Transmission Ranges - ADC OptEnet User Manual

OptEnet SM to MM Media Converter units support protocol and data rates between 10 Mb/s and
650 Mb/s with a binary NRZ optical line code.
SIGNAL TYPE/PROTOCOL
Ethernet
Ethernet/FDDI
Digital Video
ATM/SONET/SDH
* - Systems supporting FDDI or 100 Mb/s Ethernet must support a BER of 1 X 10
received power is 2dB above the minimum receiver level.
** - Bit error rates are defined at the minimum received power level for each protocol. SMPTE stan-
dards for digital protocols do not currently list a BER value.

2 TRANSMISSION RANGES

Maximum cable length for optical transmission depends on the type of fiber used. The
maximum cable length is the cable length that the signal can travel without suffering from
attenuation (degradation). See
NETWORK
10BaseFL
100BaseFX
100BaseSX
100BaseLX
100BaseLH
OC12
1000BaseSX Gigabit
1000BaseLX Gigabit
1000BaseLH Gigabit
* - The maximum distance that any optical link can support is dependent upon attenuation and dispersion
at a particular wavelength, maximum bit rate, receiver sensitivity, splice and connector loss, etc. The
information presented for single mode and multi-mode cable is based on the applicable applications
standards and does not consider installation variables.
Table 1. Supported Data Rates
DATA RATE BER
10 Mb/s 1.0 x 10
100 Mb/s 2.5 x 10
143 Mb/s 1.0 x 10
360 Mb/s 1.0 x 10
540 Mb/s 1.0 x 10
155 Mb/s 1.0 x 10
622 Mb/s 1.0 x 10
Table 2
Table 2. Cable Specifications
DATA RATE MEDIA
10 Mb/s 850 nm multimode fiber
100 Mb/s 1300 nm multimode fiber
10/100 Mb/s 850 nm multimode fiber
10/100 Mb/s 1300 nm singlemode fiber 9.3 miles (15 km) 9/125µm
Gigabit 1550 nm singlemode fiber 49.7 miles (80 km) 9/125µm
622 Mb/s 1300 nm singlemode fiber
1300 nm multimode fiber
850 nm multimode fiber
850 nm multimode fiber
1300 nm multimode fiber
1300 nm singlemode fiber
1550 nm singlemode fiber 43.5 miles (70 km) 9/125µm
Table 1 lists the supported protocols.
RECEIVER LEVEL
–9 –32.5 dBm
–31.0 dBm *
–10
**
–10
–10
–10
–19.0 dBm
–10
–26.0 dBm
–10
for cable specifications.
LENGTH
2562 feet (2000 m)* 62.5/125µm or 50/125µm
2562 feet (2000 m)* 62.5/125µm or 50/125µm
984 feet (300 m) 62.5/125µm or 50/125µm
9.3 miles (15 km) 9/125µm
1640 feet (500 m) 62.5/125µm
722 feet (220 m) 62.5/125µm
1804 feet (550 m) 50/125µm
1804 feet (550 m) 62.5/125µm or 50/125µm
6.2 miles (10 km) 9/125µm
ADCP-92-047 • Issue 1 • January 2004
REMARKS
10BASE-FL
100BASE-FX
OC-3, Applied to LW Laser
OC-12
when the
–12
© 2004, ADC Telecommunications, Inc.
Page 5
