 Airbag Supplementary Restraint System ........ 39 Airbag Tell Tale ..............41 Airbag Deployment ............... 42 Child Restraints ..............44 Automatic Locking Retractor ..........46 Persons with Disablilites ............47 8. MIRRORS & DOOR WINDOWS Interior Rear View Mirror ............48 Door Mirrors ................
  • Page 5 Electronic Brake Distribution (EBD) ........88 Electronic Differential Lock (EDL) ........... 88 Parking Brake ..............88 Gear Lever (manual transmission) ......... 90 Lotus Dynamic Performance Management......91 Sport Mode ................93 Cruise Control ............... 95 Homelink ................97 12. STARTING PROCEDURE & ENGINE BREAK-IN Operation Temperature Limit ..........
  • Page 6 13. EXTERNAL OPERATIONS Fuel Requirement ............... 102 Fuel Filling ................104 Tailgate ................106 Child Entrapment ..............109 Front Body Access Hatch ............. 110 14. SERVICING & MAINTENANCE Bodycare ................111 Body Features ............... 111 Paint Care ..............112 Ventilation ..............112 Paintwork Polishing ............
  • Page 7 14. TIRES & WHEELS Tires .................. 133 Glossary of Terms ............133 Tire Safety ..............133 Tire Care ..............134 Tire Characteristics ............135 Winter Tires ..............136 Tire Chains ..............136 Replacement Tires ............136 Uniform Tire Quality Grading ......... 138 Tire Emergency Inflator Aerosol ........
  • Page 8 17. RECOVERY & LIFTING Recovery Eye ..............164 Car Tie-Down ..............165 Towing a Trailer ..............165 Lifting The Evora ..............166 Fuel Tank Chassis Panel ............167 18. ACCESSORIES Accessories & Modifications ..........168 Storing The Evora ..............170 19.
  • Page 9 oh_evoraS_a_USA.indd 9 28/04/2011 11:52:59...

  • Page 10: Fascia Overview

    Master lighting switch - see page 70 Blank Sport mode switch - see page 93 Lotus DPM off switch - see page 92 Tell tale lamps - see page 55 Tailgate release - see page 26, 106 Heated seat switch (LH) - see page 81...

  • Page 11: Introduction

    2. INTRODUCTION Thank you for purchasing a Lotus product. We are sure you will enjoy being part of the Lotus family. The Evora has been designed for the discerning driver, and aims to provide enjoyable motoring from a lightweight, distinctively styled and efficient package.
  • Page 12 • Powerful anti-lock four wheel disc brakes, with emergency braking Hydraulic Brake Assist (HBA), and stability aiding Electronic Brake Distribution (EBD). • Lotus Dynamic Performance Management (Lotus DPM), in conjunction with Electronic Differential Lock (EDL). • Tire Pressure Monitoring System (TPMS) • High geared responsive power steering, requiring only small steering wheel movements to alter course.

  • Page 13: Important Safety Information

    3. IMPORTANT SAFETY INFORMATION To help you make informed decisions about safety, this sec- tion details some important safety information about hazardous situations which, if not avoided, could result in death or serious injury. In addition, important safety information is also provided in forms including: • Safety labels on the car;...
  • Page 14 Lotus are undertaken. DO NOT allow servicing, repairs or modifications to be carried out by unskilled persons. Lotus dealers have trained staff who are best qualified to main- tain your car to the correct specification. Failure to comply with this may result in a crash in which you and others may be killed or seriously injured.
  • Page 15 (CO), which you can’t see or smell. It can cause unconscious- ness and death. • If you ever suspect exhaust gas is entering the cockpit, do not drive the car until the fault has been repaired. • In particular, running the engine in an enclosed space can let exhaust gas into the car, even more quickly if the interior fan is switched on.
  • Page 16 • DO NOT allow servicing or repairs to be carried out by un- skilled persons as this may adversely affect the handling and safety features on your car. Lotus dealers have trained staff who are best qualified to maintain your car to the cor- rect specification. oh_evoraS_a_USA.indd 16...
  • Page 17 Before Driving the Car: • Check tires for damage, wear and correct pressure. Incor- rect inflation pressure degrades vehicle handling (See ‘Tires’ on page 131). • Check all windows, mirrors and lights are clear and unob- structed and all lights are correctly working. • Check that the tailgate and front body access panel are cor- rectly latched; • Adjust the seat and mirrors, and familiarise yourself with the controls.

  • Page 18: Care Of The Environment

    Care of the Environment By virtue of its light weight, constructional process and fuel efficiency, the Lotus Evora has a low environmental impact compared with many road cars. All drivers should, however, be aware of the effect of engine exhaust emissions on the environ- ment and drive in a way which minimises pollution by: • anticipating traffic flow to avoid needless acceleration...

  • Page 19: Reporting Safety Defects

    National Highway Traffic Safety Administration (NHTSA) in addition to notifying Lotus Cars USA, Inc. 2236 Northmont Parkway, Duluth, Georgia 30096. Tel: 770 476 6540. If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety problem exists in a group of cars, it may order a recall and remedy campaign.

  • Page 20: Vehicle Identification

    intro25 ohe40 V.I.N. ON CHASSIS V.I.N. LABEL 4. VEHICLE IDENTIFICATION The Vehicle Identification Number (V.I.N.) is a unique 17-digit number used to identify the car for licencing, warranty, spares ordering and administrative purposes. The chassis frame is stamped with the V.I.N. on the crossmem- ber beneath the driver’s seat, accessible inside the cabin with the seat slid fully rearwards.
  • Page 21 ENGINE NUMBER intro24 Engine Number The 7-digit engine serial number is stamped on the LH rear flange of the cylinder block, alongside the clutch housing joint- face, and is viewable only from beneath after removal of the engine bay undertray and release of a heatshield fixing. oh_evoraS_a_USA.indd 21 28/04/2011 11:53:02...

  • Page 22: Keys & Security Alarm Transmitter Keys

    End button; Manual siren, tailgate Centre button; Disarm, mobilise, unlock Logo button; Arm & Lock TRANSMITTER KEY ohs128d 5. KEYS & SECURITY ALARM Transmitter Keys Two transmitter keys are provided with the car. The transmit- ter keys combine a coded mechanical blade with a three button transmitter head.

  • Page 23: Vehicle Security Alarm

    Vehicle Security Alarm The Lotus Evora is fitted as standard with a PFK 457 immobi- liser/alarm which includes the following features: • ‘Dynamic coding’ of the transmitter keys; Each time the transmitters are used, the encrypted rolling code is changed to guard against unauthorised code capture.

  • Page 24: Auto Re-Arm

    Alarm tell tale Speedometer LOTUS ohe3a Auto Re-arm If a door is not opened and closed within 2 minutes of a disarm- ing command, the alarm system will automatically re-arm. Automatic Immobilisation In order to provide a measure of vehicle security independent of any driver initiative, the system will automatically immobilise the engine’s cranking and fuel pump circuits after the ignition has...

  • Page 25: Alarm Tell Tale Summary

    Note: i) If the system is armed when a door is not fully shut, three triple beeps will sound as a warning and the doors will not be locked. Opening a door will not trigger the alarm. ii) If the system is armed when the tailgate is not fully closed, three warning double beeps will be heard, and the doors will not be locked.

