  • Page 1 Compact Disc Changer C-707CHX Instruction Manual COMPACT DISC CHANGER STANDBY / ON DISC MODE STANDBY DISPLAY DUAL OPTICAL OUTPUT DISC 1 DISC 2 3 DISC CHANGER DISC 3 DISC C-707CHX English...

  • Page 2: Thank You For Purchasing

    Thank you for purchasing ... Thank you for purchasing the Onkyo C-707CHX Compact Disc Changer. Please read this manual thoroughly before making connections and plugging in the unit. Following the instructions in this manual will enable you to obtain the optimum performance and listening enjoyment from your new Compact Disc Changer.

  • Page 3: Important Safeguards

    Important Safeguards Read Instructions – All the safety and operating instructions should be read before the appliance is operated. Retain Instructions – The safety and operating instructions should be retained for future reference. Heed Warnings – All warnings on the appliance and in the operating instructions should be adhered to.
  • Page 4 Precautions 1. Warranty Claim You can find the serial number on the rear panel of this unit. In case of warranty claim, please re- port this number. 2. Power WARNING BEFORE PLUGGING IN THE UNIT FOR THE FIRST TIME, READ THE FOLLOWING SECTION CARE- FULLY.
  • Page 5 For U.S. model The laser is covered by a housing which prevents exposure during operation or maintenance. How- ever, this product is classified as a Laser Product by CDRH (Center for Devices and Radiological Health) which is a department of the Food and Drug Administration.

  • Page 6: For Canadian Model

    We, ONKYO EUROPE ELECTRONICS GmbH INDUSTRIESTRASSE 20 82110 GERMERING, GERMANY declare in own responsibility, that the ONKYO product described in this instruction manual is in compliance with the corresponding technical standards such as EN60065, EN55013, EN55020 and EN61000-3-2, -3-3. GERMERING, GERMANY ONKYO EUROPE ELECTRONICS GmbH A.HORIUCHI...

  • Page 7: Table Of Contents

    Table of contents Before Using Checking the supplied accessories ... Below Connections Connecting to Onkyo Separate Collection series components ... 8 Connecting to the other components ... 9~11 Operations Playing CDs ... 12~17 Memory play ... 18~20 Other play modes ... 21~22 Other Information Handling CDs ...

  • Page 8: Connecting To Onkyo Separate Collection Series Components

    The instructions in this manual are based on using the C-707CHX along with the R-805X. If you wish to use the A-905X, refer to the instruction manual for the A-905X and connect the C-707CH or C-705X (instead of the C-707CHX).

  • Page 9: Connecting To The Other Components

    The AC power cord of another component can be connected to this AC OUTLET connector. This means that if the C-707CHX is plugged into an AC outlet, AC power is available to this AC OUTLET even if the C-707CHX is off.

  • Page 10: Connecting For Remote Control

    Connecting to the other components (continued) Connecting for remote control ( If your other components are made by ONKYO and those components are equipped with the tors, you can control this unit with the amplifier’s remote controller. Before connecting • The amplifier must be connected in the •...

  • Page 11: Using The Remote Controller

    • To use the unit with the other Onkyo Sepa- rate Collection series components, follow the connection diagram in the R-805X instruction manual to connect the unit to the system.

  • Page 12: Playing Cds

    DISC 3) is pressed in STANDBY mode, the unit turns on automatically and then the corresponding disc tray opens. Disc tray DUAL OPTICAL OUTPUT DISC 1 DISC 2 3 DISC CHANGER DISC 3 DISC C-707CHX OPEN/CLOSE OPEN/ DISC 1 DISC 2 DISC 3 G.EQUALIZER POWER CLOCK SLEEP...
  • Page 13 DISC 2 DISC 3 POWER DISC 1 REPEAT DISC 2 PLAY MODE DISC 3 REPEAT MEMORY REPEAT DISC C-707CHX TIMER DISC UP/DOWN ENTER To pause playing Press the remote controller. To resume playback, press the the unit, or the controller. DISC...

