SMC Networks SMCD3GNV3 User Manual page 162

錯誤 錯誤! 使用 錯誤 錯誤 使用 使用 [常用 使用
Option
Service Name
Service Type
Trigger Port From
Trigger Port To
Target Port From
Target Port To
Interval
SAVE button
CANCEL button
常用] 索引標籤將 常用 常用 索引標籤將 索引標籤將 索引標籤將 Heading 1 套用到您想要在此處顯示的文字
Figure 95. Port Triggering Add Menu
Table 46. Port Triggering Add Menu
Name for identifying the trigger. The name is for reference purposes only.
The type of protocol you want to use with the trigger. Choices are:
•
TCP
•
UDP
•
TCP/UDP ( default )
For example, to track the H.323 protocol, the protocol type should be TCP.
From port ranges of the special application. For example, to track H.323 protocol, the From
port should be 1720.
To port ranges of the special application. For example, to track H.323 protocol, the To port
should be 1720.
Starting port range for the target port listening for the special application.
Ending port range for the target port listening for the special application.
Specify the interval between 50 and 30000 between two continuous sessions. If the interval
exceeds this time interval setting, the sessions are considered to be unrelated.
Click this button to save your settings.
Click this button to discard your settings on the Port Triggering Add menu.
SMCD3GNV Wireless Cable Modem Gateway User Manual
套用到您想要在此處顯示的文字 。 。 。 。
套用到您想要在此處顯示的文字 套用到您想要在此處顯示的文字
Description
162
