ION 6200 Models

Available Options

Megawatt
Integrated
Optional
Display
Optional
TRAN
Not
RMICAN
available
Integrated Display Model
The Integrated model has a large, LED front panel display.
TRAN (transducer) Model
The TRAN model has no display. You can connect a Remote Modular Display
unit (RMD) to the TRAN to display measurement values.
RMICAN Model
An integrated display meter that is RMICAN-certified for revenue metering in
Canada. RMICAN meters have different security options available, including
a factory-sealed version.
ION 6200 Product Options
1
Power Supply
Standard
Low Voltage
DC
480V
Standard
Low Voltage
DC
480V
Standard
Low Voltage
DC
480V
Notes
1
Measures power and energy in millions (e.g. megawatts) and volts in
thousands (kilovolts).
2
See "Standard Measurements and Enhanced Packages 1 & 2" on
page 26.
3
Standard security consists of a meter password.
4
Meters with RMANSI security are approved for revenue metering in the
United States.
5
Firmware-based security that meets Industry Canada revenue metering
standards.
6
Firmware-based security plus factory sealed.
For more information on the different meter options, refer to the
Options Card Retrofit Instructions
N
OTE
The term "basic meter" refers to Integrated or TRAN models with a standard
Options Card (real-time voltage and current measurements).
COM I/O
Optional Optional
Optional
Optional
Optional Optional
on the Power Measurement web site
Measurement
Security
Package
Standard
3
Standard
Enhanced #1
4
RMANSI
Enhanced #2
Standard Standard
RMANSI Enhanced #1
Enhanced #2
Standard
5
RMICAN
Enhanced #1
RMICAN
Enhanced #2
6
sealed
ION 6200
