Brush inspection, fig. 6
If the machine is new, check the carbon brushes after
the first 50 operating hours or if a new brush has been
mounted. After the initial check, check every 10 oper-
ating hours.
If the carbon is worn down to a length of 6 mm, or the
spring or the shunt wire is burnt or damaged, both
brushes must be replaced. If the brushes are found to
be usable after removal, they can be reinstalled.
1. To service the carbon brushes, open both locks
(as shown in figure 6) counter-clockwise.
2. Then remove the carbon brushes.
3. Re-insert the carbon brushes in reverse order.
Service information
With this product, it is necessary to note that the follow-
ing parts are subject to natural or usage-related wear,
or that the following parts are required as consuma-
bles.
Wearing parts*: Carbon brushes, saw band
* may not be included in the scope of supply!
Connections and repairs
Connections and repair work on the electrical equip-
ment may only be carried out by electricians.
Important note in the case of repairs:
When returning the device for repair, please ensure for
safety reasons that it is free of oil and fuel when it is
sent to the service centre.
Spare parts and accessories can be obtained from our
Service Centre. To do this, scan the QR code on the
front page.

16. Transport

Transport the metal band saw by holding it by the han-
dles (9) using your hands.
Carry the machine on the saw table (24) with the metal
band saw mounted to the saw table.
30 | GB www.scheppach.com

17. Disposal and recycling

Notes for packaging
The packaging materials are recy-
clable. Please dispose of packag-
ing in an environmentally friendly
manner.
Notes on the electrical and electronic equipment
act [ElektroG]
Waste electrical and electronic equipment
does not belong in household waste, but
must be collected and disposed of sepa-
rately!
• Used batteries or rechargeable batteries that are not
installed permanently in the old appliance must be
removed non-destructively before disposal. Their
disposal is regulated by the battery law.
• Owners or users of electrical and electronic devices
are legally obliged to return them after use.
• The end user is responsible for deleting their per-
sonal data from the old device being disposed of!
• The symbol of the crossed-out dustbin means that
waste electrical and electronic equipment must not
be disposed of with household waste.
• Waste electrical and electronic equipment can be
handed in free of charge at the following places:
- Public disposal or collection points (e.g. municipal
works yards)
- Points of sale of electrical appliances (stationary
and online), provided that dealers are obliged to
take them back or offer to do so voluntarily.
- Up to three waste electrical devices per type of
device, with an edge length of no more than 25
centimetres, can be returned free of charge to
the manufacturer without prior purchase of a new
device from the manufacturer or taken to another
authorised collection point in your vicinity.
- Further supplementary take-back conditions of
the manufacturers and distributors can be ob-
tained from the respective customer service.
• If the manufacturer delivers a new electrical appli-
ance to a private household, the manufacturer can
arrange for the free collection of the old electrical
appliance upon request from the end user. Please
contact the manufacturer's customer service for
this.
• These statements only apply to devices installed
and sold in the countries of the European Union and
which are subject to the European Directive 2012/19/EU. In countries outside the European Union, different reg-
ulations may apply to the disposal of waste electrical and electronic equipment.

18. Troubleshooting

The following table shows fault symptoms and describes remedial measures in the event of your machine failing to
work properly. If you cannot localise and rectify the problem with this, please contact your service workshop.
Fault Possible cause
Motor does not work Engine, cable or connector defective,
fuses burnt.
The engine runs slowly Voltage too low, coils damaged,
and does not reach the capacitor burnt.
operating speed.
Motor makes excessive Coils damaged, motor defective
noise
The motor does not Circuits in the network are overloaded
reach its full power. (lamps, other motors, etc.)
Motor overheats easily. Overloading of the motor, insufficient
cooling of the motor
Saw cut is rough or Saw band dull, tooth shape not appro-
wavy. priate for the material thickness
Workpiece pulls away Excessive cutting pressure and/or
and/or splinters. saw band not suitable for use.
Burn marks on the Saw band blunt.
wood when working.
Incorrect speed.
Saw band jams when Saw band blunt.
working.
Saw band resinous.
www.scheppach.com
Remedy
Have the machine checked by a specialist.
Never repair the engine yourself.
Danger! Check the fuses and replace them if
necessary.
Have the voltage checked by a utility provider.
Have the engine checked by a specialist.
Have the capacitor replaced by a specialist.
Have the engine checked by a specialist.
Do not use any other equipment or engines on
the same circuit.
Avoid overloading the engine while cutting.
Remove dust from the engine in order to
ensure optimal cooling of the engine.
Sharpen the saw band or insert a suitable saw
band.
Insert a suitable saw band.
Replace the saw band.
Choose a suitable speed for the workpiece to
be cut.
Replace the saw band.
Clean the saw band.
