COMPACT DISC PLAYER
C-755
Instruction Manual
Thank you for purchasing an Onkyo product. Please read
this manual carefully before making any connections or
using this product. By following these instructions, you'll get
the best audio performance and the most listening pleasure
from your Onkyo product. Keep this manual for future
reference.
Getting Started
............................En-
2
13
15
16
21
24
26
27
E
n
Advertisement
Table of Contents
Related Manuals for Onkyo C-755
Summary of Contents for Onkyo C-755
-
Page 1: Table Of Contents
......En- Troubleshooting ...... En- Thank you for purchasing an Onkyo product. Please read this manual carefully before making any connections or using this product. By following these instructions, you’ll get the best audio performance and the most listening pleasure from your Onkyo product. -
Page 2: Important Safety Instructions
WARNING: WARNING AVIS RISK OF ELECTRIC SHOCK RISQUE DE CHOC ELECTRIQUE TO REDUCE THE RISK OF FIRE OR DO NOT OPEN NE PAS OUVRIR ELECTRIC SHOCK, DO NOT EXPOSE THIS The lightning flash with arrowhead symbol, within APPARATUS TO RAIN OR MOISTURE. an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous CAUTION:... -
Page 3: Precautions
Precautions 1. Recording Copyright—Unless it’s for personal 9. Installing this Unit use only, recording copyrighted material is illegal • Install this unit in a well-ventilated location. without the permission of the copyright holder. • Ensure that there’s adequate ventilation all around this unit, especially if it’s installed in an 2. - Page 4 We declare, under our sole responsibility, that this product complies with the standards: – Safety – Limits and methods of measurement of radio disturbance characteristics – Limits for harmonic current emissions – Limitation of voltage changes, voltage fluctua- tions and flicker – RoHS Directive, 2011/65/EU WEEE http://www.onkyo.com/manual/weee/weee.pdf...
-
Page 5: Supplied Accessories
• Random playback • Random repeat playback Remote controller RC-822C and two batteries *1 VLSC and the VLSC logo are registered trademarks of (R03/AAA) Onkyo Corporation. Batteries are not supplied with products for China. Coaxial cable cable (80 cm) • To use , the CD Player must be connected with cable. - Page 6 Contents Important Safety Instructions ......2 Precautions............3 Supplied Accessories........5 Features .............. 5 Getting to Know the CD Player ......7 Front Panel ............7 Display .............. 8 Rear Panel............8 Remote Controller..........9 Installing the Batteries ........10 Aiming the Remote Controller......
-
Page 7: Getting To Know The Cd Player
Front Panel 6. Remote control sensor (10) ON/STANDBY button (15) Í Receives control signals from the remote Press to turn on or standby the C-755. controller. 2. Disc tray (16) 7. Display (8) The CD is loaded here. See next page. -
Page 8: Display
2. ANALOG AUDIO OUTPUT jacks (13, 14) other Onkyo components for interactive These analog audio outputs can be connected control. To use , the C-755 must be to an amplifier’s analog inputs by using the connected with an cable and an audio audio cable (not supplied). -
Page 9: Remote Controller
RC - 822C 1. [ ] button (15) Í Press to turn on or standby the C-755. 2. DIMMER button (15) Press to adjust the display brightness. 3. Pause [ ] button (16, 17) Press to pause playback. -
Page 10: Installing The Batteries
Getting to Know the CD Player-Continued Installing the Batteries Aiming the Remote Controller When you operate the remote controller, point it at the CD To open the battery compartment, press the Player’s remote control sensor, as shown below. small hollow and slide open the cover. Remote control sensor Insert two batteries (R03/AAA) into the Notes:... -
Page 11: Disc Notes
Disc Notes Precautions for Playback Playback of MP3 Discs • Only MP3 files with the extension “.MP3” or “. Compact discs (CDs) with the following logo on the label surface can be used. mp3” are supported. Do not use discs designed for purposes other than audio, •... - Page 12 Caring for Discs If the disc is dirty, the C-755 will have a hard time reading signals, and the audio quality may drop. If the disc is dirty, gently wipe off fingerprints and dust with a soft cloth.
