Specifications - Bosch ISC-FPB1-W60QS Installation And Operation Manual

Photobeam 5000
Hide thumbs

Advertisement

Photobeam 5000
11

Specifications

Product Name
Model
Outdoor range
Transmitter current draw
Receiver current draw
Power
Optical alignment
Alarm output
Tamper output
EDC output
Interruption time
Operating temperature
Storage temperature
IP rating (indoor)
Weight (each)
Dimensions
Bosch Security Systems, Inc.
Photoelectric Detector
ISC-FPB1-W60QS
60 m (196 ft)
20 mA
10.5VDC – 28 VDC
+/- 90° Horizontally,+/-10° vertically
Form C relay (COM, NC, NO) (dry-contact)
Duration - 2 sec
Contact capacity – 30 VDC, 0.2 A (resistive load)
Resistance - 3.0 Ω or less
Form B, normally closed relay (dry-contact)
Open when cover is open
Contact capacity – 30 VDC, 0.1 A (resistive load)
Resistance - 3.0 Ω or less
Form B, normally closed relay (dry- contact)
Open when EDC is activated
Contact capacity – 30 VDC, 0.2 A (resistive load)
Resistance - 3.0 Ω or less
40 ms - 500 ms (adjustable)
-25° C ー +60° C (-13° F ー +140° F) (96% or less Relative
Humidity)
-30° C ー +70° C (-22° F ー 158° F) (95% or less Relative
Humidity)
IP66
1200 g (2 lbs)
103 x 398 x 99 mm (4.05 x 15.66 x 3.89 in)
Installation and Operation Guide
Specifications | en
ISC-FPB1-W120QS
ISC-FPB1-W200QS
120 m (393 ft)
200 m (656 ft)
25 mA
30 mA
70 mA
2016.02 | 03 | F.01U.305.910
25
