ADCP-92-052 • Issue 2 • May 2004 ™ OptEnet Set Top Ethernet Media Converter User Manual 18915-A Content Page INTRODUCTION ................2 Revision History . -
Page 2: Introduction
DESCRIPTION OF CHANGE 6 & 7 Ground connection Trademark Information ADC is a registered trademark of ADC Telecommunications, Inc.; OptEnet is a trademark of ADC Telecommunications, Inc. Admonishments Important safety admonishments are used throughout this manual to warn of possible hazards to persons or equipment. -
Page 3: Fcc Compliance Statement
ADCP-92-052 • Issue 2 • May 2004 Caution: Electronic modules can be damaged by electrostatic discharge (ESD). To prevent this, take the following precautions: • Wear an anti-static-discharge wrist strap while handling modules. • Place modules in anti-static packing material when transporting or storing them. - Page 4 ADCP-92-052 • Issue 2 • May 2004 network length between same media nodes such as hubs, switches, workstations, routers, and NIC configured devices on the same network. It may also be used to interconnect Ethernet copper nodes to fiber nodes such as hubs, switches, fiber panels, workstations, and routers on the same network.
-
Page 5: Transmission Ranges
ADCP-92-052 • Issue 2 • May 2004 LED or LASER 10/100/1000 UTP CABLE OPTICAL RJ-45 ETHERNET TRANSCEIVER TRANSCEIVER 18991-B Figure 2. Basic 10/100/1000Base-X Media Converter Block Diagram 2 TRANSMISSION RANGES The OptEnet 10/100/1000 Mb/s Media Converters support 10BaseT, 100BaseTX, and 1000BaseT data rates. -
Page 6: Installation
3. File a claim with the commercial carrier and notify ADC Customer Service if damage is detected or if parts are missing. Save damaged cartons for inspection by the carrier. -
Page 7: Desk Top Installation
ADCP-92-052 • Issue 2 • May 2004 3. Connect the other end of the ground wire to the office ground conductor. Ensure this connection is made using methods and hardware that meets all applicable local and national electrical codes. Desk Top Installation 1. -
Page 8: Cabling
ADCP-92-052 • Issue 2 • May 2004 18917-A OptEnet Media Converter In Mounting Bracket Figure 3. Inserting 4 CABLING 1. All fiber connections are made on the front of the set top unit. Verify that the POWER LED is lit. - Page 9 ADCP-92-052 • Issue 2 • May 2004 18915-A Figure 4. OptEnet Converter Ethernet Connections 4. Each Ethernet media converter set top unit has an RJ45 connector located on the front. Use this connector when making the copper Ethernet connection. If an RJ45 Patchcord is...
-
Page 10: Front Panel Operation
ADCP-92-052 • Issue 2 • May 2004 PIN 1 PIN 8 RJ-JACK 11899-A Figure 5. RJ45 Connector Wiring 5. Connect Ethernet RJ45 patchcord to RJ45 receptacle on the set top unit. 6. Verify that the POWER LED is active. 5 FRONT PANEL OPERATION The RJ45 connector has one LED TP (Twisted Pair) link, located, below the connector. -
Page 11: Rear Panel Operation
ADCP-92-052 • Issue 2 • May 2004 18918-A Figure 6. OptEnet 10/100 Mb/s Converter Front View Table 5. 1000 Mb/s Set Top Unit Front Panel LED Indicators SIGNAL COLOR STATUS TP Link GREEN Link status 1000 Mb/s is OK. Link status failed or no Ethernet detected. -
Page 12: Power-Up/Check Out Procedure
ADCP-92-052 • Issue 2 • May 2004 Table 6. Set Top Rear Panel LED Indicators SIGNAL COLOR STATUS Loss of signal or operating voltage, or mismatch of speed on 10/100 set top unit Normal operation GREEN Set top unit Power OK... -
Page 13: 1000 Mb/S Set Top Check Out Procedure
ADCP-92-052 • Issue 2 • May 2004 1000 Mb/s Set Top Check Out Procedure OptEnet 1000 Mb/s Media Converter modules support Medium Dependent Interface Crossover (MDI-X). OptEnet Media Converter Module Ethernet ports allow connections to other hubs or switches without a null-modem or crossover cable. If a null-modem or crossover cable has been used the OptEnet 1000 Mb/s Media Converter module automatically detects this and switches the contacts to match the other end. -
Page 14: Troubleshooting
ADCP-92-052 • Issue 2 • May 2004 9 TROUBLESHOOTING This section provides a troubleshooting flowchart, and corrective actions for the set top unit. Power-up the Media Converter Module by connecting power to the module. Does the rear PWR LED on Check power source. -
Page 15: Specifications
ADCP-92-052 • Issue 2 • May 2004 10 SPECIFICATIONS Table Table 8, and Table 9 lists the specifications for the set top unit. Table 7. Set Top Environmental Specifications PARAMETER SPECIFICATION REMARKS Operating Conditions 41°F to +104°F (5°C to +40°C) Per Telcordia GR-63 −... - Page 16 ADCP-92-052 • Issue 2 • May 2004 Table 9. Optical Specifications NETWORK SPECIFICATION SingleMode ( 9/125µm) 1270 nm min./1355 nm max. Wavelength (1310 nm typical) Output Optical Power 100Base-LX –15 dBm min. to –8 dBm max. 100Base-LH –8 dBm min. to –2 dBm max.
-
Page 17: Customer Information And Assistance
Contents herein are current as of the date of publication. ADC reserves the right to change the contents without prior notice. In no event shall ADC be liable for any damages resulting from loss of data, loss of use, or loss of profits and ADC further disclaims any and all liability for indirect, incidental, special, consequential or other similar damages.
