MGE UPS Systems Comet EXtreme CLA Installation Manual page 5

2.2 Checking equipment compatibility
Check that the UPS and CLA modules are compatible:
Comet EXtreme CLA 6kVA
Comet EXtreme CLA 6kVA Rack
2.3 Batteries to be used
Use only 12 V / 65 Ah lead-acid batteries.
Connect them as indicated below to obtain the required backup time:
Comet EXtreme CLA 6kVA 1 string of 20
2.4 Connecting the batteries to the Comet EXtreme CLA module
This operation may be carried out only by qualified electricians using the necessary safety equipment for work on live parts
(insulated tools, gloves, goggles).
For maximum battery life, CLA and UPS modules must be installed in the same room as batteries so that the automatic
regulation of the charge voltage as a function of temperature can work correctly.
Backup time
12V / 65Ah batteries
The connection of each module to the electrical supply must be protected by an easily accessible circuit
breaker (not supplied). A module can be isolated from the electrical supply by opening this circuit
breaker.
Before making any connections or working on the equipment, make sure the battery circuit breaker is in OFF
position and that the main contacts of the upstream protective devices of the electrical installation are open (OFF
position).
UPS no.
51033060 or 51033061
51033561
2 hours
2 parallel-connected strings of 20
12V / 65Ah batteries
2. Installation
51033069
51033569
4 hours
3 parallel-connected strings of 20
12V / 65Ah batteries
CLA no.
8 hours
- Page 5
51033776EN/AA