  • Page 14: Search Play

    DUAL OPTICAL OUTPUT DISC 1 DISC 2 DISC 3 DISC C-707CHX Starting playback from a given track (remote controller only) button to jump to With the RC-414S remote controller (included with the R-805X) , you can select the track to play using the number buttons.
  • Page 15 DISC 1 DISC 2 DISC 3 The C-707CHX allows you to change the other two discs while one disc is playing. When one disc is playing, press the (DISC 1 - DISC 3) for another disc tray. The disc indicator for the open disc tray flashes.
  • Page 16 CD-single if it includes 4 tracks or less and its total playing time is less than 27 minutes, and play back only the disc’s first track. DISC 1 DISC 2 DISC 3 DISC C-707CHX Normal play TR-1 1DISC (No indication made)

  • Page 17: Changing The Display

    DISC 3 STANDBY / ON DISC MODE STANDBY DISPLAY DISC C-707CHX DISPLAY Note: In the following cases, the display will show “--:--”: • An attempt to display the remaining time is made when Track 21 or a later track is playing.

  • Page 18: Memory Play

    Memory play You can perform Memory playback, Random playback, and Repeat playback using the remote controller (RC-414S) that comes with Onkyo R-805X. (You can also control the unit using the system remote controller that came with the Onkyo Separate Collection series.) Memory play You can store your favorite selections from up to 3 discs in the CD Changer’s internal memory.
  • Page 19 MEMORY Press the button once or more to select Track 3 on the display. Then, press the MEMORY button on the remote controller to store the track. The track in memory are played in the order you specified. Remote controller MEMORY Storing tracks using the remote controller Simply press the number button “3”.
  • Page 20 Memory play (continued) Press the button once or more to select Track 12 on the display. Then, press the MEMORY button on the remote controller to store the track. You may press the number button “12” on the remote controller to store Track 12. Note: •...

  • Page 21: Other Play Modes

    DISC 1 RANDOM DISC 2 REPEAT DISC 3 DISC C-707CHX Repeat play You can repeat playing the tracks of the disc(s). Press the REPEAT button. The REPEAT indicator appears. Press the Tracks to be repeated vary depending on playback mode as shown in the table below.

  • Page 22: Other Play Modes

    TR-1 play. Then, replace the discs for which playback has been finished one after another. DISC 1 DISC 2 DISC 3 DISC C-707CHX DISC Press the DISC MODE button once or more to display “TR-1” on the display. DISC MODE Each time you press the DISC MODE...

  • Page 23: Handling Cds

    Handling CDs Playable discs This unit can play back the follwing discs. Disc Contents Disc mark size 12 cm Audio Audio 8 cm (CD single) You cannot play back discs other than those listed above. Do not use discs that are not audio discs (eg.CD- ROMs for use with personal computers), as these could damage the speakers and amplifier.

  • Page 24: Troubleshooting

    Troubleshooting If you have any problems with the unit, please check the troubleshooting table below first. For any problems not described in the table, please consult your nearest Onkyo authorized service center. Symptom STANDBY button is pressed, but power does not come...

  • Page 25: Specifications

    Specifications Signal readout system Optical non-contact D/A converter 1 bit D/A converter Frequency response 5 Hz – 20 kHz Total harmonic distortion 0.005% (at 1 kHz) Channel separation 85 dB(at 1 kHz) Dynamic range 96 dB Signal to noise ratio 90 dB Wow and Flutter Below threshold of measurability...

  • Page 26: Front Panel

    Index to parts and controls For operational instructions, refer to the page indicated in parentheses. Front panel STANDBY/ON button [11, 12] COMPACT DISC CHANGER STANDBY / ON DISC MODE STANDBY DISPLAY STANDBY indicator DISPLAY [11, 12] button [17] DISC MODE button [16, 22] Display Elapsed/Remaining...

  • Page 27: Remote Controller

    Remote controller included with the R-805X (RC-414S). To operate the included remote controller, make the appropriate connection to the connection. You can also control the unit using the system remote controller that came with the Onkyo Separate Collection series. CD operation buttons...
  • Page 28 Sales & Product Planning Div. : 2-1, Nisshin-cho, Neyagawa-shi, OSAKA 572-8540, JAPAN Tel: 072-831-8111 Fax: 072-833-5222 ONKYO U.S.A. CORPORATION 18 Park Way, Upper Saddle River, N.J. 07458, U.S.A. Tel: 201-785-2600 Fax: 201-785-2650 E-mail: onkyo@onkyousa.com ONKYO EUROPE ELECTRONICS GmbH Industriestrasse 20, 82110 Germering, GERMANY Tel: 089-849-320 Fax: 089-849-3265 E-mail: info@onkyo.de...
