10 SPECIFICATIONS

Table 5 and
PARAMETER
Operating Conditions
Short Term Conditions +23°F to +122°F (
Storage Conditions
PARAMETER
Electrical
Input Voltage
Operating Voltage
Input power
Fuse Size
Mechanical
Dimensions (H×W×D)
Weight
Optical Signal Interface
SC Duplex
SC Duplex
Optical Characteristics
Output Optical Power (Transmitter) –15 dBm min. –8 dBm max.
Input Optical Power (Receiver)
Wavelength
Output Optical Power
62.5/125µm
50/125µm
Wavelength
Input Optical Power
Wavelength
Table 6 lists the specifications for the set top unit.
Table 5. Set Top Environmental Specifications
SPECIFICATION
41°F to +104°F (5°C to +40°C)
−
40°F to +160°F (
Table 6. Set Top Specifications
SPECIFICATION
+24VDC, –48VDC, or 110 to 240VAC
+5 VDC
2.7 W max. at 5 Volts
0.25 Amp
1.55 in.×4.25 in.× 9.09 in. (3.94 cm ×
10.8 cm × 23.1 cm)
1.8 lb. (816 g.)
Singlemode (9/125µm)
Multimode (62.5/125µm or 50/125µm)
–7 dBm min. –28 dBm max.
1274 – 1356 nm range
–20 dBm min. –14 dBm max.
–22 dBm min. –14 dBm max.
1270 – 1380 nm range
–26 dBm min. –14 dBm max.
1270 – 1380 nm range
−
5°C to +50°C)
−
40°C to +70°C) at 5% to 95% RH Non-condensing
SingleMode ( 9/125µm)
Multi Mode (Transmitter)
Multi Mode (Receiver)
ADCP-92-047 • Issue 1 • January 2004
REMARKS
Per Telcordia GR-63
Per Telcordia GR-63
REMARKS
50–60 Hz
Backplane connector
Normal operation
At –48VDC
1310 nm
1310 nm
1313 nm typical
1313 nm typical
1313 nm typical
Page 11
© 2004, ADC Telecommunications, Inc.
