- Page 1 Supplementary instructions External housing VEGAFLEX 80 series Document ID: 46802...
-
Page 2: Table Of Contents
Maintenance ........................... 12 How to proceed if a repair is necessary ................12 Dismount..........................13 Dismounting steps......................13 Disposal ......................... 13 Supplement ..........................14 Technical data ........................ 14 Dimensions ........................16 Editing status: 2020-01-24 External housing • VEGAFLEX 80 series... -
Page 3: About This Document
Symbols used Document ID This symbol on the front page of this instruction refers to the Docu- ment ID. By entering the Document ID on www.vega.com you will reach the document download. Information, note, tip: This symbol indicates helpful additional infor- mation and tips for successful work. -
Page 4: For Your Safety
That is why we have introduced an environment management system with the goal of continuously improving company environmental pro- tection. The environment management system is certified according to DIN EN ISO 14001. Please help us fulfil this obligation by observing the environmental instructions in this manual: • Chapter "Storage and transport" • Chapter "Disposal" External housing • VEGAFLEX 80 series... -
Page 5: Product Description
• Instrument housing of plastic - housing base: plastic • Instrument housing of aluminium - housing base: stainless steel • Instrument housing of stainless steel - housing base: stainless steel External housing • VEGAFLEX 80 series... -
Page 6: Principle Of Operation
Dispose of the packaging material via specialised recycling companies. • Storage and transport Storage and transport temperature see chapter "Supplement - temperature Technical data - Ambient conditions" • Relative humidity 20 … 85 % External housing • VEGAFLEX 80 series... -
Page 7: Mounting
2. Depending on the mounting surface, fasten the wall mounting plate with 4 screws 90 mm (3.54") 70 mm (2.76") 8 mm (0.12") (0.32") Fig. 2: Hole pattern - wall mounting plate (external housing) External housing • VEGAFLEX 80 series... -
Page 8: Mounting - Sensor Housing
With the plastic housing, the four screws of the base may only be screwed in hand tight. Exceeding the max. torque specified in chapter "Technical data" can damage the wall mounting plate. Mounting - sensor housing → Mount the sensor to the bottom, depending on the process fitting Note: When mounting the sensor, note the instructions in the operating instructions manual of the sensor. External housing • VEGAFLEX 80 series... -
Page 9: Connect The Sensor To The External Housing
6. Insert the plug (straight plug or angle plug) of the HF connection cable into the instrument housing and hand-screw the hexagon nut. 7. Tighten the hexagon nut of the plug with the fork wrench (SW 19) with max. 3 Nm (2.212 lbf ft). External housing • VEGAFLEX 80 series... - Page 10 5 Connect the sensor to the external housing The electrical connection of the electronics module is described in the operating instructions manual of the sensor. External housing • VEGAFLEX 80 series...
-
Page 11: Setup
6 Setup Setup Setup Setup is carried out according to the operating instructions manual of the respective sensor. External housing • VEGAFLEX 80 series... -
Page 12: Maintenance
Clean the instrument and pack it damage-proof • Attach the completed form and, if need be, also a safety data sheet outside on the packaging • Please contact the agency serving you to get the address for the return shipment. You can find the agency on our home page www.vega.com. External housing • VEGAFLEX 80 series... -
Page 13: Dismount
Pass the instrument directly on to a spe- cialised recycling company and do not use the municipal collecting points. These may be used only for privately used products according to the WEEE directive. External housing • VEGAFLEX 80 series... -
Page 14: Supplement
2 m, 5 m, 10 m (6.562 ft, 16.4 ft, 32.81 ft) housing Length, HF connection cable to external 15 m (49.2 ft) housing – only with VEGAFLEX 81 – only up to 40 m probe length – only from ε > 10 External housing • VEGAFLEX 80 series... - Page 15 IP66/IP68 (1 bar) acc. to NEMA Type 6P Ʋ Instrument housing - Instrument IP66/IP67 acc. to NEMA Type 4X socket Depending on the version M12 x 1, according to ISO 4400, Harting, 7/8" FF. External housing • VEGAFLEX 80 series...
-
Page 16: Dimensions
½ NPT ½ NPT M20x1,5/ ½ NPT Fig. 5: Versions of the instrument housing Instrument housing - plastic Instrument housing - stainless steel, electropolished Instrument housing - stainless steel, precision casting Instrument housing - Aluminium External housing • VEGAFLEX 80 series... - Page 17 Sensor housing - VEGAFLEX 81 - threaded version with cable ø 2, 4 mm (0.079, 0.157 in) or rod ø 8 mm (0.315 in) Sensor housing - VEGAFLEX 81 - threaded version with rod ø 12 mm (0.472 in) Sensor housing - VEGAFLEX 81 - flange version with cable ø 2, 4 mm (0.079, 0.157 in) or rod ø 8 mm (0.315 in) Sensor housing - VEGAFLEX 81 - flange version with rod ø 12 mm (0.472 in) External housing • VEGAFLEX 80 series...
- Page 18 Sensor housing - VEGAFLEX 82 - threaded version with cable ø 4, 6 mm (0.157, 0.236 in) Sensor housing - VEGAFLEX 82 - threaded version with cable ø 6, 11 mm (0.236, 0.433 in) or rod ø 16 mm (0.63 in) Sensor housing - VEGAFLEX 82 - flange version with cable ø 4 mm (0.157 in) Sensor housing - VEGAFLEX 82 - flange version with cable ø 6, 11 mm (0.236, 0.433 in) or rod ø 16 mm (0.63 in) External housing • VEGAFLEX 80 series...
- Page 19 Sensor housing - VEGAFLEX 83 - Clamp version Sensor housing - VEGAFLEX 83 flange version Sensor housing VEGAFLEX 83 - polished Fig. 9: Sensor housing VEGAFLEX 83 - polished Sensor housing - VEGAFLEX 83 - slotted nut Sensor housing - VEGAFLEX 83 - Clamp version External housing • VEGAFLEX 80 series...
- Page 20 SW 41 mm G1½, 1½ NPT / G 1, 1 NpT Fig. 10: Sensor housing VEGAFLEX 86, 250 °C Sensor housing - VEGAFLEX 86 - threaded version Sensor housing - VEGAFLEX 86 - flange version Max. height of the vessel insulation External housing • VEGAFLEX 80 series...
- Page 21 SW 60 mm SW 60 mm (2.36") (2.36") G1½, 1½ NPT Fig. 11: Sensor housing VEGAFLEX 86, 280 °C Sensor housing - VEGAFLEX 86 - threaded version Sensor housing - VEGAFLEX 86 - flange version Max. height of the vessel insulation External housing • VEGAFLEX 80 series...
- Page 22 9 Supplement Sensor housing VEGAFLEX 86, 450 °C G1½, 1½ NPT Fig. 12: Sensor housing VEGAFLEX 86, 450 °C Sensor housing - VEGAFLEX 86 - threaded version Sensor housing - VEGAFLEX 86 - flange version Max. height of the vessel insulation External housing • VEGAFLEX 80 series...
- Page 23 Notes External housing • VEGAFLEX 80 series...
- Page 24 Subject to change without prior notice © VEGA Grieshaber KG, Schiltach/Germany 2020 VEGA Grieshaber KG Phone +49 7836 50-0 Am Hohenstein 113...