  • Page 26: Turning Off The Interior Movement Sensor

    Turning Off the Interior Movement Sensor A microwave sensor mounted behind the centre console, will detect substantial physical movement within the cockpit, and trigger the alarm. If an animal is to be left in the vehicle, or if you wish to de- activate the interior movement sensor for any other reason, press once the transmitter logo button in the normal way to set the alarm, and then press a second time (within 2 seconds) to...

  • Page 27: Transmitter Key Battery Replacement

    Transmitter fob Carrier retaining tang Key blade Type CR2025 battery TRANSMITTER BATTERY REPLACEMENT oh102c Transmitter Key Battery Replacement The transmitter fobs will normally operate within a range of 5 metres from the car, but this may be reduced by the presence of other radio signals in the vicinity.

  • Page 28: Emergency Disarming/Mobilising

    Emergency Disarming/Mobilising If the key transmitter is damaged or fails to function, and a spare key is not available, the alarm system’s unique sPecific Identification Number (PIN) may be used to disarm the alarm provided that access is available to the cabin: Turn on the ignition.

  • Page 29: Disconnecting The Car Battery

    siren will beep. Within 10 seconds press any button on the next transmitter to be programmed (if applicable), and repeat this process for all remaining transmitters. When all transmitters have been programmed, wait for 10 seconds, or turn off the ignition. To disable a lost or stolen transmitter from the system, use the above procedure to programme 6 transmitters, if necessary repeatedly reprogramming the same transmitter if less than 6...

  • Page 30: Entry & Comfort

    6. ENTRY & COMFORT CAUTION Unlocked doors can be dangerous. Young children who get into unlocked cars may be unable to get out. Always lock the car whenever you leave it. Central Door Locking (CDL) The central door locking (CDL) operates on the driver’s and passenger’s doors in conjunction with the security alarm system.

  • Page 31: Interior Cdl Switch

    Door sill button LOTUS Interior switch ohe4 ohe22a Interior CDL Switch If it is desired to lock the doors from inside the car, for ex- ample to deter highjack attempts, press the door lock switch in the cluster inboard of the steering column, with ignition on or off.

  • Page 32: To Open The Doors From Inside

    Pull DOOR INTERIOR RELEASE ohe5 To open the doors from inside. WARNING Whether locked using the transmitter fob, CDL switch, sill but- tons or ‘drive away locking’ feature, the interior release handles will be disabled. This could inhibit emergency evacuation of the car.

  • Page 33: Locking The Doors Mechanically

    Lock Unlock LOCKING ohe6 2 minute delay. To lock both doors, press once the raised logo button on the transmitter key (see also Alarm System on page 23). Locking The Doors Mechanically In the event of a discharged vehicle battery, or an inoperative transmitter key, the right hand door may be locked by pressing down the door sill button, and holding the exterior handle raised as the door is closed.

  • Page 34: Seating & Safety Restraints

    SEAT ADJUSTMENT Backrest release Backrest handle angle handwheel Fore/aft lift bar ohe11 7. SEATING & SAFETY RESTRAINTS Seats On delivery of the car, first remove the protective plastic seat covers, if this has not already been done, and dispose of safely. To adjust the fore/aft position of a front seat, raise the lift bar beneath the front of the seat, and slide to the position required.

  • Page 35: Seat Belts

    SEAT BELT POSITIONING ohe24 CAUTION Ensure that no persons or objects will be trapped when adjust ing the seat. Seat Belts Seat belts provide important safety and comfort for the driver and passengers and have proven to be the single most effective safety device in reducing the risk of death or injury in a crash.
  • Page 36 but the belt reel will lock automatically whenever the car is subjected to braking, acceleration, or cornering forces, or on impact in a collision. Reel locking will also occur if the car is significantly tilted in any direction. In the event of a severe frontal impact sufficient to trigger the airbag system, a pre-tensioning device incorporated into each front seat belt retractor, will oper- ate to tighten the belt for increased protection of the front seat...

  • Page 37: Seat Belt Precautions

    Removing the child safety seat: 1. Unbuckle the safety belt. 2. Remove the child seat. 3. Ensure that the belt has fully retracted. At this point the au- tomatic locking feature is disengaged. Seat Belt Precautions WARNING • Ensure that the driver and passengers always wear seat belts and wear them properly.
  • Page 38 AIRBAG INFLATED ON IMPACT ohe9 contaminated, or damaged. Inspect regularly. • It is essential to replace the entire seat belt assembly if it has been used in a severe impact, even if damage to the as sembly is not obvious. In situations where the airbags have been deployed, the front seat belt pre-tensioner systems must also be replaced, and the seat belt anchorage points rigorously checked.

  • Page 39: Airbag Supplementary Restraint System

    DEPLOYMENT ohe9 Airbag Supplementary Restraint System (SRS) The Lotus Evora is equipped with advanced dual stage airbags for both the driver and front seat passenger, in conjunction with pre-tensioning seat belts for both front seat occupants. The airbag Supplementary Restraint System (SRS) is supplemental to the seat belts, and does not render the seat belts redundant.
  • Page 40 incorporated into the SRS control module, detects the rate of deceleration in a collision, and when appropriate, the first stage of airbag inflation is initiated. This causes the airbags to inflate at a rate calculated to provide appropriate protection, whilst minimising the potential for airbag induced injury, especially where an occupant is not positioned optimally at the triggering moment.

  • Page 41: Airbag Tell Tale

    • Airbags inflate with great force, in a fraction of a second. If you’re too close to an inflating airbag, as you would be if you were leaning forward, you could be killed or seriously injured. Seat belts help keep you in the correct position before and during a crash.

  • Page 42: Airbag Deployment

    Airbag Deployment After airbag deployment, the airbags, seat belt pre-tensioners and electronic control unit must be replaced by a Lotus dealer or other suitably qualified organisation. Component parts of the airbag system are located in various sites around the car.
  • Page 43 damaged restraint system may not properly protect the person using it, resulting in serious injury or even death in a crash. To help make sure your restraint systems are working properly after a crash, have them inspected and any necessary replacements made as soon as possible. • The safe temperature operating range of the airbag system is between -4 and +185°F (-20 and +85°C).

  • Page 44: Child Restraints

    Child Restraints WARNING Lotus strongly recommends that children are not carried in the front passenger seat of the Evora, due to the risk of death or serious injury if the child is too close to the fascia when the airbag inflates.
  • Page 45 Child Seat Latches (2+2 versions) Two latch brackets are provided at each rear seat position to allow the fitment of latch type child seats in the rear. The position of the latch brackets is indicated by the pictogram Some child seats require a top tether to secure the seat. In such cases, the tether should be fitted in the following man- ner: To Fit Top Tether...

  • Page 46: Automatic Locking Retractor

    Steel tube Loop Eye on back of inboard seat rail 4. Finally, hook the tether into the eye at the rear end of the front seat inboard mounting rail as shown in the illustration. Automatic Locking Retractor The safety belts for the front passenger seat and for both rear seats (if fitted), are equipped with an automatic locking retrac- tor which must be used if fitting a forward-facing child restraint system in that position.

  • Page 47: Persons With Disablilites

    Use of child restraints which are not compatible with the Evora may result in death or serious injury in the event of an accident. Lotus accepts no responsibility for death or injury caused by the fitment of any child restraint device not tested and approved by Lotus.

