Closing the carry handle
while the case lock is in
line with the forward direction of
travel can result in damage to the
locking tongue.
Make sure that the case lock is
at right angles to the forward dir-
ection of travel when you close
the carry handle.
Close carry handle 1.
Turn key 2 counter-clockwise
and remove.
Removing cases
Turn key 1 clockwise.
Keep the yellow latch 2 held
and fold out the carry handle 3.
Pull red release lever 1 up.
Latching flap 2 pops up.
Fully open the latching flap.
Take a firm grip of the handle
and lift the case out of the
holder.
Mounting cases
Pull red release lever 1 up.
Latching flap 2 pops up.
Fully open the latching flap.
