10 SPECIFICATIONS

Table 7, Table
PARAMETER
Operating Conditions
Short Term Conditions +23°F to +122°F (
Storage Conditions
PARAMETER
Electrical
Input Voltage
Operating Voltage
Input power
Fuse Size
Mechanical
Dimensions (H×W×D)
Weight
Electrical Signal Interface
RJ45
RJ45
Optical Signal Interface
SC Duplex
SC Duplex
8, and Table 9 lists the specifications for the set top unit.
Table 7. Set Top Environmental Specifications
SPECIFICATION
41°F to +104°F (5°C to +40°C)
−
40°F to +160°F (
Table 8. Set Top Electrical and Mechanical Specifications
SPECIFICATION
+24VDC, –48VDC, or 110 to 240VAC
+5 VDC
2.2 W max.
0.25 Amp
1.55 in.×4.25 in.× 9.09 in. (3.94 cm ×
10.8 cm × 23.1 cm)
1.67 lb. (757.5 g.)
Two twisted pair
Four twisted pair
Singlemode (9/125µm)
Multimode (62.5/125µm or 50/125µm)
−
5°C to +50°C)
−
40°C to +70°C) at 5% to 95% RH Non-condensing
ADCP-92-052 • Issue 2 • May 2004
REMARKS
Per Telcordia GR-63
Per Telcordia GR-63
REMARKS
50–60 Hz
Backplane connector
Normal operation
At –48VDC
10/100 Mb/s
1000 Mb/s
1310 nm/1550 nm
850 nm/1300 nm
