Note: The maximum cable length is the cable length that the signal can travel without
suffering from attenuation (degradation).

3 INSTALLATION

Danger: Infrared radiation is invisible and can seriously damage the retina of the eye. Do not
look into the ends of any optical fiber or connector.
LEDs, fiber connections, and RJ45 connection are located on the front. Power connection is
located on the back of the set top unit. Install the OptEnet Set Top Media Converter using one of
the following procedures:
3.1

Unpacking and Inspection

1. Inspect the exterior of the shipping container(s) for evidence of rough handling that may
have damaged the components in the container.
2. Unpack desk top unit, carefully check for damage and verify with the packing slip. If any
item is damaged, consult ADC for repair, replacement, and warranty information. Even
though no damage is evident, save the shipping container for use if the equipment requires
shipment at a future date.
3. File a claim with the commercial carrier and notify ADC Customer Service if damage is
detected or if parts are missing. Save damaged cartons for inspection by the carrier.
4. Refer to
5. Save all shipping containers for use if the equipment requires shipment at a future date.
3.2

Ground Connection

To assure proper operation the ground stud located on the back of the set top unit (see
should be connected to a good earth ground. There must be no switching or disconnecting
devices in the grounding circuit conductor between the set top unit and the point of connection
to the grounding electrode conductor.
This procedure establishes a ground connection between the set top unit and a ground
connection. A frame ground termination (#8 screw) is provided on the back of the set top unit,
for a frame ground connection. This connection must be made in accordance with all local and
national electrical codes. Set top unit should be connected directly to a grounding electrode
conductor or to a bonding jumper from a grounded electric box.
1. Using AWG 16 (1.25mm) solid copper wire, connect one end of the ground wire to the
ground stud at the back of the set top unit (shown in
pound-force inches (1.7 Newton meters) of torque.
2. To assure proper operation, ground stud must be connected to a good earth ground.
