RELay CONfIgURaTION
RELAy STATuS:
Note: The receiver factory default setting is pulse for both relay
Press down PR or PV for 4 sec. and note the LED state (LR or LV).
The following table determine the relay status :
Relay operating mode
LED operating mode
( RR or RV )
Pulse
Latched (RR only)
Timed
RELAy SETTiNg:
The relay operating mode is cyclic, change the mode according to the
following rules:
Relay operating mode cycle
If the relay is set as pulse
If the relay is set as latching
If the relay is set as timed
Relay Configuration Not Allowed
Relay 1 (RR) latching and Relay 2 (RV) timed
Relay 1 (RR) timed and relay 2 (RV) timed (with different delay time)
To change the mode follow these steps:
Press PV or PR for 4 seconds. LED will illuminate displaying relay
1)
status. Use Table above to determine the status.
2)
Within 1 sec., press PR to change the relay mode. The relay
mode will change according to the relay setting table above.
Note: To configure the relay output time, enter the timing sequence
after step 2, see relay timing table below.
RELAy TiMiNg:
important: To set or modify relay timing, the relay has to be set as
pulse before.
1)
Press PR for 4 sec. The LR LED will turn ON (if not, set the relay
operation to pulse, see Relay Setting section).
2)
Press PR for 1 sec. and LR LED switche to OFF. Within 2
seconds, start the seven digit, PR and PV sequence, to set the
relay timing (See table below)
PR= not seclected (0)
PV= selected (1)
Pressing sequence
1
1
Seconds
10
20
2
Minutes
20
40
Example 1: 8 sec. relay activation
Pressing sequence
1
PR
PR
Seconds
10
20
2
Minutes
20
40
Input sequence= PR + PR + PR + PV + PR + PR + PR= 8 sec.
Example 2: 2 min. relay activation
PR and PV
1
pressing sequence
1
Seconds
10
20
PV
PR
Minutes
20
40
Input sequence= PV - PR - PR - PR - PR - PR - PV= 2 min.
For more information, please visit www.devancocanada.com or call toll free at 855-931-3334
Tel: (450) 682-7945, Toll Free Tel: 1-866-610-0102, Fax: (450) 682-9590, Toll Free Fax: 1-866-682-9590
SEL2641R433-IP_IE - Specifications may change without prior notice. Printed in Canada - 15/11/07
Manufacturing Access Control since 1985
( LR or LV )
LED ON
Slow blinking
Fast blinking
1- it becomes latching
2- it becomes timed if you press
the timing sequence after step 2
it becomes pulse
it becomes pulse
2
3
4
5
6
2
4
8
16
PR
40
80
160
PV
4
8
16
32
PR
80
160
320
PV
2
3
4
5
6
PR
PV
PR
PR
40
80
160
PV
4
8
16
32
PR
80
160
320
PV
2
3
4
5
6
2
4
8
16
PR
40
80
160
PV
PR
PR
PR
PR
80
160
320
PV
CDVI® 1645-A Highway 440 West, Laval, Québec, Canada, H7L3W3
MEMORy pOSITION
1)
Press transmitter key to verify if its associated to the receiver. LR
or LV will turn ON and the related relay will activate.
2)
Press and hold PR for 1 sec. and then release it. A sequence
of 7 flashes of the LEDs (LR and LV) starts. Note the LED color
sequence. Refer to the following table to decode the sequence.
Flash sequence
LV (green LED)
LR (red LED)
LR=0 all the time.
Add the value of LV (where it flashes in the sequence) to obtain the
memory position. See example below.
Example 1:
Flash sequence
LV (green LED)
LR (red LED)
Sequence Value
Memory position= 0 + 0 + 4 + 8 + 0 + 0 + 0= 12
The transmitter key is located at memory position #12.
ENROLLED TRaNSMITTER kEyS
1)
Press down PV for 1 sec. LR and LV LED starts a sequence of 7
flashes. Note the color sequence and refer to the above table to
obtain the number of enrolled transmitter keys.
MEMORy RESET (faCTORy DEfaULT)
1)
Press PR until LR LED turns on.
2)
Release PR and within 1 sec. press PR and PV simultaneously
until LR and LV LED starts to flash 3 times (about 4 sec.)
At this point all settings are erased and the receiver is reset to factory
default.
COMpaTIbLE TRaNSMITTERS
7
PR
PR
PV
PV
7
PR
PR
Available with optional
PV
built-in proximity badge
PV
faCILITy CODE aND SERIaL NUMbER LOCaTION
7
PR
PR
PV
PV
Facility code (FC)= 001
1
2
3
4
5
1
2
4
8
16
0
0
0
0
0
1
2
3
4
5
-
-
-
Flash
Flash
-
-
Flash
Flash
Flash
0
0
4
8
0
2-Channel Transmitters
S2TR2641E2
Available with built-in
proximity badge
S2TR2641E2H
4-Channel Transmitters
S2TR2641E4
2-Channel Mini Transmitters
Red: SETR2641AM2R
Blue: SETR2641AM2B
Burgundy: SETR2641AM2C
Dark Gray: SETR2641AM2N
2-Channel
ultra-Thin Transmitters
S5TR2641E2S
4-Channel
ultra-Thin Transmitters
S5TR2641E4S
Serial Number (SN)= 28886
6
7
32
64
0
0
6
7
-
-
Flash
Flash
0
0
