USER'S MANUAL. PROLINK-4C
Acquisition mode
DiSEqC
System & Standard Selects the colour system (PAL, SECAM or NTSC) and
Battery & Lnb
Channel set
Print
Press Next for the second sub-menu, and from there to the third (you will see
the same functions as those appearing in the second and third sub-menus in TV
mode).
[5]
EXT VIDEO. Video signal presence light indicator
It lights up when video on screen is coming through the SCART connector [39].
[6]
DRAIN
External units power supply indicator. Lights up when the PROLINK-4C
supplies a current to the external unit.
[7]
CHARGER
External DC charger operation indicator. When batteries are installed the
battery charger is automatically activated.
[8]
BATTERY
Battery charge level indicator. When the instrument is switched off and
connected to the mains, the battery has three states: red if the battery charge
level is below 50%, amber if it is greater than 50% and green if the battery is
fully charged.
[9]
MONITOR
[10]
MAIN KEYBOARD
12 keys to select functions and entering numeric data.
02/2003
Offers three acquisition modes: Maximum Hold, Minimum
Hold and Continuous (default).
(Only satellite channels). Defines a sequence of DiSEqC
commands and permits to send them.
the TV standard (B/G, D/K, I, L, M, N or Digital).
Displays battery voltage and external units power supply
voltage and current (V Ext and I Ext).
Selects active channels table.
Prints the spectrum shown on the screen. (See '4.14
Printing the Spectrum, the Measurement and Memories').
Page 21
