Onkyo C-701A Instruction Manual

Onkyo C-701A Instruction Manual

Compact disc player
Hide thumbs Also See for C-701A:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Service Manual
English
Compact Disc Player
C-701A
Instruction Manual
COMPACT DISC PLAYER
STANDBY / ON
STANDBY
DISPLAY
-
701 A
C

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C-701A and is the answer not in the manual?

Questions and answers

Related Manuals for Onkyo C-701A

Summary of Contents for Onkyo C-701A

  • Page 1 English Compact Disc Player C-701A Instruction Manual COMPACT DISC PLAYER STANDBY / ON STANDBY DISPLAY 701 A...

  • Page 2: Thank You For Purchasing

    Before using Thank you for purchasing ... Thank you for purchasing Onkyo C-701A CD player. Please read this manual thoroughly before making connections and plugging in the unit. Following the instructions in this manual will enable you to obtain optimum performance and listening enjoyment from your new C-701A.

  • Page 3: Important Safeguards

    Important Safeguards Read Instructions – All the safety and operating instructions should be read before the appliance is operated. Retain Instructions – The safety and operating instructions should be retained for future reference. Heed Warnings – All warnings on the appliance and in the operating instructions should be adhered to.
  • Page 4 Precautions 1. Power WARNING BEFORE PLUGGING IN THE UNIT FOR THE FIRST TIME, READ THE FOLLOWING SECTION CARE- FULLY. The voltage of the available power supply differs according to country or region. Be sure that the power supply voltage of the area where this unit will be used meets the required voltage (e.g., AC 230 V, 50 Hz or AC 120 V, 60 Hz) written on the rear panel.
  • Page 5 For U.S. model The laser is covered by a housing which prevents exposure during operation or maintenance. How- ever, this product is classified as a Laser Product by CDRH (Center for Devices and Radiological Health) which is a department of the Food and Drug Administration.
  • Page 6 We, ONKYO EUROPE ELECTRONICS GmbH INDUSTRIESTRASSE 20 82110 GERMERING, GERMANY declare in own responsibility, that the ONKYO product described in this instruction manual is in compliance with the corresponding technical standards such as EN60065, EN55013, EN55020 and EN61000-3-2, -3-3. GERMERING, GERMANY ONKYO EUROPE ELECTRONICS GmbH I.

  • Page 7: Table Of Contents

    Table of contents Connections Connecting to Onkyo Separate Collection series components ... 8 Connecting to the other components ... 10 Operations Playing CDs ... 13 Other Information Handling CDs ... 19 Troubleshooting ... 20 Indexed to parts and controls ... 21 Specifications ...

  • Page 8: Connections

    • Auto Power On – You can turn on the power to the amplifier by pressing the STANDBY/ON button on one of the system components. You can also turn off the power to only the C-701A by pressing this button. Notes: •...

  • Page 9: Using The Remote Controller

    • Make sure the audio rack doors do not have colored glass. Placing the unit behind such doors may prevent proper remote controller operation. • If there is any obstacle between the remote con- troller and the remote control sensor, the re- mote controller will not operate. C-701A...

  • Page 10: Connecting To The Other Components

    • Bundling an audio connection cable with the power cord or speaker cord may degrade the sound quality. • To use the unit with the other Onkyo Separate Collection series components, follow the connection diagram in the R-801A instruction manual to connect the unit to the system.
  • Page 11 Amplifier without digital input terminal Connection with the Amplifier Connect the ANALOG OUTPUT connectors on the rear panel of C-701A and the amplifier’s CD input connectors using the audio connection cable. Refer to the amplifier’s instruction manual for connections. Connection to DIGITAL OUTPUT connector Using the DIGITAL OUTPUT connector, you can record on digital audio equipment, such as an MD, CD-R, DAT, etc.

