- Page 1 YASKAWA VARISPEED-616G5 OPTION CARD PG SPEED CONTROLLER CARD PG-X2 INSTRUCTIONS Upon receipt of the product and prior to initial operation, read these instructions thoroughly and retain them for future reference. YASKAWA MANUAL NO. TOE-C736-40.4...
-
Page 2: Notes For Safe Operation
NOTES FOR SAFE OPERATION Read this instruction manual thoroughly before installation, operation, maintenance or inspection. In this manual, the NOTES FOR SAFE OPERATION is classified as “CAUTION”. CAUTION Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury to personnel and damage to equipment. - Page 3 PG speed controller card, PG-X2 is mounted on the control board of the inverter, and performs speed feedback using the pulse generator (PG) on the motor to cor- rect speed fluctuations caused by slipping. Motor rotation direction is detected by phase A and phase B PG pulse inputs. The card is used for flux vector control.
-
Page 4: Inspection After Delivery
S Check the name written on the product to verify that ordered products have been delivered. S Check for damage caused during transportation. If there is anything uncertain on the structure, contact your YASKAWA repre- sentative. -
Page 5: Installation Procedure
(See part A of the side view.) Verify that 4CN is precisely aligned to PG−X2. Gently push the card until it clicks. Option A installation spacer Spacer mounting PG-X2 (SRNT41028−9, comes with PG−X2) hole Option A Mounting base of inverter... - Page 6 Pulse A (Forward rotation) Pulse B Pulse monitor outputs Pulse Z Power supply for PG (From PG-X2) Grounding lead wire TA1 1-2 (0V) : +12V 200mA max. PG speed controller card PG-X2 TA2 3-2 (0V): +5V 200mA max. DO NOT use the both supplies at the same time.
- Page 7 NOTE Notes on wiring S Separate the control signal wires ( from terminals TA1 and TA2 ) of the PG−X2 from the main circuit wires and other power cables. S Use a shielded wire to connect to the PG. Connect the wire as shown in Fig.
- Page 8 In general, motor forward direction is counterclockwise (CCW) as viewed from the load shaft. For YASKAWA’s motor, phase A of PG output leads phase B by a phase angle of 90_ in clockwise (CW) rotation. According to PG, phase A lags phase B by a phase angle of 90_ in clockwise (CW) rotation.
- Page 9 For YASKAWA’s inverter motor with PG, PG is installed at the opposite drive end. Then, phase A lags phase B by a phase angle of 90_ at motor forward run. (Motor runs CCW as viewed from PG.) Therefore, when using this motor or similar motors, connect phases A and B to the option card after replacing phase output.
- Page 10 Selecting PG The maximum frequency of PG output pulse that can be detected is 300kHz. Find output frequency, f (Hz), according to the following formula. Motor rotation speed at max. frequency output (r∕min) (Hz) = × PG constant (p∕rev) If the PG power capacity is 200mA or greater, provide a separate power supply. (If momentary power loss ride-through function is necessary, provide backup capacitor or take other necessary measures.) PG power...
- Page 12 TAIPEI OFFICE 9F, 16, Nanking E. Rd., Sec. 3, Taipei, Taiwan Phone 886-2-2502-5003 Fax 886-2-2505-1280 SHANGHAI YASKAWA-TONGJI M & E CO., LTD. 27 Hui He Road Shanghai China 200437 Phone 86-21-6553-6060 Fax 86-21-5588-1190 BEIJING YASKAWA BEIKE AUTOMATION ENGINEERING CO., LTD.