  • Page 48: Mirrors & Door Windows

    night MIRROR DIMMER ohe27 8. MIRRORS & DOOR WINDOWS Interior Rear View Mirror The mirror can be dimmed to reduce headlamp glare from following cars by pressing the lever on the underside of the mirror away from the windscreen. Press the lever towards the windscreen for daytime use.
  • Page 49 Mirror select Mirror adjust Joystick knob DOOR MIRROR CONTROL ohe10 WARNING The passenger side convex mirror makes objects seem smaller and farther away than when viewed through a flat mir- ror. Take care to judge distances and speeds correctly. If you move into a lane on your right when the car behind is too close, you could cause a collision and a crash.

  • Page 50: Door Windows

    Down Driver’s Passenger’s window window DOOR WINDOW SWITCHES ohe18 Door Windows WARNING • Do not leave children unattended in the car with the ignition key in position, to guard against injury caused by careless window operation. • Before closing a window, always check that no person or object will be trapped; incautious window operation could be dangerous, especially to children.

  • Page 51: Interior Lighting

    INTERIOR LAMP ohe16 NOTICE If the battery supply is interrupted, the one touch down and auto drop features will not function. There will also be an increased risk of damage to the door window seals until: each window is fully raised and the switch held for 2 seconds (a click will be heard).

  • Page 52: Glovebox

    LOTUS Glovebox switch ohe22a mum period of 2 minutes. If a door is opened, the footwell lamp will also light. On closing the door, the footwell lamp will be extinguished, but the interior and mood lighting will abide for 2 minutes or until the ignition is switched on.

  • Page 53: Instruments & Switches

    Column unlocked; Key insert/remove; accessories audio Ignition; services Engine cranking IGNITION SWITCH ohe23 9. INSTRUMENTS & SWITCHES Ignition Switch/Steering Lock The switch/lock is located on the right hand side of the steering column. With the key out of the switch, the steering column is locked, and the following electrical circuits will function: Locking and alarm system.
  • Page 54 ll Turn further clockwise to the ‘ignition’ position to activate all remaining electrical systems (note that some circuits require the engine to be running). WARNING Do not turn the key to position lll without referring to the later chapter ‘Starting Procedure & Engine Break-In’ (page 97).

  • Page 55: Tell Tale Lamps

    High engine speed Security alarm LOTUS Tachometer Speedometer TELL TALE LAMPS ohe3a TELL TALE LAMPS Tell tale lamps are incorporated into the instrument panel to provide important information about various vehicle systems. Bulb Check In order to check that the warning systems are functional, all...
  • Page 56 Maximum engine speed is governed for both the continuous and transient (during acceleration) states, and is detailed in the LOTUS later section ‘Tachometer’ (see page 62). As the rate of engine speed increase is potentially greater in the lower gears, the tell tale trigger points are tailored to ac- commodate the reaction time available.
  • Page 57 If the headlamps have been selected, this tell tale will light up green when the ignition is switched on. A bulb check will light LOTUS the lamp for about 3 seconds following ignition switch on. Tire Pressure Monitoring System (TPMS)
  • Page 58 In order to comply with emissions regulations, data regarding activation of the MIL is recorded in the engine electronic control- ler, and may be downloaded by Lotus dealers. Low Fuel Level Tell Tale (amber)
  • Page 59 Lotus Dynamic Performance Management Off Tell Tale (amber) This amber tell tale reminds the driver that the Lotus Dynamic Performance Management (Lotus DPM) has been manually switched off. Lotus DPM should aways be active when driving on public roads in normal conditions. To re-activate Lotus DPM, press momentarily the Lotus DPM off switch and check that the tell tale is extinguished.
  • Page 60 LOTUS LOTUS Brake Tell Tale (red) A bulb check will light this lamp for about 3 seconds follow- ing ignition switch on. The tell tale will then remain lit if the parking brake is applied. Check that the tell tale is extinguished...
  • Page 61 Lotus dealer. WARNING If the airbag tell tale is lit, the airbags may not inflate correctly in a crash, or may inflate without warning;...

  • Page 62: Instruments

    Tachometer Speedometer LOTUS INSTRUMENTS ohe3a INSTRUMENTS Speedometer This analogue display uses an illuminated pointer to indicate road speed in mph. Each time the ignition is switched on, a re- setting routine will be performed with the pointer sweeping to full scale and back to zero. The scale backlighting and pointer will be illuminated whenever the ignition or sidelamps circuits are active.

  • Page 63: Odometer

    but as the rate of engine speed increase is potentially greater in the lower gears, the tell tale trigger points are tailored to ac- commodate the reaction time available. The tell tales will light in the following left to right sequence: - one red light;...

  • Page 64: Instrument Panel Left Hand Screen

    Ambient temperature Time clock Fuel Selective level display LH SCREEN ohe33 INSTRUMENT PANEL LEFT HAND SCREEN Fuel Level Display An indication of the level of fuel in the tank is displayed, with ignition on, in the form of a vertical bar graph in the instrument panel left hand screen.

  • Page 65: Ambient Air Temperature Display

    Ambient Air Temperature Display The outside air temperature in degrees Fahrenheit, is shown on the instrument panel left hand screen whenever the ignition is switched on. If the temperature drops to 39°F or below, a snowflake symbol will be added, and the display will flash for ten seconds, accom- panied by a single audible chime to alert the driver to potentially hazardous road conditions.

  • Page 66: Trip Recorder

    Tire pressure units (if TPMS is fitted) Current tire pressure units will now be displayed. To change from bar to psi, or vice-versa, press momentarily the info. button. To retain the displayed units, press the info. button for more than one second, and then release to exit the adjustment mode.

  • Page 67: Instrument Panel Right Hand Screen

    250°F Door open indication Tyre Engine pressure temperature 140°F Pressure units RH SCREEN ohe34 INSTRUMENT PANEL RIGHT HAND SCREEN Coolant Temperature Display An indication of the engine coolant temperature is displayed, with ignition on, in the form of a vertical bar graph in the instru- ment panel right hand screen.

  • Page 68: Tire Pressure Monitoring System (Tpms)

    Tire Pressure Monitoring System (TPMS) A sensor incorporated into each of the tire valves, monitors the air pressure inside the tire, and supplies an onboard control module with this data by radio transmission. As soon as the car has been driven a short distance, tire pressure readings will be displayed against the corresponding wheels on the vehicle sil- houette in the instrument cluster right hand screen.
  • Page 69 The text on this page is a legislative requirement by the Federal authorities: Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recom- mended by the vehicle manufacturer on the vehicle placard or tire inflation pressure label.

  • Page 70: Door/Tailgate Open Display

    LOTUS Parking lamps Master lighting ohe22a Door/Tailgate Open Display The instrument cluster right hand screen includes a plan view silhouette of the car, which will graphically show when either door is open, or indicate an open tailgate by flashing the corresponding area.

  • Page 71: Homesafe

    switch (see page 74) is used to select main or dip beam. A second momentary press will switch off the headlamps, but leave on the sidelamps. To switch off both the side and head- lamps, hold the switch pressed for more than one second. Homesafe The Homesafe feature keeps the headlamps lit for a 30 sec- ond period after locking/arming the alarm, in order to light the...

