SMC Networks SMCD3GNV3 User Manual page 159

錯誤 錯誤! 使用 錯誤 錯誤 使用 使用 [常用 使用
Option
Service Name
Service Type
Service IP Address
Start Public Port
End Public Port
Private Port(s)
Enable Port Range
SAVE button
CANCEL button
常用] 索引標籤將 常用 常用 索引標籤將 Heading 1 套用到您想要在此處顯示的文字 索引標籤將 索引標籤將
Figure 93. Add Service Menu
Table 45. Add Service Menu
Name for identifying the service. The name is for reference purposes only.
The protocol you want to use with the service. Choices are:
•
TCP
•
UDP
•
TCP/UDP ( default )
IP address of the LAN computer or server that is running the service.
Starting number of the port on which the service is provided.
Ending number of the port on which the service is provided. This field is unavailable if the
Gateway is configured for a single public IP port.
Numbers of the ports whose traffic the Gateway forwards to the LAN. If there is a range of
ports, enter the starting private port here and check Enable Port Range. The Gateway
automatically calculates the end private port. The LAN computer server listens for traffic/data
on this port (or these ports).
Check this box to enable the private port range specified in Private Port(s).
Click this button to save your settings.
Click this button to discard your settings on the Add Service menu.
SMCD3GNV Wireless Cable Modem Gateway User Manual
套用到您想要在此處顯示的文字 。 。 。 。
套用到您想要在此處顯示的文字 套用到您想要在此處顯示的文字
Description
159
