- Page 1 Pulsar EX 700 / 1000 / 1500 Installation and user manual - Page 1 51031604EN/AA...
- Page 2 Pulsar EX at the end of its service life. To discover the entire range of MGE UPS SYSTEMS products and the options available for the Pulsar EX range, we invite you to visit our web site at www.mgeups.com or contact your MGE UPS SYSTEMS representative.
-
Page 3: Special Precautions
Safety rules Safety of persons A UPS has its own internal power source (the battery). Consequently, the power outlets may be energised even if the UPS is disconnected from the AC-power source. Dangerous voltage levels are present within the UPS. It should be opened exclusively by qualified service personnel. -
Page 4: Using This Document
Foreword Using this document Information may be found primarily by consulting: the contents, the index. Pictograms Important instructions that must always be followed. Information, advice, help. Visual indication. Action. Audio indication. In the illustrations on the following pages, the symbols below are used: LED off. -
Page 5: Table Of Contents
Presentation Pulsar EX range ... 7 Tower model ... 7 Rack model ... 7 Back ... 8 Tower model ... 8 Rack model ... 9 Control panel ... 10 Installation Unpacking and checks ... 11 Tower model ... 11 Rack model ... 12 Installation of the rack version ... - Page 6 Contents Personalisation (optional) ... 19 Function ... 19 "ON / OFF conditions" tab ... 19 "Battery" tab ... 19 "Output" tab ... 20 "Bypass" tab ... 20 Shutdown ... 20 Maintenance Troubleshooting ... 21 Replacement of the battery module ... 22 Tower model ...
-
Page 7: Presentation
Rack model 00 Ra EX 10 1. Presentation Dimensions in mm (H x W x D) EX 700 / EX 1000 235.5 x 145 x 400 EX 1500 235.5 x 145 x 505 Weight in kg EX 700 EX 1000... -
Page 8: Back
1. Presentation 1.2 Back Tower model Pulsar EX 700 / Pulsar EX 1000 RS232 Pulsar EX 1500 RS232 Page 8 - 51031604EN/AA slot for communications-card option. RS232 communications port. USB communications port. four outlets for direct connection of protected equipment. -
Page 9: Rack Model
Rack model Pulsar EX 700 Rack / Pulsar EX 1000 Rack / Pulsar EX 1500 Rack RS232 slot for communications-card option. RS232 communications port. USB communications port. four outlets for direct connection of protected equipment. connector for automatic detection of an additional battery module. -
Page 10: Control Panel
1. Presentation 1.3 Control panel Page 10 - 51031604EN/AA Alarms UPS overload. 100% electronics fault. battery fault. hold down to display percent load: - lamp test or buzzer OFF. test - forced transfer to bypass and back by pressing button 3 times in less than 5 seconds. -
Page 11: Installation
2.1 Unpacking and checks Tower model two cords for connection of the protected equipment. RS 232 communications cable. USB communications cable. "UPS Driver" diskette for UPS personalisation. "Solution Pac" CD ROM. documentation. 2. Installation - Page 11 51031604EN/AA... -
Page 12: Rack Model
2. Installation Rack model 24 two cords for connection of the protected equipment. 25 RS 232 communications cable. 26 USB communications cable. 27 "UPS Driver" diskette for UPS personalisation. 28 "Solution Pac" CD ROM. 29 documentation. 30 telescopic rails for mounting in 19" bay with mounting hardware. Page 12 - 51031604EN/AA Rac k... -
Page 13: Installation Of The Rack Version
2. Installation 2.2 Installation of the rack version Rack mounting diagram with rails. The rails and the necessary mounting hardware are supplied by MGE UPS SYSTEMS. - Page 13 51031604EN/AA... -
Page 14: Connection To The Rs 232 Or Usb Communications Port (Optional)
2 - Connect the other end of the communications cable 25 or 26 to the RS 232 2 or USB 3 communications port on the UPS. The UPS can now communicate with all MGE UPS SYSTEMS supervision, set-up or safety software. -
Page 15: Installation Of The Communications-Card Option
2.4 Installation of the communications-card option Tower model U-Talk Rack model RS232 Slot for the communications-card option. Slot for the communications- card option. 2. Installation It is not necessary to shut down the UPS to install the communications card: 1 - Remove the slot 1 cover secured by two screws. -