  • Page 72: Hazard Warning Lamps Switch

    to the size, position and material/density of an object. If fitted, the reversing camera will switch on and display an image on the audio set screen, if and when the set is manually switched on. Note that in order to cover the whole width of the car, the view will be distorted from a conventional image.

  • Page 73: Instrument & Switch Illumination

    LOTUS Panel illumination button ohe22a Instrument and Switch Illumination The fascia mounted press button switches are backlit red whenever the sidelamps and ignition are switched on. The sidelamps switch itself is backlit with the ignition on. Most switches will light up brightly when that circuit is activated, with the brightness level dimmed when the headlamps are selected in order to reduce any potential distraction in the dark.

  • Page 74: Steering Column Lever Switches

    Right turn ohe2 Info button Left turn Flash LH STALK Low/High beam change Steering Column Lever Switches Lever switches are provided on the steering column, one on the left for turn indicators and headlamp functions, and one on the right for windscreen wiping and washing. Turn Indicators/Headlamp Flash/Dipswitch Turn Indicators: The turn indicators operate only with the ignition switched on.

  • Page 75: Windscreen Wiper & Washer Control

    ohe2 Fast wipe Intermittent Slow wipe interval Intermittent wipe Wash Flick wipe RH STALK Info Button: Momentarily pressing the ‘Info’ button on the end of the stalk will scroll through a menu of functions (see page 65). NOTICE Certain atmospheric conditions may result in some condensation inside the lamp unit.

  • Page 76: Horn

    Horn pad HORN ohe12 For short wash/wipe, a momentary press of the button on the end of the stalk will trigger the washer pump and a single sweep of the wiper. For a longer wash/wipe, press the end button for longer than one second to operate the washer, and to trigger 3 sweeps of the wiper.

  • Page 77: Audio Equipment

    AUDIO EQUIPMENT Operating instructions for the unit fitted are contained in a separate booklet supplied by the equipment manufacturer. The audio set will operate with the ignition key inserted, and in any of its positions, including the ‘0’ lock position. On cars fitted with a 2-DIN audio system and 175mm display screen, the following features are included: - AM/FM radio;...

  • Page 78: 10. Heating, Ventilation & Air Conditioning

    Distribution Defrost Temp. Re-circ. Air con. Fan speed INTERIOR CLIMATE PANEL ohe15 10. HEATING, VENTILATION & AIR CONDITIONING Interior Climate The interior climate may be adjusted via the centre console with its three rotary control knobs, for air distribution, tempera- ture and fan speed, together with four press button switches, for air conditioning, demist, air re-circulation and heated rear screen.

  • Page 79: Air Distribution

    Air Distribution This rotary control is positioned at the top of the climate panel and allows a choice of air distribution from the various outlet vents. There are 5 designated positions with corresponding sym- bols, although there is a progressive transition from each airflow mode to the next, allowing a preferred balance to be attained.

  • Page 80: Air Conditioning Request

    closed off by pressing the re-circ. switch, to result in 100% air re-circulation. This option should, however, be used sparingly to avoid stuffiness in the cockpit. Air Conditioning Request The A.C. request switch maintains its status through succes- sive ignition cycles. The current status is indicated by the button illumination; backlit red if off, brightly lit red if on.

  • Page 81: Heated Front Seats

    LOTUS Heated seat button (LH) Heated seat button (RH) Heated Front Seat Switches (If fitted) Both Driver and front passenger seat can be heated to main- tain a constant temperature. Single touch switches are located in the fascia panel below the tailgate release button and will illuminate amber when depressed.

  • Page 82: Engine Bay Ventilation

    Engine bay front cooling Hot air from around exhaust system Engine air intake Hot air from front of engine bay ohe31 Engine Bay Ventilation Various intake and outlet vents are provided in the rear body to allow ventilation and cooling of the engine bay. Intake vents ahead of the rear wheelarches provide ambient air for the engine air intake, and for engine bay cooling.

  • Page 83: Auxiliary Power Sockets

    AUXILIARY POWER SOCKETS ohe13 In cabin In boot Auxiliary Power Sockets The vehicle is equipped with three auxiliary power sockets; - two within the cabin, front and rear of the centre console; Operative with the ignition key at positions I or II. - One at the right hand corner of the trunk; Operative at all times.

  • Page 84: 11. Driving Controls

    11. DRIVING CONTROLS Foot Pedals The pedals for the clutch, brake and accelerator are arranged conventionally, and are grouped closely together for ready access and refined driving technique. CAUTION Do not attempt to drive the car without suitable narrow soled, flat heeled footwear.

  • Page 85: Footbrake

    Footbrake Ventilated disc brakes are fitted to all four wheels of the Evora. These are operated by separate front and rear hydraulic circuits, supplied from a tandem master cylinder with vacuum servo as- sistance. Anti-lock control is provided by a microprocessor based electro-hydraulic unit, integrated into the base braking system.

  • Page 86: Anti-Lock Brake System

    Anti-lock Brake System The Anti-lock Brake System (ABS) is used to optimise brake performance in extreme conditions and reduce the potential for any wheel to lock up. Under most conditions, the maximum braking force is provided by a wheel which is rotating at about 90% of road speed.
  • Page 87 hydraulic pressure. The driver should not attempt to emulate this process by ‘pumping’ the brake pedal, as modulation in this manner will treat all four wheels similarly, rather than individu- ally as afforded by the ABS electronics. An ABS tell tale lamp in the instrument panel is provided to warn that the integral self diagnostic system has identified a problem, and to indicate that the anti-lock function has been turned off.

  • Page 88: Hydraulic Brake Assist (Hba)

    See also ‘Lotus Dynamic Performance Management’ (page 91). WARNING The enhanced vehicle control that these features provide should not induce any relaxation of caution or vigilance by the driver.
  • Page 89 The brake should be applied by firmly pulling up the lever and engaging the highest ratchet setting attainable. When parking the car on a slope, take the additional precaution of leaving the transmission in first (facing downhill) or reverse (facing uphill) gear, and turn the steering wheel towards the kerb.

  • Page 90: Gear Lever (Manual Transmission)

    GEAR LEVER GATE ohs15a Gear Lever (manual transmission) The gear lever is spring biased towards the 3rd/4th gear plane, and must be moved against light spring pressure to the left before selecting first or second gear, or against similar pressure to the right before selecting 5th or 6th speed.

  • Page 91: Lotus Dynamic Performance Management

    See also ‘EDL’ (page 88). If the Lotus DPM tell tale in the instrument panel is seen to flicker, this is an indication that the system has been triggered and electronic intervention is taking place; the tractive limit has...
  • Page 92 DPM ‘off’ button is provided in the fascia, outboard of the steering column, and is operative only with the ignition on. To switch off Lotus DPM, hold the button pressed for one sec- ond, until the button surround lights up in conjunction with the amber ‘Lotus DPM off’...

  • Page 93: Sport Mode

    In all cases, anti-lock braking will be retained. WARNING Be aware that selecting Sport Mode and/or Lotus DPM OFF, will alter the handling characteristics of the car. Drivers should exercise caution until familiarity has been gained in a control- led safe environment.
  • Page 94 Selecting whilst driving: hold the button pressed for one second until the button surround lights up amber, accompanied by the amber ‘SPORT’ tell tale in the instrument panel. WARNING If Sport Mode button is pressed for more than one second whilst driving the vehicle will immediately engage Sports Mode irrespective of throttle position.