-
Page 13: Connecting The Cd Player
Note: Connection Color Coding Do not put anything on top of the C-755, as it may RCA-type audio connections are usually color- interfere with proper ventilation. coded: red and white. Use red plugs to connect right-channel audio inputs and outputs (typically labeled “R”). -
Page 14: Connections
Onkyo hi-fi amp or AV receiver, when you start play- nect either one to your Onkyo hi-fi amp or AV back on the C-755, the AV receiver will select the receiver. The other connector is for connecting C-755 as the input source. -
Page 15: Basic Operation
Connecting the Power Cord Before connecting the power cord, connect all of the other components. Plug the power cord into a suitable electrical outlet Basic Operation Make settings for this function while playback is Turning On CD Player stopped. ON/STANDBY Press the [SETUP] button. -
Page 16: Disc Playback
Disc Playback Disc tray DIMMER DISPLAY RANDOM REPEAT ENTER Selecting Tracks Press the Open/Close [ ] button to open < To return to the beginning of the track that’s currently play- the disc tray. ing or paused, press the Previous [ ] button. -
Page 17: Using The Remote Controller
Disc Playback-Continued Using the Remote Controller [DISPLAY] DIMMER DISPLAY Press repeatedly to display CD information Press to pause playback See below for details. Press to start playback RANDOM REPEAT Press to fast-forward or fast- reverse Press to select tracks During playback or while playback is •... -
Page 18: Selecting Files (Mp3 Cds)
Disc Playback-Continued Selecting Files (MP3 CDs) Selecting Files in Navigation Mode For MP3 CDs, files (MP3 files) may be organized in a In Navigation mode, you can select files by navigating hierarchy, with folders containing files and subfolders, as through the folder hierarchy. This mode can only be used shown below. -
Page 19: Selecting Files In All Folder Mode
Disc Playback-Continued To select another folder, press the [ ] button Press the [ENTER] or [ ] button. (front again (front panel: [ ]), and then use the [ ∫ panel: [ ] buttons to select it. Playback will start with the specified file or folder and continue until all of the files on the Press the [ENTER] or [ ] button to start... -
Page 20: Displaying Mp3 Information
Disc Playback-Continued When there is no ID3 tag, “ARTIST-NO DATA” appears. To select the previous folder, press the Previous [ ] button. < To select the next folder, press the Next [ > button. Album name: Name of the album (if ID3 tag is present). Press the [ENTER] button to display the file When there is no ID3 tag, “ALBUM-NO DATA”... -
Page 21: Various Playback Modes
Various Playback Modes You can select the following playback modes: Memory Playback (For Audio CDs) • Random playback In memory playback, you can create a playlist of up • Memory playback to 25 files. • Repeat playback Random Playback DIMMER DISPLAY With random playback, all of the files on the disc DISPLAY... -
Page 22: Memory Playback (For Mp3 Cds)
Various Playback Modes-Continued ∫To Cancel Memory Playback Use the Previous and Next [ ] buttons to < > • Stop playback, then press the [MEMORY] button to select the first file you want to add to the change the playback mode. The MEMORY indica- playlist, and then press [ENTER] button. -
Page 23: Repeat Playback
Various Playback Modes-Continued Repeat Playback Use the [ ]/[ ] buttons to continue < > selecting other items for memory playback. In repeat playback, you can play an entire CD To move up a level, press the [ ] button. repeatedly, play one track repeatedly, or combine it To continue selecting items for memory play- with memory playback to play the playlist repeat-... -
Page 24: Setting For Mp3
Setting for MP3 ∫ FOLDER NAME (Scroll/Not) Setting MP3 Preferences This preference determines whether the folder The MP3 preferences let you change the way MP3 name scrolls across the display when an MP3 file information is displayed and the way MP3 CDs folder is selected. - Page 25 Setting for MP3-Continued File/folder name Disable Enable 01 Pops 01 Pops Pops 10-Rock 10-Rock Rock 16_Jazz 16_Jazz Jazz 21st Century 21st Century 21st Century 05-07-20 Album 05-07-20 Album Album ∫ STOP KEY (All Folder/Navigation/Disable) This preference determines how the Stop [ ] button ∫...
-
Page 26: Troubleshooting
SETUP Can’t access the SETUP menu. • If any track has been selected even when the C-755 is stopped, you must place it into the full stop state by pressing the [ ] button before you can view all the SETUP menus. -
Page 27: Specifications
• You’re not pointing the remote controller at the C-755’s remote sensor. Point the remote controller at the C-755’s remote sensor (page 10). • You’re too far away from the C-755. Move the remote controller closer to the C-755 (page 10). The remote controller has a range of approximately 5 meters (16 ft.). - Page 28 The above-mentioned information is subject to change without prior notice. Visit the Onkyo web site for the latest update. F1608-0 (C) Copyright 2016 Onkyo & Pioneer Corporation Japan. All rights reserved. Printed in Malaysia / Imprimé en Malaisie / Напечатано в Малайзии SN 29402439...
