PROLITE-53B
FRONT VIEW
1
Trace Display Area.
2
Navigation Window.
3
Zoom Bar.
4
Quick Help Area.
5
Common Operation Buttons.
6
Info and Function Area.
7
Power On / Off.
CAUTION
Find the user's manual on the download area at: www.promaxelectronics.com
QUICK REFERENCE GUIDE
1
Invisible laser radiation
Please always avoid looking directly at the optical output
or stare at laser beam.
2
The system is on or the battery is fully
Green
charged when it is powered off.
Orange
Charging battery
Red
The laser of VLC or OTDR is beaming
3
4
5
6
7
3
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Promax PROLITE-53B
Summary of Contents for Promax PROLITE-53B
- Page 1 PROLITE-53B QUICK REFERENCE GUIDE FRONT VIEW Trace Display Area. Navigation Window. Zoom Bar. Quick Help Area. Common Operation Buttons. The system is on or the battery is fully Green charged when it is powered off. Info and Function Area. Orange Charging battery Power On / Off.
- Page 2 PROLITE-53B QUICK REFERENCE GUIDE TOP VIEW VFL (Visual Fault Locator port). OPM (Optical Power Meter port). OTDR (SM) (OTDR Port Single Mode). OTDR (MM) (OTDR Multi-Mode Port). Reset, (Revert to factory settings and format the meter). 10 / 100 Mbps Ethernet Port.
