• Tears from ageing insulation;
• Kinks due to inappropriate attachment or guidance
of the connection.
The machine connection cables have to be at least
type H05RN-F and three-core. Printing the type
designation on the connection is the law. Only ever
buy cables with the designation marked! The plugs
and coupling boxes on the machine connection ca-
bles have to be made of rubber and be protected
against spray water. The cables must not be over-
long. Longer cables require larger conductor cross
sections. Power cords and connection cables have to
be checked regularly for damage. Make sure that the
connections are turned off during checking. Unwind
the connection cable fully. Also check cable inputs,
on plugs and coupling boxes, for kinks.

14. Troubleshooting

Problem
Motor does not work.
The motor starts
slowly and does not
reach operating speed.
Motor too noisy
Motor does not reach
peak performance.
Motor overheats
easily.
Reduced cutting
performance during
sawing
Cut is rough or wavy.
Work piece tears or
splinters.
Warning! To protect the motor, it is equipped with a thermal switch which turns it off in the event of overloading. After a
short cooling down phase, the motor is turned on again automatically.
internet: www.scheppach.com / email: service@scheppach.com / telefon: +(49)-08223-4002-99 / telefax: +(49)-08223-4002- 58
internet: www.scheppach.com / email: service@scheppach.com / telefon: +(49)-08223-4002-99 / telefax: +(49)-08223-4002-58
DE GB FR DE
Possible cause
Motor, cable or plug faulty, fuses blown
Voltage too low, winding damaged,
capacitor blown
Winding damaged, motor faulty
Mains electric circuit is overloaded (lamps,
other motors etc.).
Motor overload, insufficient cooling of motor Prevent the motor overloading during cutting,
Saw blade too small (sharpened too often)
Saw blade is blunt, tooth shape is not suited
to material thickness
Cutting pressure too high or saw blade not
suited to application
GB FR DE GB

13. Disposal and recycling

The disposal notices are presented by pictograms
on the machine or on the packaging. A description
of the individual meanings can be found in Chapter
„Description of symbols on the machine".
Disposing of transport packaging
The packaging protects the machine from damage
during transport. The packaging material is usually
chosen for factors of environmental friendliness and
disposal. It can therefore be recycled. Returning the
packaging to the material life cycle saves raw mate-
rial and reduces waste.
Packaging parts (e.g. plastic sheets, Styropor®) can
be dangerous for children. Risk of choking! Store
packaging parts beyond the reach of children and
dispose of them as soon as possible.
Solution
Have the machine checked by a specialist.
Never repair the motor yourself. Danger! Check
fuses and replace, if required.
Have the voltage checked by the electricity
board. Have the motor checked by a specialist.
Have the capacitor replaced by a specialist.
Have the motor checked by a specialist.
Do not use other machines or motors in the
same electric circuit.
remove dust from the motor so that ideal cooling
of the motor is ensured.
Adjust end stop of the saw.
Sharpen the saw blade or put in suitable saw
blade.
Put in a suitable saw blade.
