Compact Disc Player
C-7000R
Instruction Manual
E
n

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C-7000R and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Onkyo C-7000R

Summary of Contents for Onkyo C-7000R

  • Page 1 Compact Disc Player C-7000R Instruction Manual...

  • Page 2: Important Safety Instructions

    Introduction WARNING: WARNING AVIS RISK OF ELECTRIC SHOCK RISQUE DE CHOC ELECTRIQUE TO REDUCE THE RISK OF FIRE OR ELECTRIC DO NOT OPEN NE PAS OUVRIR SHOCK, DO NOT EXPOSE THIS APPARATUS TO The lightning flash with arrowhead symbol, within an RAIN OR MOISTURE.

  • Page 3: Precautions

    Read the following carefully: 2. AC Fuse—The AC fuse inside the unit is not user- this unit, have it checked by your Onkyo dealer. Moisture may condense on the lens of the optical serviceable. If you cannot turn on the unit, contact 8.
  • Page 4 82194 GROEBENZELL, of the FCC Rules. These limits are designed to provide GERMANY reasonable protection against harmful interference in a declare in own responsibility, that the ONKYO product described in this instruction manual is in compliance with the residential installation. corresponding...

  • Page 5: Features

    Features • Plays Audio CD, CD-R, CD-RW, MP3 CD, and WMA • New circuit technology for Buffer Circuitry • Separate Digital/Analog Circuitry • Separate Massive Transformers for Digital and Analog Circuitry (Toroidal Transformer for Analog Circuitry) • Thermally Regulated High-Precision Clock •...

  • Page 6: Technologies

    New circuit technology is incorporated reduces jitter by comparing the input and output phases of into the buffer circuitry of the C-7000R CD player. the digital signal and creating an accurate clock waveform. This enhances the precision of digital signal processing Separate Digital/Analog Circuitry and Transformers and noticeably improves perceived audio quality.

  • Page 7: Block Diagram

    Block Diagram...

  • Page 8: Supplied Accessories

    Power cord (1.8 m/5.9 ft) ..........(1) (Plug type varies from country to country.) Thank you for purchasing an Onkyo Compact Disc Player. Please read this manual thoroughly before making connections and plugging in the unit.

  • Page 9: Table Of Contents

    Contents Introduction Important Safety Instructions .................2 Precautions.......................3 Features ........................5 Technologies ......................6 Block Diagram ......................7 Supplied Accessories ....................8 Before Using the Compact Disc Player..............10 Installing the Batteries ..................10 Using the Remote Controller ................10 Installing the Compact Disc Player ..............10 Getting to Know the Compact Disc Player ............11 Front Panel ......................11 Display .......................12 Rear Panel ......................13...

  • Page 10: Before Using The Compact Disc Player

    Before Using the Compact Disc Player Installing the Batteries Using the Remote Controller Installing the Compact Disc Player To use the remote controller, point it at the compact disc To open the battery compartment, press the small player’s remote control sensor, as shown below. hollow and slide the cover.

  • Page 11: Getting To Know The Compact Disc Player

    Getting to Know the Compact Disc Player Front Panel The page numbers in parentheses show where you can find the main explanation for each item. ON/STANDBY button (➔ button (➔ POWER switch (➔ Use this button to set the compact disc player to On or Opens and closes the disc tray.

  • Page 12: Display

    Display For detailed information, see the pages in parentheses. indicator (➔ TOTAL indicator (➔ MP3 indicator (➔ Lights during playback. Lights when the total and remaining time of the track Lights together with the folder name, file number or are shown. file name which contains MP3 tracks.

  • Page 13: Rear Panel

    Rear Panel AUDIO OUTPUT ANALOG L/R jacks AUDIO OUTPUT DIGITAL OPTICAL jack Connect the analog audio in jack of an amplifier or This optical digital audio output is for connecting similar to this jack, using the supplied audio cable. components with optical digital audio inputs, such as preamplifier.

  • Page 14: Remote Controller

    Remote Controller You can also use the remote controller to control your Onkyo C-7000R. For detailed information, see the pages in parentheses. button (➔ and ENTER buttons Sets the compact disc player to On or Standby. Used to select and adjust settings.

  • Page 15: Disc Note

    Disc Note Supported Discs CD playback with copy-control function Precautions for Inkjet Printable Discs The compact disc player supports the following discs. Some audio CDs with copy-control function do not Do not leave a CD-R/CD-RW having a label printed with comply with official CD standards.
  • Page 16 Playback of MP3 and WMA CDs Playback of WMA CDs MP3 and WMA files recorded on a CD-R/CD-RW can be • WMA stands for “Windows Media ® Audio”, an audio played with this compact disc player. compression technology developed by Microsoft Corporation USA.

  • Page 17: Connections

    Connections Connections Cable and Jacks Balanced AES/EBU This is a professional digital audio interface. Balanced AES/EBU cables are used for better noise immunity and longer cable runs. The maximum sampling rate for PCM output is 44.1 kHz/16 bit, 2ch. Optical digital audio Optical digital connections allow you to enjoy digital sound.

  • Page 18: Connecting The Power Cord

    Connecting the Power Cord AC INLET Compact Disc Player C-7000R Supplied power cord To an AC wall outlet (Plug type varies from country to country.) Make sure that the main power of the compact disc Note player is turned off.

  • Page 19: Connecting A Preamplifier Or Integrated Amplifier

    Digital (Optical or Coaxial) Connection Preamplifier P-3000R Preamplifier P-3000R Connect either of them. Compact Disc Player C-7000R Compact Disc Player C-7000R This is an example of digital connection using the preamplifier P-3000R. This is an example of analog connection using the preamplifier P-3000R.
  • Page 20 Digital (AES/EBU) Connection Preamplifier P-3000R Compact Disc Player C-7000R This is an example of AES/EBU connection using the preamplifier P-3000R.