  • Page 95: Cruise Control

    Set/raise Resume speed Icon only On/off/ cancel Reduce speed CRUISE CONTROLS ohe12 Cruise Control The cruise control system is operated by four switches mounted on the steering wheel spokes. On/off/cancel (lower left). Resume (upper left). Set/raise speed setting (upper right). Reduce speed setting (lower right).
  • Page 96 Note; The system cannot be activated below 30 mph (45 km/h) or above 130 mph (210 km/h), or in first or second gear. Deactivation: Cruise control will be deactivated when any of the following actions occur: - The brake pedal is depressed; The clutch pedal is depressed. The on/off/cancel button is pressed.

  • Page 97: Homelink

    HOMELINK CONTROL PANEL ohe35 Homelink The homelink system offers wireless control of non-vehicle based systems, such as requests for garage door opening, pe- rimeter gate opening, and house lights switching. The Homelink control panel and integrated transmitter unit is located in the roof section of the vehicle and features three switches, labelled l, ll and lll, for communication with external systems.

  • Page 98: 12. Starting Procedure & Engine Break-In

    Operation Temperature Limit The Lotus Evora is designed to operate at outside air tempera- tures above -4°F (-20°C). The engine management, windscreen demisting and vehicle safety systems are not approved for use at lower temperatures.

  • Page 99: Idle Speed

    iv) If the engine fails to start within 15 seconds, stop cranking and pause for 10 seconds before a second attempt. v) If further efforts are unsuccessful, contact your dealer or seek other expert help. WARNING An unattended car with a running engine is potentially hazard- ous.

  • Page 100: Stopping The Engine

    Note that various operating parameters are continuously monitored and recorded in the engine electronic controller. This data may be downloaded by Lotus dealers on demand in order to assist with fault diagnosis and identify any vehicle misuse. Stopping the Engine...

  • Page 101: Engine Special Features

    Engine Special Features The 3.5 litre V6 engine of the Lotus Evora uses chain driven twin overhead camshafts for each cylinder bank to operate four valves per cylinder via a Dual VVT-i (Dual Variable Valve Timing - intelligent) system. The engine also features direct ignition...

  • Page 102: 13. External Operations

    Gasohol - A mixture of 10% ethanol (grain alcohol) and 90% un- leaded gasoline may be used in the Lotus Evora. If driveability problems are experienced as a result of using gasohol, it is recommended that the car is operated on gasoline.
  • Page 103 91 (RON+MON)/2 unleaded gasoline. Do not use Ethanol blends with a higher concentration than 10%. Diesel - The Lotus Evora will not operate on diesel fuel. NOTICE • The use of leaded fuel, or lead replacement petrol (LRP), will cause irreversible contamination of the precious metal cata- lysts and of the exhaust gas sensors used by the computer controlled engine management system.

  • Page 104: Fuel Filling

    Filler cap parking ohe22a LOTUS Fuel filler flap release button ohe43 Fuel Filling WARNING • Gasoline and its attendant fumes are highly explosive. You can be burned or seriously injured when handling fuel. Be- fore stopping at a filling station, switch off mobile phones and other electronic equipment, ensure that all cigarettes are extinguished and that no naked flames or other potential ignition sources are present.
  • Page 105 Filling Procedure: Insert the pump nozzle fully into the neck, and fill until the auto-shut off mechanism is triggered. Do not attempt to ‘brim’ the tank to the top of the filler neck, as expansion of the fuel due to temperature change (e.g. cold underground fuel storage) may cause flooding of the fuel tank breather system charcoal canister, or spillage of fuel.

  • Page 106: Tailgate

    Tailgate release button Tailgate To open the tailgate with transmitter key: Press twice the end button on the transmitter key; the latch will release and allow the tailgate to be opened, assisted by pressurised struts. Boot lamps will switch on automatically whenever the tailgate is open. To open the tailgate with release button: Press the button located in the fascia panel inboard of the steering column.
  • Page 107 covered by your New Vehicle Warranty. If an open or incompletely closed tailgate is detected when the ignition is turned on, a warning will be displayed on the right hand screen in the instrument panel via the vehicle silhouette graphic. To close the tailgate, ensure that no persons or objects will be trapped before pulling down the panel and pressing firmly over each end of the aerofoil to assure complete engagement of...
  • Page 108 Tailgate manual release handle ohe44 Manual tailgate release: If the vehicle battery becomes discharged, the tailgate cannot be opened using the transmitter fob. For this situation, and if for any reason the transmitter is lost or damaged, an emergency cable release handle is provided within the cabin (access via the mechanical left hand door lock - see page 33), located beneath the rear seat cushion (2+2) or shelf pad (2+0).

  • Page 109: Child Entrapment

    ohe54 Tailgate emergency release handle Child Entrapment If a child should become trapped in the rear luggage compart- ment, an emergency release handle is provided inside the trunk to facilitate their escape. To release the latch, the fluorescent yellow/white handle at the rear of the trunk, should be pulled towards the right hand side of the car.

  • Page 110: Front Body Access Hatch

    To open HATCH RELEASE LEVER ohe20 Front Body Access Hatch The hinged front body access hatch provides access to the brake/clutch fluid reservoir and the windscreen/headlamp washer reservoir filler. To open the hatch, from the inboard side of either footwell, press down the release lever; the hatch may then be raised fully by hand.

  • Page 111: Servicing & Maintenance

    14. SERVICING AND MAINTENANCE BODYCARE Body Features Lotus is amongst the world leaders in the field of automotive composite moulding design and manufacturing techniques. Com- posite materials have major advantages for specialist car bodies, and these brief notes introduce some features of the construction and service properties of automotive composite bodies.

  • Page 112: Paint Care

    Paint Care The acrylic enamel finish of the Lotus Evora is extremely resistant to all normal forms of atmospheric attack. Follow- ing the simple maintenance procedure summarised below will help retain the gloss, colour and protective properties of the paint throughout the life of the car.

  • Page 113: Paintwork Polishing

    Washing NOTICE Lotus recommends hand washing of the painted bodywork. The car is a speciality vehicle not intended to be subjected to an automatic car wash. Automatic car washing machines may have a detrimental effect on the paint film, and any damage arising from such use will not be covered by the New Vehicle Warranty.

  • Page 114: Alloy Road Wheels

    NOTICE The leather used in the Lotus Evora is of premium quality, specifically tanned and dyed for automotive use. As a natural material, leather ages in various ways and may, over time, exhibit signs of cracking, scuffing, shrinking, etc.

  • Page 115: Footwell Mats

    Check all the belts regularly and have any problem corrected immediately Footwell Mats Use only correctly secured Lotus approved carpet mats in the footwells. Floor coverings made from plastic or other non- breathable materials may trap moisture and initiate surface corrosion of the footwell floors.

  • Page 116: Owner Maintenance

    Be sure to carry out the simple maintenance checks detailed below, and to have the car serviced regularly by your Lotus dealer, in order to ensure maximum safety, reliability, longevity and pleasure of ownership. It is important that the Maintenance Schedule (see separate...

