- Page 1 Quick setup guide TDR sensor for continuous level measurement of bulk solids VEGAFLEX 82 Modbus Rod and cable probe Document ID: 57769...
-
Page 2: Table Of Contents
Operating Instructions Manual as well as the Safety Manual that comes with instruments with SIL qualification. These manuals are available in the download area of "www.vega.com". Operating instructions VEGAFLEX 82 - Modbus - Rod and cable probe: Document-ID 51516 Editing status of the quick setup guide: 2018-10-30 VEGAFLEX 82 • Modbus... -
Page 3: For Your Safety
During work on and with the device, the required personal protective equipment must always be worn. Appropriate use VEGAFLEX 82 is a sensor for continuous level measurement. You can find detailed information about the area of application in chapter "Product description". Operational reliability is ensured only if the instrument is properly used according to the specifications in the operating instructions manual as well as possible supplementary instructions. -
Page 4: Eu Conformity
That is why we have introduced an environment management system with the goal of continuously improving company environmental pro- tection. The environment management system is certified according to DIN EN ISO 14001. Please help us fulfil this obligation by observing the environmental instructions in this manual: • Chapter "Packaging, transport and storage" • Chapter "Disposal" VEGAFLEX 82 • Modbus... -
Page 5: Product Description
Go to "www.vega.com", "Instrument search (serial number)". Enter the serial number. Alternatively, you can access the data via your smartphone: • Download the VEGA Tools app from the "Apple App Store" or the "Google Play Store" VEGAFLEX 82 • Modbus... - Page 6 2 Product description • Scan the Data Matrix code on the type label of the instrument or • Enter the serial number manually in the app VEGAFLEX 82 • Modbus...
-
Page 7: Mounting
Mounting instructions Installation position Mount VEGAFLEX 82 in such a way that the distance to vessel instal- lations or to the vessel wall is at least 300 mm (12 in). In non-metallic vessels, the distance to the vessel wall should be at least 500 mm (19.7 in). - Page 8 Use a probe in coax version for applications in liquids. Fig. 3: Mounting in non-metallic vessel Flange Metal sheet Concrete vessel When mounting in thick concrete ceilings, VEGAFLEX 82 should be mounted front flush to the lower edge. In concrete silos, the distance to the wall should be at least 500 mm (20 in). VEGAFLEX 82 • Modbus...
- Page 9 Check if this is relevant for your measurement. In such cases, always carry out a false signal suppression after mounting. You can find further information under "Setup procedure". DN25 ... DN150 ≤ 150 mm (5.91") ≤ 100 mm (3.94") > DN150 ... DN200 Fig. 5: Mounting socket When welding the socket, make sure that the socket is flush with the vessel top. VEGAFLEX 82 • Modbus...
- Page 10 3 Mounting Fig. 6: Socket must be installed flush Unfavourable mounting 2 Socket flush - optimum mounting VEGAFLEX 82 • Modbus...
-
Page 11: Connecting To Power Supply
When the screwdriver is released, the terminal closes again. You can find further information on the max. wire cross-section under "Technical data - Electromechanical data". 7. Check the hold of the wires in the terminals by lightly pulling on them 8. Connect the screen to the internal ground terminal, connect the external ground terminal to potential equalisation VEGAFLEX 82 • Modbus... -
Page 12: Wiring Plan, Single Chamber Housing
Power supply (to further Modbus sensors) Signal output (to further Modbus sensors) Ground terminal in the housing Terminal block - Output (OUT) Terminal block - Input (IN) Rotary switch for address setting 9 Contacts for the display and adjustment module or the interface adapter 10 Signal lamp - Status 11 Connectable bus resistor VEGAFLEX 82 • Modbus... - Page 13 Status 1 2 = Power supply 3 4 = Modbus Data 5 6 = Power supply addr. 7 8 = Modbus Data 5 6 7 8 Fig. 9: Electronics compartment - Connection with stub Voltage supply Signal output Ground terminal in the housing VEGAFLEX 82 • Modbus...
-
Page 14: Set Up With The Display And Adjustment Module
Parameter adjustment - Quick setup To quickly and easily adapt the sensor to the application, select Quick setup the menu item "Quick setup" in the start graphic on the display and adjustment module. You can find "Extended adjustment" in the detailed operating instructions. VEGAFLEX 82 • Modbus... - Page 15 In this menu item, you can select the application. You can choose between level measurement and interface measurement. You can also choose between measurement in a vessel or in a bypass or standpipe. Level measurement Medium - dielectric constant In this menu item, you can define the type of medium (product). Max. adjustment In this menu item, you can enter the max. adjustment for the level. VEGAFLEX 82 • Modbus...
- Page 16 Corresponding linearisation curves are preprogrammed for these vessels. They represent the correlation between the level percentage and vessel volume. The linearization applies for the measured value indication and the current output. By activating the suitable curve, the percentage vessel volume is displayed correctly. VEGAFLEX 82 • Modbus...
-
Page 17: Supplement
0.2 … 2.5 mm² (AWG 24 … 14) Ʋ Stranded wire with end sleeve 0.2 … 1.5 mm² (AWG 24 … 16) Voltage supply Operating voltage 8 … 30 V DC Power consumption < 500 mW Reverse voltage protection Integrated VEGAFLEX 82 • Modbus... - Page 18 Notes VEGAFLEX 82 • Modbus...
- Page 19 Notes VEGAFLEX 82 • Modbus...
-
Page 20: Information
Subject to change without prior notice © VEGA Grieshaber KG, Schiltach/Germany 2018 VEGA Grieshaber KG Phone +49 7836 50-0 Am Hohenstein 113...
