Meter Overview
Front of Meter
Phase
Measurements
Negative Value
Indicator
A
B
C
Down Button
Demand /
Peak Demand
Measurements
D
ANGER
Do not power up the meter until the current and voltage wiring is completed.
Recommended Tools
#1 and #2 Phillips screwdrivers
Precision flat-head screwdriver
Wire cutters / stripper
System
Measurements
Energy
Readings
Enter Button
Up Button
Rear of Meter
Voltage Inputs
COM1
Current Inputs
Power Supply
D2: Form A
Digital Out
Safety
Ground
D1: Form A
Digital Out
7