  • Page 117: Engine Cover

    ENGINE COVER LATCH RELEASE BUTTON ohe28 WARNING If an owner elects to use the Evora on a closed circuit track or in a competitive manner, the severity of operating conditions demands that appropriate levels of expert car preparation, servicing (over and above that specified in the Maintenance Schedule) and vigilance will be required, including careful inspection of all safety critical components both before and after any track or competition session.

  • Page 118: Engine Oil Level Check

    Engine Oil WARNING • Engine oil is hazardous to your health and may be fatal if swallowed. • Prolonged and repeated contact with used engine oil may cause serious skin disorders, including dermatitis and cancer. • Use protective gloves to avoid contact with skin as far as possible and wash skin thoroughly after any contact. • Take all suitable precautions to guard against scalding from hot oil and hot surfaces.
  • Page 119 Dot marks; Dipstick refer to Oil filler cap text ohe36 The level should lie between the two dots on the lower end of the dipstick. For optimum engine protection, maintain the level towards the top mark, and do not allow to fall below the mid- point.

  • Page 120: Engine Oil Change

    SUMP DRAIN PLUG ohe45 Engine Oil Change The use of high quality oil, renewed at the specified intervals, is the key to engine longevity and sustained performance. Adhere strictly to the engine oil and filter change intervals specified in the Maintenance Schedule. WARNING See WARNINGS on page 118.

  • Page 121: Oil Filter

    Filter element ‘O’ ring Filter housing Drain plug & ‘O’ ring Oil filter drain tube inserted ohe37/38 Oil Filter The cartridge type oil filter is mounted at the right hand front of the engine, and is accessible only from beneath. The filter should be renewed along with the engine oil, at intervals specified in the Maintenance Schedule.
  • Page 122 placed. Using adaptor tool T000T1441F, torque tighten the cap to 25 Nm. Check that there is no clearance between cap and hous- ing. Lubricate the small ‘O’ ring supplied with the new filter with engine oil, and fit into the groove in the filter housing. Fit the filter drain plug and tighten to 13 Nm.

  • Page 123: Used Engine Oil

    Lotus dealer. The engine and transmission should also be checked for any signs of oil leaks, and, if necessary, rectified by your Lotus dealer. oh_evoraS_a_USA.indd 123...

  • Page 124: Cooling System

    HEADER TANK CAP ohe30 Cooling System The engine cooling system uses a header tank to ensure that the system remains completely filled, and also to accommodate expansion of the coolant with increasing engine temperature. The tank is mounted at the left hand side of the engine bay, and is fitted with a 108 kPa (15 psi) pressure cap to raise the boiling point of the coolant to over 250°F (120°C).
  • Page 125 recommended cold level is 3/8 inch (10mm) below the horizontal moulded seam running around the tank, with the lowest accept- able level being 1 inch (25mm) below the seam. If topping up is required, ensure that the coolant is fully cold before slowly unscrewing the filler cap and allowing any remain- ing pressure to escape before finally removing the cap.

  • Page 126: Anti-Freeze/Corrosion Inhibitor

    ance will be degraded. Anti-Freeze/Corrosion Inhibitor It is most important that the correct coolant specification is used in order to inhibit boiling and to protect the engine and heat exchangers from both frost damage, and metal corrosion. The Evora is factory filled with a 50% concentration of Havoline XLC Extended Life Coolant, which contains Organic Acid Tech nology (OAT) based corrosion inhibitors to provide good cooling performance and long coolant change intervals, combined with...

  • Page 127: Coolant Drain/Refill Procedure

    WASHER RESERVOIR ohe19 Coolant Drain/Refill Procedure The cooling system of the Lotus Evora has been carefully optimised to allow the required cooling performance using the minimum volume of coolant. This provides for high cooling sys- tem efficiency, with quick engine warm up and interior heating.

  • Page 128: Wiper Blade

    Wiper blade Wiper arm Rotate to release ohe26 the lamp for about 4 seconds following ignition switch on, but if the lamp then remains lit, or lights after washer use, refill the reservoir at the first opportunity. The windscreen washer heated jets are mounted each side of the wiper spindle, and may, if necessary, be cleared or adjusted using a suitable pin.

  • Page 129: Brake Fluid Reservoir

    As the brake pads wear, the level will drop gradually from the 'MAX' mark towards the 'MIN', but if the level drops rapidly over a short period, have your Lotus dealer investigate without delay. If the level is found to be below the 'MIN’...

  • Page 130: Brake Pads

    WARNING • For optimum safety and brake performance, the brake fluid should be renewed every two years by your Lotus Dealer. • Brake fluid is hazardous to health and may be fatal if swal lowed. Keep out of children’s reach. • Using the wrong type of brake fluid can damage brake system components and result in brake failure causing a crash in which you and others could be killed or seriously injured.

  • Page 131: Brake Pipes And Hoses

    WARNING • Using incorrect brake pads, or pads below 2.5mm thickness, may cause a crash in which you or others could be killed or seriously injured. • With a new car, or new brake system components, maxi- mum braking efficiency will be achieved if, for the first few hundred miles, needless heavy braking is avoided, and the brake pads and discs are allowed to ‘bed in’...

  • Page 132: Air Cleaner Element

    The spark plugs should be renewed in accordance with the Maintenance Schedule, with the gaps set to 1.0 - 1.1 mm for naturally aspirated models and 0.8 mm for supercharged Evora S models. This operation should be entrusted to your Lotus dealer. oh_evoraS_a_USA.indd 132...

  • Page 133: Tires & Wheels Tires

    Lotus engineers have worked with tire manufacturers to pro- duce tire specifications for the Evora which optimise performance for all round use. To ensure that any replacement tires are to the correct Lotus specification, always refer to your Lotus dealer, who will have the latest recommendations. WARNING • In order to achieve optimum handling characteristics, the...

  • Page 134: Tire Care

    Careful inspections must be carried out before and after each session. Note: Lotus does not endorse such use of the Evora - refer to the Warranty Booklet section 2 ‘Intended Purpose’.

  • Page 135: Tire Characteristics

    Outboard tread Inboard tread pattern pattern 1,000 miles (1,700 km), whichever is the sooner, and corrections made as necessary. See ‘Technical Data’ at the back of the hand- book for the recommended tire pressures. Under-inflation will cause excessive wear, rapid deterioration of the tire sidewalls and heavy steering, whereas over-inflation results in a hard ride and increased susceptibility to tire damage.

  • Page 136: Winter Tires

    For the Evora, Lotus recommends the use of Yokohama W.drive V-902 winter tires in sizes specified in ‘Technical Data’. Wear indicators are moulded into the bottom of the tread grooves at intervals around the tire, indicated by small pointers on the outer tread blocks.

  • Page 137: Replacement Tires

    Replacement Tires When replacing tires, refer to the ‘Technical Data’ section in this handbook, or consult your dealer to check the current Lotus specification and recommendations. Do not use tires which have not been approved by Lotus. WARNING Note that the tread design of both the Pirelli P-Zero tires and the Yokohama W.drive V-902 winter tires, are asymmetric,...

  • Page 138: Uniform Tire Quality Grading

    Revise Uniform Tire Quality Grading The following information relates to the system developed by the United States National Highway Traffic Safety Administra tion, which grades tires by treadwear, traction and temperature performance. The grades are moulded on the sidewalls of most passenger car tires between the tread shoulder and maximum section width.
  • Page 139 WARNING • The temperature grade is established for a tire that is properly inflated and not overloaded. Excessive speed, underinflation, or excessive loading, either separately or in combination, can cause heat buildup and possible tire failure. • Do not exceed the vehicle maximum total weight, or maxi- mum front or rear axle weights (see below and ‘Technical Data’).

