Vega VEGAFLEX 82 Quick Setup Manual

Tdr sensor for continuous level measurement of bulk solids
Hide thumbs Also See for VEGAFLEX 82:
Table of Contents

Advertisement

Quick Links

Download this manual

Quick setup guide

TDR sensor for continuous level
measurement of bulk solids
VEGAFLEX 82
4 ... 20 mA/HART - four-wire
Rod and cable probe
Document ID: 47593

Advertisement

Table of Contents
loading

Related Manuals for Vega VEGAFLEX 82

Summary of Contents for Vega VEGAFLEX 82

  • Page 1: Quick Setup Guide

    Quick setup guide TDR sensor for continuous level measurement of bulk solids VEGAFLEX 82 4 … 20 mA/HART - four-wire Rod and cable probe Document ID: 47593...

  • Page 2: Table Of Contents

    This manual is available on the supplied DVD or in the download area under "www.vega.com". Operating instructions VEGAFLEX 82 - 4 … 20 mA/HART - Four- wire - Rod and cable probe: Document-ID 41830 Editing status of the quick setup guide: 2014-03-17...

  • Page 3: For Your Safety

    During work on and with the device the required personal protective equipment must always be worn. Appropriate use VEGAFLEX 82 is a sensor for continuous level measurement. You can find detailed information about the area of application in chapter "Product description". Operational reliability is ensured only if the instrument is properly used according to the specifications in the operating instructions manual as well as possible supplementary instructions.

  • Page 4: Namur Recommendations

    That is why we have introduced an environment management system with the goal of continuously improving company environmental pro- tection. The environment management system is certified according to DIN EN ISO 14001. Please help us fulfill this obligation by observing the environmental instructions in this manual: • Chapter "Packaging, transport and storage" • Chapter "Disposal" VEGAFLEX 82 • 4 … 20 mA/HART - four-wire...

  • Page 5: Product Description

    Go to www.vega.com, "VEGA Tools" and "Instrument search". Enter the serial number. Alternatively, you can access the data via your smartphone: • Download the smartphone app "VEGA Tools" from the "Apple App Store" or the "Google Play Store" VEGAFLEX 82 • 4 … 20 mA/HART - four-wire...
  • Page 6 2 Product description • Scan the Data Matrix code on the type label of the instrument or • Enter the serial number manually in the app VEGAFLEX 82 • 4 … 20 mA/HART - four-wire...

  • Page 7: Mounting

    Mounting instructions Installation position Mount VEGAFLEX 82 in such a way that the distance to vessel instal- lations or to the vessel wall is at least 300 mm (12 in). In non-metallic vessels, the distance to the vessel wall should be at least 500 mm (19.7 in).
  • Page 8 Fig. 3: Installation in non-metallic vessel Flange Metal sheet Concrete vessel When installed in thick concrete ceilings, VEGAFLEX 82 should be mounted front flush to the lower edge. In concrete silos, the distance to the wall should be at least 500 mm (20 in). VEGAFLEX 82 • 4 … 20 mA/HART - four-wire...
  • Page 9 Check if this is relevant for your measurement. In such cases, always carry out a false signal suppression after instal- lation. You can find further information under "Setup procedure". _ < DN40 ... DN150 _ < > DN150 ... DN200 Fig. 5: Mounting socket VEGAFLEX 82 • 4 … 20 mA/HART - four-wire...
  • Page 10 3 Mounting When welding the socket, make sure that the socket is flush with the vessel top. Fig. 6: Socket must be installed flush Unfavourable installation 2 Socket flush - optimum installation VEGAFLEX 82 • 4 … 20 mA/HART - four-wire...

  • Page 11: Connecting To Power Supply

    When the screwdriver is released, the terminal closes again. 6. Check the hold of the wires in the terminals by lightly pulling on them VEGAFLEX 82 • 4 … 20 mA/HART - four-wire...

  • Page 12: Wiring Plan, Double Chamber Housing

    Terminal Function Polarity Voltage supply Voltage supply 4 … 20 mA output (active) 4 … 20 mA output (passive) Mass - output Function ground with installa- tion according to CSA VEGAFLEX 82 • 4 … 20 mA/HART - four-wire...
  • Page 13 Fig. 9: Connection compartment with double chamber housing with low voltage Terminal Function Polarity Voltage supply Voltage supply 4 … 20 mA output (active) 4 … 20 mA output (passive) Mass - output Function ground with installa- tion according to CSA VEGAFLEX 82 • 4 … 20 mA/HART - four-wire...

  • Page 14: Set Up With The Display And Adjustment Module

    The display and adjustment module is powered by the sensor, an ad- ditional connection is not necessary. Fig. 10: Installing the display and adjustment module in the electronics compart- ment of the single chamber housing VEGAFLEX 82 • 4 … 20 mA/HART - four-wire...

  • Page 15: Parameter Adjustment - Quick Setup

    If your instrument is only suitable for a certain medium, this menu item is not visible. Application In this menu item, you can select the application. You can choose between level measurement and interface measurement. You can VEGAFLEX 82 • 4 … 20 mA/HART - four-wire...
  • Page 16 They represent the correlation between the level percentage and vessel volume. The linearization applies for the measured value indication and the current output. By activating the suitable curve, the percentage vessel volume is displayed correctly. VEGAFLEX 82 • 4 … 20 mA/HART - four-wire...

  • Page 17: Supplement

    0.2 … 1.5 mm² (AWG 24 … 16) Voltage supply Operating voltage Ʋ Version for low voltage 9.6 … 48 V DC, 20 … 42 V AC, 50/60 Hz Ʋ Version for mains voltage 90 … 253 V AC, 50/60 Hz Interpolation protection Integrated Max. power consumption 4 VA; 2.1 W VEGAFLEX 82 • 4 … 20 mA/HART - four-wire...
  • Page 18 Notes VEGAFLEX 82 • 4 … 20 mA/HART - four-wire...
  • Page 19 Notes VEGAFLEX 82 • 4 … 20 mA/HART - four-wire...

  • Page 20: Information

    Subject to change without prior notice © VEGA Grieshaber KG, Schiltach/Germany 2014 VEGA Grieshaber KG Phone +49 7836 50-0 Am Hohenstein 113...
