2 TRANSMISSION RANGES

The OptEnet 10/100/1000 Mb/s Media Converters support 10BaseT, 100BaseTX, and 1000BaseT
data rates. Singlemode and multimode units are available.
NETWORK
10BaseT
10BaseFL
100BaseTX
100BaseFX
100BaseSX
100BaseLX
100BaseLH
100BaseLH
1000BaseT
1000BaseCX Gigabit
1000BaseSX Gigabit
1000BaseLX Gigabit
1000BaseLH Gigabit
UTP = Unshielded Twisted Pair
* - The maximum distance that any optical link can support is dependent upon attenuation and dispersion
at a particular wavelength, maximum bit rate, receiver sensitivity, splice and connector loss, etc. The
information presented for single mode and multi-mode cable is based on the applicable applications
standards and does not consider installation variables.
LED or
LASER
OPTICAL
TRANSCEIVER
PIN
Figure 2. Basic 10/100/1000Base-X Media Converter Block Diagram
Table 1. Cable Specifications
DATA RATE MEDIA
10 Mb/s UTP Cat 3, 4, or 5 (2-pair) 328 feet (100 m)
10 Mb/s 850 nm multimode fiber
100 Mb/s UTP Cat 5 (2-pair)
100 Mb/s 1300 nm multimode fiber
10/100 Mb/s 850 nm multimode fiber
10/100 Mb/s 1300 nm singlemode fiber 9.3 miles (15 km) 9/125µm
10/100 Mb/s 1300 nm singlemode fiber 24.9 miles (40 km) 9/125µm
10/100 Mb/s 1550 nm singlemode fiber 49.7 miles (80 km) 9/125µm
Gigabit UTP Cat 5e (4-pair)
Balanced STP, 150
850 nm multimode fiber
850 nm multimode fiber
1300 nm multimode fiber
1300 nm singlemode fiber
1550 nm singlemode fiber 43.5 miles (70 km) 9/125µm
10/100/1000
RJ-45
ETHERNET
TRANSCEIVER
18991-B
Table 1 lists the cable specifications.
LENGTH
6562 feet (2000 m)* 62.5/125µm or 50/125µm
328 feet (100 m)
6562 feet (2000 m)* 62.5/125µm or 50/125µm
984 feet (300 m) 62.5/125µm or 50/125µm
328 feet (100 m)
Ω
Z 82 feet (25 m)
o
722 feet (220 m) 62.5/125µm
1804 feet (550 m) 50/125µm
1804 feet (550 m) 62.5/125µm or 50/125µm
6.2 miles (10 km) 9/125µm
