Summary of Contents for Onkyo C-705TX
- Page 1 English Compact Disc Player C-705TX Instruction Manual COMPACT DISC PLAYER TR-1 DUAL OPTICAL OUTPUT STANDBY/ ON STANDBY DISPLAY C-705TX...
-
Page 2: Thank You For Purchasing
Before using Thank you for purchasing ... Thank you for purchasing Onkyo C-705TX CD player. Please read this manual thoroughly before making connections and plugging in the unit. Following the instructions in this manual will enable you to obtain optimum performance and listening enjoyment from your new C-705TX. -
Page 3: Important Safeguards
Important Safeguards Read Instructions – All the safety and operating instructions should be read before the appliance is operated. Retain Instructions – The safety and operating instructions should be retained for future reference. Heed Warnings – All warnings on the appliance and in the operating instructions should be adhered to. - Page 4 Precautions 1. Warranty Claim You can find the serial number on the rear panel of this unit. In case of warranty claim, please re- port this number. 2. Power WARNING BEFORE PLUGGING IN THE UNIT FOR THE FIRST TIME, READ THE FOLLOWING SECTION CARE- FULLY.
- Page 5 For U.S. model The laser is covered by a housing which prevents exposure during operation or maintenance. How- ever, this product is classified as a Laser Product by CDRH (Center for Devices and Radiological Health) which is a department of the Food and Drug Administration.
- Page 6 We, ONKYO EUROPE ELECTRONICS GmbH INDUSTRIESTRASSE 20 82110 GERMERING, GERMANY declare in own responsibility, that the ONKYO product described in this instruction manual is in compliance with the corresponding technical standards such as EN60065, EN55013, EN55020 and EN61000-3-2, -3-3. GERMERING, GERMANY ONKYO EUROPE ELECTRONICS GmbH A.HORIUCHI...
-
Page 7: Table Of Contents
Table of contents Connections Connecting to Onkyo Separate Collection series components ... 8 Connecting to the other components ... 10 Operations Playing CDs ... 13 Other Information Handling CDs ... 19 Troubleshooting ... 20 Indexed to parts and controls ... 21 Specifications ... -
Page 8: Connections
Note: If an R-805TX has been connected to the system and the R-805TX’s energy save function has been enabled, pressing the STANDBY/ON button of the C-705TX will not turn on the power to the C-705TX. You need to press the STANDBY/ON button on the R-805TX. (Refer to the instruction manual for the R-805TX for more information.) -
Page 9: Using The Remote Controller
• Make sure the audio rack doors do not have colored glass. Placing the unit behind such doors may prevent proper remote controller operation. • If there is any obstacle between the remote con- troller and the remote control sensor, the re- mote controller will not operate. C-705TX... -
Page 10: Connecting To The Other Components
• Bundling an audio connection cable with the power cord or speaker cord may degrade the sound quality. • To use the unit with the other Onkyo Separate Collection series components, follow the connection diagram in the A-905TX/R-805TX instruction manual to connect the unit to the system. - Page 11 Amplifier without digital input terminal Connection with the Amplifier Connect the ANALOG OUTPUT connectors on the rear panel of C-705TX and the amplifier’s CD input connectors using the audio connection cable. Refer to the amplifier’s instruction manual for connections. Connection to DIGITAL OUTPUT connector Using the DIGITAL OUTPUT connector, you can record on digital audio equipment, such as an MD, CD-R, DAT, etc.
-
Page 12: Connecting The Power Cord
Connecting the power cord Insert the AC power cord into a wall outlet. The STANDBY indicator lights. control operations. connectors. There hookup example. • To use the unit with the other Onkyo Sepa- cable • If you press the cable Supplied cable... -
Page 13: Operations Playing Cds
DUAL OPTICAL OUTPUT STANDBY/ ON STANDBY DISPLAY Normal play • When you are using the C-705TX with the A- 905TX/R-805TX Onkyo Separate Collection se- ries component, turn the A-905TX’s/R-805TX’s POWER switch ON. Press STANDBY/ON button to turn on the unit. -
Page 14: Search Play
(or the the remote controller). Press the button. The CD player starts playing the selected track. Using the remote controller With the RC-456S remote controller (supplied with the A-905TX/R-805TX), you can select the track to play using the number buttons. In either case, selecting a track automatically starts play of that track. -
Page 15: Checking The Playing Time Of Each Track
“– – : – –” due to the memory limitations. • If you switch to the remaining time display while the CD player is playing the 21st or later song on the disc • If you switch to the total remaining time display after storing the 21st or later song on the disc •... -
Page 16: Playing Tracks In Random Order
Playing tracks in random order (Random play) Press the RANDOM button to enter Random play mode. The CD player plays the tracks in a random order. • Random play will be canceled when the RAN- DOM, or when all tracks on disc have been played. -
Page 17: Memory Play
Memory play • Up to 25 tracks can be stored in memory. Press the MEMORY button to enter Memory play mode. MEMORY MEMORY Press the number button(s) to se- lect your desired track. To enter further track numbers into memory, repeat this step. - Page 18 Playing CDs To quit Memory play Press the MEMORY or The MEMORY indicator disappears to indicate that you are in Normal play mode. The contents of the memory are completely cleared. MEMORY Playing all tracks on disc (Repeat play) Press the REPEAT button to enter Repeat play mode.
-
Page 19: Other Information Handling Cds
Also, do not use conventional record cleaner or antistatic agents. • Do not place a CD in direct sunlight or locations subject to high humidity or low temperature. • Do not store a CD in the CD player tray for long periods of time. -
Page 20: Troubleshooting
Troubleshooting If you have any problems with the unit, please check the troubleshooting table below first. For any problems not covered in the table, please consult your nearest Onkyo authorized service center. Symptom STANDBY/ON button is pressed, but power does not come on. -
Page 21: Indexed To Parts And Controls
MEMORY Multi-purpose Music calendar display Button (Open/Close) [13, 18] TR-1 button [16] TR-1 button (Stop) [13] button (Play) [13, 14, 16, 17, 18] C-705TX button (Track down/Fast reverse, Track up/Fast forward) [14, 15] TR-1 indicator TR - 1 Over indicator... -
Page 22: Remote Controller
Remote controller supplied with the A-905TX/R-805TX (RC-456S) To operate the supplied remote controller, make the appropriate connection to the nectors. STANDBY/ON button [13] CD player operation buttons REPEAT : Repeat mode button [18] RANDOM : Random play button [16] : Stop button [13, 17]... -
Page 23: Specifications
Specifications Signal readout system : Optical non-contact Reading rotation : About 500 – 200 r.p.m. (constant linear velocity) Linear velocity : 1.2 –1.4 m/s Error correction system : Cross Interleave Reed Solomon code D/A converter : 1 bit D/A converter Sampling frequency : 352.8 kHz (Eight-times oversampling) Number of channels : 2 (stereo) - Page 24 Sales & Product Planning Div. : 2-1, Nisshin-cho, Neyagawa-shi, OSAKA 572-8540, JAPAN Tel: 072-831-8111 Fax: 072-833-5222 ONKYO U.S.A. CORPORATION 18 Park Way, Upper Saddle River, N.J. 07458, U.S.A. Tel: 201-785-2600 Fax: 201-785-2650 E-mail: onkyo@onkyousa.com ONKYO EUROPE ELECTRONICS GmbH Industriestrasse 20, 82110 Germering, GERMANY Tel: 089-849-320 Fax: 089-849-3265 E-mail: info@onkyo.de...
