DMX Protocol

Channel 1 – Red
0-255
Channel 2 – Green
0-255
Channel 3 – Blue
0-255
Channel 4 – Dimmer intensity
0-255
Channel 5 – Sound sensitivity
0-25
26-255
Note: When using the Sound active function, please be sure to first select CH1, CH2, CH3 and CH4
Channel 6 – Auto Fade
0-4
5-255
Note: When using the Auto Fade function, please be sure to first select CH1, CH2, CH3 and CH4
Gradual adjustment Red from 0 – 100%
Gradual adjustment Green from 0 – 100%
Gradual adjustment Blue from 0 – 100%
From black to brightest
No functions
Sound-active
No fade
Fade between the active channels
