- Page 1 www.mgeups.com MGE UPS SYSTEMS Comet EXtreme CLA 12 kVA Installation manual - Page 1 51033777EN/AB...
- Page 2 Page 2 - 51033777EN/AB...
- Page 3 1. Unpacking ... and checking the contents Comet EXtreme CLA 12 kVA Tower model Rack model Comet EXtreme CLA module. connection box. connection cable. installation manual. documentation. telescopic rails and 19" rack mounting hardware. - Page 3 51033777EN/AB...
-
Page 4: Installation
2. Installation 2.1 Mounting (Rack model) Mounting the rails in the rack The rails and the screws required to mount them are included in the box. To mount the connection box in a rack, use the mounting brackets and screws packed with the connection box. Page 4 - 51033777EN/AB... - Page 5 2. Installation 2.2 Checking equipment compatibility Check that the UPS and CLA modules are compatible: UPS no. CLA no. (x2) Conn. box no. Comet EXtreme CLA 12kVA 51033120 or 51033121 51033069 51033772 51033602 51033772 Comet EXtreme CLA 12kVA (Rack) 51033569 2.3 Batteries to be used Use only 12 Volt/65 Ah lead-acid batteries.
- Page 6 2. Installation 2.5 Connecting the batteries to the connection box Use a 3-conductor cable (shielded, max. length 6 m, 3 x 10 mm conductors) to be passed through the shielded cable gland. 5 0 A Use a 50 A circuit breaker (curve B) for protection.
- Page 7 2. Installation 2.7 Connecting the UPS to the two Comet EXtreme CLA modules Use the connection cables supplied with the modules. 2.8 Setting the UPS Before connecting the loads to be protected and starting the system, the UPS must be reconfigured using the UPS Driver software supplied on a diskette with the UPS.
-
Page 8: Technical Specifications
3. Technical specifications Dimensions and weights For 1 module Dimensions in mm (H x W x D) Weight in kg Tower model 443 x 173 x 465 Rack model 177(4U) x 483 x 462 Operating voltage and frequency of the Comet EXtreme CLA Voltage: 160 to 260 volts. - Page 9 5103377700/AB...
-
Page 10: Mge Ups Systems
MGE UPS SYSTEMS Nothing will stop you now 140, Avenue Jean Kuntzmann ZIRST - Montbonnot St Martin 38334 - Saint Ismier Cedex - France www.mgeups.com 5103377700/AB 5103377700-AB...
