en | Optical alignment
7

Optical alignment

Perform the following to align the detector.
7.1

Level LED - alignment of the Upper Beam

Perform the following to align the upper beam.
Aligning of the upper bean:
1.
2.
3.
4.
Figure 7.1: Optical alignment
Callout ー Description
1 ー Turntable
2 ー Verticle adjustment screw
3 ー Horizontal adjustment screw
Notice!
Turn on Function switches 1 and 2 of the transmitter after finishing the alignment to verify the
monitor LEDs light up once every 3 seconds.
7.2

Level LED - alignment of the Lower Beam

Perform the following to align the lower beam.
Aligning of the lower beam:
1.
2016.02 | 03 | F.01U.305.910
Turn on the transmitter Function switch 1 (Upper Beam). The monitor LED flashes (5
times/sec).
Turn on the receiver Function switch 2 (Level Check) of the receiver.
Look into the scope at the center of the lens from a 10-15 cm (4-5 in) distance, adjust the
horizontal direction by rotating the turntable and the horizontal adjustment screw. Adjust
the vertical direction by rotating the vertical adjustment screw. Adjust until you locate the
other part of the sensor in the center of the scope view.
Check the level LED of the receiver. Perform fine adjustments and repeat procedure until
LED turns off. Refer to Volt meter alignment, page 21.
1
2
Turn on the transmitter Function switch 2 (Lower Beam).
Installation and Operation Guide
5
4
3
Callout ー Description
4 ー Scope view finder
5 ー On/Off switch
6
Photobeam 5000
Bosch Security Systems, Inc.