  • Page 21: Basic Operations

    Turning On & Basic Operations Basic Operations Turning On/Off the Compact Disc Player Turning On the Compact Disc Player Turning Off the Compact Disc Player ON/STANDBY Set POWER to the ON position ( ) on the front Press to set the compact disc player to Standby. panel.

  • Page 22: Playing The Disc

    Playing the Disc ■ To Select Tracks Place the disc on the tray with the label-side facing Press to select the next track/file or to select the previous track/file. • If you press during playback or while playback is paused, the beginning of the current track/file is selected.

  • Page 23: Selecting Files (Mp3/Wma)

    Selecting Files (MP3/WMA) Selecting Files in Navigation Mode For MP3/WMA CDs, files (MP3/WMA files) may be or ENTER (front panel: Press organized in a hierarchically, with folders containing files The first folder name in ROOT appears on the display. and subfolders, as shown below. If the disc contains no folders, the first file name appears.

  • Page 24: Setting The Display Brightness

    Selecting Files in All Folder Mode Setting the Display Brightness Press (front panel: The first file name inside the folder appears. to select the files within the DIMMER folder. To select another folder, press again (front panel: ), and then use to select it.

  • Page 25: Advanced Operations

    Advanced Operations Advanced Operations Repeat Playback Press REPEAT repeatedly to select Repeat All, Repeat 1 or Repeat Off. The “ ” or “ 1” indicator lights. Repeat All → Repeat 1 → Repeat Off Repeat All indicator REPEAT Repeat 1 1 indicator In repeat playback, you can play an entire disc repeatedly, play one track repeatedly, or combine it with memory...

  • Page 26: Memory Playback (Cd)

    Memory Playback (CD) ■ To Change the Display Press MEMORY. While the memory setting operations, press DISPLAY The MEMORY indicator lights. repeatedly to change the display information as follows: Track number/Playlist number → Track number/Playing MEMORY indicator DISPLAY time → Track number/Total playing time ■...

  • Page 27: Memory Playback (Mp3/Wma)

    Memory Playback (MP3/WMA) Memory Playback in Navigation Mode ■ To Change the Display Press MEMORY. While the memory setting operations, press DISPLAY to The MEMORY indicator lights. change the display information as follows: File name → Folder name → Folder number/File number Press The compact disc player enters Navigation mode and Note...
  • Page 28 Memory Playback in All Folder Mode Press (front panel: to select the files. Press to memorized the first file. Press (front panel: ), then repeat steps 3 to 6. To memorize other files of the same folder in the playlist, repeat steps 5 to 6. Press ENTER (front panel: Memory playback starts.

  • Page 29: Random Playback

    Random Playback Selecting a Folder (Search Mode) • Random playback is cancelled when you press to open the disc tray. • Random playback is cancelled when you press ON/STANDBY to turn off the compact disc player. ENTER RANDOM SEARCH In random playback, all of the files on the disc are played This section explains how to select MP3/WMA folders in random order.

  • Page 30: Displaying Disc Information

    Displaying Disc Information During playback or pause (Audio CD Display) Folder name: Name of the current folder. Elapsed file time: The length of time that the current file has been playing DISPLAY (default display). Title name: Title of the current file (if ID3 tag present). When there is no ID3 tag, the message “TITLE-NO DATA”...

  • Page 31: Custom Setup

    Custom Setup Custom Setup Setup Procedures Preferences This preference determines whether or not the file name AUDIO scrolls across the display when an MP3/WMA file is selected. ■ FILTER In Navigation mode, the file name scrolls across the SHARP (default) display regardless of this setting (➔...

  • Page 32: Setting The Analog/Digital Output

    ■ STOP-KEY EXTRA Setting the Analog/Digital Output NAVI (default) FOLDER ■ ID3-VER1 DISABLE READ (default) OUTPUT MODE This preference determines how on the compact disc NO READ player works. This preference determines whether or not version When the “NAVI” (Navigation) option is selected, 1.0/1.1 tags are read and displayed.

  • Page 33: Troubleshooting

    Others Troubleshooting Power Audio Can’t turn on the Compact Disc Player. There’s no sound. Audio output is intermittent when the Compact Disc Player is subjected to • Make sure that the power cord is properly plugged into • Check all connections and correct as necessary (➔...
  • Page 34 15). • The disc is dirty. Remove the disc and clean it (➔ Onkyo is not responsible for damages (such as CD rental fees) due to unsuccessful recordings caused by • The disc is very scratched. Replace the disc. the unit’s malfunction. Before you record important data, make sure that the material will be recorded Can’t enter track numbers for memory...

  • Page 35: Specifications

    Specifications C-7000R Frequency Response 2 Hz - 20 kHz Signal to Noise Ratio 116 dB Audio Dynamic Range 100 dB THD (Total Harmonic Distortion) 0.0015 % Audio Output/Impedance Optical –22.5 dBm 0.5 Vp-p / 75 Ω Coaxial 3.3 Vp-p / 110 Ω...
  • Page 36 Unit 1 & 12, 9/F, Ever Gain Plaza Tower 1, 88, Container Port Road, Kwai Chung, N.T., Hong Kong. Tel: 852-2429-3118 Fax: 852-2428-9039 http://www.ch.onkyo.com/ Y1011-1 SN 29400529 (C) Copyright 2010 ONKYO CORPORATION Japan. All rights reserved. * 2 9 4 0 0 5 2 9 *...