  • Page 140: Tire Emergency Inflator Aerosol

    TIRE EMERGENCY INFLATOR AEROSOL ohe42 Tire Emergency Inflator Aerosol In order fully to exploit the benefits of light weight, and to maximise stowage space, the Evora has no provision for spare wheel carriage or lifting jack. A temporary puncture sealing facility is provided in the form of a tire emergency inflator aerosol mounted in a spring clip in the right hand side of the trunk.
  • Page 141 designated secure stowage position. Never carry loose in the passenger compartment. Directions for use of the aerosol: Before using, carefully read all the instructions on the canister, or on any literature accompany ing the product. The following instructions apply to the use of Holts Tireweld: 1.

  • Page 142: Wheels

    Coded adaptor 17mm socket, extension & torque wrench ohs114d Wheels Ensure that only original equipment, or Lotus approved wheel and tire combinations are fitted. WARNING After striking a pothole or kerb, the wheels should be removed and the wheel and tire thoroughly inspected for damage. If necessary, renew the wheel and/or tire.

  • Page 143: Wheel Alignment & Tire Balance

    If the wheel bolts come loose after having been correctly fitted, the wheel and bolts should be re placed. If the wheel leaks air, have it replaced. See your Lotus dealer if any of these conditions should arise, and ensure that only Lotus approved wheels and wheel bolts are used.
  • Page 144 Careful inspection of all wheels must be carried out before and after each session. Note: Lotus does not en- dorse such use of the Evora - refer to the Warranty Booklet section 2 ‘Intended Purpose’.

  • Page 145: Electrical Battery

    16. ELECTRICAL BATTERY WARNING POISON/DANGER - CAUSES SEVERE BURNS - KEEP OUT OF REACH OF CHILDREN - RISK OF SHORT CIRCUIT AND FIRE • Batteries contain sulphuric acid - avoid contact with skin, eyes, mouth or clothing. If in contact with skin or eyes; flush with copious amounts of water.
  • Page 146 Check battery terminal symbols; Orientation may Positive differ terminal Negative terminal Retaining clamp plate BATTERY ACCESS (cover removed) ohe46 i) Ensure that all electrical loads (e.g. lights) are switched off. If the car is fitted with security coded audio equipment, check that the code is available for entering after battery reconnec- tion.

  • Page 147: Reconnecting The Battery

    Lotus Dealers. Starting difficulties may be encountered after an unattended period of 3 weeks. A battery conditioner is able to...
  • Page 148 quent conditions of car use may not allow for sufficient alternator charging of the battery to achieve a fully charged state. The bat- tery should be trickle charged by external means until 12.8 volts is recorded, which process may take 24 hours or longer. Putting the battery into service at a lower state of charge will reduce the time period for which the car can be parked without subsequent starting concerns.

  • Page 149: Jump Starting

    Note: Orientation of ohs14f batteries may differ; Always check Evora terminal markings Slave JUMP STARTING ‘Jump’ Starting If the battery becomes discharged to the extent that the engine cannot be started, the recommended action is to remove the bat- tery for bench charging, and/or fit a substitute battery until this process is complete.
  • Page 150 connection should therefore be made to a point well away from the battery, and from any fuel vapour area or moving parts. An engine hanger bracket is often ideal. iv) Start the subject vehicle in the usual way, and run at a fast idle.

  • Page 151: Electrical Accessories

    Owners should note that the only approved extras and modi- fications are those which are specified by Lotus and carried out by Lotus or by an authorised dealer. Lotus will accept no liability whatsoever for defects which arise from extras or modifications which are not approved by Lotus.

  • Page 152: Fuses

    Fuses The main fuseboxes are located at the front of the passenger footwell, protected by a removable panel secured by a quarter turn fastener at each top corner, and a location channel on the floor. Forty slots are provided for mini fuses which are numbered, and coloured according to their amperage rating, and may be pulled out from their slots using the fuse extractor tool clipped to the fusebox.

  • Page 153: Mainfusebox

    Main Fuseboxes Maxi fuses ACCESSORY POWER (50A) POWER (50A) Relays HEADLAMP KEY IN RECIRC WASHER SW ILL GLOVE BOX HEADLAMP C10 C9 C8 C7 C6 C5 C4 C3 C2 C1 Mini fuses C11 C12 C13 C14 C15 C16 C17 C18 C19 C20 ohe25g C30 C29 C28 C27 C26 C25 C24 C23 C22 C21 Slot Rate Circuit...

  • Page 154: Rear Fusebox

    Rear Fusebox Fuses for the engine bay and rear mounted systems are con- tained in a fusebox mounted in the cabin, behind the left hand rear quarter trim panel. For access, use a coin to release the quarter turn fastener on the lower edge of the removable panel, and unhook the top edge.
  • Page 155 Rear Fusebox Relays Mini fuses Maxi fuses ohe25g oh_evoraS_a_USA.indd 155 28/04/2011 11:53:32...

  • Page 156: Footwell Relays

    RAD FAN 2 WIPER HRS/MIRROR Passenger footwell relay postions HRS/MIRROR WIPER RAD FAN 2 AUTO DEMIST RAD FAN 3 RAD FAN 1 oh_evoraS_a_USA.indd 156 28/04/2011 11:53:32...

  • Page 157: Headlamp Alignment

    Headlamp Alignment The headlamps of your Lotus Evora were correctly adjusted during the manufacture of the car, and should not subsequently require adjustment unless the headlamp assembly or front body is disturbed. Simply replacing the bulb or burner unit will not affect alignment.
  • Page 158 4. Each headlamp assembly features a single vertical alignment adjustment screw positioned to the outboard top of the lamp. Turn clockwise to raise the beam, or counterclockwise to lower. Optimum setting is -1.2%. 5. Repeat for the opposite lamp. Note that there is no adjustment for lateral alignment. 6.

  • Page 159: Bulb Replacement

    Spring clip HID burner unit Protective boot ohe48 BULB REPLACEMENT Headlamp Units HID Xenon Headlamps: On cars fitted with High Intensity Discharge (HID) headlamp assemblies, the light sources utilise a plasma discharge arc between two electrodes in a xenon gas envelope to provide a blue-white light for optimal illumination of the road- way.

  • Page 160: Front Turn Indicator & Sidelamp Bulbs

    These lamps are designed for long life and are serviceable only by replacement of the complete headlamp unit, which job should be entrusted to your Lotus dealer. Rear Turn Indicator, Stop and Tail Lamps Each outboard tail lamp comprises a complete ring of red col-...

  • Page 161: Centre High Mounted Stop Lamp (Chmsl)

    Aerofoil Connector CHMSL ohe50 Centre High Mounted Stop Lamp (CHMSL) The CHMSL, mounted to the underside of the rear aerofoil, uses a string of light emitting diodes (LEDs) for optimum visibility. The lamp is a sealed unit with no replaceable bulbs, and may be replaced complete, after releasing the two retaining screws and unplugging the harness connector.