  • Page 12: Connecting The Power Cord

    Connecting the power cord Insert the AC power cord into a wall outlet. The STANDBY indicator lights. control operations. connectors. There hookup example. • To use the unit with the other Onkyo Sepa- • If you press the cable Supplied cable REMOTE...

  • Page 13: Operations Playing Cds

    CD, if it is loaded in the disc tray. Your tuner amplifier also turns on if it is an Onkyo R-801A (refer to page 8). If the CD player does not start playing when • The disc may be upside down in the tray. Press button to open the disc tray.

  • Page 14: Search Play

    Select the track you wish to play using the mote controller). Press the The CD player starts playing the selected track. Using the remote controller With the RC-466S remote controller (supplied with the R-801A), you can select the track to play us- ing the number buttons.

  • Page 15: Display Information

    “– – : – –” (in rare cases “– – – : – –” is displayed) due to the memory limitations. • If you switch to the remaining time display while the CD player is playing the 21st or later song on the disc • If you switch to the total remaining time display after storing the 21st or later song on the disc •...
  • Page 16 RDM indicator. MODE Press the button. The CD player plays the tracks in a random order. To quit Random play • Press the MODE button on the remote control- ler repeatedly to turn off the RDM indicator.

  • Page 17: Memory Play

    Memory play • Up to 25 tracks can be stored in memory. Press the MODE button repeatedly while the unit is stopped to turn on the MEM indicator. MODE Press the number button(s) to se- lect your desired track. To enter further track numbers into memory, repeat this step.
  • Page 18 Playing CDs Playing all tracks on disc (Repeat play) Press the REPEAT button while the unit is stopped to enter Repeat play mode. The REPEAT indicator lights. REPEAT Press the button to start Repeat play. • When the last track is completed, the CD player returns to the beginning of the disc and plays all the tracks on the disc again.

  • Page 19: Other Information Handling Cds

    Also, do not use conventional record cleaner or antistatic agents. • Do not place a CD in direct sunlight or locations subject to high humidity or low temperature. • Do not store a CD in the CD player tray for long periods of time.

  • Page 20: Troubleshooting

    Troubleshooting If you have any problems with the unit, please check the troubleshooting table below first. For any problems not covered in the table, please consult your nearest Onkyo authorized service center. Symptom S TA N D B Y / O N b u t t o n i s pressed, but power does not come on.

  • Page 21: Indexed To Parts And Controls

    Indexed to parts and controls For operational instructions, refer to the page indicated in parentheses. Front panel Disc tray [13] STANDBY/ON button [13] COMPACT DISC PLAYER STANDBY / ON STANDBY DISPLAY STANDBY indicator [12] DISPLAY button [15] Display Multi-purpose display Button (Open/Close) [13, 18]...

  • Page 22: Remote Controller

    To operate the supplied remote controller, make the appropriate connection to the nectors. STANDBY/ON button [13] : Track down button [14] : Track up button [14] CD player operation buttons MODE : Mode select button [16, 17] Each press changes the mode as fol- lows: RDM (RANDOM)

  • Page 23: Specifications

    Specifications Signal readout system : Optical non-contact Reading rotation : About 500 – 200 r.p.m. (constant linear velocity) Linear velocity : 1.2 –1.4 m/s Error correction system : Cross Interleave Reed Solomon code D/A converter : 1 bit D/A converter Sampling frequency : 352.8 kHz (Eight-times oversampling) Number of channels : 2 (stereo)
  • Page 24 Tel: 201-785-2600 Fax: 201-785-2650 http://www.onkyousa.com ONKYO EUROPE ELECTRONICS GmbH Industriestrasse 20, 82110 Germering, GERMANY Tel: 089-849-320 Fax: 089-849-3265 E-mail: info@onkyo.de ONKYO CHINA LIMITED Units 2102-2107, Metroplaza Tower I, 223 Hing Fong Road, Kwai Chung, N.T., HONG KONG Tel: 852-2429-3118 Fax: 852-2428-9039...
