*En̲C733̲01.fm Page 1 Wednesday, December 22, 2004 3:06 PM
Compact Disc Player
C-733
Instruction Manual
Thank you for purchasing an Onkyo Compact Disc
Player. Please read this manual thoroughly before
making connections and plugging in the unit.
Following the instructions in this manual will enable
you to obtain optimum performance and listening
enjoyment from your new Compact Disc Player.
Please retain this manual for future reference.
Get other manuals https://www.bkmanuals.com
Contents
Introduction .................................... 2
Connections ................................... 8
Operation...................................... 10
Troubleshooting........................... 14
Specifications .............................. 15
E
n

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C-773 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Onkyo C-773

  • Page 1 C-733 Instruction Manual Connections ........8 Operation........10 Thank you for purchasing an Onkyo Compact Disc Troubleshooting......14 Player. Please read this manual thoroughly before making connections and plugging in the unit. Following the instructions in this manual will enable you to obtain optimum performance and listening enjoyment from your new Compact Disc Player.
  • Page 2: Introduction Important Safety Instructions

    *En̲C733̲02.fm Page 2 Wednesday, December 22, 2004 3:07 PM WARNING: WARNING AVIS TO REDUCE THE RISK OF FIRE OR ELECTRIC RISK OF ELECTRIC SHOCK RISQUE DE CHOC ELECTRIQUE DO NOT OPEN NE PAS OUVRIR SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN OR MOISTURE.
  • Page 3: Precautions

    If water or any other liquid gets leave this unit turned on for two to three hours. By inside this unit, have it checked by your Onkyo this time, the unit will have warmed up and any con- dealer.
  • Page 4 We, ONKYO EUROPE ELECTRONICS GmbH LIEGNITZERSTRASSE 6, 82194 GROEBENZELL, GERMANY declare in own responsibility, that the ONKYO product described in this instruction manual is in compliance with the corresponding technical standards such as EN60065, EN55013, EN55020 and EN61000-3-2, -3-3. GROEBENZELL, GERMANY I.
  • Page 5: Table Of Contents

    *En̲C733̲02.fm Page 5 Wednesday, December 22, 2004 3:07 PM Features Table of Contents ❑ Onkyo’s unique Vector Linear Shaping Introduction Circuitry (VLSC) greatly improves the Important Safety Instructions ....2 sound quality by deriving a pure analog Precautions..........3 signal from the digital source.
  • Page 6: Front & Rear Panels

    Onkyo components for interactive control. To use DIGITAL OUT OPTICAL (9) , the C-733 must be connected with an cable and an audio cable.
  • Page 7: Remote Controller

    • The remote controller may not work reliably if the (RC-613S) that’s supplied with the Onkyo A-933 A-933 is subjected to bright light, such as direct sun- Integrated Amplifier. The C-733 and A-933 must be light or inverter-type fluorescent lights.
  • Page 8: Connecting The C-733

    *En̲C733̲02.fm Page 8 Wednesday, December 22, 2004 3:07 PM Connecting the C-733 About the System Functions If you connect another component from the Onkyo Separate Collection to the C-733 with the supplied and audio cables, you can use the following system functions.
  • Page 9: Connecting An Amplifier With An Analog Input

    C-733 and the other component. • Use only dedicated cables for connections. • If you use the C-733 with other components from the Onkyo Separate Collection, refer to the instruction manuals supplied with the A-933 as well. Get other manuals https://www.bkmanuals.com...
  • Page 10: Turning On The C-733

    If you’re using the C-733 together with the A-933 ampli- With CDs that contain many tracks, fier from the Onkyo Separate Collection, press the playback may take a while to start. remote controller’s [ON] button once to turn on the A-933, and press it again to turn on the C-733.
  • Page 11: Displaying The Remaining Time

    *En̲C733̲02.fm Page 11 Wednesday, December 22, 2004 3:07 PM Playing CDs —Continued Displaying the Remaining Time STANDBY STANDBY Number buttons >10 10/0 GROUP STANDBY/ON CLEAR 10/0 >10 GROUP DISPLAY STANDBY CLEAR TAPE /CDR VOLUME TAPE /CDR DISPLAY VOLUME PRESET PRESET MUTING PRESET MUTING...
  • Page 12: Memory Playback

    *En̲C733̲02.fm Page 12 Wednesday, December 22, 2004 3:07 PM Playing CDs —Continued ■ To Stop Memory Playback Press the Stop [ ] button. STANDBY ■ To Remove the Last Track from the Program Number While memory playback is stopped, press the [CLEAR] buttons 10/0 >10...
  • Page 13: Repeat Playback

    *En̲C733̲02.fm Page 13 Wednesday, December 22, 2004 3:07 PM About CDs Playing CDs —Continued Handling CDs Repeat Playback • Carefully lift the disc from With the Repeat function, you can play all tracks its case, making sure to repeatedly. hold it by its edges or cen- During playback, press the ter hole.
  • Page 14: Troubleshooting

    In the unlikely event that this should happen, unplug the power cord, wait at least five seconds, and then plug it again. Onkyo is not responsible for damages (such as CD rental fees) due to unsuccessful recordings caused by the unit’s malfunction. Before you record important data, make sure that the material will be recorded correctly.
  • Page 15: Specifications

    *En̲C733̲02.fm Page 15 Tuesday, February 15, 2005 3:14 PM Specifications Power supply: AC 230–240 V, 50 Hz Power consumption: 14.5 W Standby power consumption: 1.0 W Dimensions (W × H × D): 275 × 103 × 304 mm Weight: 4.5 kg Operation condition Temperature, humidity: 5–35 °C, 5–85% (no condensation)
  • Page 16 Units 2102-2107, Metroplaza Tower I, 223 Hing Fong Road, Kwai Chung, N.T., HONG KONG Tel: 852-2429-3118 Fax: 852-2428-9039 Printed in Japan http://www.ch.onkyo.com/ I0502-2 SN 29343928A (C) Copyright 2005 ONKYO CORPORATION Japan. All rights reserved. * 2 9 3 4 3 9 2 8 A * Get other manuals https://www.bkmanuals.com...