  • Page 162: Licence Plate Lamps

    Festoon bulb LICENCE PLATE LAMP BULB ohe41 Licence Plate Lamps To replace a bulb in a rear licence plate lamp, first remove the two screws securing the lamp to the body, and withdraw sufficiently to allow access to the festoon bulb. oh_evoraS_a_USA.indd 162 28/04/2011 11:53:33...

  • Page 163: Interior Lamp

    Festoon bulb INTERIOR LAMP BULB ohe51 Interior Lamp To withdraw the interior lamp from the rear of the roof trim panel, first ease one end of the lamp from its aperture. With- draw the lamp sufficiently to allow access to the festoon bulb, if necessary, unplugging the harness connector.

  • Page 164: Recovery Eye

    Recovery eye ohe001 17. RECOVERY AND LIFTING Recovery Eye A recovery eye is provided with the vehicle tool kit, and stowed in the rear luggage compartment. When required, fit the eye to its anchorage point in the top left hand corner of the radiator air intake aperture, having first removed the protective bung (if fitted), and screw fully into the tapped boss.

  • Page 165: Car Tie-Down

    NOTICE Before being towed: • Release the parking brake and ensure that the transmis sion is in neutral. • Comply with all local legislation applicable to cars being towed. • Do not use the recovery eye to secure the car on a transporter. (see ‘Car Tie-Down’ below). Car Tie-Down When moving a car by transporter or trailer, the car should be secured only by chocking and strapping around the road wheels.

  • Page 166: Lifting The Evora

    LIFTING POINTS ohe52 Lifting The Evora WARNING • Using a lifting jack can be dangerous. If the car falls off the jack, you or others could be seriously injured or killed. NEVER get under a car when it is supported only by a jack. • Before raising the car with a jack: - Turn off the engine;...

  • Page 167: Fuel Tank Chassis Panel

    rear lifting point (see ‘B’ above) may be used to raise both wheels on that side of the car. Note that in order fully to exploit the benefits of light weight, and to maximise stowage space, the Evora has no provision for spare wheel carriage or lifting jack.

  • Page 168: 18. Accessories

    Accessories: Lotus dealers have genuine Lotus accessories that offer ve- hicle personalisation. These accessories have been designed and approved for the Lotus Evora, and are supported by Lotus warranty. Non-Lotus accessories may be designed for universal appli- cation, and although they may fit the Evora, they may not meet Lotus specifications, and could adversely affect the car’s safety...
  • Page 169 • In addition, any modifications that decrease ground clear- ance outside of Lotus approval, increase the chance of undercarriage parts striking a kerb, speed bump, or other raised object, which could cause your airbags to deploy as well as damaging the chassis and body underside.

  • Page 170: Storing The Evora

    Storing The Evora If you intend to store the car for a prolonged period, consult your Lotus dealer who will be pleased to advise you. We recom- mend that the car is stored inside a secure garage. The following guidelines are provided for your information: • Ensure the engine oil and filter, coolant and brake fluid have...

  • Page 171: 19. Recommended Lubricants

    Booklet section 2 ‘Intended Purpose’), the recommended fully synthetic engine oil is Castrol Edge 10W/60. NOTICE Lotus recommends against the use of any oil ad- ditives, the use of which may invalidate the terms of the New Vehicle Warranty. ‘Severe Service’ Conditions...

  • Page 172: Engine

    • Track use, with repeated high rpm, wide throttle openings and high oil temperatures. For appropriate maintenance, discuss with your Lotus dealer. Note that use of the car off road or in a competitive manner, including timed runs or laps, will invalidate warranty and require appropriate levels of expert car preparation and servicing.

  • Page 173: Engine Coolant Additive

    Engine Coolant Additive Only approved product: Havoline XLC Type: Ethylene glycol antifreeze with OAT corrosion inhibitors Colour: Orange Concentration: Quantity reqd. @ 50%: (See capacities information in 20. Technical Data) Coolant change interval: 4 years oh_evoraS_a_USA.indd 173 28/04/2011 11:53:35...

  • Page 174: 20. Technical Data

    20. TECHNICAL DATA Tyres (normal use) Type - Std Pirelli P-Zero Size - front 225/40 ZR18 - rear 255/35 ZR19 Pressure (cold) - normal driving conditions - front 2.3 bar (33.5 psi) - rear 2.5 bar (36 psi) Type -Optional Pirelli P-Zero Corsa Size - front...
  • Page 175 Dimensions Evora Evora S A. Overall length 4350 mm 4361 mm Evora Evora S B. Overall width - excl. mirrors 1848 mm Overall length 4350.5 4360.5 Overall width (including mirrors) - incl. mirrors 1972 mm 1884 C. Overall height (mid-unladen) Overall Height (mid laden weight) 1229 mm 1229...
  • Page 176 Capacities Evora Engine oil (refill inc. filter) 6.1 litre High/low dipstick mark difference 1.5 litre Evora S Capacity - refill inc. filter*: 10.1 litre (*Engine oil capacity is 6.1 litres but supercharged cars fitted with front mounted oil coolers contain an additional 4 litres of oil. This oil is not drained during routine servicing) High/low dipstick mark difference 1.5 litre...
  • Page 177 Electrical Light Bulbs Watt. Type Headlamps D1S electronic igniter/ burner unit Licence plate lamps Interior lamp Festoon Footwell/glovebox/boot Festoon Note that other lamps are likely to be long life LED type, serviced only by lamp replacement. System voltage/polarity 12V negative earth Alternator 100A Battery (service replacement)
  • Page 178 - Sport mode 7,200 rpm Fuel requirement Unleaded Minimum octance 88 - 89 (RON+MON)/2 Recommended octance 91 (RON+MON)/2 Fuel system Port fuel injection with Lotus T6 electronic controller Transmission Designation 6 speed manual type EA60 Differential Open bevel gear Gear ratios (standard):...
  • Page 179 Brakes Brake discs Front and rear cast iron discs with curved vane ventilation & optional cross-drilling Disc size - front 350 x 32 mm - rear 332 x 26 mm with 185 mm dia parking drum Callipers AP Racing aluminium-alloy body, 4 pistons in opposed pairs Operation...
  • Page 180 oh_evoraS_a_USA.indd 180 28/04/2011 11:53:35...

  • Page 181: Alphabetical Index

    21. INDEX Access Hatch, front body ............110 Accessories & Modifications, warnings ......151, 168 Active Exhaust Valve ............. 101 Air Filter Element ..............132 Air Conditioning ............... 78 Airbag Supplementary Restraint System (SRS) ....39 Alarm, car security ..............22 Ambient Air Temperature Display ..........
  • Page 182 ‘Jump’ Starting ...............149 Keys ................... 22, 33 Lighting Switches ..............70 ‘Lights On’ Warning ............32, 71 Lotus Dynamic Performance Management ......91 Lubrication - Dipstick, engine oil level check ........118 - Engine Oil Change ............120 - Oil Filter ................121 - Recommended Lubricants ..........171...
  • Page 183 Reversing Lamp ..............71 Safety Information ..............13 Satellite Navigation ..............77 Seat Belts ................35 Seats ..................34 Servicing ....see separate Maintenance Record booklet Sparking Plugs ..............132 Special Features, engine ............101 Speedometer ................62 Sport Mode ................93 Starting Procedure ..............
