MGE UPS Systems Comet EXtreme CLA Installation Manual page 6

2. Installation
1
20
2.5 Connecting the Comet EXtreme CLA module to the power source
1
Page 6 -
51033776EN/AA
90
10
2
3
4
1 2 V -
50
10
+
3
t
B
2 5 A
In
2 5 A
6 5 A h
5
2
Use a 3-conductor cable (shielded, max.
2
length 6 m, 3 x 4 mm conductors) to be
passed through the shielded cable gland.
Use a 25 A circuit breaker
(curve B) for protection.
Note: the cable and circuit breaker are not
supplied with the product.
1. Prepare the cable.
2. Unscrew the plate and dismantle the
metal cable gland on the Comet EXtreme
CLA module.
3. Mount the cable gland on the shielded
cable.
4. Connect the 3 conductors to the terminal
block and refit the plate.
5. Connect the other end of the cable to the
circuit breaker.
Use a flexible cable (3 x 2.5 mm
conductors) to be passed through the plastic
cable gland.
Always connect the earth wire
first. Use a 10 A circuit breaker
(curve C) for protection.
Note: the cable and circuit breaker are not
supplied with the product.
1. Prepare the cable.
2. Unscrew the plate with the plastic cable
gland.
3. Connect the 3 conductors and remount
the plate.
2
