Table 9. Optical Specifications
NETWORK
SingleMode (
1270 nm min./1355 nm max. Wavelength (1310 nm typical)
Output Optical Power
100Base-LX
100Base-LH
Input Optical Power
100Base-LX
100Base-LH
1480 nm min./1580 nm max. Wavelength (1550 nm typical)
Output Optical Power
100Base-LH
Input Optical Power
100Base-LH
MultiMode (50/125µm or 62.5/125µm)
800 nm min./900 nm max. Wavelength (850 nm typical)
Output Optical Power
100Base-SX
Input Optical Power
100Base-SX
1270 nm min./1360 nm max. Wavelength (1300 nm typical)
Output Optical Power
100Base-FX
Input Optical Power
100Base-FX
SPECIFICATION
9/125µm)
–15 dBm min. to –8 dBm max.
–8 dBm min. to –2 dBm max.
–32 dBm min. to –8 dBm max.
–34 dBm min. to –7 dBm max.
–5 dBm min. to 0 dBm max.
–34 dBm min. to –7 dBm max.
–17 dBm min. to –12 dBm max.
–26 dBm min. to –12 dBm max.
–19 dBm min. to –14 dBm max.
–32 dBm min. to –11 dBm max.