Page 16: Connections
2. Installation 2.5 Connections Check that the indications on the rating plate on the back of the UPS correspond to your AC-power system and to the actual electrical consumption of all the equipment to be connected to the UPS. Tower model Rack model Page 16 - 51031604EN/AA... -
Page 17: Operation
3.1 Start-up The protected equipment connected to the UPS can be energised, whether AC input power is available or not. 3.2 Bargraph indications bypass Caution: the AC input power source must be present when energising for the first time. Press the ON / OFF button 23 . The buzzer beeps and all the LEDs go ON. -
Page 18: Operation On Battery Power (Following Failure Of Ac Input Power)
3. Operation 3.3 Operation on battery power (following failure of AC input power) Transfer to battery power bypass Threshold for the low-battery warning bypass End of backup time test bypass The UPS goes to sleep mode at the end of the battery backup time until complete shutdown due to tripping of the battery- protection function against deep discharge. -
Page 19: Sleep Mode
3.4 Personalisation (optional) Function Personalisation parameters can be set and modified using the "UPS Driver" software installed on a computer that is connected to the UPS (see section 2.3 Connection to the RS 232 (or USB) communications port). Check that the RS 232 25 or USB 26 cable is properly connected. "UPS Driver"... -
Page 20: Output" Tab
3. Operation "Output" tab Personalisable function Rated UPS voltage Rated UPS frequency UPS tolerance for AC-power source frequency Overload alarm threshold UPS restart following short-circuit "Bypass" tab Personalisable function Transfer to bypass if overload Transfer to bypass following a fault, whatever the conditions on the AC-power source 3.5 Shutdown bypass... -
Page 21: Maintenance
If any of LEDs 12 , 13 or 14 flash, there is a operating anomaly or an alarm. If a LED flashes, the bargraph data is no longer displayed. Troubleshooting not requiring MGE UPS SYSTEMS after-sales support Indication LED 12 flashes and the buzzer beeps. - Page 22 4. Maintenance Troubleshooting requiring MGE UPS SYSTEMS after-sales support Indication LED 13 flashes and the buzzer sounds continuously. Page 22 - 51031604EN/AB Signification UPS electronics have detected a UPS fault. Depending on the UPS personalisation parameters (see section 3.4), there are two possibilities:...
-
Page 23: Replacement Of The Battery Module
4.2 Replacement of the battery module Safety rules: Batteries constitute a danger (electrical shock, burns). The short-circuit current may be very high. Precautions must be taken for all handling: remove all watches, rings, bracelets and any other metal objects; use tools with insulated handles. Tower model Removal of battery module A - Press to open door. -
Page 24: Rack Model
4. Maintenance Rack model Removal of battery module A - Remove the two screws securing the door. B - Slide the door open and remove it. C - Unscrew the bar that holds the battery module in place. D - Remove the bar. E - Disconnect the battery module. -
Page 25: Environment
UPS recycling at the end of service life: MGE UPS SYSTEMS undertakes to recycle, by certified companies and in compliance with all applicable regulations, all UPS products recovered at the end of their service life (contact your MGE branch office). -
Page 26: Appendices
6. Appendices 6.1 Technical characteristics Simplified diagram Operating conditions Relative humidity: 20 to 90% without condensation. Temperature: 0 to 40 C. Page 26 - 51031604EN/AB... -
Page 27: Glossary
This function makes it possible to energise the connected equipment even when AC input power is not available (operation exclusively on battery power). Uninterruptible Power Supply It is possible to enable or disable use of UPS ON / OFF controls by the computer- system protection software. -
Page 28: Index
6. Appendices 6.3 Index AC power Failure ... 18 Frequency tolerance ... 20 Return ... 18 Automatic start ... 19 Bargraph ... 10-17 Battery Battery test ... 19 End of backup time ... 18 Fault ... 10-17 Handling precautions ... 3 Low-battery warning ...
