Using the
EVAL-3CH4CHSOICEBZ

FEATURES

Access to all 4 data channels
Enable/disable controls
Multiple connection options
Support for active probes
Provision for cable terminations
Support for PCB edge-mounted coaxial connectors
Easy configuration
Sample iCoupler digital isolator must be ordered separately

SUPPORTED iCoupler GENERICS

ADuM1300/ADuM1301
ADuM1310/ADuM1311
ADuM1400/ADuM1401/ADuM1402
ADuM1410/ADuM1411/ADuM1412
ADuM2400/ADuM2401/ADuM2402
ADuM3300/ADuM3301
ADuM3400/ADuM3401/ADuM3402
ADuM4400/ADuM4401/ADuM4402
ADuM130D/ADuM130E/ADuM131D/ADuM131E
ADuM140D/ADuM140E/ADuM141D/ADuM141E/ADuM142D/
ADuM142E
ADuM230D/ADuM230E/ADuM231D/ADuM231E
ADuM240D/ADuM240E/ADuM241D/ADuM241E/ADuM242D/
ADuM242E
PLEASE SEE THE LAST PAGE FOR AN IMPORTANT
WARNING AND LEGAL TERMS AND CONDITIONS.
EVAL-3CH4CHSOICEBZ User Guide
iCoupler Data Isolator Evaluation Board

GENERAL DESCRIPTION

The
EVAL-3CH4CHSOICEBZ
and quad-channel standard data isolators in 16-lead SOIC
packages. The evaluation board provides a JEDEC standard
16-lead SOIC_N and SOIC_W pad layout and routing appropriate
for the evaluation of supported devices. The evaluation board
provides a connection to power supplies by screw terminals and
includes optimal bypass capacitors. Signal channel routing supports
signal distribution, loopback, and provides positions for loads
referenced to the VDD1/VDD2 and GND1/GND2 planes. Signal
sources can be conducted to the board through header pins or
edge-mounted SMA connectors; SMA connectors must be ordered
separately. Positions for through-hole 0.2 inch headers compatible
with active probes are provided on the printed circuit board (PCB);
probe header pins must be ordered separately.
The board follows PCB design practices for 4-layer boards,
including a full power and ground plane on each side of the
isolation barrier. No other EMI or noise mitigation design
features are included on the board. In cases of very high speed
operation or when ultralow emissions are required, refer to the
AN-1109
application note for additional board layout techniques.
Full specifications for the device under test (DUT) are available in
the corresponding product data sheet, which should be consulted
in conjunction with this user guide when using the
evaluation board.
Rev. 0 | Page 1 of 10
UG-935
evaluation board supports triple-
