INTRODUCTION
This manual describes the OptEnet 10/100 or 1000 Mb/s Media Converter Module with SFPs, and
provides procedures for unpacking, installing, and operating this product.
Revision History
ISSUE
1
05/2005
1323274 Rev A
Front Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1000 Mb/s Module. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
10/100 Mb/s Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
10/100 Mb/s Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
1000 Mb/s Module. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
DATE
REASON FOR CHANGE
Original Publication
™
OptEnet
10/100 or 1000 Mb/s
Ethernet Media Converter
Module with SFPs User Manual
© 2005, ADC Telecommunications, Inc.
ADCP-92-063 • Issue 1 • May 2005
Page
Page 1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ADC 10
Summary of Contents for ADC 10
-
Page 1: Table Of Contents
POWER-UP/CHECK OUT PROCEDURE........ -
Page 2: List Of Changes
PAGE IDENTIFIER – Trademark Information ADC is a registered trademark of ADC Telecommunications, Inc.; OptEnet is a trademark of ADC Telecommunications, Inc. Related Publications Listed below are related manuals and their publication numbers. Copies of these publications can be ordered by contacting the ADC Technical Assistance Center at 1-800-366-3891 (in U.S.A. -
Page 3: General Safety Precautions
The OptEnet Media Converter modules and chassis complies with the requirements of GR-63- CORE, Issue 1, October 1995 and GR-1089-CORE, Issue 2, December 1997 with Revision 1, February 1999 as specified in SR-3580, Issue 1, 1995. ADCP-92-063 • Issue 1 • May 2005 Page 3 © 2005, ADC Telecommunications, Inc. -
Page 4: Product Description
ADCP-92-063 • Issue 1 • May 2005 1 PRODUCT DESCRIPTION The OptEnet 10/100 or 1000 Mb/s Media Converter with Small Form-factor Pluggable (SFP) module is one of a family of modules that can be plugged into a OptEnet Media Converter chassis. - Page 5 Figure 2. OptEnet Media Converter Converter SIGNAL COLOR STATUS TP Link YELLOW Auto negotiation complete, link status 10 Mb/s is OK. GREEN Auto negotiation complete, link status 100 Mb/s or 1000 Mb/s is OK. Link status failed or no Ethernet detected. Link YELLOW Auto negotiation complete, link status 10 Mb/s is OK.
-
Page 6: Unpacking And Inspection
3. File a claim with the commercial carrier and notify ADC Customer Service if damage is detected or if parts are missing. Save damaged cartons for inspection by the carrier. -
Page 7: 10/100 Mb/S Module
4. If not already installed insert SFP into OptEnet media converter until you hear it click in place. Figure 3. Installing Media Converter Module ADCP-92-063 • Issue 1 • May 2005 Figure 20473-A Page 7 © 2005, ADC Telecommunications, Inc. - Page 8 RECEIVE OPTICAL TRANSMIT Figure 4. 10/100 Mb/s OptEnet Media Converter Module Connections Caution: Ethernet signals over copper should not be used between buildings. Ground potential differences may cause transmission errors or line card failures. 8. Each media converter module has an RJ45 connector located on the front. Use this connector when making the copper Ethernet connection.
- Page 9 7 and 8. 9. Connect Ethernet RJ45 patchcord to RJ45 receptacle on the converter module. 10. Verify that the front panel LEDs are active. Link LEDs are not lighted if there is no Ethernet or optical signal present.
-
Page 10: Specifications
ADCP-92-063 • Issue 1 • May 2005 4 SPECIFICATIONS Table 6 Table 7 PARAMETER Electrical Input Voltage Input power (10/100 Mb/s) Input power (1000 Mb/s) Mechanical Chassis Compatibility Module Retention Dimensions (H×W×D) Weight Electrical Signal Interface RJ45 RJ45 Optical Signal Interface Refer to the OptEnet SFP Transceiver Specifications listed in optical specifications. -
Page 11: 10/100 Mb/S Module
If a valid optical link has been established, FOLink LED will be YELLOW for 10 Mb/s operation or GREEN for 100 Mb/s operation. The preferred mode of operation for the port is auto select for both speed and duplex. This will insure that a link can be established regardless of the far end operational mode. -
Page 12: Troubleshooting
Module light? Do both Media Converter Module Link LEDs light? Link Yellow 10 Mb/s signal asserted. Link Green 100 Mb/s or 1000 Mb/s signal asserted. TPLink Yellow 10 Mb/s signal asserted. TPLink Green 100 Mb/s or 1000 Mb/s signal asserted. -
Page 13: Customer Information And Assistance
Contents herein are current as of the date of publication. ADC reserves the right to change the contents without prior notice. In no event shall ADC be liable for any damages resulting from loss of data, loss of use, or loss of profits and ADC further disclaims any and all liability for indirect, incidental, special, consequential or other similar damages.
